IEEE802.3at Task Force
Technical and market considerations
regarding PoEp output voltage range
Vancouver BC, November 2005
Arkadiy Peker
Daniel Feldman
Yair Darshan

www.powerdsine.com
Part A
Technical Considerations regarding
PoEp output voltage range

PowerDsine Presentation October 2005 Page 3
www.PowerDsine.com
Objectives
To discuss optimum voltage range for PoEp
To show advantages of having PoEp minimum voltage of 51V

PowerDsine Presentation October 2005 Page 4
www.PowerDsine.com
HP POE voltage range
Maximum voltage: 57V (safety consideration)
What is most optimum value for minimum voltage?
PoEp group objective; maximum power within practical limit (Power
Dissipation, Safety consideration)
Power dissipation is function of the current
Increasing minimum voltage reduces current level for the same load
power or
Increasing Power delivery to the load for a given current value.
Hence same infrastructure delivers more power to PDs for given
PSE PS size and cost
Bottom line: more applications may supported
– Larger POEp market

PowerDsine Presentation October 2005 Page 5
www.PowerDsine.com
PoEp minimum voltage
Lets assume current is 0.35A and calculate power delivered to the load by four
pairs
It means, that at 51V, for the same power dissipation on the cable, power
delivered to the load will be 4.9W more then at 44V.
The advantage of higher voltage is further increased for higher currents than
0.35A
32.64W27.74WMaximum power
delivered to the PD
3.06W3.06WPower dissipation
on 4 pair
51V44V

PowerDsine Presentation October 2005 Page 6
www.PowerDsine.com
PoEp minimum voltage
Let us look on this issue under another angle assume minimum load need
to be delivered to PD by four pair is 40W
Power dissipation on a cables for 51V PSE will be 2.45W less then for 44V
Advantages of higher voltage is increase with increasing power level
0.890.84System efficiency
for ~500W PSE PS
44.88W47.52WPSE power
4.85W7.3WPower dissipation
on a cables (4P)
0.44A0.54ACurrent per pair
40W40WPd power 51V44V

PowerDsine Presentation October 2005 Page 7
www.PowerDsine.com
PoEp minimum voltage
51V required smaller PSE power supply then at 44V, for the same
load.
The technical advantage is clear for using higher voltage minimum
voltage level for POEp PSE.
Let consider different options in PoEp Power architectures :
- AC input and battery back up
- AC UPS input

PowerDsine Presentation October 2005 Page 8
www.PowerDsine.com
PoEp Power Architecture-AC Input

PowerDsine Presentation October 2005 Page 9
www.PowerDsine.com
PoEp Power Architecture-AC Input
One of the arguments for not using 51V power supply is that back up
battery operates up to ~ 43 - 44V.
However most batteries used in telecommunication have one of the
terminal grounded (mostly positive)
This would prevent direct use of this batteries in POE and would
require to have isolated converter between batteries and PSE
regardless of output voltage considerations
Therefore increasing output voltage to ~51V would not add any
system cost
But boost converter would be useful even in case of isolated
batteries (DC UPS), which really is not very popular power
architecture.

PowerDsine Presentation October 2005 Page 10
www.PowerDsine.com
HP POE Power Architecture-AC Input
Taken at account the voltage drop on a high current battery cable
and PSE voltage drop (Mosfet and CS resistor), it would require
Low Voltage Disconnect to shutdown battery at ~46V in order to
have 44V on the PSE output
It means battery life would not be fully utilize
Adding boost converter, which would keep output voltage of the
system constant, in our case 51V,would extend batteries
capabilities on ~15% in POE systems
