Read these instructions thoroughly before starting installation. For easier assembly, we suggest
you run all wires prior to mounting your Pod speakers.
1. Determine where the Pod will be placed on the tower bar and a what angle the speaker will be mounted.
mark the bar with a felt-tip pen. This will be where the speaker wire comes through the bar and to the
Pod. NOTE: This first step is VERY important. Make sure of the exact location and orientation
you want BEFORE drilling any holes.
2. Drill a 0.25 to 0.5-inch hole for the speaker wire on the mark made on the bar. De-burr the hole to keep
from damaging the wire’s insulation and causing a short. It is a good idea to treat the hole to inhibit
corrosion.
3. Remove the Allen Screws securing the Clamp to the Aluminum Base. (Fig. 1, Fig. 2)
4. Run minimum of 16-gauge speaker wire through the tower bar and leave 8” to 12” of the wire hanging
out of the hole you previously drilled. Run the speaker wire through the hole in the insert.
5. Connect the speaker wire coming out of the bar to the speaker wire coming out of the Pod. Note the polarity
(the black-stripe wire from the Pod is negative – ) See Fig. 3
6. Place the clamp over the bar and screw in the Allen Head bolt at first by hand. Next using the supplied
Allen wrench tighten the bolt. When fully tightened the clamp should slide into the base mounted to the
Pod. (Fig. 1)
7. Hold the Pod and place the Aluminum Base flush with the bar. Be sure to push any excess speaker wire
back into the bar. Make sure the speaker hole from the Aluminum Base of the Pod is aligned with the hole
in the bar—use caution not to pinch the wire. Tighten 2 allen head bolts to secure. (Fig. 1, Fig. 2)
8. Connect the other end of the speaker wire to the amplifier following the instructions supplied with the
amplifier. Be sure to observe proper polarity of the speaker wire when connecting to the amplifier.
9. To adjust the position, loosen the Allen Head bolts on the base and turn the pod to the desired position
then tighten the Allen Head bolts to secure in place.
10. Depending on the position of your clamp installation, use 2 allen head base bolts on opposing sides
to secure the swivel clamp to the POD. Use a 3rd allen head bolt to secure the safety cable. (Fig
4) For the unused base hole use the supplied plug to prevent moisture and water to enter the clamp
assembly. (Fig1, Fig2)
Fig.3
The speaker wire from the Pod
with black is the negative lead Fig.4
7
1/2”
Attach to Pod
Pull tight
