Power2max NGeco User manual

User’s Manual
power2max NGeco
deutsch
1 Quick Start Guide
Warning
Please read the user’s manual carefully before installation and use! Improper installation can cause
accidents. In case of doubt, consult a professional bicycle mechanic. Observe the indicated torque
values when installing screws and bolts. (See installation instructions at www.power2max.com.)
Before going on a ride, get to know the functions and operation of your power meter. Get a checkup
from a sports physician before starting your training program. Pay attention to traffic and road
conditions before checking any data.
Quick start guide
Thank you for choosing a power2max NGeco power meter!
Scope of delivery
Included:
power meter power2max NGeco
Quick Start Guide including inspection certificate
Optional:
Lockring tool
power meter crankset
bottom bracket
chainring set
chainring bolts
Installation and operation:
1. Remove the red isolation strip by pulling it out of the battery compartment. (You do not
need to open the battery compartment.)
2. The LED indicator is now flashing green. Please connect the power meter to your head unit
(observe manufacturer’s instructions).
3. Install the chainrings to the power meter (observe manufacturer’s instructions and torque
values!).
4. Install the power meter to the crankset (observe manufacturer’s instructions and torque
values!).
5. Install the crankset to the bicycle (observe manufacturer’s instructions and torque values!).
After installing, check the function of the front derailleur and adjust as necessary.
Finished! Now: go ride and have fun with your power2max NGeco!
deutsch

2 Contents
1 Quick Start Guide...............................................................................................................................
2 Contents...............................................................................................................................
3 Declaration of conformity......................................................................................................................
4 Warranty...................................................................................................................................
4.1 Scope of the warranty............................................................................................................
4.2 Local regulations.......................................................................................................................
4.3 For consumers in Australia.................................................................................................................
4.4 Limitation of liability....................................................................................................................
4.5 Warranty disclaimer.............................................................................................................
5 Introduction............................................................................................................................................
5.1 Warning .................................................................................................................................
6 Scope of delivery....................................................................................................................................
7 Operation and installation...........................................................................................................
7.1 Necessary tools......................................................................................................................
7.2 Operation..............................................................................................................................
7.3 Installation.........................................................................................................................................
8 Using your power meter ..................................................................................................
8.1 Before your ride...............................................................................................................................
8.2 During your ride..........................................................................................................................
8.3 Zero-point adjustment and thermal correction................................................................................
8.4 Battery life ..............................................................................................................
8.5 After your ride................................................................................................................................
8.6 Changing the battery.......................................................................................................................
8.7 Turning the power meter on and off..................................................................................................
8.8 After a crash ...........................................................................................................................
9 Maintenance and care...........................................................................................................................
10 Disposal.......................................................................................................................................
11 Accessories, replacement parts
12 Repair.........................................................................................................................................
13 Service calibration and control of function...................................................................................
14 Troubleshooting....................................................................................................................................
15 Technical specifications..................................................................................................................
16 Copyright ........................................................................................................................................
17 Trademarks..........................................................................................................................................
18 Changes and errors .............................................................................................................
19 Notes............................................................................................................................................

3 Declaration of conformity
Saxonar GmbH hereby declares that the power2max power meters complies with the essential
requirements and further relevant regulations of the 1999/5/EG Directive. You can view the
complete text of the declaration of conformity at www.power2max.com.
RoHS declaration of conformity
Saxonar GmbH certifies that this product and its packaging are in compliance with the directive
2002/95/ EG of the European Union on the Restriction of Hazardous Substances in Electrical and
Electronic Equipment (commonly known as RoHS).
Statement of Compliance for FCC and lndustry Canada
This equipment has been tested and found to comply with the Iimits for a Class B digital device,
pursuant to Part 15C of the FCC Rules and Radio Standards Specification RSS-247, Issue 1. These
Iimits are designed to provide reasonable protection against harmful interference in a residential
Installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
Installation.
Operation is subject to the following two conditions: This device may not cause harmful interference,
and this device must accept any interference received, including interference that may cause
undesired operation. This product meets the applicable lndustry Canada technical specifications. The
term „IC:“ before the radio certification number only signifies that lndustry Canada technical
specifications were met.
WARNING:
Any changes or modifications not expressively approved by Saxonar GmbH could void the user‘s
authority to operate this equipment.
DÉCLARATION DE CONFORMITÉ
Saxonar GmbH déclare par la présente que power2max est conforme aux exigences essentielles et
aux autres dispositions pertinentes de la 1999/5/EC Directive. La déclaration de conformité complète
est disponible à l'adresse https://www.power2max.de
Déclaration de conformité pour FCC et lndustry Canada
Cet équipement a été testé et reconnu conforme aux Iimits pour un appareil numérique de classe B,
conformément à la partie 15C de la norme FCC concernant les normes et les normes radiophoniques
RSS-247, numéro 1. Ces limites sont conçues pour fournir une protection raisonnable contre les
interférences nuisibles dans une installation résidentielle. Cet équipement génère, utilise et peut
émettre de l'énergie radiofréquence et, s'il n'est pas installé et utilisé conformément aux
instructions, peut causer des interférences nuisibles aux communications radio. Cependant, il n'y a
aucune garantie que des interférences ne se produiront pas dans une installation particulière. Son
utilisation est soumise aux deux conditions suivantes: Cet appareil ne doit pas provoquer
d'interférences nuisibles et cet appareil doit accepter toute interférence reçue, y compris les
interférences susceptibles de provoquer un fonctionnement indésirable. Ce produit répond aux
spécifications techniques applicables d'lndustry Canada. Le terme «IC» avant le numéro de
certification radio signifie seulement que les spécifications techniques d'Industrie Canada ont été
respectées.
ATTENTION:
Toute modification ou modification non expressément approuvée par Saxonar GmbH peut annuler la
permission pour utiliser cet équipement.

Déclaration de Conformité RoHS
Saxonar GmbH certifie que ce produit et son emballage sont conformes à la directive européenne
2002/195 / CE sur la Limitation de l'utilisation de Certaines Substances Dangereuses dans les
Équipements Électriques et Électroniques, connue sous le nom de RoHS.
Statement of Compliance for Japan
Japanese Radio Law Compliance.
This device is granted pursuant to the Japanese Radio Law (電波法).
This device should not be modified (otherwise the granted designation number will become invalid).
4 Warranty
4.1 Scope of warranty
Unless it is stated differently in this document, Saxonar GmbH guarantees that the product is free of
manufacturing and material defects. Any claims resulting from this warranty are to be directed to the
Saxonar GmbH. The original proof of purchase must be submitted. Unless it is stated differently in
this document, Saxonar GmbH does not cover any other guarantees and warranties, makes no other
assurances of any kind (expressed or implied) and hereby excludes any liability (including any implied
guarantee for proper use, handling or suitability for a specific purpose).
4.2 Local regulations
This warranty grants you specific rights. Depending on the state (USA), province (Canada) or your
home country, you may also have other rights. To the extent that this warranty is inconsistent with
local regulations, it must be modified to conform with existing legislation. The respective local laws
and regulations may be subject to exclusions or limitations due to this warranty. As an example, for
specific states in the USA as well as other countries outside of the USA (including Canadian
provinces), the following applies:
Exclusions and limitations in this warranty may not limit statutory consumer rights (e.g., United
Kingdom). Any such exclusions and limitations are thus invalid.
4.3 For consumers in Australia
In order to file a warranty claim, please contact the local importer or dealer from whom you
purchased this product. In the case of a valid warranty claim, Saxonar GmbH reserves the right to
choose whether to repair or replace your power2max product.
You are required to cover any costs you incur when filing a warranty claim. The rights you are
granted in this warranty apply in addition to other rights and legal remedies that you may be legally
granted in the context of our products. Warranties apply to our products that can not be excluded by
Australian consumer protection laws. In the case of substantial defects/major failure, you have a
claim to a replacement or a refund of the purchase price as well as a compensation for any further
reasonable foreseeable losses or damages. You also have a right to have products be repaired or
replaced if their quality is flawed and the flaw is not deemed to be a substantial defects/major
failure.

4.4 Limitation of liability
To the degree allowed in accordance with local regulations and with the exception of the expressly
described obligations in this warranty, the Saxonar GmbH and its suppliers exclude any liability for
direct, indirect, special, accidental/coincidental or consequential damages.
4.5 Warranty disclaimer
The warranty does not apply to products that are not installed and/or adjusted professionally or in
accordance with Saxonar GmbH’s appropriate user’s manual. The power2max user’s manuals can be
downloaded on the internet at www.power2max.com.
This warranty does not apply to damages to the product as a result of accidents, crashes or incorrect
use, not observing manufacturer’s specifications or other circumstances in which the product was
subject to loads or forces that the product was not intended for.
This warranty does not apply if the product was modified; this includes but is not limited to any
attempt at opening or repairing any electronic and associated components including motors,
controllers, batteries, wiring, switches and charging units.
Warranty claims are also void if the serial number or manufacturing code has been altered, made
illegible or removed.
Normal wear and tear are excluded from warranty. Normal wear of components can take place as a
result of appropriate use, not adhering to the Saxonar GmbH’s maintenance recommendations and
/or riding in conditions that are not recommended.
The following components are subject to “normal wear”:
Dust seals
Sockets/bushings
Airtight O-rings
Mechanical seals
Moveable rubber parts
Foam rubber rings
Stripped threading/screws (aluminum, titanium, magnesium or steel)
Tools
Batteries
The warranty for the batteries and the power meter does not apply to damages resulting from power
surges, a lack of maintenance or any other inappropriate use.
Damages that are caused by third-party components are excluded from this warranty.
Damages resulting from the use of parts that are not compatible or appropriate or are not authorized
for use by the Saxonar GmbH for power2max power meters are excluded from this warranty.
The warranty shall not cover any damages that are caused by commercial use (rentals).

5 Introduction
Thank you for choosing a power2max NGeco power meter. Your power2max NGeco is a quality
product that has been developed and manufactured with great care by the power2max Team. It
offers you precise and reliable power measurement in all weather conditions while being simple and
intuitive to operate. Please read the user’s manual carefully before using and observe the directions
for correct use of your power2max NGeco power meter.
We wish you plenty of enjoyment and success with your power2max NGeco!
5.1 Warning
Please read the user’s manual before installation and operation! Improper installation can lead to
accidents. In case of doubt, consult a professional bicycle mechanic. Observe the indicated torque
values when installing screws and bolts. Screws and bolts that are too tight or loose can damage your
power meter.
Before going on a ride, get to know the functions and operation of your power meter.
Get a checkup from a sports physician before starting your training program.
Pay attention to traffic and road conditions before checking or controlling any data from your head
unit.
6 Scope of delivery
Your power2max NGeco power meter system is made up of:
A specific power2max NGeco power meter (corresponding crank version and bolt circle diameter)
Quickstart Guide with inspection certificate
Packaging
Optional:
Lockring tool to install the power2max NGeco power meter to the crankset
Crankset, bottom bracket, chainring set, chainring bolts as ordered.
IMPORTANT:
Please check that delivery contents are complete and correct.
7 Operation and installation
IMPORTANT:
It is necessary to observe indicated torque values during installation.
You can also find these values in the download area of power2max.com. Screw and bolt connections
that are torqued too heavily or weakly could damage the power meter and impair the function.
In the case of bicycle frames with a BB86 or BB386EVO bottom bracket standard, the compatibility
between the power meter and frame must be tested before installation.

7.1 Necessary tools
In the case of models with lockrings like FSA BB386evo, a specific lockringtool for installing the
crankset to the power2max NGeco power meter is needed.
Depending on the model: medium-strength threadlock (e.g. Loctite 243).
Optional: bench vice to fixate the lockring tool during installation.
7.2 Operation
Your power2max NGeco power meter has an LED indicator light to control its function. This enables
you to easily test functionality and operate the system in a quick and uncomplicated way.
1. Remove the isolation strap by pulling it out of the battery compartment. Check if the battery cap is
in the correct position.
2. Now, the LED indicator light flashes green for approximately one minute.
3. Connect the power meter to your head unit (observe manufacturer’s instructions). As long as the
green LED indicator light blinks, the power2max NGeco power meter is emitting signals that can be
received by an ANT+ enabled head unit. Pair your power meter-compatible head unit with your
power2max NGeco power meter. Observe the respective manufacturer’s manual. Pairing your head
unit is only necessary when operating the power meter for the first time. Numerous power2max
NGeco power meters on different bicycles should be put into operation one after another to avoid
unwanted connections between different power2max NGeco power meters and head units. You can
repeat the pairing of your ANT+ enabled head unit at any time. To do so, you just have to activate
your power2max NGeco power meter by turning the crankarm. Your power2max NGeco power
meter then signalizes its availability for pairing by blinking its green LED indicator light for one
minute.
You need an ANT+-compatible head unit that supports the power-only profile (PWR). For example,
suitable head units are:
CYCLEOPS: Joule 2.0 and 3.0
GARMIN: Edge 500/510/520/800/810/820/1000, Forerunner 310XT/910XT
O-SYNCE: navi2coach, Macro X and Macro High X
You can find a current list of compatible products at the ANT+ Alliance:
http://www.thisisant.com/directory/power2max-road-rotor-3d-plus-bcd-110-or-130/
The data for power and cadence are calculated and transmitted via ANT+.
7.3 Installation
1. First install the chainrings on the power2max NGeco power meter. In the process, take care
that they are aligned correctly and solidly attached in accordance with the respective
manufacturer’s specifications. Guide the large chainring from above onto the power2max
NGeco power meter.
2. Align the holes for the bolts.
3. After you have guided the small chainring onto the power2max NGeco power meter from the
rear, tighten everything with the dedicated chainring bolts.
IMPORTANT:
Observe the torque values prescribed by the manufacturer.
Pay attention to the alignment of the chainrings and bolts. Please adhere to the
manufacturer’s specifications.
4. Then mount the right crankarm to the power2max NGeco power meter. Guide the right
crankarm from the front through the opening in the power meter. Pay attention to the
alignment and the correct fitting of the crankset to the power meter. For models with
lockrings like FSA BB386EVO: place a few drops of medium-strength threadlock (e.g. Loctite
243) on the inner side of the lockring and tighten it with the help of the lockring tool.
IMPORTANT:
Please pay attention that the lockring is correctly seated on the threads.

Lock the lockring tool into a vice. This guarantees that the lockring tool is secure and stable
for further installation: tighten the lockring to the prescribed torque values. You can also find
these values in the download area on power2max.com or ask the crankset manufacturer.
5. Install the entire power meter unit with crankset to your bicycle. To do so, follow the steps in
the installation instructions provided by the crankset manufacturer. If necessary, these can
be requested from the crankset manufacturer or from a retail store. We recommend
checking the correct function of the front derailleur and, if needed, re-adjusting it.
IMPORTANT:
Observe the installation instructions prescribed by the manufacturer.
6. Initial operation and installation of your power2max NGeco power meter is thus completed.
You can go for a ride!

8 Using your power meter
Using your power2max NGeco power meter is as easy as the initial operation and installation is.
8.1 Before your ride
When your bicycle isn’t being used, the power2max NG power meter is in standby. Once the crank is
moved, the power2max NGeco power meter is activated automatically, and it begins emitting a
signal. This is shown by the blinking of the green LED indicator light.
8.2 During your ride
Your power2max NGeco power meter updates the parameters power and cadence in 1 second
intervals; they are transmitted per ANT+ protocols.
8.3 Zero-point adjustment and thermal correction
To ensure a precise power measurement, the zero-point (the measured value when no torque is
present) is automatically determined by your power2max NGeco power meter. The zero-point
adjustment compensates for influences caused by temperature variations and mechanical zero-point
shifts. It is possible to repeatedly set the zero point at the head unit, but it isn’t necessary! This is
performed by the system automatically when it is not under power. “Not being under power” means
a stop in pedaling for at least two seconds during a ride. If a de-powering as described above is not
possible, for example during a long mountain climb, then your power2max NGeco power meter
automatically compensates for temperature. Thus your power2max NGeco guarantees a reliable
power measurement.
8.4 Battery life
Battery life is approximately 400 hours. Battery life can be decreased by low temperatures and by
transporting your bicycle, for example in your car.
8.5 After your ride
Your power2max NGeco power meter independently enters standby mode approximately two
minutes after ending your ride. This reduces electricity consumption and increases battery life.
8.6 Battery change
To change the battery, remove the battery cap. Pull out the empty battery and insert a new battery.
Pay attention to the correct position of the positive pole and negative pole. Close the battery cap and
check if it is in the correct position.
8.7 Turning the power meter on and off
You can turn off your power2max NGeco power meter yourself by removing the battery. You can
turn your power2max NGeco power meter back on by inserting the battery again.
NOTE: When transporting your bicycle, the power2max NG power meter is activated. Therefore, it is
recommended to turn off the power meter for longer transports. You should generally turn it off
when transporting your bike in a plane.

8.8 After a crash
The power2max NGeco power meter was developed to have a high level of reliability. Usually, crash
forces are generally completely absorbed by the crankarms and the bottom bracket. Crash damage
to a power2max NGeco power meter is thus almost completely ruled out.
In the interest of your own security and health, you should do the following checks:
Could the cranks have sustained any damage? The cranks could suffer from hairline fractures that
you may eventually not recognize. This could, over time, result in sudden failure. Therefore,
replacement is recommended. If anything is rattling around the crankset, this could indicate
potential damage. Examine all mechanical connections.
9 Maintenance and care
The battery cap should be checked occasionally to see whether it is seated correctly and, if
necessary, it should be replaced so that it maintains its waterproof seal.
After longer rides in the rain, please examine if water has penetrated the battery cover. Should this
be the case, allow this area to dry out while having removed the battery and with the battery cap off.
You can assist in this process by using an absorbent cloth.
Do not use thinners or solvents to clean your power2max NGeco power meter. Use clear water or
soapy water and a soft sponge or rag.
IMPORTANT:
Do not clean your power meter with a high-pressure power hose!
deutsch
10 Disposal
The symbol of the crossed-out garbage pail on wheels, which can be found on the product, the
documentation and the packaging, means that electrical and electronic products, batteries and
accumulators need to be discarded separately in the European Union. Do not dispose of these
products in general household garbage. Separate these products from other garbage in order not to
damage people’s health or the environment due to uncontrolled garbage disposal and in order to
promote sustainable recycling of material resources.
11 Accessories, replacement parts
If needed, you can order the following accessories or replacement parts for power2max NGeco
power meter at www.power2max.com:
battery cap
Decorative stickers in various colors (power2max green, white, red, blue, black)
Additional components, such as cranksets, etc. are also available at www.power2max.com. We will
forgo an extensive list here.
12 Repair
To a certain degree, repairing a power2max NGeco power meter is possible. In case of need, please
contact [e-mail].

13 Service calibration and control of function
The power2max NGeco power meter is calibrated at the factory and doesn’t have to be newly
calibrated within the warranty period. Regardless of this fact, you still have the option of ordering a
calibration and function control at www.power2max.com. In this case, we will examine your
power2max NGeco power meter on the outside, perform a new factory calibration and control of
function. In addition to your power2max NGeco power meter, you also receive a new test and
approval certificate.
IMPORTANT:
Ordering a calibration and function control can be advisable after a crash, among other things.
However, it does not extend warranty coverage and only excludes a possible liability resulting from
mechanical damage that has not been identified.
14 Troubleshooting
1. Green LED indicator light doesn't blink after activation
Battery is low –change battery
2. Red LED indicator light blinks after activation
Power meter error –turn off and then on. If this is unsuccessful, then contact
[e-mail].
3. Power meter does not pair with a head unit
Battery is low –change battery
Head unit is not in pairing mode –place head unit in pairing mode
Power meter is in standby –activate power meter by rotating the crank.
Transmission is flawed –avoid sources of disturbance such as WiFi networks, microwaves, mobile
phones and other active power meters.
4. Power meter shows no function
Battery is low –change battery
Operating software is in an undefined state (the power meter has “crashed”) – Turn off and then on
by removing and inserting the battery. If this is unsuccessful, contact [e-mail].
5. Power measurements are not plausible
The zero point has changed uncontrollably –during a ride: do a zero point adjustment by depowering
6. Water intrusion into the battery compartment
battery cap has not been closed correctly –remove battery and let area dry, insert battery again and
close battery cap
battery cap is damaged or worn –remove battery and let area dry, insert battery again and close
battery cap

15 Technical specifications
Weight: depending on the version –details on the website
Power source: battery
Battery life: approximately 400 hours of active power measurement
Transmission standards: ANT+ Power Only Profile
Transmitted data:
Power,
Cadence
Accuracy: ±2%
Additional features:
Active thermal correction
Automatic zero-point adjustment
Calibration is independent of chainring selection
No magnet necessary for cadence measurement
Range of measurement and display:
Power: 10 - 2999 W
Torque: 0 - 250 Nm
Cadence: 30 - 250 RPM
Decorative colors: power2max green, white, red, blue, black
LED signals:
Green blinking: power meter activated, ANT+ active for pairing with head unit
Red blinking short: power meter error
Directly after activation:
3 x green: battery charged 60 - 100%
2 x green: battery charged 40 -60%
1 x green: battery charged 20 -40%
1 x red short: battery charged 10 - 20% (equates to "weak battery")
1 x red long (5 seconds): battery charged 0 - 10%
16 Copyright
Copyright 2016. All rights reserved. No part of this publication can be reproduced, copied,
photographed, translated, passed on, downloaded or saved on any kinds of storage media.
17 Trademarks
power2max is a registered trademark of the power2max GmbH. All other names of products, brands
or business names used in this manual can be trademarks or registered trademarks of the respective
owners.
18 Changes and errors
Errors excepted. Illustrations in this user’s manual are similar and can deviate from the product. The
information contained in this manual is subject to change without notice. The Saxonar GmbH
reserves the right to make changes and improvements in the product without previous notice.
