Power Sentry PS30250 Instruction sheet

See appropriate Power Sentry Installation Instructions for applicable warnings and precautions
Power Sentry Field Install
Wiring Diagram & Instructions - PS30250 Two Boards in Parallel
Field Install Instructions *
1. Disconnect Battery Enable connector (RED wires with mating connectors)
2. Disconnect Driver Line input from Mains
3. Connect Mains Line to Test Switch
4. Connect Un-switched Line to Test Switch (Line input to Power Sentry must be un-switched)
5. Connect Test Switch output (Mains Line) to Driver
6. Connect Test Switch output (Un-switched Line) to Power Sentry (BLACK for 120V, ORANGE for 277V)
7. Cap unused Power Sentry Un-switched Line input wire
8. Connect Mains Neutral to Power Sentry WHITE
9. Connect Power Sentry RED wire to wire nut with Driver LED (+) (in this example RED)
(An additional or larger wire nut may be required)
10. Remove Driver LED (-) wire from wire nut (in this example BLACK)
11. Connect Power Sentry YEL wires to wire nut with LED Board (-)
(An additional or larger wire nut may be required)
12. Connect Power Sentry BLU wires to wire nut with Driver LED (-) (in this example BLACK)
(An additional or larger wire nut may be required)
13. Ensure PURPLE wires are not connected
14. Connect Battery Enable connector (RED wires with mating connectors)
*SEE LAST PAGE FOR MOUNTING OPTIONS AND PLACEMENT

See appropriate Power Sentry Installation Instructions for applicable warnings and precautions
Power Sentry Field Install
Wiring Diagram & Instructions - PS30250 Two Boards in Series, Two Boards in Parallel
Field Install Instructions *
1. Disconnect Battery Enable connector (RED wires with mating connectors)
2. Disconnect Driver Line input from Mains
3. Connect Mains Line to Test Switch
4. Connect Un-switched Line to Test Switch (Line input to Power Sentry must be un-switched)
5. Connect Test Switch output (Mains Line) to Driver
6. Connect Test Switch output (Un-switched Line) to Power Sentry (BLACK for 120V, ORANGE for 277V)
7. Cap unused Power Sentry Un-switched Line input wire
8. Connect Mains Neutral to Power Sentry WHITE
9. Connect Power Sentry RED wire to wire nut with Driver LED (+) (in this example RED)
(An additional or larger wire nut may be required)
10. Remove Driver LED (-) wire from wire nut (in this example BLACK)
11. Connect Power Sentry YEL wires to wire nut with LED Board (-)
(An additional or larger wire nut may be required)
12. Connect Power Sentry BLU wires to wire nut with Driver LED (-) (in this example BLACK)
(An additional or larger wire nut may be required)
13. Ensure PURPLE wires are connected
14. Connect Battery Enable connector (RED wires with mating connectors)
*SEE LAST PAGE FOR MOUNTING OPTIONS AND PLACEMENT

See appropriate Power Sentry Installation Instructions for applicable warnings and precautions
Power Sentry Field Install
Wiring Diagram & Instructions - PS30250 Three Boards in Series, Two Boards in Parallel
Field Install Instructions *
1. Disconnect Battery Enable connector (RED wires with mating connectors)
2. Disconnect Driver Line input from Mains
3. Connect Mains Line to Test Switch
4. Connect Un-switched Line to Test Switch (Line input to Power Sentry must be un-switched)
5. Connect Test Switch output (Mains Line) to Driver
6. Connect Test Switch output (Un-switched Line) to Power Sentry (BLACK for 120V, ORANGE for 277V)
7. Cap unused Power Sentry Un-switched Line input wire
8. Connect Mains Neutral to Power Sentry WHITE
9. Connect Power Sentry RED wire to wire nut with Driver LED (+) (in this example RED)
(An additional or larger wire nut may be required)
10. Remove Driver LED (-) wire from wire nut (in this example BLACK)
11. Connect Power Sentry YEL wires to wire nut with LED Board (-)
(An additional or larger wire nut may be required)
12. Connect Power Sentry BLU wires to wire nut with Driver LED (-) (in this example BLACK)
(An additional or larger wire nut may be required)
13. Ensure PURPLE wires are not connected
14. Connect Battery Enable connector (RED wires with mating connectors)
*SEE LAST PAGE FOR MOUNTING OPTIONS AND PLACEMENT

See appropriate Power Sentry Installation Instructions for applicable warnings and precautions
Power Sentry Field Install
Wiring Diagram & Instructions - PS30250 Four Boards in Parallel
Field Install Instructions *
1. Disconnect Battery Enable connector (RED wires with mating connectors)
2. Disconnect Driver Line input from Mains
3. Connect Mains Line to Test Switch
4. Connect Un-switched Line to Test Switch (Line input to Power Sentry must be un-switched)
5. Connect Test Switch output (Mains Line) to Driver
6. Connect Test Switch output (Un-switched Line) to Power Sentry (BLACK for 120V, ORANGE for 277V)
7. Cap unused Power Sentry Un-switched Line input wire
8. Connect Mains Neutral to Power Sentry WHITE
9. Connect Power Sentry RED wire to wire nut with Driver LED (+) (in this example RED)
(An additional or larger wire nut may be required)
10. Remove Driver LED (-) wire from wire nut (in this example BLACK)
11. Connect Power Sentry YEL wires to wire nut with LED Board (-)
(An additional or larger wire nut may be required)
12. Connect Power Sentry BLU wires to wire nut with Driver LED (-) (in this example BLACK)
(An additional or larger wire nut may be required)
13. Ensure PURPLE wires are not connected
14. Connect Battery Enable connector (RED wires with mating connectors)
*SEE LAST PAGE FOR MOUNTING OPTIONS AND PLACEMENT

See appropriate Power Sentry Installation Instructions for applicable warnings and precautions
Power Sentry Field Install
Wiring Diagram & Instructions - PS30250 Four Boards in Series
Field Install Instructions *
1. Disconnect Battery Enable connector (RED wires with mating connectors)
2. Disconnect Driver Line input from Mains
3. Connect Mains Line to Test Switch
4. Connect Un-switched Line to Test Switch (Line input to Power Sentry must be un-switched)
5. Connect Test Switch output (Mains Line) to Driver
6. Connect Test Switch output (Un-switched Line) to Power Sentry (BLACK for 120V, ORANGE for 277V)
7. Cap unused Power Sentry Un-switched Line input wire
8. Connect Mains Neutral to Power Sentry WHITE
9. Connect Power Sentry RED wire to wire nut with Driver LED (+) (in this example RED)
10. Remove Driver LED (-) wire from wire nut (in this example BLACK)
11. Connect Power Sentry YEL wires to wire nut with LED Board (-)
(An additional or larger wire nut may be required)
12. Connect Power Sentry BLU wires to wire nut with Driver LED (-) (in this example BLACK)
(An additional or larger wire nut may be required)
13. Ensure PURPLE wires are not connected
14. Connect Battery Enable connector (RED wires with mating connectors)
*SEE LAST PAGE FOR MOUNTING OPTIONS AND PLACEMENT

Mounting Distance of Battery Backup from Driver and Mounting Heights of Luminaire
Fixture Family
Minimum distance of battery pack from driver
Alternative Mounting
Max Mounting Height (ft)
IBG
Remote mount only
22
IBH
Remote mount only
32
IBL
Remote mount only
33
Part#: 912-00022-003 Rev B
