power King PK0915 Instruction Manual

1
POWERKING 1-800-344-3371 [e-mail]
5” 14HP Chipper Shredder
4” 9.5HP Chipper Shredder
MODEL PK0915 (5”) / PK0903 (4”)
OWNER’S MANUAL AND OPERATIONS GUIDE
WARNING: This product can expose you to chemicals including
benzene, carbon monoxide, and lead which is known to the State of
California to cause cancer and birth defects or other reproductive
harm. For more information go to www.P65Warnings.ca.gov.

2
POWERKING 1-800-344-3371 [e-mail]
General Safety Rules
Read this Safety & Operating Instructions manual before using your PowerKing Chipper
Shredder. Become familiar with the operation and service recommendations to ensure
the best performance from your machine. If you have any questions or need assistance,
don’t hesitate to give us a call at 1-800-344-3371 or send us an E-mail at
[e-mail].
Safety Instructions
The machine must not be used in any other way than described in the manual.
Use only original equipment and spare parts. If you use non-approved spare parts, there
is an increased risk and this is, therefore, not permissible. All liability is renounced in the
event of an accident or other damage caused by the use of non-approved parts.
Before using the machine for the first time, read and follow this manual
Check Emergency Stop Switch before each operation.
Make sure all bolts and nuts are properly tightened before operation.
Choose a flat work place. Machine can only be used outdoors, away from flammable
materials.
User must wear close fitting work clothes, work gloves, eye protectors, ear plugs, dust
proof mask and work boots.
Before and after using the machine, proper maintenance is necessary.
Failure to comply with these safety instructions could result in personal injury and/or
damage to product or property.

3
POWERKING 1-800-344-3371 [e-mail]
Protecting Yourself and Those Around You
This is a high-powered machine, with moving parts operating with a high amount of
energy. You must operate the machine safely. Unsafe operation can create a number of
hazards for you as well as anyone else in the vicinity. Always take the following
precautions when using this machine:
•Keep in mind that the operator is responsible for accidents or hazards occurring
to other people, their property, and themselves
•Always wear protective goggle / safety glasses with side shields while using the
chipper to protect your eyes from debris
•Avoid wearing loose clothing or jewelry, which can catch on moving parts
•We recommend wearing gloves. Be sure your gloves fit properly and do not have
loose cuffs or drawstrings
•Wear steel toed boots with non-slip treads. Do not use machine while barefoot or
with open toed sandals
•Wear long pants / jeans
•Keep bystanders at least 50 feet away from your work area at all times. Stop the
engine when another person or pet approaches.
Safety for Children and Pets
Tragic accidents can occur if the operator is not alert to the presence of children and
pets. Children are often attracted to the machine and the operation of the unit. Never
assume that children will remain where you last saw them. Always follow these
precautions.
•Keep children and pets at least 50 feet from the working area and ensure they
are under the watchful care of a responsible adult.
•Be alert and turn the machine off if children or pets enter the work area.
•Never allow children to operate the chipper.

4
POWERKING 1-800-344-3371 [e-mail]
Safety with Gas Powered Engines
Gasoline is a highly flammable liquid. Gasoline also gives off flammable vapor that can
be easily ignited and cause a fire or explosion. Never overlook the hazards of gasoline.
Always follow these precautions:
•Never run the engine in an enclosed area or without proper ventilation as the
exhaust from the engine contains carbon monoxide, which is an odorless,
tasteless, and a deadly poisonous gas.
•Store all fuel and oil in containers specifically designed and approved for this
purpose and keep away from heat and open flame, and out of reach of children.
•Fill the gasoline tank outdoors with the engine off and allow the engine to cool
completely. Don’t handle gasoline if you or anyone nearby is smoking, or if you’re
near anything that could cause it to ignite or explode. Reinstall the fuel tank cap
and fuel container cap securely.
•If you spill gasoline, do not attempt to start the engine. Move the machine away
from the area of the spill and avoid creating any source of ignition until the gas
vapors have dissipated. Wipe up any spilled fuel to prevent a fire hazard and
properly dispose of the waste.
•Allow the engine to cool completely before storing in any enclosure. Never store
a machine that has gas in the tank, or a fuel container, near an open flame or
spark such as a water heater, space heater, clothes dryer, or furnace.
•Never make adjustments or repairs with the engine running. Shut down the
engine, disconnect the spark plug wire, keeping it away from the spark plug to
prevent accidental starting, wait 5 minutes before making adjustments or repairs.
•Never tamper with the engine’s governor setting. The governor controls the
maximum safe operation speed and protects the engine. Over revving the engine
is dangerous and will cause damage to the engine and to the other moving parts
of the machine. The engine’s governor setting has been preset by the factory.
•Keep combustible substances away from the engine when it is hot.
•Never cover the machine while the muffler is still hot.
•Do not operate the engine with the air cleaner or the carburetor air intake cover
removed. Removal of such parts could create a fire hazard. Do not use flammable
solutions to clean the air filter.

5
POWERKING 1-800-344-3371 [e-mail]
•The muffler and engine become very hot and can cause severe burns. DO NOT
TOUCH!
A Note to all Users
No list of warnings and cautions can be all-inclusive. If situations occur that are not
covered by this manual, the operator must apply common sense and operate the
chipper in a safe manner.
Mechanical Specifications
Model
PK0915 (5”)
PK0903 (4”)
Engine
14HP CH440
Kohler engine
9.5HP CH395 Kohler
Engine
Chipping
Fineness
Granulated
Detrital
Granulated Detrital
Function
Chipping leaves,
branches, crop
stray, farming
feed, etc.
Chipping leaves,
branches, crop stray,
farming feed, etc.
Max Blade
Speed
2530r/min
2530r/min
Fuel Type
87 Octane
Unleaded Gas
87 Octane Unleaded
Gas
Chipper
Weight
397lbs
387lbs
Shipping
Weight
451lbs
441lbs
Shipping
Dimensions
45”x26”x44”
45”x26”x44”

6
POWERKING 1-800-344-3371 [e-mail]
Chipper Operation
All branches should not exceed 5in (PK0915)/ 4in (PK0903) diameter. Fresh cut branches
and straw are recommended for best performance. Due to different hardness and
moisture content, the engine may struggle but will continue to chip. Proper insertion of
branches is large diameter to smaller diameter. It is best to put branches with leaves all
together. Small logs are not recommended.
Procedure
1. Make sure chipper is on flat dry surface.
2. Adjust exit chute to location for processed material.
3. Refer to Kohler manual on how to start the engine.
4. Adjust throttle to maximum RPM.
5. Do not stand directly behind entry chute. Stand to the side of entry chute as
material may kick back.
6. Load material from large diameter side.
7. When machine starts to auto-feed, let go of branch.
8. Let it completely process material before adding more.
9. If machine does not auto-feed, you may need to slowly load the branches or use
other branches to guide it in.
Maintenance
Regular maintenance is the way to ensure the best performance and long life of your
machine. Please refer to this manual for proper maintenance procedures.

7
POWERKING 1-800-344-3371 [e-mail]
Before performing any maintenance procedure or inspection, stop the motor, unplug
the power cord and wait 5 minutes to allow all parts to cool. Disconnect the spark plug
wire to prevent accidental startup.
Important Setup Notes
Our unit does NOT have a GEAR REDUCTION SYSTEM as noted in the Kohler manual.
This engine does not need OIL for a GEAR REDUCTION SYSTEM.
Unit does NOT come with oil. There may be left over residue from factory testing but is
not enough to run the engine.
We recommend 10W-30 Motor Oil and the engine holds 1.2quarts.
Both Yellow Oil Fill Holes go to the same reservoir. Use which ever is easiest to reach.
Make sure all bolts are snug before running.
Maintenance Checklist
PR O C E DU RE
Before each use
Every 5 hours
Every 25 hours
Every 100 hours
C h e ck engine oil level
Δ
Check general equipment
Δ
Grease bearings
Δ
Check belts
Δ
Clean engine exterior
and cooling
Δ
Change engine oil
First time 5hours
Δ
Replace air filter
Δ
Replace spark plug
Δ
Engine Service
Refer to the engine manufacturer’s user manual for engine maintenance.
Lubrication
We recommend 1 pump of lithium grease in each flange bearing before each use.
Blades
Check blades for any cracks, dullness or chips. If there are any cracks, do not use until
they have been replaced. If the blade shows dullness or chips, these blades can be
reversed.

8
POWERKING 1-800-344-3371 [e-mail]
The blades can be removed by using the included T-bar wrench or a 17mm Socket with
extension and ratchet driver. Make sure to use 2x4 or any soft material in the drum to
prevent it from moving. If the drum moves, you may strip the bolts. Also, use rags or
paper towel in the entry to prevent bolts or blades from falling into the drum.
Bar Blade
The bar blade is located at the bottom of the drum housing towards the entry chute. It
creates a gap for the chipping blades and creates a scissor action. If you have poor
chipping performance, we recommend adjusting this by loosening the bolts underneath,
adjusting the bar blade to about 1-5mm to the chipping blades, make sure it is parallel
to the chipping blades and retighten.
Jams
Stop the machine, remove both entry chute and exit chute. Remove the cap on the
bearing and turn the shaft using the included wrench. You can also use a larger
adjustable wrench if more force is needed. Try rotating in both directions to loosen
jammed material.
Note: Wing nuts are provided in addition to hex nuts for entry and exit chute. Wing
nuts can be used for easy access to drum housing. Wing nuts should be checked
frequently for looseness.

9
POWERKING 1-800-344-3371 [e-mail]
Troubleshooting
SYMPTOM
POSSIBLE CAUSE
The engine won’t start.
(Please refer to the
engine user manual
for engine-specific
procedures.)
Is the ignition switch in the “ON” position?
Is the fuel shut-off valve on?
Are you using fresh, clean gas? If the gas is old, change it. Use
a fuel stabilizer if you keep gas longer than 30 days.
Is the spark plug clean? If the spark plug is dirty or cracked, change it. If it’s
oily, leave it out, hold a rag over the plug hole and pull the recoil cord several
times to blow out any oil in the cylinder, then wipe off the plug and reinsert it.
The engine lacks power
or is not running
smoothly.
(Please refer to the
engine user manual
for engine-specific
procedures.)
Check that the Throttle Lever is in the “Run” position.
Is the air filter clean? If it’s dirty, change it following the procedure in the engine
manufacturer’s owner’s manual.
Is the spark plug clean? If it’s fouled or cracked, change it. If it’s oily, leave it
out, hold a rag over the plug hole and pull your recoil cord several times to
blow out any oil in the cylinder, then wipe off the plug and reinsert it.
Are you using fresh, clean unleaded gas? If it’s old, change it. Use a fuel
stabilizer if you keep gas longer than 30 days.
Does your engine have the right amount of clean oil? If it’s dirty, change it
following the procedure in the engine manufacturer’s owner’s manual.
Check the oil level and adjust as needed.
Engine smokes.
(Please refer to the
engine user manual
for engine-specific
procedures.)
Check the oil level and adjust as needed.
Check the air filter and clean or replace if needed.
You may be using the wrong oil—too light for the temperature. Refer to your
Engine Owner’s Manual for detailed information.
Clean the cooling fins if they’re dirty.
Engine stops while chipping
Check if the engine is stopped by overloading.
Check if something is blocked in the chutes.
check the emergency stop button and protection switch.
Drum is jammed
Stop the machine, remove both entry chute, exit chute, cap on bearing, and turn
the shaft to force the material out. You can use the included wrench or use a
larger adjustable wrench for more force.
Poor chipping performance
Check the gap between bar blade and chipping blades. We recommend 1-5mm
of clearance for best performance.

10
POWERKING 1-800-344-3371 [e-mail]
Assembly
Number
1
2
3
4
5
6
7
8
Part
Drum
Housing
Wheel
Axle
Stand
Support
Leg
Tow Bar
Joint
Tow Bar
Locking
Knob
Safety
Pin
Installation Procedure:
1. Lay the Drum Housing (1) on a small platform. Make sure it has space on the
sides for installation of the wheels (2) and support leg (4).
2. Attach wheels (2) to axle stand (3) and use the proper nuts to secure.
3. Attach wheels (2) with axle stand (3) to the drum housing (1) using proper bolts
and nuts.
4. Install the tow bar joint (5) to drum housing (1) using proper bolts and nuts.
5. Attach support leg (4) to tow bar joint (5) using bolt and nut and safety pin (8).
6. Tow bar (6) attaches to tow bar joint (5) and use locking knob (7) to secure.
7. Remove from platform.

11
POWERKING 1-800-344-3371 [e-mail]
Number
9
10
11
12
Part
Entry Chute
Exit Chute
Adjustable
diverter
Set Knob
10. Attach the hinge of the entry chute (9) to the hinge on the drum housing (1). Use
wing nuts or hex nuts to secure.
11. Attach the hinge of the exit chute (10) to the hinge on the drum housing (1). Use
wing nuts or hex nuts to secure.
12. Attach adjustable diverter (11) to top of exit chute (10) and use set knob (12) to
secure.

12
POWERKING 1-800-344-3371 [e-mail]
Parts Diagram

13
POWERKING 1-800-344-3371 [e-mail]
part No.
description
part No.
description
1
engine
38
safety switch
2
left tyre
39
switch box
3
right tyre
40
bolt
4
Lower part of exit
chute
41
feed chute
5
Upper part of exit
chute
42
lock nut
6
exit chute diverter
43
protect sheet
7
knob
44
protect sheet plate
8
washer
45
small pulley
9
bolt
46
belt cover
10
D-pin
47
belt
11
knob
48
big pulley
12
bolt
49
hitch trailer
13
chain
50
key
14
Buckle
51
washer
15
plug
52
bolt
16
D-pin
53
key
17
lock nut
54
pulley sleeve
18
spring washer
55
washer
19
washer
56
belt plate
20
bolt
57
bushing
21
lock nut
58
bearing block plate
22
plate for engine
59
blade
23
lock nut
60
bolt
24
spring washer
61
drum
25
bushing
62
bottom blade
26
bearing with block
63
washer
27
bearing block cap
64
axle
28
crush room
65
bolt
29
bolt
66
bolt
30
Connecting Tube
67
bolt
31
tow bar
68
Shaft ring
32
Wire Harness
69
rubber binding hook
33
bolt
70
tool box
34
support foot
71
hour timer plate
35
rubber
72
hour timer
36
bolt
73
bolt
37
Baffle plate
74
lock nut

14
POWERKING 1-800-344-3371 [e-mail]
WARRANTY POLICY
Thank you for choosing QV TOOLS Products. We're here to ensure that your experience is
perfect. In some rare instances, you may need some help with a warranty claim.
Please call us at 1-800-344-3371.
Product must be registered to activate the warranty. Warranty registration is
below. Warranty begins from date of purchase.
Engine Warranty
Kohler engines are covered with a 3-year commercial and 3-year residential warranty for
Command Pro series. Parts and Labor are covered as well. Power King engines by Lifan
are covered with a 1-year residential warranty. Visit your engine manufacturer for warranty
details or visit www.QVTools.com.
Equipment Warranty
Manufactures defects of chassis and component parts are covered for 1 year. Only parts
are covered. Shipping cost is not covered.
QV Tools will replace any part that is proven to be defective in material or workmanship.
This warranty is not valid for products or parts affected or damaged by accident, collision,
normal wear, fuel contamination, abuse, neglect, misuse, alteration and/or unsuitable use or
unauthorized parts. Transportation charges to and from service centers, if assigned, is not
covered. Shipping cost of product for repair is not covered. Labor to repair equipment is not
covered. Consumable parts such as brake pads, tires, racks, splines, grinding teeth, blades,
bar blades, etc. are not covered under warranty. Power King has all replacement parts at
value pricing.
Damaged Products
You must take the time to inspect the goods before you sign the delivery receipt from the
carrier. If you sign the delivery receipt without inspecting the shipment. you will be
responsible for filing a freight claim and arranging for a repair or return of the damaged
goods.
Concealed damage claims must be reported immediately.
Suspected Damage
On occasion, the outer carton may look damaged, but the product inside the box is perfectly
fine. If you suspect concealed damage, notate "Possible Freight Damage" on the
delivery receipt while the driver is present. This way, if you discover later that the
product is damaged, the remedy of a freight claim is less of a hassle.
Obvious Damage
Do not sign for damaged products. If your product arrives damaged, please (a) REFUSE
DELIVERY and (b) Call where you purchased the item Immediately so the dealer can
process the appropriate claims and coordinate an exchange for you.

15
POWERKING 1-800-344-3371 [e-mail]
Defective Products
We encourage you to test your product within 15 days of receipt so we can quickly remedy
any mechanical problems. If you think your product is defective, call QVTools at 1-800-
344-3371. In most cases, it's a simple issue that can be resolved over the phone. We have
expert technicians standing by to help resolve your issue. Please have your model number
and serial number available and your proof of purchase receipt for faster service.
Original Owner Warranty
Warranty is non-transferable and covers the original owner only who purchased from a
QVTOOLS authorized dealer.
