Portland 63254 User manual

!"#"$%&'(%)*+#"$*%,$-%.$$/-00)))1.,(+&(2(*"3.$14&5
65,"7%&'(%$*4.8"4,7%#'//&($%,$-%/(&9'4$#'//&($:.,(+&(2(*"3.$14&5
Owner’s Manual & Safety Instructions
Save This Manual%Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 17d
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2016 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assem bly and service may not be included.
;*,9%$."#%5,$*(",7%+*2&(*%'#"83%$."#%/(&9'4$1%
<,"7'(*%$&%9&%#&%4,8%(*#'7$%"8%#*("&'#%"8='(>1%
?@!6%ABC?%D@EF@G1

Page 2 <&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1 Item 63254
?@<6AQ RS6;@ACRE D@CEA6E@ET6?6AFS
A,+7*%&2%T&8$*8$#
Safety ......................................................... 3
Setup .......................................................... 7
Setup – Before Use: ................................... 7
Operation ................................................... 10
Maintenance .............................................. 14
Parts List and Assembly Diagram.............. 18
Warranty .................................................... 20
U@;ECEV%?QDWRG?%@EX%X6<CECACRE?
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.

Page 3<&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1Item 63254
?@<6AQRS6;@ACRED@CEA6E@ET6 ?6AFS
CDSR;A@EA%?@<6AQ%CE?A;FTACRE?
% U@;ECEV%K%U.*8%'#"83%$."#%/(&9'4$%+,#"4%/(*4,'$"&8#%#.&'79%
,7),>#%+*%2&77&)*9I%"847'9"83%$.*%2&77&)"83-
?,2*$>%U,(8"83#
1. Read all the instructions before using the product.
2. To reduce the risk of injury, close supervision is
necessary when a product is used near children.
3. Know how to stop the product and bleed pressures
quickly. Be thoroughly familiar with the controls.
4. Stay alert – watch what you are doing.
5. Do not operate the product when fatigued or under
the influence of medication, alcohol or drugs.
6. Keep operating area clear of all persons.
7. Do not overreach or stand on unstable support.
Keep good footing and balance at all times.
8. Follow the maintenance instructions
specified in the manual.
9. This product is provided with a ground fault
circuit interrupter (GFCI) built into the power
cord plug. If replacement of the plug or cord is
needed, use only identical replacement parts.
10. WARNING – Risk of injection or injury–
do not direct discharge stream at persons.
11. Connect to individual branch circuit only.
12. WARNING – To reduce the risk of electrocution,
keep all connections dry and off the ground.
Do not touch plug with wet hands.
13. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the pressure
washer. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
14. V<TC%S;6T@FACRE?%
Test GFCI (Ground Fault Circuit Interrupter)
before each use as follows:
a. Plug GFCI into power outlet and press
reset button. Indicator should turn on.
b. Press test button. Indicator should turn off.
c. Press reset button again for use.
Do not use if above test fails.
The GFCI device does not protect against electrical
shock due to contact with both circuit conductors or
a fault in any wiring supplying the GFCI device.
A&%,77&)%V<TC%'8"$%$&%2'84$"&8%/(&/*(7>I%
6YA6E?CRE%TR;X?%DF?A%ERA%W6%
F?6X%)"$.%$."#%/(*##'(*%),#.*(1
?*$%'/%S(*4,'$"&8#
1. The work area should have adequate
drainage to reduce the possibility of a fall
or electric shock due to wet surfaces.
2. Wear ANSI-approved safety goggles
during set up and use.
3. Only feed cold, clean water through this tool.
Pressure washer detergent may be used in
the Detergent Bottle only. Do not use caustic
materials, solvents, flammable materials, or
detergents not designed for pressure washers.
Use of any such material can cause injury,
or damage this tool or personal property.
4. Prior to starting the Pressure Washer in
cold weather, check all of the parts of the
unit to make sure ice has not formed. Do
not store the unit anywhere that the
temperature will fall near 32° F (0° C).

Page 4 <&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1 Item 63254
?@<6AQ RS6;@ACRE D@CEA6E@ET6?6AFS
R/*(,$"83%S(*4,'$"&8#
1. Disconnect the plug from the power source
before making any adjustments, changing
accessories, or storing pressure washers. Such
preventive safety measures reduce the risk of
starting the pressure washer accidentally.
2. Do not leave the equipment unattended
when it is running. Turn off the equipment
before leaving the work area.
3. Wear ANSI-approved safety goggles and heavy-
duty nonslip rubber work boots during use.
4. Use only accessories that are recommended by
Harbor Freight Tools for your model. Accessories
that may be suitable for one piece of equipment may
become hazardous when used on another one.
5. This product must continuously run with
cold water only. Never use hot water. Do
not dry run this product. Dry running will
cause serious damage to the seals.
6. To avoid electrical shock, never start and run the
Pressure Washer in the rain. Never allow water
to leak into the Body of the Pressure Washer.
Do not direct discharge stream at the Pressure
Washer itself or at other live electrical equipment.
7. Do not allow the GFCI Plug to become wet.
Always place the GFCI Plug in a dry location and as
far away as possible from the object being sprayed.
8. DO NOT use an extension cord with this product.
9. When using the Pressure Washer, always maintain
a firm grip on the Spray Gun. Squeezing the
Trigger of the Spray Gun causes a kickback force.
10. Do not feed already-pressurized water (such as that
from another pressure washer) into this washer.
11. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
12. WARNING: The brass components of this product
contain lead, a chemical known to the State
of California to cause cancer and birth defects
or other reproductive harm. (California Health
& Safety Code § 25249.5, et seq.)
13. WARNING: The cord of this product contains
lead and/or di (2-ethylhexyl) phthalate (DEHP),
chemicals known to the State of California
to cause cancer, and birth defects or other
reproductive harm. Wash hands after handling.
(California Health & Safety Code § 25249.5, et seq.)
14. Use the correct equipment for the application.
Do not modify the equipment and do not use the
equipment for a purpose for which it is not intended.
15. If water is leaking out of the Pressure Washer
immediately turn off the unit. Unplug the
Pressure Washer, and discharge all pressure
before tightening fittings or having repair
work done by a qualified technician.
16. The high pressure water flow can damage
the work surface if not used properly.
Always test the spray in an open area first.
17. Injection Hazard. The high pressure
water jet produced by this tool can cut
skin or cause injury to hands or eyes.
Do not allow spray to strike you and do
not spray toward people or animals.
Do not spray the tool itself or any electrical source.
18. This Pressure Washer is intended for
outdoor residential use only.
19. C8%4,#*%&2%,8%*5*(3*84>%9'("83%'#*I%
"55*9",$*7>%(*7*,#*%$.*%$("33*(%&8%$.*%#/(,>%
.,897*I%$'(8%$.*%/&)*(%#)"$4.%&22%,89%$.*8%
'8/7'3%$.*%'8"$1%X&%8&$%#*$%$.*%#/(,>%.,897*%
9&)8%)"$.&'$%$'(8"83%&22%$.*%/&)*(%#)"$4.1%%

Page 5<&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1Item 63254
?@<6AQRS6;@ACRED@CEA6E@ET6 ?6AFS
!"+(,$"&8%B,Z,(9-
This tool vibrates during use. Repeated or long-term exposure to vibration may cause temporary or permanent
physical injury, particularly to the hands, arms and shoulders. To reduce the risk of vibration-related injury:
1. Anyone using vibrating tools regularly or for an
extended period should first be examined by a
doctor and then have regular medical check-
ups to ensure medical problems are not being
caused or worsened from use. Pregnant women
or people who have impaired blood circulation
to the hand, past hand injuries, nervous system
disorders, diabetes, or Raynaud’s Disease should
not use this tool. If you feel any medical or
physical symptoms related to vibration (such as
tingling, numbness, and white or blue fingers),
seek medical advice as soon as possible.
2. Do not smoke during use. Nicotine reduces
the blood supply to the hands and fingers,
increasing the risk of vibration-related injury.
3. Wear suitable gloves to reduce the
vibration effects on the user.
4. Use tools with the lowest vibration when there
is a choice between different processes.
5. Include vibration-free periods each day of work.
6. To reduce vibration, maintain the tool as
explained in this manual. If any abnormal
vibration occurs, stop use immediately.
?*(["4*%S(*4,'$"&8#
V(&'89%<,'7$%T"(4'"$%C8$*(('/$*(%S(&$*4$"&8
This pressure washer is provided with a ground-fault circuit-interrupter (GFCI) built into the plug of the
power-supply cord. This device provides additional protection from the risk of electric shock. Should replacement
of the plug or cord become necessary, use only identical replacement parts that include GFCI protection.
?*(["4"83%,%X&'+7*KC8#'7,$*9%@//7",84*
In a double-insulated product, two systems of insulation are provided instead of grounding. No grounding
means is provided on a double-insulated product, nor should a means for grounding be added to the
product. Servicing a double-insulated product requires extreme care and knowledge of the system,
and should be done only by qualified service personnel. Replacement parts for a double-insulated
product must be identical to the parts they replace. A double-insulated product is marked with the words
“DOUBLE INSULATION” or “DOUBLE INSULATED.” The symbol may also be marked on the product.
%?@!6%AB6?6%CE?A;FTACRE?1

Page 6 <&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1 Item 63254
?@<6AQ RS6;@ACRE D@CEA6E@ET6?6AFS
?>5+&7&3>
Double Insulated
Intertek Testing Services
!@TVolts Alternating Current
@Amperes
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.
Read the manual before
set-up and/or use.
WARNING marking concerning
Risk of Electric Shock.
Properly connect power cord
to appropriate outlet.
WARNING marking concerning
Risk of Injection.
Do not direct spray at any
person or animal.
?/*4"2"4,$"&8#
Electrical Rating 120VAC / 60Hz / 13A
Working Pressure
Maximum Pressure
1450 PSI
1750 PSI
Maximum Flow Rate 1.3 GPM
Maximum Water Temperature 120ºF
Maximum Inlet Water Pressure 58 PSI
High-Pressure Hose 20 ft
Power Cord 35 ft
\]^JN^L

Page 7<&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1Item 63254
?@<6AQRS6;@ACRED@CEA6E@ET6 ?6AFS
?*$'/%_%W*2&(*%F#*-
% ;*,9%$.*%6EAC;6%CDSR;A@EA%?@<6AQ%CE<R;D@ACRE%#*4$"&8%,$%$.*%+*3"88"83%&2%$."#%
5,8',7%"847'9"83%,77%$*`$%'89*(%#'+.*,9"83#%$.*(*"8%+*2&(*%#*$%'/%&(%'#*%&2%$."#%/(&9'4$1
AR%S;6!6EA%?6;CRF?%CEaF;Q%<;RD%@TTCX6EA@G%RS6;@ACRE-%
A'(8%$.*%S&)*(%?)"$4.%&2%$.*%$&&7%&22I%'8/7'3%$.*%$&&7%2(&5%"$#%*7*4$("4,7%&'$7*$I%
#.'$%&22%$.*%),$*(%#'//7>%,89%#,2*7>%9"#4.,(3*%,77%(*#"9',7%),$*(%/(*##'(*%2(&5%
$.*%'8"$%+*2&(*%,##*5+7"83%&(%5,b"83%,8>%,9='#$5*8$#%$&%$.*%$&&71
<'84$"&8#
B,897*
X*$*(3*8$%
W&$$7*
U,89
?/(,>%
V'8
S&)*(%
T&(9
S&)*(%
T&(9%B&&b
B"3.KS(*##'(*%
B&#*%B&&b
S&)*(%
?)"$4.
B"3.KS(*##'(*%
B&#*
U,$*(%C87*$
c&8%+,4bd
?/(,>%V'8%
B&79*(
E&ZZ7*%
B&79*(
X*$*(3*8$%
W&$$7*%
B&79*(
U,$*(%
R'$7*$
E&ZZ7*%A"/%
T7*,8*(
E&ZZ7*

Page 8 <&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1 Item 63254
?@<6AQ RS6;@ACRE D@CEA6E@ET6?6AFS
@##*5+7>
E&$*- For additional information regarding the parts listed in the following pages,
refer to Parts List and Assembly Diagram on page 18.
Remove shipping caps from Water Inlet/Outlet.
?."//"83%
T,/%&8%
U,$*(%C87*$
@$$,4.%B,897*
1. Attach Handle (1) to front of Pressure Washer
using four Screws (27).
?4(*)%
c^Od
B,897*%
cJd
@$$,4.%B"3.KS(*##'(*%B&#*%B&&b
1. Slide High-Pressure Hose Hook into
slot on back of Pressure Washer.
B"3.KS(*##'(*%
B&#*%B&&b
?7&$

Page 9<&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1Item 63254
?@<6AQRS6;@ACRED@CEA6E@ET6 ?6AFS
T&88*4$%B"3.KS(*##'(*%B&#*%$&%F8"$
1. Connect High-Pressure Hose (31) to front of
Pressure Washer by pushing Hose in as far as
it will go, then threading coupler on tightly.
T&88*4$%B"3.KS(*##'(*%B&#*%$&%?/(,>%V'8
1. Move Hose Lock away from Hose inlet.
Insert Hose as far as it will go, then
move Hose Lock toward Hose inlet.
B&#*%
G&4b
B&#*%
C87*$

Page 10 <&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1 Item 63254
?@<6AQ RS6;@ACRE D@CEA6E@ET6?6AFS
R/*(,$"83%C8#$('4$"&8#
% ;*,9%$.*%6EAC;6%CDSR;A@EA%?@<6AQ%CE<R;D@ACRE%#*4$"&8%,$%$.*%+*3"88"83%&2%$."#%
5,8',7%"847'9"83%,77%$*`$%'89*(%#'+.*,9"83#%$.*(*"8%+*2&(*%#*$%'/%&(%'#*%&2%$."#%/(&9'4$1
U&(b%S"*4*%,89%U&(b%@(*,%?*$%F/
1. Designate a work area that is clean and well-lit.
The work area must not allow access by children
or pets to prevent distraction and injury.
2. CHECK THE WATER SUPPLY. Prior to using
the Pressure Washer for the first time, it is
ESSENTIAL to verify that the water supply is
adequate. The Pressure Washer needs TWICE the
water supply (or volume) of the listed water output
(1.3 GPM). This Pressure Washer will need about
2.6-3 GPM to operate correctly and efficiently. If
the water is being supplied by a well/pump, make
certain that the well/pump produces enough
water to keep up with the Pressure Washer’s
water demands. Water supply hoses should be
heavy-duty. Water supply hoses up to 25' long must
be 5/8" ID. Water supply hoses up to 50' long must
be 3/4" ID. Do not use hoses longer than 50'. The
flow rate of the water supply must never be allowed
to fall below 2.6 GPM.
To determine the water supply’s flow rate: Run the
water at full for one minute into a 5 gallon container,
then measure the amount of water in the container.
T@FACREe If the Pressure Washer is run
with an inadequate water supply, the pump
may cavitate. Cavitation causes the pump
to operate loudly and will damage it.
3. USE PROPER ELECTRICAL SUPPLY. This
unit uses a large amount of current, especially
during start-up. Turn off power switch, then
connect this unit only to a dedicated household
circuit with no additional loads (running devices)
connected to it. For best results, use the outlet
that is nearest to the circuit breaker panel.
4. PLAN OUT THE JOB Plan out areas to be
cleaned, how many sessions will be necessary,
and how long the individual sessions will
need to be. Plan to clean the higher areas
first. Plan a safe direction for runoff, and plan
on working your way in that direction.
5. Clear the area of all objects that are not being
cleaned. If any water-sensitive or delicate items
cannot be moved, cover them. If detergent is to
be used, cover or remove any plants or animals.
Disconnect power to and protect any nearby
electrical wiring. Close windows and doors.
6. Place the Pressure Washer in a location
which is protected from runoff. The location
should be close enough so that the water
supply hose will reach every portion of the
area with some slack for movement.
7. Route the power cord along a safe route
to reach the work area without creating a
tripping hazard or exposing the power cord
to possible damage. The power cord must
reach the work area with enough extra length
to allow free movement while working.

Page 11<&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1Item 63254
?@<6AQRS6;@ACRED@CEA6E@ET6 ?6AFS
A&&7%?*$%F/
AR%S;6!6EA%?6;CRF?%CEaF;Q%<;RD%@TTCX6EA@G%RS6;@ACRE-%
A'(8%$.*%S&)*(%?)"$4.%&22I%'8/7'3%"$%2(&5%"$#%*7*4$("4,7%&'$7*$I%,89%(*7"*[*%,77%
/(*##'(*%+*2&(*%5,b"83%,9='#$5*8$#%&(%"8#$,77"83%,44*##&("*#1
1. MAKE SURE THE WATER INLET STRAINER AND WAND
ARE FREE OF MINERAL BUILDUP OR DEBRIS.
2. Insert Wand into end of Spray Gun, press in and twist Wand clockwise until it locks into place.
3. If using Detergent Bottle:
a. Twist lid clockwise and remove. Fill Bottle with pressure washer detergent (sold separately). Replace lid.
b. Insert Detergent Bottle into end of Spray Gun, press in and twist Bottle clockwise until it locks into place.
4. Run water through water supply hose (not included)
to remove any debris. Turn off water.
5. Connect water supply hose to Water Inlet on back of
Pressure Washer. Tighten securely.
6. Nozzle Adjustment:
• Twist Nozzle to left for high-impact narrow spray.
T@FACREe AR%S;6!6EA%CEaF;Q%@EX%S;RS6;AQ%X@D@V6I%F?6%BCVBKCDS@TA%?S;@Q%UCAB%T@FACRE1
• Twist Nozzle to right for low-impact fan spray.

Page 12 <&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1 Item 63254
?@<6AQ RS6;@ACRE D@CEA6E@ET6?6AFS
V*8*(,7%R/*(,$"83%C8#$('4$"&8#
AR%S;6!6EA%6G6TA;CT%?BRTf%@EX%X6@AB-%%A*#$%V(&'89%<,'7$%T"(4'"$%C8$*(('/$*(%cV<TCd%+*2&(*%*,4.%
'#*1%%A.*%V<TC%9&*#%8&$%/(&$*4$%,3,"8#$%*7*4$("4,7%#.&4b%9'*%$&%4&8$,4$%)"$.%+&$.%4"(4'"$%4&89'4$&(#%&(%,%
2,'7$%"8%,8>%)"("83%#'//7>"83%"8%$."#%9*["4*1%%X&%8&$%,7$*(%&(%9"#,+7*%$.*%V<TC1%%X&%8&$%'#*%,8%*`$*8#"&8%4&(91%%%
This unit is intended for light to moderate cleaning. It is not intended for paint stripping or deep concrete cleaning.
1. Uncoil High-Pressure Hose completely. X&%8&$%'#*%
S(*##'(*%U,#.*(%"2%B&#*%"#%b"8b*9%&(%7&&/*91
2. Plug GFCI into dedicated, grounded
120V outlet, then:
a. Press ;6?6A button. Indicator should light up.
b. Press A6?A button. Indicator should turn off.
c. Preset ;6?6A button again. Indicator
should light up, unit is ready for use.
T
E
S
T
R
E
S
E
T
C89"4,$&(
;*#*$
W'$$&8
A*#$
W'$$&8
3. Turn on water supply.
4. Release Trigger Safety Lock, then press
Trigger until water flows through Nozzle.
A("33*(%
?,2*$>%G&4b
A("33*(
5. Turn Power Switch to ON position.
E&$*- If the unit does not turn on or turns
off suddenly, turn Power Switch to OFF
position, then check and reset the GFCI.
O
F
F
/
O
O
N
/
I
R<<%
S&#"$"&8
RE%
S&#"$"&8
ERACT6- Pressure Washer will run &87> while
Trigger is pressed. When trigger is released,
Pump will turn off. X&%8&$%7*,[*%"97*%2&(%5&(*%
$.,8%&8*%5"8'$*%)"$.&'$%#/(,>"831
6. A*#$%#/(,>%,8%"84&8#/"4'&'#%,(*,:
a. Set Nozzle to low-impact fan spray.
b. Point Spray Gun at 45° angle to test area.
Press Trigger. W*%,),(*%&2%b"4b%+,4b1
c. Spray test area, adjusting pressure,
as needed, by changing distance from
surface and/or adjusting Nozzle.
d. If using detergent:
• Turn off unit, remove Wand, fill detergent
bottle, then attach Detergent Bottle.
• Turn on unit, then spray area with detergent
according to detergent manufacturer's
instructions. Scrub surface as necessary.
• Turn off unit, remove Detergent Bottle,
then attach Wand.
• Set Nozzle to low-impact fan spray.
• Turn on unit, then spray area to rinse
off detergent, adjusting pressure. as
needed, by changing distance from
surface and/or adjusting Nozzle.
e. Inspect test area for damage or discoloration.

Page 13<&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1Item 63254
?@<6AQRS6;@ACRED@CEA6E@ET6 ?6AFS
T7*,8"83%U"89&)#
a. Inspect caulking and/or glazing. Inspect trim.
XR%ERA%S;6??F;6%U@?B%UCEXRU?%C<%
T@FGfCEV0VG@gCEV0A;CD%C?%ERA%CEA@TA1
b. If needed, apply detergent according
to manufacturer's instructions.
c. Set Nozzle to low-impact fan spray.
XR%ERA%F?6%BCVBKCDS@TA%?S;@QI%
<R;T6%D@Q%W;6@f%VG@??1
d. Point Spray Gun at 45° angle to, and 4 feet
away from, window. Spray window.
T7*,8"83%U&&9
XR%ERA%TG6@E%URRX%AB@A%C?%
BRA%R;%CE%XC;6TA%?FEGCVBA1
a. If needed, apply wood cleaning
detergent according to manufacturer's
instructions. For vertical surfaces,
apply detergent from bottom to top.
b. Scrub stained areas as needed.
c. Set Nozzle to low-impact fan spray.
d. Point Spray Gun at 45°. Spray surface,
working with the grain of the wood.
e. Let surface dry completely, then apply
stain or sealer, as needed, according
to manufacturer's instructions.
T7*,8"83%W("4b%,89%D&($,(
a. Inspect mortar, patching as needed. Let mortar
cure according to manufacturer's instructions.
b. Soak surface prior to applying detergent.
c. If needed, apply brick cleaning
detergent according to manufacturer's
instructions. For vertical surfaces,
apply detergent from bottom to top.
d. Scrub stained areas as needed.
e. Set Nozzle to low-impact fan spray.
AR%S;6!6EA%X@D@V6I%REGQ%
F?6%GRUKCDS@TA%?6AACEV1
f. Point Spray Gun at 45°. Spray surface.
g. Let surface dry completely, then
apply sealer, as needed, according to
manufacturer's instructions as needed.
7. When finished:
• Release Trigger, then set Trigger Safety Lock.
• Turn off Power Switch.
• Turn off water supply.
• Unplug the unit.
• Point Spray Gun in safe direction, press Trigger
to release all pressure, then release Trigger.
• Disconnect water supply hose.
• Disconnect High-Pressure Hose from unit.
• Disconnect High-Pressure
Hose from Spray Gun.
8. CDSR;A@EA-%%TG6@E%AB6%ERggG6%@<A6;%
6!6;Q%F?6%AR%D@CEA@CE%?S;@QCEV%
SRU6;%@EX%S;6!6EA%SFDS%X@D@V61
• Remove Wand from Spray Gun.
• Remove Nozzle from Wand by
turning Nozzle clockwise.
• Twist Nozzle to expose tip.
W7,9*#
E&ZZ7*%
A"/
• Push Nozzle Tip Cleaner into tip to
push out debris and buildup.
• Remove Nozzle Tip Cleaner and
back-flush water through Nozzle.
• Reattach Nozzle to Wand.
• Clean and store according to
F#*(KD,"8$*8,84*%C8#$('4$"&8#%&8%/,3*%Jh1

Page 14 <&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1 Item 63254
?@<6AQ RS6;@ACRE D@CEA6E@ET6?6AFS
F#*(KD,"8$*8,84*%C8#$('4$"&8#
AR%S;6!6EA%?6;CRF?%CEaF;Q%<;RD%@TTCX6EA@G%RS6;@ACRE-%
A'(8%$.*%S&)*(%?)"$4.%&2%$.*%$&&7%&22I%'8/7'3%$.*%$&&7%2(&5%"$#%*7*4$("4,7%&'$7*$I%
#.'$%&22%$.*%),$*(%#'//7>%,89%#,2*7>%9"#4.,(3*%,77%(*#"9',7%),$*(%/(*##'(*%2(&5%
$.*%'8"$%+*2&(*%/*(2&(5"83%,8>%"8#/*4$"&8I%5,"8$*8,84*I%&(%47*,8"83%/(&4*9'(*#1
AR%S;6!6EA%?6;CRF?%CEaF;Q%<;RD%ARRG%<@CGF;6-%
X&%8&$%'#*%9,5,3*9%*H'"/5*8$1%%C2%,+8&(5,7%8&"#*%&(%["+(,$"&8%
&44'(#I%.,[*%$.*%/(&+7*5%4&((*4$*9%+*2&(*%2'($.*(%'#*1
T7*,8"83I%D,"8$*8,84*I%,89%G'+("4,$"&8
1. W6<R;6%6@TB%F?6I inspect the general
condition of the tool. Check for:
• loose hardware,
• misalignment or binding of moving parts,
• damaged cord/electrical wiring,
• damaged high-pressure hose/accessories,
• cracked or broken parts, and
• any other condition that may
affect its safe operation.
2. @<A6;%F?6-%
• Drain water by tipping the unit.
Frost will damage the unit if it contains water.
• Flush Detergent Bottle with water.
• Use only a clean cloth and mild detergent
to clean the body of the Pressure
Washer. Do not use solvents.
• Do not immerse any part of the tool in liquid.
• Dry off any remaining water
on all parts and fittings.
• Remove mineral deposits from the
nozzle using a thin, stiff wire brush.
3. S6;CRXCT@GGQ, remove mineral buildup.
Unplug the unit and lay it face down. Fill Water
Inlet with de-mineralizing solution, following
solution manufacturer's instructions. Drain
de-mineralizing solution out of Water Inlet
and rinse out inlet thoroughly before use.
4. U@;ECEVe%%C2%$.*%#'//7>%4&(9%&(%V<TC%'8"$%
&2%$."#%/&)*(%$&&7%"#%9,5,3*9I%"$%5'#$%+*%
(*/7,4*9%&87>%+>%,%H',7"2"*9%#*(["4*%$*4.8"4",81
?$&(,3*%%
1. Place accessories, High-Pressure Hose and
Power Cord in their storage locations.
E&ZZ7*
?/(,>%
V'8
S&)*(%
T&(9 B"3.K
S(*##'(*%
B&#*
2. Insert Detergent Bottle into storage
location under High-Pressure Hose Hook,
then twist Bottle clockwise.
3. Store in a dry, frost-free room. Flush the unit with
automotive antifreeze prior to long-term storage.
Dispose of antifreeze according to local ordinances.

Page 15<&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1Item 63254
?@<6AQRS6;@ACRED@CEA6E@ET6 ?6AFS
A(&'+7*#.&&$"83
S(&+7*5 S&##"+7*%T,'#*# G"b*7>%?&7'$"&8#
Pressure Washer
will not start
1. Cord not connected.
2. No power at outlet.
3. GFCI circuit breaker tripped.
4. Internal damage or wear.
(Carbon brushes or
switch, for example.)
1. Check that cord is plugged in.
2. Check power at outlet. If outlet is unpowered,
turn off tool and check circuit breaker. If breaker
is tripped, make sure circuit is right capacity
for tool and circuit has no other loads.
3. Press reset button on GFCI unit on cord.
4. Have a qualified technician service tool.
Pressure Washer
stops suddenly
1. GFCI circuit breaker tripped.
2. Water leaking from housing.
1. Press reset button on GFCI unit on cord.
2. SHOCK HAZARD! IMMEDIATELY discontinue use.
Have the unit repaired by a qualified
technician before further use.
Output pressure
varies
1. Not enough water supply.
2. Air in water supply.
3. Water Inlet Filter is clogged.
4. Nozzle not attached
to Spray Gun.
5. Nozzle is clogged.
6. Nozzle has mineral build up.
7. Water supply hose is too
long.
8. Internal valves or seals
may be worn or sticking.
1. Check water supply hose for kinks, leaks,
or blockage. Open faucet all the way.
2. Check that all connections are tight.
3. Remove Filter and clean.
4. Pressure is created by the Nozzle, not the
Spray Gun. Attach Nozzle to Spray Gun.
5. Remove Nozzle and clean with Nozzle Tip Cleaner.
6. Remove Nozzle and clean with
de-mineralizing solution.
7. Recommended water supply hose length
is 25' with 5/8" ID up to 50' with 3/4" ID.
Shorten the length of the water supply
hose if needed to increase pressure.
8. Have a qualified technician service tool.
Trigger does
not depress
Safety lock is still engaged. Press Trigger Safety Lock on the bottom of the
Spray Gun to release the Safety Lock.
Detergent will
not dispense
Incorrect detergent type. Check that the detergent is the recommended
type of detergent. Clean out dispenser and
replace with correct type if needed.
Performance
decreases
over time
Clogged with mineral deposits. Clean unit with de-mineralizing solution.
% <&77&)%,77%#,2*$>%/(*4,'$"&8#%).*8*[*(%9",38&#"83%&(%#*(["4"83%$.*%$&&71%%X"#4&88*4$%/&)*(%
#'//7>%+*2&(*%#*(["4*1

Page 16 <&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1 Item 63254
?@<6AQ RS6;@ACRE D@CEA6E@ET6?6AFS
SG6@?6%;6@X%AB6%<RGGRUCEV%T@;6<FGGQ
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Page 17<&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1Item 63254
?@<6AQRS6;@ACRED@CEA6E@ET6 ?6AFS
;*4&(9%S(&9'4$i#%?*(",7%E'5+*(%B*(*-%
E&$*- If product has no serial number, record month and year of purchase instead.
E&$*- Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.

Page 18 <&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1 Item 63254
?@<6AQ RS6;@ACRE D@CEA6E@ET6?6AFS
S,($#%G"#$%,89%@##*5+7>%X",3(,5
S,($#%G"#$
S,($ X*#4("/$"&8 j$>
1 Handle 1
2 Upper Housing 1
3 Conductor Wire 1
4 Switch Shaft 1
5 Terminal 2
6 Upper Motor Housing 1
7-1 Power Cord Rubber Sheath 1
7-2 Power Cord Plastic Sheath 1
7-3 Power Cord Clip 1
7-4 GFCI Plug 1
7-5 Power Cord 1
8 Motor & Pump Assembly 1
9 Waterproof Cap 1
10 Left Holder 1
11 Right Holder 1
12 Power Cord Clamp 1
13 Bottom Housing 1
14 Hose Hook 1
S,($ X*#4("/$"&8 j$>
15 Wheel Cap 2
16 Wheel Axle 2
17 Wheel 2
18 Lower Motor Housing 1
19 Pump Head Fixing Plate 1
20 Switch 1
21 O Ring 1
22 Terminal Box 1
23 Power Switch 1
24 Screw ST4x16 21
25 Screw ST3.5x15 2
26 Screw ST4x25 16
27 Screw ST5x20 4
28 Wand and Nozzle 1
29 Spray Gun 1
30 Detergent Bottle 1
31 High-Pressure Hose 1
32 Nozzle Tip Cleaner 1

Page 19<&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1Item 63254
?@<6AQRS6;@ACRED@CEA6E@ET6 ?6AFS
@##*5+7>%X",3(,5

G"5"$*9%P]%X,>%U,((,8$>
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
\hPJ%D"##"&8%R,b#%W7[91%%k%%SR%W&`%M]]P%%k%%T,5,("77&I%T@%P\]JJ%%k%%JKLLLKLMMKNOPO
