1 Introduction
PCOM-B657VGL is COM Express module based on Intel® 11th Gen H Processor. It is compatible with COMe 3.0/3.1 standard. The
platform adopts 10nm++ process and VNNI instruction set, offers advance computing power with 25~45W theraml and industrial use
condition for wide range applications. PCOM-B657VGL supports PCIe Gen 4.0 x16, and both ECC and Non-ECC DDR4 by different
SKUs, which is best for mission critical use conditions and AI edge computing with TSN enabled.
This module provides 8x PCIe x1 (Option to 2x PCIe x4 and support PCIe storage), four USB 3.2 Gen2 x1, and four SATA III. The
fully integrated and flexible I/O capacity also mapped to wide range of industrial applications.

COM Express™ PORTWELL PCOM-B657VGL User's Guide
Copyright © PORTWELL 2021 PCOM-B657VGL User's Guide
10
1.1 PCOM-B657VGL SKU List
Series
PCOM-B657VGL
Ordering P/N
AB1-3L58
AB1-3L67
AB1-3L65
AB1-3L66
CPU Specifications
Processor
i7-11850HE
i5-11500HE
i3-11100HE
Celeron 6600HE
# of Cores
8
6
4
2
# of Threads
16
12
8
2
Cache
24 MB
12 MB
8 MB
8 MB
Base Frequency
2.6 GHz
2.6 GHz
2.4 GHz
2.6 GHz
Turbo Frequency
4.7 GHz
4.5 GHz
4.4 GHz
N/A
TDP
45 W
45 W
45 W
35 W
Temperature Range
0 °C ~ 60 °C
0 °C ~ 60 °C
0 °C ~ 60 °C
0 °C ~ 60 °C
Memory Specifications
Capacity
2x SO-DIMM (64GB)
2x SO-DIMM (64GB)
2x SO-DIMM (64GB)
2x SO-DIMM (64GB)
Speed
3200 Mhz
3200 Mhz
3200 Mhz
3200 Mhz
ECC
No
No
No
No
I/O Specifications
PCIe
PEG (PCIe 4.0 x16)
8x PCIe 3.0
PEG (PCIe 4.0 x16)
8x PCIe 3.0
PEG (PCIe 4.0 x16)
8x PCIe 3.0
PEG (PCIe 4.0 x16)
8x PCIe 3.0
USB 3.2 Gen2 /2.0
4x / 8x
4x / 8x
4x / 8x
4x / 8x
SATA
4x
4x
4x
4x
Ethernet
1x 2.5 GbE
1x 2.5 GbE
1x 2.5 GbE
1x 2.5 GbE
Table 1 PCOM-B657VGL Embedded SKU

COM Express™ PORTWELL PCOM-B657VGL User's Guide
Copyright © PORTWELL 2021 PCOM-B657VGL User's Guide
11
Series
PCOM-B657VGL
Ordering P/N
AB1-3L57
AB1-3L64
AB1-3L63
AB1-3L59
AB1-3L62
AB1-3L61
CPU Specifications
Processor
W-11865MRE
W-11555MRE
W-11155MRE
W-11865MLE
W-11555MLE
W-11155MLE
# of Cores
8
6
4
8
6
4
# of Threads
16
12
8
16
12
8
Cache
24 MB
12 MB
8 MB
24 MB
12 MB
8 MB
Base Frequency
2.6 GHz
2.6 GHz
2.4 GHz
1.5 GHz
1.9 GHz
1.8 GHz
Turbo Frequency
4.7 GHz
4.5 GHz
4.4 GHz
4.5 GHz
4.4 GHz
3.1 GHz
TDP
45 W
45 W
45 W
25 W
25 W
25 W
Temperature Range
-40 °C ~ 85 °C
-40 °C ~ 85 °C
-40 °C ~ 85 °C
0 °C ~ 60 °C
0 °C ~ 60 °C
0 °C ~ 60 °C
Memory Specifications
Capacity
2x SO-DIMM (64GB)
2x SO-DIMM (64GB)
2x SO-DIMM (64GB)
2x SO-DIMM (64GB)
2x SO-DIMM (64GB)
2x SO-DIMM (64GB)
Speed
3200 Mhz
3200 Mhz
3200 Mhz
3200 Mhz
3200 Mhz
3200 Mhz
ECC
Yes
Yes
Yes
Yes
Yes
Yes
I/O Specifications
PCIe
PEG (PCIe 4.0 x16)
8x PCIe 3.0
PEG (PCIe 4.0 x16)
8x PCIe 3.0
PEG (PCIe 4.0 x16)
8x PCIe 3.0
PEG (PCIe 4.0 x16)
8x PCIe 3.0
PEG (PCIe 4.0 x16)
8x PCIe 3.0
PEG (PCIe 4.0 x16)
8x PCIe 3.0
USB 3.2 Gen2 /2.0
4x / 8x
4x / 8x
4x / 8x
4x / 8x
4x / 8x
4x / 8x
SATA
4x
4x
4x
4x
4x
4x
Ethernet
1x 2.5 GbE
1x 2.5 GbE
1x 2.5 GbE
1x 2.5 GbE
1x 2.5 GbE
1x 2.5 GbE
Table 2 PCOM-B657VGL Industrial SKU

COM Express™ PORTWELL PCOM-B657VGL User's Guide
Copyright © PORTWELL 2021 PCOM-B657VGL User's Guide
12
2 Block Diagram
Figure 1 Block Diagram
Intel® Tiger Lake PCH
RM590E/QM580E
IT 5121
PEG #0~#15
Tiger Lake-H Processors
SO-DIMM 1
DDR4 Dual Channel
PCOM-B657VGL
GbE Intel I225
SO-DIMM 2
HSIO #30~#33
COM Express® Type 6 Basic
Module 125x95mm
AT / ATX
Mode -40ﾟC ~ +85ﾟC
+12VDC
+5VSB
Row AB Row CD
PCIe #0~#3
PCIe #4~#5
8x USB 2.0USB 2.0 #0~#7
SATA #0~#1
GPIO
Misc.
GbE
PEG #0~#15
PCIe #6~#7
USB 3.2 #0~#3
DDI1
DDI2
DDI3
CH0 CH1
VGA
PCIe 4.0 x16
PCIe x1 HSIO #22
eDP #0
eDP
eDP/LVDS
DDI1 (DP/HDMI)TCP #0
DDI2 (DP/HDMI)TCP #1
DDI3 (DP/HDMI)TCP #2
HSIO #0~#3
HSIO #34~#35 HSIO #36~#37
HSIO #25~#26
USB 2.0 #0~#7
HDAHDA
CH7517 eDP #1
PTN3460
SPI SPI
SMBus
LPC
I2C
SER 0/1
TPM 2.0(SLB9670)
eSPI
EC Flash
Fan Fan
LVDS eDP
eDPVGA
4x PCIe 3.0 x1
2x PCIe 3.0 x1 2x PCIe 3.0 x1
4x USB 3.2 Gen2
2x SATA III
eSPI to LPC
SMBus
BIOS Flash
I2CI2C
SMBus
SER0 / SER1
WDT / HW Monitor / FAN
LPC
LPC
HSIO #28~#29SATA #2~#3 2x SATA III
SMBus
I2C
4x GPI / 4x GPO SPI
DMI Gen 3

COM Express™ PORTWELL PCOM-B657VGL User's Guide
Copyright © PORTWELL 2021 PCOM-B657VGL User's Guide
13
3Specifications
Product
➢PCOM-B657VGL
Form Factor
➢COM Express® Type 6, Basic Size (125 X 95mm)
Processor
➢Intel® CoreTM i7-11850HE
➢Intel® CoreTM i5-11500HE
➢Intel® CoreTM i3- 11100HE
➢Intel® Celeron® 6600HE
➢Intel® Xeon® W-11865MRE
➢Intel® Xeon® W-11555MRE
➢Intel® Xeon® W-11155MRE
➢Intel® Xeon® W-11865MLE
➢Intel® Xeon® W-11555MLE
➢Intel® Xeon® W-11155MLE
BIOS
➢AMI BIOS
Memory
➢2x SO-DIMM DDR4
➢Support ECC (selected SKU)
➢Up to 64GB 3200MHz
Graphic
➢Intel® UHD Graphics for 11th Gen Intel® Processors
Ethernet
➢1x 2.5 GbE (via Intel® i225LM/IT)
Audio
➢HDA
PCI Express
➢PEG (PCIe 4.0 x16)
➢8x PCIe 3.0
I/O
➢4x USB 3.2 Gen2 / 2.0
➢4x USB 2.0

COM Express™ PORTWELL PCOM-B657VGL User's Guide
Copyright © PORTWELL 2021 PCOM-B657VGL User's Guide
14
➢4x SATA
➢8 bit GPIO ( default 4 in / 4 out )
➢I2C / SMBus
➢2x UART
Hardware Monitors
➢ITE series Embedded Controller, Voltage, Fan and Temperature
Security
➢TPM 2.0 (Option)
Power Management
➢ACPI
Environment
➢Operating Temperature
0 °C ~ 60 °C
Extended : -40 °C ~ 85 °C (selected SKU)
➢Storage Temperature -40 °C ~ 85°C
➢Relative Humidity 5% ~ 95%
Table 3 PCOM-B657VGL SPEC

COM Express™ PORTWELL PCOM-B657VGL User's Guide
Copyright © PORTWELL 2021 PCOM-B657VGL User's Guide
15
3.1 Supported Operating Systems
The PCOM-B657VGL supports the following operating systems.
Vendor
Operating System
Supported
Microsoft
Windows 10 IoT Enterprise RS5 LTSC
Linux
Linux LTS kernel v5.4.x & v5.10.x
Yocto Project 3.0 VxWorks7
Table 4 OS Support list
Portwell does not endorse/validate/support any specific Linux distribution or entity mentioned on this list.
Portwell recommends customers to work with Linux vendors/open source communities to find feature list and support model.

COM Express™ PORTWELL PCOM-B657VGL User's Guide
Copyright © PORTWELL 2021 PCOM-B657VGL User's Guide
16
3.2 Windows OS Driver
Please download the drivers from Portwell download center website http://www.portwell.tw/support/download_center.php

COM Express™ PORTWELL PCOM-B657VGL User's Guide
Copyright © PORTWELL 2021 PCOM-B657VGL User's Guide
17
3.3 Electrical Characteristics
Input voltage
+12V ± 5%
RTC Battery
From Carrier
Power on mode
ATX Mode & AT Mode
Table 5 Electrical characteristics
Figure 2 PCOM-B657VGL Power on sequence

COM Express™ PORTWELL PCOM-B657VGL User's Guide
Copyright © PORTWELL 2021 PCOM-B657VGL User's Guide
18
⚫ATX Power Sequence
Figure 3 ATX style boot
(Reference from COM Express® Carrier Design Guide)
VCC_5V_SBY (To CEX)
PSON# (To ATX PS)
VCC_12V (To CEX)
SUS_S3# (From CEX)
PWR_BTN# (To CEX)
(Or other wake event)
PWR_OK (To CEX)
odule Internal Power Rails
SYS_RESET# (To CEX) (Optional)
CB_RESET# (From CEX)
PCI_RESET# (From CEX)
VCC_5V
VCC_3V3 For Carrier Board use (not needed by odule)
T
PSR
T
PB
BIOS Starts
T
P1

COM Express™ PORTWELL PCOM-B657VGL User's Guide
Copyright © PORTWELL 2021 PCOM-B657VGL User's Guide
19
⚫AT Power Sequence
Figure 4 AT style boot
(Reference from COM Express® Carrier Design Guide)
VCC_5V_SBY (Optional) ( ay be tied to VCC_5V)
VCC_12V (To CEX)
PWR_BTN# (To CEX) (Optional)
VCC_5V
SUS_S3# (From CEX)
PWR_OK (To CEX)
odule Internal Power Rails
SYS_RESET# (To CEX) (Optional)
CB_RESET# (From CEX)
PCI_RESET# (From CEX)
For Carrier Board use
(not needed by odule)VCC_3V3
T
PSR
T
P1
BIOS Starts

COM Express™ PORTWELL PCOM-B657VGL User's Guide
Copyright © PORTWELL 2021 PCOM-B657VGL User's Guide
20
⚫PWR_OK signal
Carrier board hardware must keep this signal low until all power rails and clocks are stable. Releasing PWR_OK too early or not
driving it low at all may cause boot up abnormal symptom. It is a good design implementation to delay the PWR_OK signal a little (at
least 100ms) after all carrier board power rails are up, to ensure a stable system.
Figure 5 PWR_OK signal brief diagram
5v
12v
3.3v
PWR_OK
T ≥ 100ms
