Powerbuilt EGS0252 User manual

©COPYRIGHT 2010 ALLTRADE TOOLS, LLC.
1431 VIA PLATA
LONG BEACH, CA 90810-1462 USA
EGS0252 – 2400 PSI Washerblaster_Rev 9/20/2010
Printed in China

MODEL EGS0252
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION,
MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ CAREFULLY AND
UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS. FAILURE TO DO SO
COULD RESULT IN SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE.
2400PSI / 12LPM
WATERBLASTER
INSTRUCTION MANUAL

TABLE OF CONTENTS
CONGRATULATIONS! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
GENERAL SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
RECOGNISE SAFETY SYMBOLS, WORDS AND LABELS . . . . . . . . . . . 2-4
IMPORTANT INFORMATION ABOUT THIS MANUAL . . . . . . . . . . . . . . 4
UNPACKING & INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
SAFETY WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
GENERAL SAFETY RULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
SAFETY RULES FOR PETROL ENGINES . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
SYMPTOMS OF CARBON MONOXIDE POISONING . . . . . . . . . . . . . . . 8
ADDING OR DRAINING PETROL TO OR FROM THE ENGINE . . . . . . . 8
STARTING THE ENGINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
MAKING ADJUSTMENTS OR REPAIRS TO THE ENGINE . . . . . . . . . . 10
TESTING SPARK PLUG FOR SPARK . . . . . . . . . . . . . . . . . . . . . . . . . . 10
TRANSPORTING OR REPAIRING EQUIPMENT . . . . . . . . . . . . . . . . . . 10
STORING PETROL OR EQUIPMENT WITH PETROL IN PETROL TANK . . . . . 11
SAFETY RULES FOR WATERBLASTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-13
FUNCTIONAL DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
WATERBLASTER TERMINOLOGY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
ASSEMBLY / ATTACHMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-18
WATERBLASTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-16
PRESSURE HOSE TO PRESSURE PUMP . . . . . . . . . . . . . . . . . . . . . . 16
PRESSURE HOSE TO SPRAY GUN . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
SPRAY WAND TO SPRAY GUN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
SELECTING THE RIGHT NOZZLE FOR THE JOB . . . . . . . . . . . . . . . . . 17
NOZZLES TO SPRAY WAND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-18
PRESSURE PUMP TO WATER SUPPLY . . . . . . . . . . . . . . . . . . . . . . . . 18
PREPARING THE WATERBLASTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-20
PRESSURE PUMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-19
ADDING ENGINE OIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
LOW OIL SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
ADDING PETROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-20
USING WATERBLASTER AT HIGH ALTITUDES . . . . . . . . . . . . . . . . . . 20
STARTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-21
OPERATING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-25
USING THE SPRAY GUN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
WASHING / CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
PRESSURE ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
USING CHEMICALS AND CLEANING SOLVENTS . . . . . . . . . . . . . . . . 23-24
SHUTTING DOWN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-27
1

STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-29
ENGINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-28
PRESSURE PUMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29
WATERBLASTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
PREPARING FOR USE AFTER STORAGE . . . . . . . . . . . . . . . . . . . . . . . 29
TROUBLESHOOTING GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-34
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
1 YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35-37
CONGRATULATIONS!
Thank you for choosing this waterblaster. Our aim is to provide you with
quality professional products, and we want you to be totally satisfied with your prod-
uct and our Customer Service.When properly cared for, this product will give you many
years of satisfaction.
INTRODUCTION
This instruction manual is intended for your benefit. Please read and follow the safe-
ty, installation, maintenance and troubleshooting steps described within to ensure
your safety and satisfaction. The contents of this instruction manual are based upon
the latest product information available at the time of publication. The manufactur-
er reserves the right to make product changes at any time without notice.
GENERAL SAFETY
READ AND FOLLOW ALL INSTRUCTIONS.
Failure to follow all instructions in this manual could result in severe
personal injury or death. Keep this manual and refer to it for Safety
Instructions, Operating Procedures, and Warranty.
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
RECOGNISE SAFETY SYMBOLS, WORDS AND LABELS
The safety instructions provided in this manual are not intended to cover all possible
conditions and practices that might occur when operating, maintaining and clean-
ing power tools.
Always use common sense and pay particular attention to all the DANGER,
WARNING, CAUTION and NOTE statements in this manual.
This is the safety alert symbol. It is used to alert
you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid
possible injury or death.
DANGER
2

DANGER indicates an imminently hazardous
situation which, if not avoided, could result in
death or serious injury.
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
CAUTION indicates a potentially hazardous
situation which, if not avoided, could result in
minor or moderate injury.
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which,
if not avoided, could result in property damage.
NOTE provides additional information that is useful
for proper use and maintenance of this tool. If a NOTE
is indicated, make sure it is fully understood.
In addition to SAFETY ALERTS listed above, there could also be numerous symbols
alerting the operator that specific safety measures are required to safely operate this
tool. Learn these SAFETY SYMBOLS as well as the SAFETY ALERTS to prevent
injury to the operator and to bystanders.
READ OPERATING INSTRUCTIONS: Read and understand tool labels,
safety warnings and precautions in this manual before operating the tool.
Failure to follow WARNINGS could result in serious injury or even death
to the operator or bystanders.
FIRE HAZARD: Heat from engine exhaust can ignite combustible materi-
als, building structures or gas tanks resulting in a fire. Place the tool on
a flat surface a safe distance from buildings or other combustible
material. Ensure exhaust is directed away from tool.
WEAR APPROVED EYE PROTECTION: This tool has rotating and moving
parts that could become airborne if damaged. Always wear approved eye
protection when operating equipment with moving parts. Safety glasses
must conform to the requirements and provide protection against flying
particles from both front and side.
POISONOUS FUMES: This tool uses a petrol powered engine that
produces poisonous fumes from its exhaust. Always make sure there is
adequate ventilation when operating this equipment.
3

EXPLOSION HAZARD: Petrol and its vapors are extremely flammable and
explosive. Fire or explosion from these vapors can cause severe burns or
even death.
ROTATING PARTS: Starter and other rotating parts on this tool can
entangle loose clothing, long hair and accessories resulting in moderate
to severe injury.
HOT SURFACES: Engine muffler and other engine parts can become very
hot. Coming in contact with hot engine components can cause serious
burns. Hot exhaust gases from the engine can cause clothing to ignite if
in contact for any length of time.
KICKBACK: Starter cord can kickback (recoil) very rapidly. Kickback will
recoil starter cord quicker than you can let go. This action can result in
broken bones, bruises, sprains or fractures.
UNIT IS HEAVY: Take care when lifting or moving unit.
INJECTION HAZARD: Waterblasters can produce fluid streams severe
enough to penetrate animal and human flesh.
SLIPPING and FALLING: Waterblasters produce puddles of slippery liq-
uid that can result in falls. Kickback from spray wand can result in falls
when using unstable platforms.
IMPORTANT INFORMATION ABOUT THIS MANUAL
Improper and unsafe use of this Waterblaster can result
in death, fire and/or bodily injury. This instruction manual contains impor-
tant information about product safety. Keep the instruction manual available
for others to read before they use the Waterblaster.
Improper maintenance and operation are responsible for the majority of accidents
involving petrol Waterblaster. The largest portion of these may be prevented by rec-
ognizing the basic safety rules and precautions. Most accidents can be avoided if
the operator recognizes a potentially hazardous situation before it happens and by
observing appropriate safety rules and procedures as outlined in this manual.
Basic safety precautions are outlined in the SAFETY portion of this manual and
throughout the text in this manual where a potential hazard might occur.
Hazards that MUST be avoided to prevent serious injury follow headers marked DANGER
or WARNING. These same precautions are placed as labels on the tool itself.
NEVER use this Waterblaster for applications that are NOT specified in this manual.
4

UNPACKING & INSPECTION
After opening the carton, unpack your new Waterblaster and related parts & acces-
sories. Please inspect it carefully for any damage that may have occurred
during transit.
Do not operate this Waterblaster if damaged during ship-
ment, handling or misuse. Damage could result in bursting, which can cause
serious injury or property damage. All damaged parts must be repaired or
replaced as needed prior to operating this Waterblaster.
Check to see that all nuts, bolts and fittings are secure before putting this
Waterblaster into service. I or missing parts, please contact our Consumer Helpline:
Phone: [phone]
Please have the serial number, model number, date of purchase, and parts list (with
missing parts identified) available for reference when calling.
MODEL NUMBER:
SERIAL NUMBER:
DATE OF PURCHASE:
SAFETY WARNINGS
READ ALL SAFETY WARNINGS BEFORE
USING WATERBLASTER.
GENERAL SAFETY RULES
People with electronic devices, such as pacemakers, should consult their physi-
cian(s) before using this product. Operation of electrical equipment or the elec-
tromagnetic wave created by the engine spark plug in close proximity to a heart
pacemaker could cause interference or failure of the pacemaker.
WARNING: This product contains chemicals known to the State of California to
cause cancer and birth defects or other reproductive harm.
WARNING: The Engine Exhaust from this product contains chemicals known to
the State of California to cause cancer, birth defects or other reproductive harm.
5

Keep work area clean and well lit. Messy areas and cluttered workbenches
invite personal injury and/or property damage. Clear all work areas of unneces-
sary tools, debris, furniture, etc.
Make sure the work area is well ventilated. Never operate in an enclosed area.
Do not place objects on top or against the tool.
Handle correctly. Always operate according to the instructions provided.
Never allow the tool to be operated by children, individuals unfamiliar with its
operation or unauthorized personnel.
Keep children and visitors away. All children should be kept away from the
work area. DO NOT let children handle the tool. Maintain a safe distance for any
person near the work area.
Childproof the workshop. The use of master switches and padlocks is highly
recommended.
Stay alert, watch what you are doing, and use common sense. Do not stand
on tool. Do not use tool while tired or under the influence of drugs, alcohol
or medication. A moment of inattention while operating the tool could result in
serious personal injury.
Operating any tools or equipment under the influence of drugs, alcohol, or
medication can cause personal injury to yourself and others.
Use the right tool. Use tools properly and for their intended task. Do not force
a small tool to do the job of a heavy-duty tool. Using the right tool to do the
right job will make doing the job safer.
Always make sure the tool is in the OFF position when making adjustments,
changing parts, or performing any maintenance.
Service must be performed only by qualified repair personnel. Service or
maintenance by unqualified personnel may result in a risk of injury.
Do not use the tool if the power switch does not turn it “ON” or “OFF”. A tool that
cannot be controlled with the switch is dangerous and must be repaired.
Store all maintenance tools away from the immediate area before turning ON
the tool.
Do not overreach. Proper footing and balance is a must at all times while using
tools. Unstable support may lead to personal injury. Do not stand on the tool.
Serious injury could result if the tool tips over or you accidentally contact tool.
When using accessories, consult the owner’s manual provided by the manufactur-
er. The use of improper accessories can cause risk of injury to yourself and others.
6

Keep protective guards in place and in proper working condition.
Maintain tools and equipment with care. They will function better and more
safely when kept clean and in good working condition. Keeping the tool clean,
dry, and free of grime will add to its life and performance.
Do not use the tool for applications other than specified.
SAFETY RULES FOR PETROL ENGINES
Carbon monoxide is a product of incomplete combustion, such as
exhaust fumes from the engine. Carbon monoxide is colorless,
odorless and tasteless and can kill in a matter of minutes.
Gas particulate filters and respirators will not protect someone from carbon
monoxide poisoning. If symptoms of carbon monoxide poisoning appear,
take the affected person outdoors immediately and away from all structures
and equipment that could produce the gas. Call for emergency medical treat-
ment and make them aware of the situation.
Operate Waterblaster only outdoors. Do not allow exhaust gas fumes to enter
confined areas through windows, open doors, ventilation ducts and other
openings.
Do not start or run engine indoors or in an enclosed area, such as a garage
(even if windows and doors are open). This also applies to the engine com-
partment of a recreational vehicle (RV).
Install a battery powered Carbon Monoxide (CO) detector near all bedrooms to
alert occupants of dangerous levels of carbon monoxide. Carbon monoxide is a
colorless, odorless, very poisonous gas.
The Emission Control System for engine is warranted for standards set forth by
the EPA/Environmental Protection Agency and CARB/California Air Resources
Board.
7

SYMPTOMS OF CARBON MONOXIDE POISONING
Carbon monoxide (CO) is a colorless, odorless, tasteless, extremely toxic gas that
can KILL in a matter of minutes. Breathing air containing carbon monoxide
produces symptoms of headache, dizziness, loss of muscular control, a sleepy
feeling and finally coma. Moderate or severe brain damage can result from inhaling
air containing carbon monoxide. Carbon monoxide is a product of incomplete
combustion of fuels and occurs in exhaust fumes of fuel-burning heaters and all
internal combustion engines. Carbon Monoxide collects in spaces where there is no
constant air flow or ventilation. If you start to feel sick, dizzy or weak due to
exposure to CO while using a petrol engine, GET TO FRESH AIR IMMEDIATELY.
ADDING OR DRAINING PETROL TO OR FROM THE ENGINE
Petrol and petrol vapors are extremely flammable and
explosive. Fire and explosion can result in severe burns
and even death.
• Turn engine to the OFF position and let cool at least two minutes before
removing petrol cap. Loosen cap slowly to relieve pressure in petrol tank.
• DO NOT fill or drain petrol tank inside enclosed structures. Accidental sparks
can result in fires or explosions leading to severe burns and even death.
• DO NOT overfill petrol tank. Leave ample space for expansion of petrol.
• DO NOT start engine in area of petrol spillage. Fire and explosion can occur.
• Keep petrol away from sparks, open flames, pilot lights, heat and other ignition
sources. DO NOT smoke while operating the engine.
• DO NOT tip engine or equipment at an angle that could result in petrol spilling
from petrol tank.
STARTING THE ENGINE
Starter cord kickback (rapid retraction) can
pull your hand and arm toward the engine faster than it can be let
go of. Failure to be aware of this function can result in broken
bones, fractures, bruises and sprains can result.
• When starting the engine, pull cord slowly until resistance is felt, then pull
rapidly to avoid kickback.
8

Unintentional sparking can result in fire or electric shock.
Failure to observe this warning can result in property
damage, severe burns and/or death.
• Ensure spark plug is in place before attempting to start engine.
• Ensure muffler is secured to engine before starting.
• Ensure petrol cap is on petrol tank and tightened securely.
• Ensure air cleaner is clean and properly attached to engine.
A dirty air cleaner element changes the air to petrol ratio and
promotes incomplete combustion of petrol increasing the output
of carbon monoxide. Always make sure air cleaner element is
clean before every operation of the engine.
• DO NOT crank engine with spark plug wire removed. The resulting spark
could ignite spilled petrol.
Do not contact muffler area with engine running. Muffler gets
extremely hot and can cause severe burns. Exhaust gases can
ignite combustible items such as clothing or structures in close
proximity. Gases leaking from worn muffler can heat up and damage
petrol tank resulting in fire or explosion.
• DO NOT touch hot parts of engine or muffler.
• AVOID hot exhaust gases.
• Keep a minimum of 1.5 m clearance on all sides of the engine including top.
Starter and other rotating parts of engine can entangle hair, hands,
clothing and accessories.
• NEVER operate with protective housing or covers removed.
• DO NOT use while wearing loose clothing or jewelry that might get caught up
in starter or other rotating parts. Tie up long hair or wear hair net or cap.
9

MAKING ADJUSTMENTS OR REPAIRS TO THE ENGINE
Excessively high operating speeds increase risk of injury and damage to
engine. Excessively low speeds produce heavy load on engine.
• DO NOT attempt to alter pre-set governed speed. Engine governor is factory
set to supply optimum output horse power (HP) when running at governed speed.
• DO NOT modify engine in any way.
TESTING SPARK PLUG FOR SPARK
• DO NOT check spark plug for spark by removing from cylinder head.
• Disconnect spark plug wire from spark plug and cover tip with
non-conducting material such as electrical tape to prevent it from coming in
contact with spark plug, petrol tank or other parts of the engine where damage
can result from sparking.
• Replace a defective spark plug only with authorized parts.
•Use approved spark plug tester.
TRANSPORTING OR REPAIRING EQUIPMENT
RISK OF PROPERTY DAMAGE WHEN TRANSPORTING WATERBLASTER
Turn off the Waterblaster before transport. Use caution when moving the
Waterblaster. Oil/petrol can leak or spill and could result in fire or breathing hazard,
serious injury or death. Oil/petrol leaks will damage carpet, paint, or other surfaces
in vehicles or trailers. Be sure to use the handle to lift or carry the Waterblaster.
•The wheel kit is not designed for over-the-road use. Waterblaster
must be transported in a vehicle or on a trailer.
•Unit is heavy.Take care when lifting or moving unit.
• Transport or repair with petrol tank EMPTY to prevent an unintentional spark
igniting petrol vapors resulting in a fire or an explosion.
• Transport or repair with spark plug wire DISCONNECTED.
10

STORING PETROL OR EQUIPMENT WITH PETROL IN PETROL TANK
Store away from furnaces, stoves, water heaters,
clothes dryers, and all other appliances with pilot lights or other ignition
sources. These appliances can heat petrol tanks and ignition sources can
ignite petrol vapors.
SAFETY RULES FOR WATERBLASTER
RISK OF FIRE OR EXPLOSION
Always store petrol away from the Waterblaster and in an
approved container.
Petrol and petrol vapors are extremely flammable and explo-
sive. Fire and explosion can result in severe burns and even death.
Make sure all ventilation openings are clear and free from restrictions.
Restricted ventilation openings can cause overheating and/or fire.
Do not operate the Waterblaster in explosive areas, such as in the
presence of flammable liquids, gases or dust. Waterblasters
can create sparks which might ignite the dust or fumes.
Never use the Waterblaster in damp or wet locations.
Wear proper apparel. Remove your Jewellery before using Waterblaster. Do
not wear loose clothing, necklaces, rings, bracelets, or other Jewellery, which
might get caught in moving parts. Non-skid footwear and electrically non-con-
ductive gloves are highly suggested while working. Wear protective hair cover-
ing to contain long hair.
Be responsible for your hearing. Wear hearing protection during extended
periods of operation.
Do not use the Waterblaster if it is emitting excessive noise or vibration. Have it
repaired immediately.
Store the Waterblaster indoors, in a dry, secured area away from
other equipment. Never store the Waterblaster near an open flame or
flammable materials.
Keep Waterblaster a minimum of 1.5m of clearance on all sides including
overhead.
11

RISK OF INJURY
Waterblaster produces fluid pressures and velocities high enough to pene-
trate human and animal flesh which could result in serious injury or ampu-
tation.
Ensure all connections are tightened securely. Inspect all hoses to
ensure they are not damaged or kinked. Loose connections or dam-
aged hoses can result in injection injuries.
Ensure all quick-connect fittings are properly connected. Pull on connection to
ensure fittings are secure. Improperly connected quick-connect fittings can
unexpectedly separate resulting in injury.
NEVER place hands in front of nozzle.
NEVER attempt to attach or remove spray wand or hose fittings while
Waterblaster system is pressurized.
DO NOT treat fluid injection injuries as a simple cut. Seek immediate med-
ical attention.
DO NOT allow pressure hose to come in contact with engine muffler.
HIGH VELOCITY fluid spray can cause objects to break, propelling particles
at high speeds.
ALWAYS wear approved safety glasses when using or doing
maintenance on waterblaster.
NEVER substitute safety glasses for GOGGLES. Injury to eyes could occur.
DO NOT permanently secure spray wand trigger in open position.
DO NOT use spray wand that does not have a trigger lock or trigger
guard in place and in proper working order.
12

DO NOT use acids, toxic or corrosive chemicals, poisons, insecticides, flamma-
ble solvents or bleach with Waterblaster. Use of these chemicals can result in
damage to equipment or serious injury or death.
DO NOT direct spray toward electrical outlets, switches or products
connected to electrical service. Failure to observe this warning can
result in electrocution resulting in severe electrical shock or burns
and possibly resulting in death.
NEVER run the pressure pump without the water supply connected and turned
on. Non-repairable damage to the pump will occur.
RISK OF FALLING
Waterblaster can create puddles of slippery solutions that can
become hazardous.
Ensure you stand on a stable surface while operating Waterblaster. Initial kick-
back from engaging spray wand can cause you to lose your balance and fall
resulting in minor to severe injuries.
Use extreme caution if you must operate Waterblaster from a ladder or
scaffolding. Kickback from spray wand can result in a loss of balance and result
in a fall that could cause serious injuries.
When cleaning with the waterblaster, ensure there are adequate slopes for drainage
so solutions don’t create puddles around unit that could result in slipping and falling.
Firmly hold spray wand with both hands when using high pressure spray avoid-
ing injury should spray wand kick back.
The Waterblaster must be run with the rubber feet resting on a flat and
stable horizontal surface.
The Waterblaster must be used in a clean and well-ventilated area. Keep Waterblaster a
minimum of 1.5 m of clearance on all sides including overhead.
DO NOT place Waterblaster in an area:
• Where there is evidence of oil or gas leaks.
• Where flammable gas vapors or materials may be present.
• Where extremely dirty air or water could be drawn into the Waterblaster.
13

FUNCTIONAL DESCRIPTION
WATERBLASTER FEATURES:
1. Spray Wand
2. Spray Gun
3. Foldable Handle
4. Carburetor
5. Petrol Tank Cap
6. Petrol Engine
7. Disposable Plug
8. Pressure Control Valve
9. Chemical Inlet Fitting
10. High Pressure Outlet
11. Water Hose/Filter Inlet
12. Thermal Relief Valve
13. Pressure Pump
14. Handle Pin Lock
15. Pressure Hose Housing
16. Pressure Nozzles (5)
17. Detergent tank Cap
18. Pump Breather Plug
19. Gun Holder kit (Top)
20. Gun Holder kit (Bottom)
21. Wheels
22. Axel Kit
23. Leg Kit
24. Tool Kit
25. High Pressure Hose
26. Cleaning Needle
27. Engine Oil 10W 30 and Funnel
2400 PSI / 12 LPM
14

WATERBLASTER TERMINOLOGY
Following are common terms associated with the use of waterblasters:
PSI: Pounds per square inch – common unit measure used for water pressure, air
pressure, hydraulic pressure and pounds of force.
LPM: Liters per minute – common unit measure used for flow rate of water.
.
Bypass Mode: In bypass mode, high pressure pump recirculates water because
spray gun trigger is not squeezed.
Thermal Relief Valve: When in Bypass Mode, this valve releases a jet of water to
prevent water temperatures from reaching harmful levels that damage the pump. Once
the water has cooled, the thermal relief valve will reset itself. Do not allow pump to run
without spraying (in Bypass Mode) for more than 2 minutes.
ASSEMBLY / ATTACHMENTS
This Waterblaster requires some assembly and will be ready for use after servicing
with manufacturer approved oil and petrol. If you have any problems with the
assembly of your waterblaster, please call the waterblaster helpline at
1-888-278-8092. If calling for assistance, please have the model, revision, and seri-
al number from the data tag available.
WATERBLASTER
Unit is heavy.Do not attempt to lift and remove
the Waterblaster unit from the carton.
1. Using a box cutter, open carton completely by cutting the four corners allowing
the sides to lay flat. Leave Waterblaster on the carton.
2. Remove all items except the Waterblaster from the box and inspect for com-
pleteness (See Functional Description).
3. Carefully tip the Waterblaster forward and place on its front side and
proceed to assemble the unit using the provided tools.
4. Insert the shaft through the holes in the bottom frame tubing as shown.
5. Assemble the wheels to the shaft (using the bushings, washers and cotter
pins). To secure the Wheels to the shaft, insert the Cotter Pins inside the small
holes in the shaft and bend back the end of the Cotter Pins using a pair of pliers
(not provided).
6. Assemble the Legs to the bottom frame tubing (using the nuts and bolts) as
shown. Tighten all mounting hardware.
7. After completion of wheel/leg assembly, carefully place the Waterblaster on
its wheels and legs. 15

8. Pull the handle lock
pin and fully raise the
handle upright.
Release and snap the
lock pin into its lock-
ing hole in the frame.
9. Assemble the top and
bottom gun holders
(using the nuts and
bolts) to the frame as
shown. Tighten all
mounting hardware.
PRESSURE HOSE TO PRESSURE PUMP
Connect the hose to the pressure pump outlet and FIRMLY
tighten the nut by hand. fitting and release collar. Tug on the
hose to make sure it is secured.
PRESSURE HOSE TO SPRAY GUN
Connect the hose to the spray gun and FIRMLY tighten
the nut by hand.
2. Insert male quick-disconnect fitting on spray
gun into female quick-disconnect on high pressure hose
3. Release slip ring on female quick-disconnect and
twist. Listen for “click” to ensure both quick-disconnects are coupled.
4. Pull high pressure hose and spray gun in opposite direction to ensure they do
not separate.
SPRAY WAND TO SPRAY GUN
1. Remove the protective plastic cap at the inlet of the wand.
2. Thread spray wand onto spray gun.
3. Tighten the nut to secure the Wand to the Gun.
16
2400 PSI / 12 LPM
NUT
GUN HOLDER (TOP)
GUN HOLDER
(BOTTOM) LEG (2)
SHAFT
LOCK NUT
COTTER PIN
LOCK NUT
LOCK NUT
BOLT
BOLT
BOLT
WHEEL (2)
BUSHING
WASHER
HANDLE
LOCK PIN

SELECTING THE RIGHT NOZZLE FOR THE JOB
To prevent damage to your surface and to select an
appropriate nozzle size for your application, always start with lowest pressure
nozzle size (White) and continue changing to the higher nozzle size until the
best work result is achieved.
The Waterblaster comes furnished with five spray nozzles. Each nozzle is color
coded and delivers a specific spray pattern and pressure for a particular cleaning
job. The size of the nozzle determines the size of the fan spray and the pressure out
of the nozzle.
0° Nozzle – Red: This nozzle delivers a pinpoint stream of pressurized
water and is extremely powerful. It covers only a small area of cleaning. This
nozzle should only be directed at surfaces that can withstand high pressure
such as metal or concrete. Do not use this nozzle to clean wood.
The Waterblaster nozzles are stored in receptacles on a panel mounted to the han-
dle of the washer. Colors on the panel identify nozzle location and spray panel.
NOZZLES TO SPRAY WAND
Never place hands in front of nozzle. Never grasp hose or fittings during
Waterblaster operation. Never attempt to attach or remove spray wand or hose
fittings while Waterblaster system is pressurized.
Turn off waterblaster, release pressure by pulling gun trigger then lock the
gun trigger before attempting to change pressure nozzles.
17
Chemical Nozzle – Black: This nozzle is used to apply special chemi-
cals and cleaning solutions. This nozzle produces the weakest pressure
stream of the five nozzles.
15° Nozzle – Yellow: This nozzle delivers a powerful 15 degree spray
pattern for intense cleaning of small areas. This nozzle should only be
used on areas and materials that can withstand high pressure.
25° Nozzle – Green: This nozzle delivers a 25 degree spray pattern for
intense cleaning of larger areas. This nozzle should only be used on
areas that can withstand pressure from this nozzle.
40° Nozzle – White: This nozzle delivers a 40 degree spray pattern and
a less powerful stream of water. This nozzle can cover a wide area and
should be used for most general cleaning jobs.

1. To attach, insert nozzle into female quick-disconnect spray wand and
press to snap in the nozzle.
2. To detach, slide down slip ring on female quick-disconnect to eject
the nozzle.
PRESSURE PUMP TO WATER SUPPLY
1. Connect the garden hose to the water supply and turn water sup-
ply on to fill the hose with water and also remove any debris in
the hose. Turn OFF water supply.
2. Make sure that the filter inside Waterblaster water inlet is clean
and undamaged. Thread the garden hose fitting into water hose
inlet. Hand tighten the inlet nut.
3. Turn on water supply.
The Waterblaster requires a minimum of 50 PSI and a flow
rate of 20 LPM.
PREPARING THE WATERBLASTER
Improper treatment of Waterblaster can damage internal components and
shorten the life of unit. Failure to follow this warning will void warranty.
PRESSURE PUMP
The Waterblaster is shipped with shipping oil plug to prevent oil leakage from the
pump during shipping. To replace the shipping plug with the Breather Plug
(provided) perform the following:
Failure to remove shipping plug and replace it with the
dipstick/oil plug will damage pressure pump. Failure to add pump Breather
Plug will void warranty.
1. Using a wrench, remove shipping plug from pressure pump. Discard shipping
plug.
2. Remove pump Breather Plug from parts bag and insert it into pressure
pump.
3. Tighten pump Breather Plug securely by hand. Do not use wrench
to tighten. Using a wrench to tighten pump Breather Plug could
strip threads.
18
