Instruction Manual
Manual de Instrucciones
Manuel d’Instructions
PP4000C
Electrolux Home Products
North America
Div. of WCI Outdoor Products, Inc.
Augusta, GA 30907
Copyright E2001 WCI Outdoor Products, Inc. 530088058 9/20/01
NOT DESIGNED FOR USE WITH
ELECTRIC POWERHEADS
NO ESTA DISEÑADO PARA EL USO CON
CABEZAS DE MOTOR ELÉCTRICO
NON CONÇU POUR L’USAGE AVEC
BLOC---MOTEURS ÉLECTRIQUES
R

2
SAFETY RULES
WARNING: When using gardening
appliances, basic safety precautions should
always be followed to reduce the risk of fire
and serious injury. Read and follow all instruc-
tions. Failure to do so can result in serious in-
jury.
DANGER:This power tool can be dan-
gerous! This unit can cause serious injury in-
cluding amputation or blindness to the opera-
tor and others. The warnings and safety
instructions in this manual must be followed to
provide reasonable safety and efficiency in
using the unit. The operator is responsible for
following the warnings and instructions in this
manual and on the unit. Read the entire in-
struction manual before assembling and using
the unit! Restrict the use of this unit to persons
who read, understand, and follow the warn-
ings and instructions in this manual and on the
unit. Never allow children to operate this unit.
SAFETY INFORMATION
ON THE UNIT
INSTRUCTION
MANUAL
DANGER:Never use flailing devices.
DANGER: Blade can thrust violently
away from material it does not cut. Blade
thrust can cause amputation of arms or legs.
Keep people and animals 50 feet (15 meters)
away.
WARNING: Blade can throw objects
violently. You can be blinded or injured. Wear
eye and leg protection.
Leg
Guards
Boots
Eye
Protection
ALWAYS WEAR
Thrown
objects
WARNING: Hazard zone for thrown
objects. Blade can throw objects violently.
Others can be blinded or injured. Keep people
and animals 50 feet (15 meters) away.
Hazard Zone
50 Feet
(15 Meters)
WARNING: The blade continues to
spin after throttle is released or engine is
turned off. The coasting blade can throw ob-
jects or seriously cut you if accidentally
touched. Stop the blade by contacting the left
hand side of coasting blade with material al-
ready cut.
Stop coasting
blade by contact
with cut material.
OPERATOR SAFETY
SDress properly. Always wear safety glasses
or similar eye protection when operating, or
performing maintenance on your unit (safe-
ty glasses are available). Eye protection
should be marked Z87.
SAlways wear face or dust mask if operation
is dusty.
SAlways wear heavy, long pants, long
sleeves, boots, and gloves. Wearing safety
leg guards is recommended.
SAlways wear foot protection. Do not go
barefoot or wear sandals.
SSecure hair above shoulder length. Secure
or remove loose clothing and jewelry or
clothing with loosely hanging ties, straps,
tassels, etc. They can be caught in moving
parts.

3
SBeing fully covered also helps protect you
from debris and pieces of toxic plants
thrown by spinning blade.
SStay alert. Do not operate unit when you are
tired, ill, upset or under influence of alcohol,
drugs, or medication. Watch what you are
doing; use common sense.
SWear hearing protection.
SNever start or run the engine inside a closed
room or building. Breathing exhaust fumes
can kill.
SKeep handles free of oil and fuel.
SAlways use the handlebar and a properly
adjusted shoulder strap when using brush-
cutter attachment (see ASSEMBLY).
UNIT/MAINTENANCE SAFETY
WARNING: Disconnect powerhead
spark plug (or disconnect powerhead from
power source) before performing mainte-
nance.
SLook for and replace damaged or loose
parts before each use. Look for and repair
fuel leaks before use. Keep unit in good
working condition.
SThrow away blades that are bent, warped,
cracked, broken, or damaged in any other
way. Replace trimmer head parts that are
cracked, chipped, broken, or damaged in
any other way before using the unit.
SMaintain the unit according to recom-
mended procedures. Keep the blade sharp.
Never use flailing devices, wire, rope,
string, etc.
SUse only specified blade; make sure it is
properly installed and securely fastened.
SNever start engine with clutch shroud re-
moved. The clutch can fly off and cause se-
rious injury.
SBe sure blade stops turning when engine
idles.
SMake carburetor adjustments with the lower
end supported to prevent the blade from
contacting any object. Hold the unit by hand;
do not use the shoulder strap for support.
SKeep others away when making carburetor
adjustments.
SUse only recommended Poulan PRO!ac-
cessories and replacement parts.
SHave all maintenance and service not ex-
plained in this manual performed by an au-
thorized service dealer.
FUEL SAFETY
SMix and pour fuel outdoors.
SKeep away from sparks or flames.
SUse a container approved for fuel.
SDo not smoke or allow smoking near fuel or
the unit or while using the unit.
SAvoid spilling fuel or oil. Wipe up all fuel
spills before starting engine.
SMove at least 10 feet (3 meters) away from fu-
eling site before starting engine.
SStop engine and allow it to cool before re-
moving fuel cap.
SRemove fuel cap slowly.
CUTTING SAFETY
WARNING: Inspect the area to be cut
before each use. Remove objects (rocks, bro-
ken glass, nails, wire, string, etc.) which can
be thrown or become entangled in the blade.
SKeep others including children, animals, by-
standers, and helpers at least 50 feet (15
meters) away. Stop the engine immediately
if you are approached.
SAlways keep engine on the right--hand side
of your body.
SHold the unit firmly with both hands.
SKeep firm footing and balance. Do not over-
reach.
SKeep blade below waist level.
SDo not raise powerhead engine above your
waist.
SKeep all parts of your body away from blade
and muffler.
SCut from your left to your right. Cutting on
the right side of the shield will throw debris
away from the operator.
SUse only in daylight or good artificial light.
SUse only for jobs explained in this manual.
TRANSPORTING AND STORAGE
SStop the powerhead engine before carrying
unit.
SKeep muffler away from your body.
SAllow engine to cool and secure unit before
storing or transporting it in a vehicle.
SEmpty the fuel tank before storing or trans-
porting the unit. Use up fuel left in the carbu-
retor by starting the engine and letting it run
until it stops.
SStore unit and fuel in an area where fuel va-
pors cannot reach sparks or open flames
from water heaters, electric motors or
switches, furnaces, etc.
SStore unit so the blade cannot accidentally
cause injury.
SStore unit indoors, out of reach of children.
SPECIAL NOTICE: Exposure to vibrations
through prolonged use of gasoline powered
hand tools could cause blood vessel or nerve
damage in the fingers, hands, and joints of
people prone to circulation disorders or abnor-
mal swellings. Prolonged use in cold weather
has been linked to blood vessel damage in
otherwise healthy people. If symptoms occur
such as numbness, pain, loss of strength,
change in skin color or texture, or loss of feel-
ing in the fingers, hands, or joints, discontinue
the use of this tool and seek medical attention.
An anti-vibration system does not guarantee
the avoidance of these problems. Users who
operate power tools on a continual and regular
basis must monitor closely their physical
condition and the condition of this tool.
SAVE THESE INSTRUCTIONS

4
ASSEMBLY
WARNING: If received assembled, re-
peat all steps to ensure your unit is properly as-
sembled and all fasteners are secure.
Examine parts for damage. Do not use dam-
aged parts.
NOTE: If you need assistance or find that parts
are missing or damaged, call 1-800-554-6723.
TOOLS REQUIRED
SHex wrench (provided)
HANDLEBAR ASSEMBLY
DANGER: RISK OF CUT. To avoid se-
rious injury, the barrier portion of the handle-
bar must be installed as shown on the upper
tube of the powerhead to provide a barrier be-
tween operator and the spinning blade. Attach
tube clamp above arrow on safety warning de-
cal on the upper tube (powerhead end of unit).
Ensure handlebar is positioned on handlebar
clamp between the arrows on the handlebar
decal.
NOTE: The tube clamp base has four spacer
tabs attached. These tabs are provided to
adapt this attachment for use with power-
heads that have a 1"diameter upper tube (the
tube clamp will not tighten down securely on
the 1"diameter upper tube without using these
spacer tabs). The tabs must be broken off
completely before use and placed over the
screw holes on the clamp base. These tabs
are not needed for powerheads with a 7/8"up-
per tube.
Spacer Tabs
HANDLEBAR CLAMP BASE
Spacer Tabs
positioned for use
on 1"diameter
upper tube
1. Place the tube clamp over the upper tube
above the arrow on the safety decal.
2. Position the clamp base under the upper
tube and align the tube clamp and clamp
base screw holes (use spacer tabs be-
tween tube clamp and clamp base if nec-
essary to secure clamp, i.e. for 1"diame-
ter upper tube).
POWERHEAD
END
ATTACHMENT
END
Screws
Clamp
Base
Handlebar Clamp
between arrows on
handlebar decal
Clamp
Knob
Tube
Clamp
Handlebar
Arrow on
Safety Decal
3. Insert four screws into the screw holes.
4. Secure tube clamp by tightening screws
with the hex wrench.
5. Position the handlebar as shown, ensur-
ing the handlebar is positioned on the
handlebar clamp between the two arrows
on the handlebar decal.
6. Retighten handlebar by turning clamp
knob clockwise until handlebar is secure
and stationary in clamp (clamp knob can-
not be overtightened).
SHOULDER STRAP ASSEMBLY
WARNING: Proper shoulder strap and
handlebar adjustments are required before use.
The shoulder strap clamp must be installed as
shown above the handlebar on the upper tube
(powerhead end of unit).
NOTE: The lower shoulder strap clamp has
two spacer tabs attached. These tabs are pro-
vided to adapt this attachment for use with
powerheads that have a 1"diameter upper
tube (the shoulder strap clamp will not tighten
down securely on the 1"diameter upper tube
without using these spacer tabs). The tabs
must be broken off completely before use and
placed over the screw holes on the lower
shoulder strap clamp. These tabs are not
needed for powerheads with a 7/8"upper
tube.

5
Spacer Tabs
LOWER SHOULDER STRAP
CLAMP
Spacer Tabs
positioned for use
on 1"diameter
upper tube
1. Place the upper shoulder strap clamp
over the upper tube above the handlebar.
2. Position the lower shoulder strap clamp
under the upper tube and align the upper
and lower clamp screw holes (use
spacer tabs between upper and lower
clamps if necessary to secure clamp, i.e.
for 1"diameter upper tube).
Upper Shoulder
Strap Clamp
Screws
Lower Shoulder
Strap Clamp
POWERHEAD
END
ATTACHMENT
END
3. Insert two screws into the screw holes.
4. Secure shoulder strap clamp by tighten-
ing screws with the hex wrench.
5. Try on shoulder strap and adjust for fit and
balance before starting the engine or begin-
ning a cutting operation.
6. Insert your right arm and head through
the shoulder strap and allow it to rest on
your left shoulder. Make sure the danger
sign is on your back and the hook is to the
right side of your waist.
NOTE: A one-half twist is built in the shoulder
strap to allow the strap to rest flat on the shoul-
der.
7. Adjust the strap, allowing the hook to be
about 6 inches below the waist.
8. Fasten the strap hook to the upper clamp
and lift the tool to the operating position.
Shoulder Strap
Shoulder
Strap
Clamp
OPERATION
KNOW YOUR BRUSHCUTTER ATTACHMENT
READ THIS INSTRUCTION MANUAL AND SAFETY RULES BEFORE OPERATING YOUR
BRUSHCUTTER ATTACHMENT. Compare the illustrations with your unit to familiarize yourself
with the location of various controls and adjustments. Save this manual for future reference.
B
l
a
d
e
S
h
i
e
l
d
Locking Lever
Blade
Gearbox
Tube
Hanger
BLADE
The BLADE is designed for cutting grass,
weeds, and brush up to 1/2 inch in diameter.
LOCKING LEVER
The LOCKING LEVER is used to prevent the
blade shaft from turning during blade replace-
ment.

6
OPERATING THE COUPLER
Your powerhead is equipped with a coupler
which enables optional attachments to be
installed. The optional attachments are:
MODEL:
Edger PP1000E........................
Cultivator PP2000T....................
Blower PP3000B.......................
WARNING: Always disconnect pow-
erhead spark plug before removing or instal-
ling attachments.
REMOVING ATTACHMENT
CAUTION: When removing or installing at-
tachments, place the powerhead and attach-
ment on a flat surface for stability.
1. Loosen the coupler by turning the knob
counterclockwise.
Coupler
Knob
LOOSEN
TIGHTEN
Upper Tube
Lower
Attachment
2. Press and hold the locking/release but-
ton.
Locking/Release
Button
Coupler Upper Tube
Lower Attachment
3. While securely holding the upper tube,
pull the attachment straight out of the
coupler.
INSTALLING ATTACHMENT
1. Remove the tube cap from the attach-
ment (if present) and discard.
2. Position locking/release button of attach-
ment into guide recess of upper tube cou-
pler.
Coupler Primary Hole
Upper
Tube
Locking/
Release
Button
Attachment
Guide Recess
3. Push the attachment into the coupler until
the locking/release button snaps into the
primary hole.
4. Before using the unit, tighten the knob se-
curely by turning clockwise.
INSTALLING ATTACHMENT
HANGER
An attachment hanger is provided for storage
when attachment is not in use. To install hang-
er on attachment:
1. Remove the tube cap from the attach-
ment (if present) and discard.
2. Press and hold the locking/release but-
ton.
3. Push hanger onto the attachment until
the locking/release button snaps into the
hole.
OPERATING POSITION
Boots
Heavy,
Long Pants
Eye Protection
ALWAYS WEAR:
Cut from your left to your right.
NOTE: This brushcutter attachment is not
designed for use with electric powerheads.
When operating unit with brushcutter attach-
ment, clip shoulder strap onto upper shoulder
strap clamp, stand as shown and check for the
following:
SWear eye protection and heavy clothing.
SKeep arms extended with right hand holding
the trigger handle of powerhead.
SKeep left arm extended with left hand hold-
ing the handlebar.
SKeep unit below waist level.
SShoulder strap pad should be centered on
your left shoulder and danger sign centered
on your back.
SMaintain full weight of tool on left shoulder.
SWithout bending over, keep the blade near
and parallel to the ground and not crowded in-
to material being cut.
OPERATING INSTRUCTIONS FOR
BRUSHCUTTER ATTACHMENT
SBlade Thrust is a reaction that only occurs
when using a bladed unit. This reaction can
cause serious injury such as amputation.
Carefully study this section. It is important that
you understand what causes blade thrust,
how you can reduce the chance of its occur-
ring, and how you can remain in control of unit
if blade thrust occurs.
SWHAT CAUSES BLADE THRUST -- Blade
Thrust can occur when spinning blade con-
tacts an object that it does not cut. This contact
causes blade to stop for an instant and then
suddenly move or “thrust” away from object
that was hit. The “thrusting” reaction can be
violent enough to cause operator to be pro-
pelled in any direction and lose control of unit.
The uncontrolled unit can cause serious injury
if blade contacts operator or others.

7
SWHEN BLADE THRUST OCCURS --
Blade Thrust can occur without warning if
the blade snags, stalls, or binds. This is
more likely to occur in areas where it is diffi-
cult to see the material being cut. By using
the unit properly, the occurrence of blade
thrust will be reduced and the operator will
be less likely to lose control.
SCut only grass, weeds, and woody brush up to
1/2 inch in diameter with weed blade. Do not
let blade contact material it cannot cut such as
stumps, rocks, fences, metal, etc., or clusters
of hard, woody brush with a diameter greater
than 1/2 inch.
SUse a sharp blade. A dull blade is more likely
to snag and thrust.
SCut only at full throttle. The blade will have
maximum cutting power and is less likely to
bind or stall.
S“Feed” the blade deliberately and not too
rapidly. The blade can thrust away if it is fed
too rapidly.
SCut only from your left to your right. Cutting on
right side of the shield will throw debris away
from the operator.
SUse the shoulder strap and keep a firm grip
on the unit with both hands. A properly ad-
justed shoulder strap will support the weight
of the unit, freeing your arms and hands to
control and guide the cutting motion.
SKeep feet comfortably spread apart and
braced for a possible sudden, rapid thrust of
unit. Do not overreach. Keep firm footing and
balance.
SKeep blade below waist level. It will be eas-
ier to maintain control of unit.
SDo not raise the engine above your waist as
the blade can come dangerously close to
your body.
SDo not swing the unit with such force that
you are in danger of losing your balance.
Bring the powerhead engine to cutting speed
before entering the material to be cut.
If the blade does not turn when you squeeze
the throttle trigger of the powerhead, make
sure the attachment is fully inserted into the
coupler.
Always release the throttle trigger and allow
powerhead engine to return to idle speed
when not cutting. The blade should not turn
while the engine is running at idle. If the blade
turns at idle, do not use your unit. Refer to the
CARBURETOR ADJUSTMENT section of
the powerhead manual or contact your autho-
rized service dealer.
SMaintain good firm footing while using the
unit. Do this by planting feet firmly in a com-
fortable apart position.
SCut while swinging the upper part of your
body from left to right.
SAs you move forward to the next area to cut,
be sure to maintain your balance, and footing.
Cut using the 2
o’clock to 4 o’clock
position of the
blade
2 o’clock
4 o’clock
RECOMMENDED CUTTING POSITION
WARNING: The operator or others
must not try to clear away cut material with the
engine running or the blade turning to avoid
serious injury. Stop engine and blade before
removing materials wrapped around blade or
tube.
MAINTENANCE
WARNING: Always stop unit and dis-
connect spark plug wire before performing
maintenance.
CHECK FOR DAMAGED OR
WORN PARTS
Contact an authorized service dealer for re-
placement of damaged or worn parts.
SBlade Shield -- Discontinue use of brushcut-
ter attachment if shield is damaged.
CHECK FOR LOOSE FASTENERS
AND PARTS
SBlade nut
SFasteners
INSPECT AND CLEAN UNIT
AND DECALS
SAfter each use, inspect complete unit for
loose or damaged parts. Clean the unit and
decals using a damp cloth with a mild deter-
gent.
SWipe off unit with a clean dry cloth.
BLADE MAINTENANCE
WARNING: The blade will continue to
spin after the engine stops or after the throttle
trigger has been released. To avoid serious
injury, make sure the blade has stopped
coasting and disconnect the spark plug before
performing work on the blade.
WARNING: Always replace a blade
that is bent, warped, cracked, broken, or dam-
aged in any other way. Never attempt to
straighten and reuse a damaged blade. Use
only specified replacement blade. Wear pro-
tective gloves when handling or performing
maintenance on the blade to help avoid injury.
SCheck blade for flatness periodically. Lay
the blade on a flat surface to inspect for flat-
ness. Throw away a blade that is not flat.

8
SERVICE AND ADJUSTMENTS
BLADE REPLACEMENT
WARNING: The blade will continue to
spin after the engine stops or after the throttle
trigger has been released. To avoid serious
injury, make sure the blade has stopped
coasting and disconnect the spark plug before
performing work on the blade.
WARNING: Wear protective gloves
when handling or performing maintenance on
the blade to avoid injury. The blade is sharp and
can cut you even when it is not moving.
Locking Lever
GEARBOX
1. To remove the blade, push in locking le-
ver and hold.
2. Rotate blade nut until the locking lever
falls into one of the grooves in the dust
cup.
3. Continue to hold in locking lever. This will
keep the shaft from turning while loosen-
ing the blade nut.
4. Loosen blade nut by turning clockwise as
you are facing the nut.
5. Remove the blade nut, both washers,
and the blade from the blade shaft. Leave
the dustcup on the gearbox.
6. Install new blade and retaining washer
onto the threaded shaft extending from
the gearbox (blade must be between the
dust cup and the retaining washer). Make
sure the raised part of the retaining wash-
er is facing the gearbox, and the raised
area fits into the hole in the center of the
blade.
Shield
Blade
Retaining
Washer
Dust Cup
Cupped
Washer
Nut
Threaded Shaft
Gearbox
7. Place the cupped washer onto the shaft.
Make sure the cupped side of the washer
is toward the blade.
8. Install blade nut by threading onto the
shaft counterclockwise as you are facing
the nut.
NOTE: Make sure all parts are in place as illus-
trated, and the blade is sandwiched between the
dust cup and the retaining washer. There should
be no space between the blade and the dust cup
or the retaining washer.
9. Push in locking lever and hold.
10. Rotate blade nut until the locking lever
falls into one of the grooves in the dust
cup.
11. Continue to hold in locking lever. This will
keep the shaft from turning while tightening
the blade nut.
12. Tighten blade nut firmly with a wrench.
13. Release locking lever.
14. Turn blade by hand. If the blade binds
against the shield, or appears to be un-
even, the blade is not centered, and you
must reinstall.
STORAGE
WARNING: Perform the following
steps after each use:
SAllow attachment and gearbox to cool be-
fore storing or transporting.
SStore attachment with blade shield in place.
Position attachment so that any sharp ob-
ject cannot accidentally cause injury.
SStore the attachment in a dry, well ventilated
area out of the reach of children.
SEASONAL STORAGE
Prepare attachment for storage at end of sea-
son or if it will not be used for 30 days or more.
If your brushcutter attachment is to be stored
for a period of time:
SClean the entire attachment.
SInspect the blade shield area and clean any
dirt, grass, leaves, or debris that has col-
lected. Inspect the blade and blade shield;
replace a blade that is bent, warped,
cracked, broken or damaged in any other
way.
SLightly oil external metal surfaces.
SApply a coating of oil to the entire surface of
the blade; wrap it in heavy paper or cloth.
SCheck entire attachment for loose screws
or nuts. Replace any damaged, worn or
broken parts.
SAt the beginning of the next season, use
only fresh fuel having the proper gasoline to
oil ratio.

9
LIMITED WARRANTY
ELECTROLUX HOME PRODUCTS NORTH
AMERICA, Division of WCI Outdoor Prod-
ucts, Inc., warrants to the original purchaser
that each new Poulan PRO!
!!
!brand gasoline
tool or attachment is free from defects in mate-
rial and workmanship and agrees to repair or
replace under this warranty any defective
gasoline product or attachment as follows
from the original date of purchase.
2 YEARS-- Parts and Labor, when used for
household purposes.
90 DAYS -- Parts and Labor, when used for
commercial, professional, or income produc-
ing purposes.
30 DAYS -- Parts and Labor, if used for rental
purposes.
This warranty is not transferable and does not
cover damage or liability caused by improper
handling, improper maintenance, or the use of
accessories and/or attachments not specifi-
cally recommended by ELECTROLUX
HOME PRODUCTS NORTH AMERICA for
this tool. Additionally, this warranty does not
cover tune-ups, spark plugs, filters, cutting
line, or rotating head parts that will wear and
require replacement with reasonable use dur-
ing the warranty period. This warranty does
not cover predelivery setup or normal adjust-
ments explained in the instruction manual.
THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS, AND YOU MAY HAVE
OTHER RIGHTS WHICH VARY FROM
STATE TO STATE.
NO CLAIMS FOR CONSEQUENTIAL OR
OTHER DAMAGES WILL BE ALLOWED,
AND THERE ARE NO OTHER EXPRESS
WARRANTIES EXCEPT THOSE EX-
PRESSLY STIPULATED HEREIN.
SOME STATES DO NOT ALLOW LIMITA-
TIONS ON HOW LONG AN IMPLIED WAR-
RANTY LASTS OR THE EXCLUSION OR
LIMITATIONS OF INCIDENTAL OR CONSE-
QUENTIAL DAMAGES, SO THE ABOVE
LIMITATIONS OR EXCLUSION MAY NOT
APPLY TO YOU.
ELECTROLUX HOME PRODUCTS NORTH
AMERICA’S policy is to continuously improve
its products. Therefore, ELECTROLUX
HOME PRODUCTS NORTH AMERICA re-
serves the right to change, modify, or discon-
tinue models, designs, specifications, and ac-
cessories of all products at any time without
notice or obligation to any purchaser.
