Powerlink PL-3000 SERIES Configuration guide

1
FEATURES AND OPERATIONS
TWO WAY COMMUNICATION
REMOTE STARTER & SECURITY SYSTEM
OWNER'S MANUEL

2
TRANSMITTER OPERATIONS
ONE WAY TRANSMITTERS FOR
PL-3000 & PL-7000 SERIES TWO WAY TRANSMITTER FOR PL-3000 SERIES TWO WAY LCD TRANSMITTER FOR
PL-7000 SERIES
COMMON BUTTON USED BY 3 TYPES OF TRANSMITTERS
:ARM & LOCK THE DOORS
:DISARM & UNLOCK THE DOORS
:ENGINE START
2 sec: TRUNK OPENER
2 sec: COLD START EVERY 3 HOURS
, :TEMPORARY VALET MODE
2 sec: PANIC MODE

3
TRANSMITTER OPERATIONS
TRANSMITTER FOR PL-3000 SERIES
AUX:TRUNK OPENER
AUX 2 sec: SLIDE DOOR OPEN
, (AT THE SAME TIME): SELECT 1ST OR 2ND VEHICLE
, AUX (AT THE SAME TIME): BATTERY SAVER: SELECT PAGING ON/OFF
LCD TRANSMITTER FOR PL-7000 SERIES
F THEN :STATUS REPORT S THEN :STATUS REPORT
F THEN :TEMPERATURE CHECK (optional) S THEN :SLIDE DOOR OPEN
F THEN :ENGINE START TIMER S THEN :STATUS REPORT
•Every time you press a button, transmitter emits 1 short beep. If you keep pressing the same button you will hear a
second beep. Depending on the number of beeps (1 short or 2 short beeps) you will have access to the different
functions of the system.
•When alarm is triggered the system will page the transmitter. To stop the alarm it requires pressing any button on the
remote.

4
TWO WAY LCD TRANSMITTER OPERATIONS
(Option)
Adjust real time clock
Keep pressing "F" button until appear then release. The display will show the hour numbers flashing. Use " "
button to select the hour, minutes or Am/Pm. Then use the "" button to increase or the "" button to decrease
time. When it is done, press "F" button to exit.

5
TWO WAY LCD TRANSMITTER OPERATIONS
Adjust start timer
Keep pressing "F" button until appear then release. The display will show the hour numbers flashing. Use ""
button to select the hour, minutes or Am/Pm. Then use the "" button to increase or the "" button to decrease
time. When the start timer is set, you can enable or disable it by pressing the "F," button. The "Start timer" icon will
turn ON and the engine of your vehicle will start at preset time. When it is done, press "F" button to exit.
NOTE: You can exit a mode anytime by pressing the "F" button.
Adjust wake-up timer
Keep pressing "F" button until appear then release. The display will show the hour numbers flashing. Use " "
button to select the hour, minutes or Am/Pm. Then use the "" button to increase or the "" button to decrease
time. When the wake-up timer is set, you can enable or disable wake-up by accessing the "S" functions. When it is done,
press "F" button to exit.
Enable wake-up timer
Keep pressing "S" button until appear then release. Then use the "" button or the "" button to
enable/disable this option. The "wake-up timer" icon will turn ON if it is enable.

6
TWO WAY LCD TRANSMITTER OPERATIONS
Change SOUND / VIBRATION mode
Keep pressing "S" button until appear then release. Then use the "" button or the "" button to toggle
between SOUND or VIBRATION option. The corresponding "Audible" or "Vibration" icon will be display.
Replace the battery
If you want to replace the battery without readjust the time and all your settings, use the following instructions. Keep
pressing "S" button until appear then release. Then press the "" button or the "" button, you will see
displayed. Now, you can replace the battery. Otherwise, press "S" button to exit this mode.
Enable/Disable paging
If you do not want the transmitter paging, you can disable the paging option. Keep pressing "S" button until
appear then release. Then press the "" button or the "" button to enable/disable this option. When this option is
disable, the battery will last more long time however, you will lose the paging feature. When it is done, press "S" button to
exit this mode.

7
TRANSMITTER OPERATIONS
FUNCTION BUTTON PRESSING REMOTE AUDIBLE
FEEDBACK ACTIVATION
BUTTON ARM:
ARMING NO CHIRP Press once 1 Hi/Lo beep
¦ Arm & lock ON System armed and doors locked without chirp
ARMING WITH CHIRP Press twice 1 Hi/Lo beep
¦ Arm & lock ON System armed and doors locked with 1 chirp
PANIC MODE Press 2 seconds while ignition
OFF 15 seconds alarm beep ¦ Paging ON Panic mode activation
BUTTON DISARM:
DISARMING NO CHIRP Press once 1 Hi/Lo beep
¦ Arm: OFF & unlock: ON System disarmed and doors unlocked without chirp
DISARMING WITH CHIRPS Press twice 2 Hi/Lo beeps
¦ Arm: OFF & unlock: ON System disarmed and doors unlocked with 2 chirps
TRUNK OPEN Press 2 seconds 3 Hi/Lo beeps Trunk opened
¦PL-7000 series LCD transmitter icons display only.

8
TRANSMITTER OPERATIONS
BUTTON START:
START ENGINE Press once 1 Cricket sound beep Send signal to start engine
STOP ENGINE Press once 1 Cricket sound beep followed
by 3 long beeps after a 4
seconds delay
Send signal to stop engine
Press once 3 long beeps System cannot start the
engine
KEYLESS RUNNING MODE
(when engine is running) Press once 1 Cricket sound beep Activation of keyless running
mode
NIGHT TIMER MODE Press 2 seconds 4 Cricket sound beeps Night timer mode activated
TEMPORARY VALET MODE Press twice while system
disarm 4 Hi/Lo beeps System keep disarm until
pressing
BUTTON " AUX "AUXILIARY (for PL-3000 series transmitter):
TRUNK OPEN Press once 3 Hi/Lo beeps Trunk opened
SLIDE DOOR OPENED Press twice 3 Hi/Lo beeps Slide door opened
SLIDE DOOR OPENED Press 2 seconds 3 Hi/Lo beeps Slide door opened

9
TRANSMITTER OPERATIONS
PAGING SIGNALS TO TRANSMITTER:
1 Hi/Lo beep Automatic arming or security rearm engaged
3 Long beeps Engine stops running via remote or engine running time has expired
5 Hi/Lo beeps Alarm has been triggered while you were away
15 Long beeps Alarm in progress
1 Cricket sound Engine running via remote and doors locked
2 Cricket sound Engine running via remote and doors unlocked
3 Cricket sound Engine running via remote and trunk opened
SIGNALS EMITTED BY TRANSMITTER:
3 Double beeps Error signal or out of range
Intermittent beeping Low battery indicator
IMPORTANT NOTE: If you have intermittent beeping on your transmitter, you have to reset transmitter by
removing battery and putting it back so that you can disarm your vehicle. Replace battery as soon as possible.

10
FEATURES AND OPERATIONS
ARMING:
Arming the system will also enable the starter kill and lock the doors, if installed. You can select silent or audible arming by
programming option #3. If you try to arm the system and you hear 3, 4 or 5 beeps, one of the protected zones is opened.
The system will ignore the defective zone and force the system to arm. Consult your installer to check your system.
PASSIVE ARMING:
If selected, the system will automatically arm itself 30 seconds after the ignition has been turned OFF and the last door
closed.
DISARMING:
Disarming the system will also disable the starter kill and unlock the doors, if installed. If you hear 5 beeps when you
disarm the system, it is means the alarm has been triggered while you were away.
SAFETY REARMING:
If you disarm the system by accident and you do not open any access, it will rearm automatically after 30 seconds, unless
the engine is running.
STARTER KILL OPERATION:
When the system is armed manually or via passive arming the starter kill will arm at the same time.
TURBO MODE:
When the engine is running with ignition key and the turbo mode is enable, press button to activate keyless running
mode. The engine is keep running 4 or 6 minutes (ask your dealer for this feature).

11
FEATURES AND OPERATIONS
PANIC MODE:
With engine not running, keep pressing button for 2 seconds: panic mode is engaged. The horn or siren will be
triggered. To stop the panic mode simply press button.
VALET MODE:
To disarm the system in case of transmitter loss or for vehicle servicing, you must perform the sequence twice to enable
the valet mode. The first time will disarm the alarm and the second time will enable the valet mode. Under valet mode,
door locks, remote start, trunk are still functional.
TO ACTIVATE OR DEACTIVATE VALET MODE:
VIA TRANSMITTER: VIA VALET SWITCH:
Step 1: Turn key ignition to ON position and do
not start the engine, you have 15 seconds
to do step 2 and step 3.
Step 2: Hold brake pedal depressed.
Step 3: Keep pressing the button for 2
seconds, vehicle horn or siren will emit 5
beeps.
a. When valet mode is enabled: L.E.D. turns
ON steady.
b. To deactivate valet mode repeat steps 1,
2 and 3: L.E.D. will turn OFF.
Step 1: Put ignition to ON and do not start the
engine, you have 15 seconds to do step 2.
Step 2: Hold brake pedal depressed and press
valet switch at least 3 times.
a. When valet mode is enabled: L.E.D. turns
ON steady.
b. To deactivate valet mode repeat steps 1
and 2: L.E.D. will turn OFF.
Note: if 15 seconds expire just turn off the ignition key, then start step #1

12
FEATURES AND OPERATIONS
IGNITION LOCK:
Doors locks automatically when ignition is ON and brake pedal is depressed. Doors will unlock when ignition is turned OFF
(ask your dealer for this feature).
SHOCK SENSOR PRE-WARNING:
Siren/Horn chirps rapidly when shock sensor is triggered. If shock sensor is triggered for a second time within 10 seconds,
the siren/horn sounds for 30, 60 or 120 seconds (depending on the programming).
ALARM/REMOTE STARTER INTERACTION:
Your remote engine starter can be activated even if the alarm system is armed. You can start your vehicle with the
transmitter as usual and disarm the alarm when you are ready to get into your vehicle.
REMOTE ENGINE STARTER:
Press button on the transmitter to activate remote engine starter. Parking lights will turn ON for 2 seconds, engine will
start 6 seconds later. Lights will stay ON as long as the engine is running 10, 15 or 25 minutes (depending on setting) If the
engine does not start, the system will try a second time. If after the second try, the engine refuses to start, the system
shuts-off completely. You may be experiencing a mechanical problem. Press again to shutdown.
NIGHT TIMER MODE:
Keep pressing button until the parking lights flash 4 times to confirm activation of the night timer mode. The engine will
start every 2, 3 or 4 hours (programmable) for 6 minutes (4 times maximum). The night timer mode will be deactivated if
the vehicle is started by key or via transmitter. For manual transmission, sequence must be enabled before activating night
timer mode.

13
FEATURES AND OPERATIONS
KEYLESS RUNNING MODE:
FOR AUTOMATIC TRANSMISSION:
1. You are seated in the vehicle, engine running with the ignition key, make sure the hood is closed and that the toggle
valet switch is in the OFF position and that the doors and windows are closed.
1. Press button on the transmitter to activate the keyless running mode. The parking lights will flash once and stay ON.
2. Remove the key from the ignition, the engine is still running, exit the vehicle and close the door. The engine will shut
down automatically 15 minutes after the door is closed.
FOR MANUAL TRANSMISSION:
IMPORTANT: Never activate the sequence with the vehicle’s windows open. The vehicle can accidentally be put in
gear without the doors being opened and can cause an accident.
1. You are seated in the vehicle, engine running with the ignition key, make sure the hood is closed and that the toggle
valet switch is in the OFF position and that the doors and windows are closed.
2. Place shifter in neutral position and pull the hand brake, do not depress the brake pedal. If option #14: without remote
sequence is enabled, the parking lights will flash once and stay ON to indicate keyless running mode is engaged, you
then go to step #4 and ignore step # 3. However if option #14: with remote sequence is enabled, you must perform step
#3.
3. Press button on the transmitter to activate the keyless running mode. The parking lights will flash once and stay ON.
4. Remove the key from the ignition, the engine is still running, exit the vehicle and close the door. The engine will shut
down automatically 3 seconds after the door is closed.
5. The vehicle is now programmed and ready for remote starting.
NOTE: If a door is opened after the sequence is made you will not be able to start the vehicle via the transmitter.
This safety feature avoids the possibility of someone shifting the transmission in gear by accident.

14
LIMITED WARRANTY
The manufacturer guarantees to the purchaser of origin the remote starter and alarm to be free of defect material and labour. However, if it is proven that the product is
defective, inside the two year period as from the original date of purchase, the manufacturer will repair or replace, without expenses towards the purchaser, any part (excluding
any expenses incurred to deliver the product to the manufacturer) remote starter or alarm which the manufacturer considers defective. After the initial warranty period of 2
years, the manufacturer must repair or replace the defective products with a forwarding costs of 30.00$US. All the guarantees apply to the original purchaser and ONLY to the
vehicle in which it is initially installed. Repairs or replacement of the defective modules must remain at the discretion of the manufacturer. All the other parts, components,
accessories or optional equipment relating to the remote starter and alarm are not included in the guarantee of the manufacturer. This guarantee is nontransferable. The
original receipt must accompany a request for guarantee of service of any authorized retailer in factory. The fact of not conforming to these conditions can result in cancellation
of the guarantee.
This guarantee does not cover the following elements: expenses for labour of removal or reinstallation, transport charges, abuse, misuse or accidental damage of the remote
starter and the alarm or parts of the latter. This guarantee is cancelled in the event of amendments, repairs or deteriorations of any part of the product. The manufacturer does
not guarantee or does not insure against the loss of the vehicle or its contents. The models of alarm are used only as dissuasion against any possible loss. This alarm can be
considered for a reduction of the insurances; premiums please contact your insurance agent for more details. The manufacturer should not be held responsible for any
consequent damage connected to a violation of this or any other guarantee express or implicit. This guarantee gives you specific statutory duties. These rights vary according
to the area in which you reside.
CERTAIN DAMAGE IS EXCLUDED. The manufacturer declines any responsibility for additional damage caused by the product, including a financial loss, loss of use of the
product, hiring of vehicle or all other expenses connected to the maintenance and the guard of the product. The manufacturer declines any responsibility for any additional
damage caused by the product or resulting from his use, including the expenses of repair or replacement of other goods damaged or caused by his use, even if the product
functions correctly. This product is designed to dissuade from an unauthorized use of the vehicles in which it is installed. The manufacturer does not guarantee that the product
is proof against loss and vandalism and the human error or an inadequate use. The manufacturer does not accept any responsibility for any damage occurring any kind that it is
caused by a vehicle in which the product is installed or resulting from damage from its use. The manufacturer does not accept any responsibility for any damage resulting from
the loss of the vehicle or its contents, caused or claimed caused, directly or indirectly, by a failure of the product.
STARTER WITH MANUAL SHIFT –the installation of a remote starter MUST be carried out with an indicated manual transmission remote starter. It is the sole
responsibility of the operator of the vehicle to make sure that the vehicle is left with the transmission in neutral when the remote starter is used. The manual
transmission remote starter is designed as supplementary measure of safety ONLY! The manufacturer does not guarantee or does not insure against any damage
or loss of life, which can result from remote starting the remote starter when the vehicle is in gear. The models for manual transmission are only designed to act as
a preventive measure against starting in gear; it remains the sole responsibility of the operator or the owner of the vehicle to make sure the transmission is in
neutral.
