pottery barn kids EVERETT MODULAR DESK LARGE CORNER TOP User manual

Date: 25-Apr-16 Page 1 of 6
Rev:
pottery barn kids
EVERETT MODULAR DESK LARGE CORNER TOP
www.potterybarnkids.com

Date: 25-Apr-16 Page 2 of 6
Rev:
Important Safety Instructions:
Please read all instructions carefully before assembling this desk.
For your safety, assembly by two or more adults is strongly recommended.
Keep these instructions for future use.
Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the
structural integrity of the item.
Pre-assembly:
Remove all parts and hardware from the box. Place all items on a carpeted or scratch-free work surface, as this
will avoid damaging parts during assembly. The shipping box provides an ideal work surface.
To avoid accidentally discarding small parts or hardware, do not dispose of any packaging or contents of the
shipping carton until assembly is complete.
Use the parts and hardware lists below to identify and separate each of the pieces included.
The illustrations provided allow for easier assembly when used in conjunction with the assembly instructions.
The use of power tools to aid in assembly is not recommended. Power tools can damage the hardware and split
the wood.
Parts Included:
(N) Desk Top - 1x
(O) Leg–1x
Parts Required:
(B) Drawer Base - 2x (sold separately)
Hardware Included:
C –Mending Plate
65 x 20 x 2-1x
D –Machine Screw
5/32 x 1/2” -2x
F - Spring Washer
1/4” x Ф11 x 1.2 -4x
P –Bolt
1/4” x 3/4” -4x
Q –Bolt Screw
1/4” x 25 -4x
R –Metal Bracket
126 x 126 x 53 -1x
Tools Required:
Philips Head Screwdriver (not included)
Assembly Instructions
Preston Media Base
Please read all instructions before beginning assembly.
PART LIST HARDWARE LIST
Allen key (10 pcs )
PART LIST HARDWARE LIST
( 1 pc )
Short bolt (1/4" x 28mm)
Spring washer (1/4")
L. Flat washer (1/4") ( 8 pcs )Shelf pin
K. (10 pcs )
(10 pcs )
J.
( 1 pc )
Plastic restraint
Plastic wall bracket ( 2 pcs )
( 2 pcs )
Long wood screw 3 x 32mm
Short wood screw 3 x 19mm ( 2 pcs )
Philips Screwdriver (Not included)
Wood screw 3.5 x 19mm
N.
(22 pcs )
Plastic cap
M.
( 4 pcs )
A
B
C
D
E
F
G
H
I
Machine screw (5/32" x 22mm)
P.
( 4 pcs )
Door knob
O.
( 2 pcs )
R.
Q.
Wood screw (3 x 12mm) (12 pcs )
Bracket ( 2 pcs )
T.
S.
E

Date: 25-Apr-16 Page 3 of 6
Rev:
R
N
Hardware Required (From Drawer Base):
E –Flat Washer
1/4” x Ф13 x 1-8x
F - Spring Washer
1/4” x Ф11 x 1.2- 8x
G –Bolt
1/4” x 1”- 8x
H - Allen Key
M4 x 110mm x 30-1x
Assembly Instruction Steps:
1. Remove the Top Drawer from (B) and set it aside.
-The drawer is equipped with 1 rubber stopper that prevents the drawer from being removed during normal
operation.
-During assembly the drawer can be removed with minor force, as the rubber stoppers will bend to allow the
drawer to be completely removed.
-When removing the drawer, it MUST be removed at a straight angle. If it is not straight, the drawer will stick
on the wooden runners.
2. Attach (R) to (N) and secure with the hardware, as shown in the illustration below. Do not over tighten.
R
1x
F
4x
P
4x
Drawer Stopper

Date: 25-Apr-16 Page 4 of 6
Rev:
R
R
3. Attach (O) to (R) and secure with (Q), as shown in the illustration below. A Philips Head Screw Driver is
required to tighten. Do not over tighten.
4. Attach the assembled Desk Top to (B) by aligning the pre-drilled holes with the wooden dowels and secure with
the hardware, as shown below. Do not fully tighten.
5. Check alignments and fully tighten all connections at this time. Do not over tighten.
Q
4x
E
8x
F
8x
G
8x
8x

Date: 25-Apr-16 Page 5 of 6
Rev:
6. Put the Drawers back into the Drawer Bases (B) by bending the rubber stoppers as needed to allow the drawer
to enter the Drawer Base.
-This will require some force to get the drawers back into the Drawer Bases.
-Make sure the wooden drawer runners and the rubber stoppers are properly aligned as you re-install the
drawer
7. If the desk does not sit level adjust the levelers underneath the legs, as seen in the illustration below.
UP
DOWN
9x

Date: 25-Apr-16 Page 6 of 6
Rev:
Multiple Desks can be combined together by following the assembly instructions below:
8. Place the Desks in the desired location.
9. Align the Desks together.
10. Place a Mending Plate (C) over the metal insert holes on the rear side of the Desk Tops, as seen below.
11. Insert 2 Machine Screws (D) through each of the pre-drilled holes of the Mending Plate and then into the metal
insert holes on the Desk Tops.
12. Tighten all screws with a Phillip Head Screw Driver (not included).
Care Instructions:
Dust often using a soft, dry, and clean lint-free cloth.
Blot spills immediately and wipe with a clean, damp cloth.
We do not recommend the use of chemical cleansers, abrasives, or furniture polish on our lacquered finish.
Hardware may loosen over time. Periodically check to make sure all connections are tight. Re-tighten if
necessary.
Thank you for your purchase.
stores | catalog | www.potterybarnkids.com
USA 1.800.290.8181
C
1x
D
2x
