Bixolon SRP-770II
Manual
More information available at POSMicro.com

User's Manual
SRP-770II/770IIE
Label Printer
Rev. 1.18
http://www.bixolon.com

Rev. 1.18
- 2 -
SRP-770II/770IIE
■Table of Contents
※Manual Information & Usage Precautions························································3
1. Content Confirmation·····················································································7
2. Product Part Names·······················································································8
3. Installation & Usage·····················································································10
3-1 Power Connection·····················································································10
3-2 Interface Cable Connection········································································· 11
3-3 Paper Installation······················································································12
3-4 LED Display·····························································································13
3-5 Test printing ·····························································································14
4. Self-Test ·····································································································15
5. Detailed features··························································································16
5-1 Printer Settings with Dip switches·································································16
5-2 Pause/Restart ··························································································17
5-3 Gap Sensor Auto-Calibration·······································································18
5-4 Gap Sensor Manual-Calibration···································································19
5-5 The Peel-Off ····························································································20
5-6 Using Fan-Fold Paper················································································22
5-7 Auto Cutter (option) ···················································································23
6. Cleaning Head·····························································································24
7. Appendix ····································································································25
7-1 Specifications···························································································25
7-2 Certification ·····························································································26
7-3 Label Types ·····························································································26

Rev. 1.18
- 3 -
SRP-770II/770IIE
■Manual Information
※Manual Information & Usage Precautions
This user manual contains basic information for product usage as well as for emergency
measures that may be required.
※The following separate manuals provide more detailed content on various technological
issues and areas.
1. Windows Driver Manual
This manual provides information on the installation instructions and main functions
of the Windows Driver.
2. Unified Label Printer Utility Manual
This manual provides information on the usage of software for function selection of
this product, operating condition modification, etc.
The following functions are available.
1) Firmware Downloader
2) Factory Font Downloader
3) Soft-Font (or Downloadable-font) Downloader
4) PCX File Downloader
5) User Setting Manager
6) File Transfer Manager
7) SLCS Tester
3. Programming (SLCS) Manual
This manual provides information on label printer commands.
4. True Font Downloader Manual
This manual provides information on the usage of the font downloader that can
download True Fonts and facilitate their usage as Device Fonts.
5. Ethernet interface Manual
This manual provides information on the configuration and usage of Ethernet
interface.
6. Label craft Manual
This manual provides information on the usage of the Windows PC program that can
make labels by adding text, graphics, or barcodes at desired positions.
We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and quality
of all our products. In following, product specifications and/or user manual content may be
changed without prior notice.

Rev. 1.18
- 4 -
SRP-770II/770IIE
■Safety Precautions
In using the present appliance, please keep the following safety regulations in order to
prevent any hazard or material damage.
WARNING
Violating following instructions can cause serious injury or death.
Do not bend the cable by force or leave it under any
heavy object.
•A damaged cable can cause a fire.
Do not plug in or unplug with your hands wet.
•You can be electrocuted.
Keep the plastic bag out of children’s reach.
•If not, a child may put the bag on his head.
Do not pull the cable to unplug.
•This can damage the cable, which is the origin of a fire or a
breakdown of the printer.
You must use only the supplied adapter.
•It is dangerous to use other adapters.
Do not plug several products in one multi-outlet.
•This can provoke over-heating and a fire.
•If the plug is wet or dirty, dry or wipe it before usage.
•If the plug does not fit perfectly with the outlet, do not plug in.
•Be sure to use only standardized multi-outlets.
PROHIBIT
ED
PROHIBIT
ED
PROHIBIT
ED
PROHIBIT
ED
PROHIBIT
ED
ONLY SUPPLIED ADAPTER
PROHIBIT
ED

Rev. 1.18
- 5 -
SRP-770II/770IIE
CAUTION
Violating following instructions can cause slight wound or damage the appliance .
Do not use the printer when it is out of order. This
can cause a fire or an electrocution.
•Switch off and unplug the printer before calling your dealer.
Do not let water or other foreign objects in the
printer.
• If this happened, switch off and unplug the printer before
calling your dealer.
Use only approved accessories and do not try to
disassemble, repair or remodel it for yourself.
•Call your dealer when you need these services.
• Do not touch the blade of auto cutter.
Install the printer on the stable surface.
• If the printer falls down, it can be broken and you can hurt
yourself.
Keep the desiccant out of children’s reach.
•If not, they may eat it.
If you observe a strange smoke, odor or noise from
the printer, unplug it before taking following
measures.
• Switch off the printer and unplug the set from the mains.
• After the disappearance of the smoke, call your dealer to
repair it.
TO UNPLUG
PROHIBIT
ED
DISASSEMBLING
PROHIBITED
PROHIBIT
ED
PROHIBIT
ED
TO UNPLUG
PRINTER
PRINTER
PRINTER
PRINTER
DEALER
PRINTER

Rev. 1.18
- 6 -
SRP-770II/770IIE
■Other Precautions
The copyright for this user manual and various other manuals is property of the BIXOLON
Co., Ltd. Any copying or conversion into electronic firm and saving of this material without
the express written permission of BIXOLON Co., Ltd. is strictly prohibited.
Use of the information contained in this manual is not subject to any patent liability. This
manual has been prepared with utmost care and attention to detail but may contain certain
errors and/or omissions.
BIXOLON Co., Ltd. is not legally liable for any damages resulting from the use of the
information in this manual.
BIXOLON Co., Ltd. and its affiliates are not legally liable (United States excluded) for any
damages, loss, costs, and/or expenses that result from the breakdown, malfunction, and/or
misuse of the product due to violation or neglect of the operation and maintenance
information and instructions provided by the BIXOLON Co., Ltd., as well as from the
unauthorized alteration, repair, and/or modification of the product by the user and/or third
party.
BIXOLON Co., Ltd. is not legally liable for any damages and/or issues resulting from the use
of options and/or parts that are not authentic BIXOLON products or authorized products.

Rev. 1.18
- 7 -
SRP-770II/770IIE
1. Content Confirmation
The following items should all be contained in the printer package.
Contact the dealer from which the purchase was made if any item is damaged and/or
missing.
SRP-770II/770IIE
Power Cord
AC Adapter
CD
User’s Manual
※Optional items
RS-232C(Serial) Cable
IEEE1284 (Parallel) Cable
USB Cable

Rev. 1.18
- 8 -
SRP-770II/770IIE
2. Product Part Names
Feed Button
Cover Peel-off
Cover Lever
Printer Head
Paper Holder
Paper Guide
Peel-off Sensor
Paper Gap Sensor
Paper Cover
Power Switch

Rev. 1.18
- 9 -
SRP-770II/770IIE
SAMSUNGLABE
L
PRNTER
Dip Switch
Auto Cutter (Option)
IEEE1284 Receptacle
USB Receptacle
Fan-Fold
Power Receptacle
RS-232C Receptacle
