PX-HDKVM60 USER MANUAL
60M HDMI KVM Extender
1. Description
The extender provides extension of HDMI signals long distances over a single CAT6 cable , it supports high
resolution up to 1920*1200P and keyboard/mouse signal transmission. The extender can use for a wide
range of applications requiring long distance transmission of high resolution with high quality by its good
stability and powerful security.
2. Features
Transmits HDMI video and audio signals up to 60m over a single CAT6 cable;
Support video resolution up to 1920*1200@60Hz, 3D signal;
Support keyboard and mouse signal transmission;
Support copy EDID function, can match many kind display device;
Support POC single power supply；
Compliance with HDMI 1.3 and HDCP 1.2 standard;
High compatibility, can auto-match source and display device;
Built-in automatic adjustment system, make the image smooth, clear and stable;
Built-in ESD protection system;
Simple to install, plug and play;
3. Specifications
Parameter
Description
Video
Standards
HDMI 1.3; HDCP 1.2
Maximum pixel clock
165MHz
Maximum data rate
6.75Gbps
Maximum resolution
1920*1200@60Hz

深圳市倾玄科技有限公司 官方网址：http://www.pourxuan.com 联系电话：[phone]
Connector
HDMI-A
Impedance
100Ω
USB
Interface
To PC: standard USB-B
To K/M: standard USB
UTP
Interface
RJ45
Transmission distance
CAT6-60m
Other
Power supply
The power adapter: DC 5-15V
Power dissipation
MAX 3W
Temperature
Operating: -5℃~ +70℃
Humidity
Operating: 5% ~ 90%
Dimension
94.5*71*26mm
The warranty
1 year free warranty
4. Panel
Transmitter:
Receiver:

深圳市倾玄科技有限公司 官方网址：http://www.pourxuan.com 联系电话：[phone]
Port name
Description
INPUT/OUTPUT
HDMI signal input/output
Cat5e/6
RJ45 port connect cat5e/6.
PC IN
USB-B cable connect to PC
K/M
connect to keyboard and mouse
DC5-15V
Power adapter socket
EDID
EDID button, press 3 second to copy EDID form displayer
that connect TX INPUT port.
LED indicator
Description
POWER
System power indicator
STATUS
Video signal indicator.
Copy EDID indicator
5.Package list
HDMI transmitter ………………………. 1 pcs
HDMI receiver ……………………………. 1 pcs
USB-B cable……………………………. 1 pcs
Power adapter …………………………….1pcs
User manual ………………………………. 1 pcs
6.Installation
1. The HDMI signal source (such as set-top boxes, Blu ray DVD, computers, etc.) access to
the HDMI transmitter transmitter;
2. Connect the receiver of the HDMI extender to the display device (such as a high
definition TV, a tiled screen, etc.);
3. Use the network cable (recommended 6 types of cable) to connect the sender and
receiver network interface;
4. The computer USB and sending the USB link, connect the USB keyboard mouse device at
the receiving end.
5. Will be the transmitter or the receiver connected to a power source, when the lamp
lights up normally, normal operation of system.
6. EDID key uses, such as after connecting the transmitter POWER, indicating STATUS long
bright, the receiving end of the POWER, indicating STATUS long bright, display no
image or color, the transmitter electricity HDMI and transmitter monitor HDMI port

深圳市倾玄科技有限公司 官方网址：http://www.pourxuan.com 联系电话：[phone]
connection, press the EDID button until the STATUS lights flashing, flashing stop after
the restart repeat steps 1-5 to power.
7.Diagram
