PourXuan PX-HD10KM-SDI User manual

深圳市倾玄科技有限公司 官方网址：http://www.pourxuan.com 联系电话：[phone]
PX-HD10KM-SDI USER MANUAL
HD-SDI Fiber Extender
1. Introduction
The HD-SDI transmitter and receiver is economy transfer device for one way HD-SDI
video by single mode optical fiber cable transfer. HD-SDI transmitter and receiver is
designed by digital optical transfer technology, transfer long distance one way
HD-SDI video signal, one way reverse 485 control signal on one single mode optical
fiber. Support SMPTE292M.SMPTE259M.SMPTE424 signal. The device comprise of
transmitter and receiver: transmitter convert SDI signal to optical signal; receiver
convert optical signal to SDI signal and output.
2. Feature
HD-SDI video and audio transmission
Adapt to SDI 270Mbps, 1.485Gbit Speed automatically
Automatic adapt to SDI 270Mbps, 1.485Gbit
Support 1 ways reverse RS485 data control.
built in equilizer, reclocker, cable driver
3. Specification
Parameter
Description
Video
connector
BNC
The interface
1.4835Gbps、1.485Gbps、2.967Gbps、

深圳市倾玄科技有限公司 官方网址：http://www.pourxuan.com 联系电话：[phone]
bandwidth
2.97Gbps
impedance
75Ω
Resolution
1920*1080@30Hz; 1920*1080@25Hz;
1920*1080@24Hz; 1280*720@60Hz;
1280*720P@50Hz; 525i; 625i
RS485
connector
Industrial terminals
Baud rate
Self-adaptive, Max：115200bps
Optical
fiber
connector
LC
type
Single-mode
Wavelength
Single-mode 1310nm
bandwidth
2.97Gbps
Transmission distance
Single-mode：10km
Other
Power
Power adapter：DC 5-12V
Power dissipation
MAX 2.5W
Temperature
-5℃ ~ +70℃
Humidity
5% ~ 90%
Size
118mmX90mmX25mm
Warranty
1 year
4. Interface
Transmitter
Receiver

深圳市倾玄科技有限公司 官方网址：http://www.pourxuan.com 联系电话：[phone]
Port description
Connect Name
Function
INPUT/OUTPUT
SDI signal input/output
+ / - / G
485 signal interface
OPT IN/OUT
Fiber Interface
DC/5-12V
The power adapter input
Light
Function
D
RS485 The communications light
R
system operating
S
Video signal lamp
P
The indicator system
5. Package list：
HD-SDI optical fiber transmitter 1pcs
HD -SDI optical fiber receiver 1pcs
The power adapter 2pcs
User manual 1pc
6. Installation
1、 SDI signal source connect to SDI transmitter，
2、 SDI receiver connect to display equipment，
3、 use optical cable connect transmitter and receiver
4、 power on the transmitter and receiver, when the light is normal lights up,
normal operation of system。

深圳市倾玄科技有限公司 官方网址：http://www.pourxuan.com 联系电话：[phone]
7. Diagram
