Positron G1001-CR User manual

Document 180-0209-001 R01
G1001-CR
Self-installation Guide
WWW.POSITRONACCESS.COM
5101 Buchan Street, Suite 220,
Montreal, QC H4P 2R9 Canada
[email protected]
© Positron Access Solutions
Troubleshooting
The G1001-CR has ve (5) Status LEDs:
• PWR: it will be ON when connected to a
local power source. If it is OFF, please verify
you have connected the 12V wall adapter to
a working power jack.
• STA: it will be yellow while the G1001-CR is
booting and then will be OFF.
• G.hn: it will be ON (green) to indicate that
the link to the Internet is UP. It will be OFF in
the link is DOWN. It will blink ON and OFF
to indicate a bad link. You can restart the
G1001-CR if you see a blinking G.hn LED.
If this does not solve the problem, please
reach out to your Operator for assistance.
• RFP: it will be ON (green) to indicate the
G1001-CR is providing the Reverse Power
Feed (RPF) to the GAM-4-CRX serving the
customer.
• FLT: it will be ON (yellow) to indicate an
overload or a short circuit condition on one
of the pairs when attempting to provide a
RPF to the GAM-4-CRX device. The power
source is protected and will attempt retries
to provide power to the pairs every 500mS
approximately.
G1001-CR Port and LED Definition

Step 4. Connect the port labeled as GE (on the opposite end of the G1001-CR) to your
Residential Gateway using a standard Ethernet cable (usually provided with your
Residential Gateway).
Step 2. Connect the port labeled as LINE to your coaxial jack.
Step 3. Connect the 12V wall adapter to a nearby power plug and connect it to the
G1001-CR 12V connector.
Unpacking the G1001-CR
Connecting the G1001-CR to
your Residential Gateway
Step 1. Find a location close to where you
will install your Residential Gateway.
This location should also be close
to the telephone jack where you will
connect the G1001-CR and to a
power outlet.
Power Up
The G1001-CR takes less than one (1) minute to power up and establish the connection to the
Internet. The STA LED will turn solid green to indicate that the G1001-CR boot sequence is
completed. The G.hn LED will turn green solid to indicate that the link is UP.
Your Residential Gateway will now be able to obtain its conguration and IP address and begin
providing access to the Internet for your in-home devices. Refer to the installation document for
your Residential Gateway if needed.
12V wall adapter
Step 4
Ethernet Cable
Residential Gateway
G1001-CR
Coaxial jack
Step 3 Step 2
12V wall adapter
Power plug
G1001-CR
