PowerBase 577144 User manual

30cm 450W Electric
Grass Trimmer 577144
These instructions contain important information that will help you get the best from your product,
ensuring it is assembled correctly and safely. If you need help or have damaged or missing parts, call
the Customer Helpline on 0343 515 1905.
IMPORTANT!
Please read these
instructions fully before
starting assembly.
Instruction
Manual

2
Contents
Safety Information 3
In the box 12
Assembly 14
Operating Instructions & Tips 16
Maintenance 20
Troubleshooting 23
Technical Data 24
Disposal 25
Getting Help 25
Warranty 26

3
Safety Information
Warning symbols
Important - Please read these instructions
fully before starting assembly.
The following warning symbols appear
throughout this instruction manual and
indicate the appropriate safety measures you
should take when assembling and operating
the trimmer.
Read the instruction manual.
Wear ear and eye protection (PPE).
Do not expose to rain.
Disconnect the mains plug if the cord is
damaged or entangled.
Keep bystanders away.
Guaranteed sound power level data
(96dB), in accordance with Directive
2000/14/EC.
Class II equipment.
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your local authority or store
for recycling advice.

4
The product complies with the applicable
European directives and an evaluation
method of conformity for these directives
was done.
The product complies with the applicable
UK directives and an evaluation method
of conformity for these directives was
followed.
Important! When using this equipment,
the following safety precautions must be
followed to avoid injuries and damage.
• This machine can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge, if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved.
• Children shall not play with the trimmer.
Cleaning and user maintenance shall not be
made by children without supervision.
• Read all operating instructions carefully
and comply with them. It is important to
understand these instructions and to
acquaint yourself with the machine, its
correct usage and all safety requirements.
• Keep this manual in a safe place so that the
information is available at all times.

5
Safety warning
WARNING! Be extra careful when using
mains-powered equipment. Basic safety
precautions, including the following, should
always be followed to reduce the risk of fire,
electric shock and personal injury.
• Before use, check the supply and extension
cord for signs of damage or ageing. If
the cord becomes damaged during use,
disconnect the cord from the supply
immediately. DO NOT TOUCH THE CORD
BEFORE DISCONNECTING THE SUPPLY.
Do not use the appliance if the cord is
damaged or worn.
• Read the instructions carefully. Be familiar
with the controls and proper use of the
equipment.
• Keep the extension cord away from the
cutting elements.
•
Wear eye protection, long trousers and
suitable shoes while operating the machine.
• If you give the equipment to any other
person, give them these operating
instructions as well.
•
We accept no liability for damage or accidents
which result from non-compliance with these
instructions.

6
• Never allow children or people unfamiliar with
these instructions to use the trimmer.
• Avoid using the trimmer if bystanders, especially
children or pets, are nearby.
• Use the trimmer only in daylight or good artificial
light.
•
Avoid using the machine in bad weather
conditions, especially when there is a risk of
lightning.
• Never operate the trimmer with damaged guards
or shields, or without guards or shields in place.
• Only switch on the motor when your hands and
feet are a safe distance from the cutting means.
• Never fit metal cutting elements to this trimmer.
•
Use only the manufacturer’s recommended
replacement parts and accessories.
• Always disconnect the machine from the
power supply:
1) whenever the machine is left unattended;
2) before clearing a blockage;
3) before checking, cleaning or working on the
machine;
4) after striking a foreign object;
5) whenever the machine starts vibrating
abnormally.
• Inspect and maintain the trimmer regularly.
Have the trimmer repaired only by an authorised
repairer.

7
• Take care against injury from the line cutter on
the grass guard which controls the cutting line
length. After adjusting or extending new cutter
line, always return the trimmer to its normal
operating position before switching on.
• Always ensure that the ventilation openings
are kept clear of debris.
• When not in use, store the trimmer out of
the reach of children.
• If the supply cord is damaged, it must be
replaced by a qualified service agent to
avoid further risk of electrocution or injury.
• Ensure you are familiar with the controls and
proper use of the equipment.
• Before use, always check the supply and
extension cord for signs of damage or ageing.
• If the cord becomes damaged during use,
disconnect the plug from the mains supply
immediately. Do not touch the cord before
disconnecting the plug from the mains supply.
• Never use the lawn trimmer if the mains
cords are damaged or worn.
•
Warning: Cutting elements continue to rotate
after the motor is switched off.
• Keep extension cords away from cutting
elements at all times.
•
For the safe operation of this machine, it should
always be used together with a residual current
device (RCD) with a tripping current of not more
than 30mA.

8
ATTENTION! Danger! The cutting line
continues to rotate for a few moments after
the motor is switched off.
Work area
• Do not expose the appliance to rain. Do not
use the appliance in damp or wet conditions.
• Only use the appliance in daylight or good
artificial light.
Personal protection
• Wear suitable shoes or boots to protect your
feet. Do not operate the appliance wearing
open-toed sandals or when barefoot.
• Wear long trousers to protect your legs.
Using your trimmer
• Be sure that the trimmer is switched off
before connecting it to the mains supply.
• Stay alert at all times. Take care with what
you are doing. Use common sense.
• Do not operate the appliance when you are
tired.
•
If the appliance begins to vibrate abnormally,
switch it off and remove the plug from the
socket. Allow rotating parts to stop and
inspect the trimmer for damage and loose
parts.
Precautionary measures

9
• Never pull the cord to disconnect the plug
from the socket. Keep the cord away from
heat, oil and sharp edges.
• If the main cable becomes damaged during
use, switch the appliance off and disconnect
the plug from the mains immediately. Do not
touch the mains cable before disconnecting
from the mains.
Safety of others
• Do not allow children or any person unfamiliar with
these instructions to operate the appliance.
• Do not allow children, bystanders or animals
to come near the work area, or to touch the
appliance or mains cable.
• Remember that the operator maybe held
responsible for the accidents or hazards
occurring to other people or their property.
After use
• Switch off, remove the plug from the socket
and ensure that moving parts have stopped
rotating before leaving the appliance
unattended and before changing, cleaning
or inspecting any parts of the appliance.
• When not in use, the appliance should be
stored in a dry place. Children should not
have access to stored appliances.

10
Inspection and repairs
•
Before use, check the trimmer for damaged
or defective parts. Check for misalignment
and seizure of moving parts, broken parts,
damage to guards and switches, or any other
conditions that may affect its operation.
•
Do not use the appliance if any part is damaged
or defective. Do not use the appliance if the
switch does not turn it on and off.
• Never use the appliance when any guard or
housing element is damaged or not in place.
•
Ensure that the appliance will operate properly
and perform its intended function.
•
Have any damaged or defective parts repaired
or replaced by an authorised repair agent.
• Before use, check the mains cable for signs
of damage, ageing or wear.
• Do not use the appliance if the mains cable
is damaged or defective.
•
If the mains cable is damaged or defective
it must be repaired by an authorised
repair
agent to avoid any further hazard.
•
Never attempt to remove or replace any parts
other than those specified in this manual.
General safety during usage
This tool is double insulated; therefore, no earth
wire is required. Always check that the power supply
corresponds to the voltage on the rating plate.

11
• Before using the trimmer, check that your cutting
path is free from sticks, stones, wire and any other
dangerous objects that may cause damage or be
thrown from the device.
• Only use the trimmer in the correct position, with
the cutting line near the ground. Never switch it on
in any other position.
• Switch on the appliance only when hands and feet
are at a safe distance from the cutting line.
• Avoid any body contact with the cutting line while
the trimmer is running.
• Do not work on steep slopes; be sure of your
footing. Be aware that freshly cut grass is damp
and slippery.
• Only use the correct cutting line. Never use metal
cutting line or fishing line.
• After extending new cutting line, always return the
appliance to its normal operating position before
switching on.
• Take care to keep the mains cable away from the
cutting line. Always be aware of the position of the
cable.

12
In the Box
1
2
3
4
5
6
7
8
9
16
17
18
15
12
13
14
10
11

13
Parts
1On/Off switch 10 Cutting line
2Power cable 11 Line release button
3Power cable strain relief 12 Line eyelet
4Auxiliary handle 13 Spool cap
5Lever for tube and cutting
head angle adjustment 14 Line spool
6Screw sleeve for tube length
adjustment 15 Cutter head with line spool
7Telescopic tube 16 Flower guard
8Motor housing 17 Winged nut
9Safety guard 18 Main handle

14
9
Step 1 - Assembling the auxiliary handle
Step 2 - Assembling the safety guard
Assembly
Carefully unpack the trimmer and check that it is complete:
• Pull open the ends of the auxiliary handle to extend it and slide it over
the handle mount (Fig. 1).
• Fasten the auxiliary handle (4) with the rod and winged nut (17) (Fig. 1).
• Fold open the retainer on the plastic guard.
• Place the safety guard (9) in the guide and make sure that the two
marks ‘▲’ on the safety guard and motor head are aligned (Fig. 2).
• Tighten the 3 screws to secure the safety guard.
Fig. 1
Fig. 2
4
17
WARNING! Before assembly, make sure that the trimmer is
switched off and unplugged.

15
Step 3 - Fitting the flower guard
• To position the flower guard (16), insert one end into the channel on
the side of the motor housing (8), making sure it is secured in place.
Apply outward pressure to the other side and insert it into the opposite
channel (Fig. 3).
Fig. 3 Fig. 4
8
16

16
Never use the trimmer without its safety guard. Always wear goggles
when working with the trimmer.
Before each use, check the trimmer for any damage and that it functions
correctly. Check that the mains voltage is the same as indicated on the
rating plate.
• Form a loop in the end of the power cable (2), feed it through the
opening in the main handle and hang it onto the power cable strain
relief (3) (Fig. 5).
• Connect the trimmer to the mains socket.
• Ensure a safe stance and hold the trimmer firmly with both hands. Do
not rest the cutting head on the ground.
• To switch on, press the on/off switch (1) (Fig. 5).
• To switch off, release the on/off switch (1) (Fig. 5).
After the trimmer has been switched off, the cutting head will
continue
to rotate for a few seconds.
Keep hands and feet well away.
The on/off switch must not be locked in place. The trimmer must
not be used if the on/off switch is damaged. There is the immediate
danger of injury if the motor does not switch off after the on/off
switch has been released.
CAUTION: Always remove grass residue from the line cutter so that the
cutting effect is not impaired.
Starting and stopping
Operating Instructions & Tips
Fig. 5 1
3
2

17
Cutting
WARNING: Danger of injury! Before starting the trimmer, check
that the cutting head will not come into contact with stones, rubble or
other foreign bodies.
- Switch on the trimmer before you approach the grass that is to be cut.
- Do not cut damp or wet grass.
- Do not overload the trimmer during operation.
- Avoid contacting solid obstacles (stones, walls, fences, etc.) as this
wears the line out quickly. Use the flower guard to keep the trimmer
away from such obstacles.
- Always trail the power cable behind you. Do not pass a running trimmer
over the power cable as it could be damaged.
• Cut the grass by swaying the trimmer sideways to the right and left. Cut
slowly, tipping the appliance forwards by about 30° (Fig. 6).
• Long grass should be cut in layers from top to bottom. Use the flower
guard to maintain the necessary distance whenever required.
Fig. 6

18
Trimmer settings
Fig. 7 Fig. 8
Adjusting the auxiliary handle
• The auxiliary handle (4) can be set in different positions.
• Set the handle in such a manner that the cutting head is slightly tilting
forwards when in the working position.
• Release the winged nut (17) and adjust the auxiliary handle in the
required position. Retighten the winged nut (Fig. 7).
Adjusting the height of the telescopic tube
The telescopic tube enables you to adjust the trimmer to your height.
• Release the screw sleeve for tube length adjustment (6). Adjust the
telescopic tube (7) to the required length and retighten the screw
sleeve (Fig. 8).
4
6
7
17
Adjusting the main handle
• The handle assembly turns by 90° and 180° for vertical edging (Fig. 9).
• Pull down the lever for tube and cutting head angle adjustment (5), and
turn the main handle (18) until it snaps into the desired position (Fig. 9).
Adjusting the flower guard
The flower guard (16) keeps plants and stalks that are not to be cut away
from the cutting lines.
• Fold down the flower guard for trimming.
• If the flower guard is no longer required, it can be folded up flush against
the motor housing (park position) (Fig. 10).

19
Lengthening the cutting lines
Fig. 9 Fig. 10
18
16
5
180°
0°
90°
A short or worn cutting line will not cut effectively. If you notice reduced
cutting performance, you should check if there is still enough line on the
spool. Disconnect the power plug first! Spool replacement is detailed in
section ‘Replacing the Trimming Assembly’.
Fully automatic dual line system:
The trimmer features a fully automatic dual line system. The lines will
automatically elongate every time you start the trimmer. To support
proper line elongation, ensure that the head has stopped moving
completely before starting the trimmer again.
If the lines should be longer than defined by the cutting circle then they
will be automatically cut to the correct length by the line cutter.
Regularly check the nylon lines for damage and whether the lines still
have the correct length defined by the line cutter.
When no line ends are visible:
Renew the line spool (see ‘Maintenance’).
Adjusting the line length manually:
First, disconnect the plug from the mains socket! Press the line-release
button, pull the ends of the cutting line out and let go of the line-release
button. Avoid releasing very long lengths of the cutting line.

20
Cleaning
Replacing the trimming assembly
Maintenance
Before undertaking any work on the trimmer, always disconnect the
plug from the mains socket.
Any work that is not described in these Instructions must be carried
out by a qualified technician. Only use original parts and be very
careful with the line cutter during installation work. Danger of injury!
Do not spray water onto the trimmer and do not clean it under a
flowing tap. This would result in the danger of an electric shock and
the trimmer could be damaged.
Always keep the trimmer clean. Do not use cleaning agents and solvents.
• After the work has been completed, remove all grass and soil from the
cutting device and the protective cover.
• Ensure that the ventilation slots are always clean and free of grass.
• Clean the trimmer with a soft brush or a cloth.
Never manipulate the cutting device by inserting worn out original
or non-approved parts. Only use original spare parts. Never use
metal lines. The use of non-approved parts can result in serious
personal injury and cause irreparable damage to the trimmer, and
the warranty will become void.
• Disconnect the plug from the mains socket.
• Turn over the trimmer so that the cutting head (15) is facing upwards.
Fig. 11
10
13
14
12
11 15
