POS M200III User manual

User’s Manual
IMPACT DOT-MATRIX PRINTER
Proficient in Commercial POS Receipt printers
M200III
M200IIIC
POS

1
1.Safety Notice:
* Don't touch the printer head with anything.
* Don't touch the cutter blade.
* Don't bend the power cord excessively or place any heavy objects onto it.
* Don't use the printer when it is out of order. This can cause a fire or and electrocution.
* When connecting or disconnecting the plug, always hold the plug but not the cord.
* Keep the desiccant out of children's reach.
* Use only approved accessories and do not try to disassemble, repair or remodel it by yourself.
* Install the printer on the stable surface. Choose firm, level surface where avoid vibration.
* Don't let water or other foreign objects into the printer.
* Don't connect a telephone line into the peripheral drive connector.
* We recommend that you unplug the printer from the power outlet if no use it for a long period .
2. Applications:
* POS system Receipts
* EFT POS system Receipts
* Gym, post, hospital, civil aviation system Receipts
* Inquiry, Service system Receipts
* Instrument test Receipts
* Tax, Tab Receipts
3. Unpacking
After unpacking the unit, check that all the necessary accessories are included in the package.
Printer 1 PCS
Data Cable 1 PCS
Power Adapter (include power cord) 1 SET

2
* Command protocal is based on ESC/POS standard.
* Low-noise thermal printing.
* Various Layouts are possible by using page mode.
* Repeated operation and copy printing are possible.
* Character font size optional.
* Easy paper-roll installation.
* Easy paper jam clearance.
* Easy maintenance for tasks such as head cleaning.
* Built-in interface provides control capability for cash drawer.
Impact Dot-matrix
4.5 line / secretary.
76±0.5mm
ANK Character: Font A: 9×9dots FontB:7
Simplify/Traditional: 16×9dots 16 dots
×9dots
Print command
Print speed
Paper width
Print columns
Character
Interface
Print method
400dots/line
Compatible with ESC/POS
Parallel/Serial/Wireless/USB
Auto cutter
Reliability print
Dimension 155 135 265mm W D H × × （ × × ）
Adaptor power input AC 110V/220V, 50~60Hz
Powersupply DC 24V/2.5A
Power adapter Input:AC110V/220V,50～60HZ
Output:DC 12V/3A
Cash Drawer DC 24V/1A
Work Temperature 0~50℃ Dampness: 10~80%
Storage temperature -10~60℃, Dampness: 10~90%
10 million lines
All or half
4. Main Features:
5. Technique Spec.

a
bc
3
Power adapter
Power line
7. Paper Roll Installation
b. Install the paper roll according to the chart below.
c. Place the paper into the paper path, and printer will automatically feed the paper.
d. Open the cutter, separate plies of paper. Insert the upper copies through the upper cutter slot, and
the lower copies under the cutter.
e. Insert the lower copies into the paper receiver gap, and rotate the receiver pole a round to lock the
paper. Then close the cutter and place the ribbon cartridge followed by the arrow.
f. Cut off excess paper, then close the top cover.
a. Turn on the printer and open the top cover.
6. Printer Connection
a. Plug the DC cord connector into the printer's power connector.
b. Plug the data cable connector into the printer's interface connector.
c. Plug the drawer cable into the drawer kick-out connector on the back of the printer
next to the interface connector.

4
8. Setting the Printing Mode (DIP switches)
The DIP switches are used to set the printer to perform various functions, such as cutter mode, character set,
speed, beeper, print density and etc.
b
d e
ac
DIP SWITCH SETTINGS
1 2 3 4 5 6 7 8

9. Driver Installation
5

6

7

8

9

10

WARNING:
All rights reserved. No part of this publication may be reproduced,
stored in a retrieval, or transmitted in any form or by any means,
electronic, mechanical, photocopying, recording, or otherwise, without
the prior written permission. The company reverses the rights of
modifications of manufacture technology, assembly, software and
hardware without notice. Contact your franchiser if you need further
information about the product.
