Powdeom EV1200 User manual

Thanks for purchasing
To ensure a better operating experience for your mobile phone or electronic product,
please refer to the manual of your mobile phone or electronic product while reading this manual.
The first charge is Vital to the battery performance of the EV1200.Please connect the EV1200 to
the power socket and charge until it is fully charged for the first charging.
Please read the manual caarefully before using the product
Please keep the manual properly for future reference
Please fully understand the contents of the manual to use the product correctly
MANUAL
EV1200

1
1、 Cautions
To protect you and others from harm and the product from damage,
please read the manual carefully before using the product
1.About storage
Do not expose the product to an extreme cold or hot environment
(below -0°C or above 40°C) for storage;
Do not place the product near the vent of a heating device;
Please avoid putting the product in a rainy or wet environment;
Please keep it away from flammable liquids, gases or explosive materials;
Please keep it away from dust or a dusty environment;
Do not store the product with coins, jewelry, keys and other metal objects;
otherwise, it will damage the product, reduce the charging capacity,
shorten the service life, or even explode. The product should be stored in a
cool and dry environment.
2.About Charger
Do not use a defective charger or a charger of mismatched output voltage;
Please use the original charger, as incompatible or unqualified chargers
may cause danger or damage the product;
Do not use chargers without safety certification to charge the product.
3.About storage of leaving unused
Please make sure to charge it at least once every 6 months to extend the life
of the product (battery cells). When taking out the product after long-term
storage, please fully charge it before use. When the product charger is not
in use, the power must be disconnected at both ends.
4.About disposal of defective\old battery and charger
Please dispose of scrapped products in accordance with regulations, and
do not dispose the built-in batteries as domestic garbage to avoid explosion
and pollution.
5.Do not squeeze or pierce the product, and do not subject the
product to high external pressure, otherwise it may cause internal
short-circuit, overheating, burning or explosion.
6.Do not place this product in the reach of people with low
physiology, perception, and mentality (including children)and
people without experience and related knowledge. Avoid the
above people from using this product to avoid misuse.

7.The product cannot be used as a substitute for the mains AC
power supply in order to extend the cycle life of the battery cells.
8.Do not paint or put up stickers on this product. Paint and stickers
may block the equipment parts and affect normal use.
9.About the environment temperature for charging.
Do not store the product in hot or cold places, please use the
product in an environment of 0~60°C;
The temperature inside a closed car in summer can be as high as
80°C(putting the product in a car may put you or your car in danger.)
Do not directly expose the product to sunlight for a long time, since
when the heat dissipation is not started, the temperature of the
battery cells will rise sharply. When charging the product, the
operating temperature should be between 0°C~40°C.
Do not store the product near or inside water heaters, microwave
ovens, hot cooking products, or high and low pressure parts, which
may may cause overheating or cause fire.
10.About product cleaning
Use a dry towel or eraser to wipe the product or charger.
Do not use corrosive chemicals or cleaner.
11.Please do not disassemble, repair or modify the product,
otherwise warranty will be invalid.
2

2、 Operation Cautions
1. Due to low power status during transportation, the residual power
showing on digital screen may be different from actual power. It will
get normal after charging and discharging for 2-3 times.
2. When using this product, please do not cover it with towels,
clothing, etc., and make sure to keep more than 10cm of heat
dissipation space around the product.
3. Please keep the product and electrical products dry to prevent
moisture and liquid from entering the product, otherwise it may
damage the internal parts or circuits of the device.
Do not turn on the product when it is wet, if the product is already
turned on, please turn it off immediately.(If the product cannot be
turned off, please contact the after-sales service center immediately.)
4. Do not use the product in a very dusty environment , otherwise it
may cause product failure, fire or explosion.
5. Do not use the product in flammable and explosive environments
such as gasoline, gas, chemical agents, mines, etc., otherwise it may
endanger safety Always operate in accordance with regulations,
instructions and signs in potentially explosive environments.
6. Do not use the product in a corrosive environment, otherwise it will
cause damage to the product.
7. Do not use the product during thunderstorms. The product may
malfunction and increase the risk of lightning strikes.
8. Please place the product on a flat surface to prevent the product
from falling, otherwise it may damage the product or cause parts
failure.
9. About recharging the product
Please use original charger to charge the product.
Do not exceed the charging time of this product. Please unplug the
charger when fully charged. It is recommended to charge during the
day or when someone is present for easy inspection.
Due to energy conversion during charging, this product may heat up.
This is a normal phenomenon. Please be careful when handling.
10.About the discharge of the product
When the power is 1 bar left or the indicator is flashing, to prolong the
life of the battery, please immediately stop using and fully recharge
EV1200 before using it again.
3

4
NO Packaging List Type
EV1200 Standard
Standard
1
2Adapter
Standard
3
4
Car charge connetor to DC cable
Standard
Manual
The contents will be different according to the needs of different
regions. Please contact with Yoobao service center if you have any
question.
3、 Package contents
EV1200 is a multi-functional emergency energy storage power
supply. It adopts UL authorized automobile power cell and efficient
SPWM inverter conversion technology. It is more durable and has
longer cycle life than ordinary battery cell. It enjoys the reputation
of "outdoor mobile power station". It is widely used in outdoor party
and camping, household emergency, outdoor live broadcasting,
mobile office, medical rescue, emergency rescue, power equipment
repair, communication emergency and other fields. It is compatible
with most of digital appliances and household appliance of power
rate under 700W.
4、 Product Introduction

5
5、 Specification
6、 Structure and functions
Power Button
DC Input
DC Output DC2
Flashlight
USB Output A1
Car Charger Socket
USB Output A2
LED Screen Display AC Power
Buttom
DC Power
Buttom
DC Output DC1
AC Output Socket
AC Output Socket
Type-C Output C
LED Button
Specification
Model
AC Output*2
Battery Capacity
AC Input
Type-C Output
DC5521 Input
USB-A1 Output
USB-A2 Output
DC5521+Car Charger
Socket
Charging Temperature
EV1200
AC 1200W 100-120V，50/60Hz （Pure Sine Wave）
25.6V/48AH（Lithium Iron Phosphate）
1000W（ 100-120V，50/60Hz）
DC 5V⎓3A/9V⎓3A/12V⎓3A/15V⎓3A/20V⎓5A (PD 100W)
12V-28V⎓5A（Max 120W）
DC 5V⎓2.4A
DC 5V⎓2.4A
DC 12V⎓10A
0℃-50℃
USB A1+A2 Output
Power of Light
XT60 solar input
Dimension
Weight
Discharging Temperature
DC 5V⎓3A （Max）
2W
12V-60V（400W Max）
308x208x300mm (About)
16 Kg (About)
-5℃-65℃
Battery Power 1228.8Wh

6
Battery Symbol
Remaining Power
Percentage
Remaining Using/
Recharging Time
Power rate of
flashlight
Real-time DC Output
Power Rate(W)
Real-time USB Output
Power Rate(W)
Real-time AC Output
Power Rate(W)
EV1200 Screen
22 0
HOURS
OUTPUT
AC DC USB-A USB-C
60Hz
W
AC Input XT60 solar input Heat Dissipation Vent

7
7、 How to charge the product
Please read the following notes first:
Accessories are only equipped. When using solor panel to charge, it
is advised to use 100W or 400W to achieve higher charging efficiency.
with this product. It is forbidden to use on other electrical
appliances.The product is fully charged when the power indicator
stop flashing and stay on. Please stop charging and unplug the
power cord from the AC socket.
We can charge the product in the following three ways:
1. AC charging
The product adopts quick charging technology for AC charging,
and the maximum input power can reach 1000W.
2. Charging with solar panel. Connect one end of the cable to the
solar panel (solar panel needs to be purchased separately), and
insert the other end into the DC input "DC5521 IN" interface of the
product to charge the product (It is recommended to buy solar
panels specially designed for this product).

8
Please read following cautions before use:
Please ensure that the input voltage and frequency of electrical
equipment are consistent with the parameters of this product.
Please ensure that the rated power of electrical equipment is less
than 1200W, preferably within 80% power range.
If the rated power of electrical equipment is higher than 1200W, the
overload protection may be activated.
If the power of electrical equipment is higher than the rated power
of 1200W, please choose portable power supply with higher power.
The AC output will be off automatically when there is no load more
than 12 hours.
The instantaneous power of some electrical equipment is greater
than its rated power. For example, the starting power of inductive
load equipment is generally 3-8 times of a certain rated power, and
the starting power of energy-saving lamp is dozens of times of its
rated power. The above situation does not rule out the possibility of
activating the overload protection of this product and turning off the
power supply.
Steps of using the AC output
Step 1: Turn it on with the AC button and the indictor will be on. Remaining
power can be seen on LED screen.
8、 How to use the AC output
3. Charge with a cable with car charger plug connect the car charger plug to
the cigarette lighter and the other end to DC input “DC5521 IN” interface
of the power station.
AC Power Button
AC 1200W

9
Step 5: Turn it off with the AC button and pull out the appliance plug when
stop using.
Step 6: Please recharge it if it is of low battery or out of battery.
Note:
To avoid power loss, please turn it off with the AC button when you
are not using AC port.
Since different countries have different plug type and voltage
standards, to avoid danger, please carefully check if the appliance
is compatible with the
9、 How to use the DC output
When using DC output(include USB-A output, DC output, Type-C PD 100W
output), please ensure that the digital device support the current of the
corresponding output port, so as to prevent the interface from overheating
and causing damage to the device.
1. Use USB ports to charge digital devices
2 ways to use USB output:
USB-A QC3.0: the orange USB-A can provide QC3.0 quick charge, it will need
a cable supporting QC3.0 protocol to connect power station
and the digital devices. Long press the DC button and the
power station will charge the digital devices quickly.
AC Output Socket
Step 2: Check whether the input voltage and frequency is compatible with
the product.
Step 3: Make sure the rated power of appliances is under 700W.
Step 4: Connect the appliance to the AC output.

10
Flashlight
The product has a built-in flashlight.
1. Strong LED reading light, short-press the switch to turn it on and switch
the modes of luminance: strong→soft→SOS
Please don't use the flashlight directly point to eyes to avoid the damage
from strong light.
10、Steps to use flashlight
USB-C: USB-C output interface, also known as Type-C, can provide PD fast
charging and the output power is 100W. It will need a cable
supporting PD protocol to connect power station and the digital
devices. Long press the DC button and the power station will charge
the digital devices quickly.
2. Use DC output to power appliances
Long press DC button, the DC indicator light will be on and two DC ports
start to provide power at voltage 12V and total current 6A. Connect to the
DC output to power appliances. Long press the DC button again, the DC
indicator will be off and the power will be cut. This DC output can provide
power to DC fan and LED lights etc.
When you are not using DC output, please turn it off with the DC button,
otherwise the remaining power will be consumed by itself.
LED

11
11、 After-sales services
To ensure your legal right, please pay attention to:
1. The warranty card must be sealed by the seller before it can take effect.
2. The warranty card shall be properly kept by the user. If it is lost or altered,
it will be invalid.
3. In case of any failure caused by non-human reasons, you can take the
warranty card to the designated repair center for free repair within the
warranty period.
4. Free maintenance service will be unavailable under the following
circumstances even within the warranty period:
You will no longer enjoy the warranty if you disassemble, refit or repair the
product without permission;
Damage of surface coating and appearance is not within the scope of
warranty;
Failure caused by incorrect installation, packaging and use which is not in
accordance with the requirements of the user manual;
Failure or damage caused by accidental, man-made reasons or environ
ment and other factors (wrong operation, collision, unreasonable voltage,
damp, etc.);
Failure or damage caused by force majeure like earthquake,
fire disaster, tsunami Product packaging box and accessories are not
within the scope of warrantyIf your product has expired the warranty
period, we offer compensated repair service.

Toxic and hazardous substances or elements
Polybrominated
Diphenyl Ether
Polybrominated
biphenyls
chromium
cadmium
mercuryLead
0:means that the content of the hazardous substance in all
homogeneous materials of the component is below the limit
requirement specified in the 2002/95/EC (ROHS) standard
0 0 0 0 0 0
12、 Name and content of toxic and hazardous
substances or elements in the product
Warning
AC socket is for output only, no input!
Do not disassemble, soak in water or
leave in fire!
12
