PowerPac PPC566 User manual

Model: PPC566
230016-24

PARTS & DESCRIPTION
LIST OF COMPONENTS
1.
2.
3.
4.
5.
6.
7.
This newly introduced Digital Pressure cooker will help you cook the foods you like in a consistent
and convenient manner. Food is also hygienically prepared. Cooking occurs extremely rapidly, and
thus you might find yourself unexpectedly having some very welcomed free time. All the more to
think about preparing other delicious foods like cakes & biscuits, etc. Numerous safety devices are
installed to protect you and your loved ones from injury and to ensure your safety: Anti-block,
Pressure-control, Temperature-control safety devices, among others.
Lid Handle
Lid
Handle(s)
Main Body
Control Panel and Display
Measuring Cup
Inner Pot (non-stick)
8.
9.
10.
11.
12.
13.
14.
Spatula
3-pin Plug
Power Cable
Water outlet
Float Valve
Pressure Release Valve
Removable Aluminium Plate (with Seal Ring)
Top View
1
2
3
4
5
8
7
10
9
11
12
13
6
1

ATTENTION :
Read this booklet carefully it contains important instructions for a safe installation, use and
maintenance.
Important instructions to be kept for future reference.
The following basic precautions should always be followed when using electrical appliances:
1.
2.
3.
4.
Read all instructions before using the appliance.
The Appliance
This appliance must be used only for the purpose it was expressly designed; any use NOT
complying with the instructions contained in the manual is considered inappropriate and
dangerous. The manufacturer is NOT responsible for possible damages caused by the
inappropriate and/or unreasonable use.
The installation/assembly of the appliance will be made in accordance with the indications of
the manufacturer. A wrong procedure may cause damages to persons, animals or objects, for
which the manufacturer cannot be considered responsible.
Before use, check the integrity of the appliance and power cable. DO NOT operate the
appliance when its housing is damaged. In case you are not sure, contact a qualified person.
If the power cable is damaged, it must be replaced by the manufacturer or its service agent or
a qualified technician in order to avoid a shock hazard.
WARNINGS
LED Display
Quick Select
Cooking Programs
Button(s)
Time/Temperature
Button
Set or change Cooking
time and temperature
Time Adjustment
Button
Start/Delay Button
To Delay Cooking
Press for 5 seconds and
select your choice
Keep Warm/Cancel
Programs Button
Quick Select
Cooking Programs
Button(s)
2

5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
Before powering the appliance make sure the rating (voltage and frequency) corresponding
to the grid and the socket is suitable for the plug of the appliance, and that the wall socket is
properly grounded. This appliance is fitted with an earth wire for extra safety.
DO NOT power the appliance using multiple sockets. If possible, avoid the use of adapters
and/or extension cables; if their use is absolutely necessary, use only materials in compliance
with the current safety regulations and according to the electrical parameters of the adapters.
The appliance must NOT be switched on using external timers and/or other remote control
appliances, which are not specified in this manual.
Only use original components & accessories (e.g. Inner Pot, Lid, etc.) provided by the
manufacturer. Any non-original component or accessory NOT recommended by the
manufacturer (including, but not limited to, Inner Pots, Lids, etc. made by other manufacturers
or by the same manufacturer but for other models of the same capacity or otherwise) may
cause injuries to persons or damage to the appliance.
The packing materials (plastic bags, expanded polystyrene, etc.) must be kept out of the reach
of children or disabled persons since they represent potential sources of danger.
Location
This appliance is NOT suitable to be used or stored near heat sources (open flame, ovens,
heaters, stoves, etc.) and/or in an explosive environment (in the presence of flammable
substances such as gas, vapour, mist or dust, in atmospheric conditions when, after ignition,
the combustion is spread in the air). Items containing these substances should never be
placed in the appliance, and never be used to clean the appliance in order to avert the risk of
fire or explosion.
The appliance should NOT be placed on a surface, or in the vicinity of objects which can be
damaged by heat such as carpets or plastics. DO NOT locate multiple portable socket outlets
or power supplies at the bottom or rear of the appliance. During operation, as heat is
transferred away from the appliance, the surface that the appliance is placed upon as well the
surface immediately above or adjacent to it may become very hot. There should be at least
10 cm of free space from the back, left & right sides and at least 20 cm from the top. Never
put things on top of the appliance. Never use the appliance near curtains or textiles. If the
appliance is operated on wooden furniture, use a protective pad to prevent damage to
delicate finishes.
Avoid placing the power cable on abrasive or sharp surfaces or in positions where it can be
damaged easily. DO NOT pull the power cable, tug it or use it to drag the appliance to which
is connected. The cable must NOT be placed under carpets, or covered with throw rugs,
runners or similar. Arrange the cable away from the high traffic area, and where it will NOT be
tripped over.
DO NOT use or store the appliance outdoors. Store and use the appliance only indoors, or in
any case, protected from weathering such as rain, direct radiation of the sun and dust.
Operation
If you are using the appliance for the first time, you should:
a.
b.
c.
d.
e.
f.
g.
h.
Turn the Lid Handle clockwise and lift the Lid off the Main Body.
Clean the Lid, Aluminium Plate & Inner Pot thoroughly with hot water & detergent with a
non-abrasive sponge.
Notice: you can use a dishwasher to clean the Inner pot & Aluminium plate
Clean the inside and outside of the appliance with a wet cloth.
Pour 2 litres of water into the Inner Pot.
Wipe away excess water from the outside of the Inner pot before placing the Inner pot into
the Main Body.
Gently lower the Lid onto the Main Body and ensure the tab on the back of the Lid slots
into the channel at the back of the Main Body. Turn the Lid anti-clockwise until it clicks into
place.
To cook under high pressure you MUST turn the Pressure Release Valve to the CLOSED
position as indicated on the valve. Check that the valve sits down correctly to seal the
opening.
Insert the end of the power cable into the socket at the rear of the Main Body and plug the
3-pin plug into a wall socket and switch it ON. Make sure that the appliance is resting on a
stable, horizontal and heat-resistant surface.
3

i.Press the Meat/Stew button followed by the Start/Delay Button to begin the cooking
process.
After the cooking program has ended, press the “Cancel” button to cancel the Keep Warm
function.
Switch off the wall switch and unplug the power cable from the wall socket.
Wear oven gloves and use tongs to turn the Pressure Release Valve from the CLOSED
position to the OPEN position.
Holding the Handles, give the appliance a few gentle shakes to release any residual steam.
Wait until the Float Valve drops down. This may take 1 – 2 minutes. Allow the appliance to
cool down for 15 minutes.
Turn the Lid clockwise and lift the Lid off the Main Body.
Remove and empty the Inner Pot using oven gloves or a heat proof cloth. Repeat the steps
above ever the interior of the Main Body, Lid and Valves require cleaning.
Make sure to remove any label or protective sheet which may prevent its proper functioning.
cover the appliance during functioning;
obstruct totally nor partially the Pressure Release Valve, Float Valve & Water Storage Box;
insert objects (other than food to be cooked) or body parts inside the protection cover of
the appliance;
lift the appliance by the Lid Handle – when you need to move the appliance, lift the
appliance by the Handles instead;
heat the Inner Pot by any other means, e.g. heating directly on a gas stove, as the pot can
be deformed as a result;
press the buttons too forcefully so as to avoid any damage;
leave the appliance unsupervised during operation.
fill the Inner Pot with hot water;
use the appliance without any liquid in the Inner pot or to heat oil or melt butter without
any food present as this could cause serious damage to the appliance;
add food with its packaging (plastic wrapper, paper, foil, metal can, etc.) still attached
without first removing the packaging;
place any container inside the appliance;
move the appliance whilst the appliance is in operation;
touch any part of the appliance except the buttons on the Control panel, Lid Handle or
Handle(s) during operation or just after switching the appliance off as it will still be very hot
and may cause scalding. The bottom of the appliance becomes exceedingly hot during
operation;
use force to open the Lid;
(Note: the Lid should be opened only when the pressure has decreased sufficiently as high
pressure could cause personal injury and damage to surroundings)
direct steam at any person or animal & one’s hands and face should be angled away from
the steam coming out of the Pressure Release Valve or Float Valve!
15.
16.
17.
18.
19.
20.
i.
j.
k.
l.
m.
n.
o.
p.
DO NOT:
•
•
•
•
•
•
•
During (and immediately after) the period of operation, high temperature steam may escape
from the container. To avoid scalding:
DO NOT
•
•
•
•
•
•
•
•
During operation, DO NOT touch the appliance with wet body parts, and it is recommended
to have between you and the standing surface, an isolating element (for example, wearing
shoes with rubber soles).
DO NOT soak the appliance in water or other liquids, wash it under the tap, or let any liquid
flow into the internal casing of the appliance to prevent electric shock. In case of accidental
fall in water, DO NOT try to take it out, but immediately switch the socket switch OFF and
detach the 3-pin plug from the socket on the wall (holding it firmly with dry hands).
Switch the appliance off, switch the socket switch OFF and unplug the plug if it is NOT used
for a long period and before storing, cleaning or performing any maintenance operation.
In case of malfunction or anomaly during the functioning, switch the appliance off, switch
the socket switch OFF and unplug the plug and check the cause of the anomaly, if possible,
with the support of a qualified person.
If smoke is observed coming out of the appliance, switch the appliance off immediately.
4

21.
22.
23.
This appliance is NOT intended for commercial use but to be used in households and similar
applications, such as:
• Staff kitchen areas in shops, offices and other working environments;
• By clients in dormitories, hotels, motels and other residential environments;
• Bed and breakfast type environments.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall NOT play with the appliance. Cleaning and
user maintenance shall NOT be made by children unless they are older than 8 and supervised.
Keep the appliance and its cable out of reach of children less than 8 years old.
Save these instructions.
1.
2.
3.
Turn the Lid Handle clockwise and lift the Lid off
the Main Body.
Remove the Inner Pot from the Main Body and
fill with solid ingredients, followed by liquids.
NEVER place food or liquid directly into the
Main Body. ALWAYS ensure the Inner Pot is in place before cooking, and that the Inner Pot is
neither empty nor overfilled above the MAX line in the Inner Pot.
In addition, food with skins (e.g. sausages, ox tongue, bacon joints, chicken and fruit) MUST
be pierced before cooking. Not piercing the skin may result in the food expanding and may
cause splashing of hot food after the Lid is released. Due to the effects of pressure, do not
pierce the skin after cooking if it appears swollen: you could get burnt.
When cooking food with a thick texture (apple-sauce, cranberries, pearl barley, oatmeal or
other cereals, split peas, chick peas, rhubarb, noodles, macaroni, and spaghetti, compotes, etc.)
or high starch content (e.g. porridge, congee, sticky liquids, soup, etc.), do not fill the Inner
Pot above the "halfway" point.
Wipe away excess water from the outside of the Inner pot before placing the Inner pot into
the Main Body.
Always check the Pressure Release Valve for
clogs before use. If clogged, grip the sides of
the Pressure Release Valve and pull upwards
until it comes off the Lid. Use a pin to remove
any blockages in the valve. Replace by
pushing back into the recess.
Everything elseBeans, rice, pasta, pulses and porridge
USING YOUR APPLIANCE
5

4.
5.
6.
7.
8.
9.
10.
11.
12.
Thereafter, check the Float Valve. Clean the Float
Valve using a pin to ensure there is no debris
trapped inside or around it. Check that the valve
can be raised and will drop back down without
sticking.
Gently lower the Lid onto the Main Body and
ensure the tab on the back of the Lid slots into
the channel at the back of the Main Body. Turn the Lid anti-clockwise until it clicks into place.
DO NOT operate the appliance with the Lid not locked to the Main Body except for Fry and
Saute functions.
To cook under high pressure you MUST turn the Pressure Release Valve to the CLOSED
position as indicated on the valve. Check that the valve sits down correctly to seal the
opening.
Insert the end of the power cable into the socket at the rear of the Main Body and plug the
3-pin plug into a wall socket and switch it ON. Make sure that the appliance is resting on a
stable, horizontal and heat-resistant surface.
Press one of the Quick Select Cooking Programs Buttons.
Press the Time/Temperature Button to set or adjust the Cooking time and temperature.
Please note that the temperature of the food needs to reach the default temperature before
the timer countdowns. This may take several minutes, depending on the amount of the food,
the temperature of the food you put in, and the default temperature itself. Frozen food will
naturally take a while longer.
(optional: to delay cooking, press the Start/Delay Button for 5 seconds to delay cooking.
Press the Time/Temperature Button to set or adjust the specified duration, up to 24 hours)
Press the Start/Delay Button to begin the cooking process.
After the cooking program has ended and you wish to commence pressure release, press
the “Cancel”button to cancel the Keep Warm function.
Releasing the pressure :
(a)Quick release (takes 1 – 2 minutes)
Recommended for : Vegetables and seafood.
Steps: Wear oven gloves and use tongs to turn the
Pressure Release Valve from the CLOSED position to
the OPEN position.
Holding the Handles, give the appliance a few gentle
shakes to release any residual steam. Wait until the Float
Valve drops down. This may take 1 – 2 minutes.
Pressure Release
Valve in “CLOSED”
Position
Pressure Release
Valve in “CLOSED”
Position
6

13.
14.
15.
Caution: One’s hands and face should be angled away
from the steam coming out of the Pressure Release
Valve or Float Valve!
(b)Slow release (takes at least 15 minutes)
Recommended for :
Food with skins (e.g. sausages, chicken and fruit) and foods with large liquid volume or high
starch content (e.g. porridge, soup, pasta, rice, fruit, grains, potato) and also delicate foods
such as meats can trap air and cause the food to foam and expand which may cause
splashing of hot food after the Lid is removed.
Foods with a thick texture (apple-sauce, cranberries, pearl barley, oatmeal or other cereals,
split peas, chick peas, rhubarb, noodles, macaroni, spaghetti, compotes, etc.) or high starch
content (e.g. porridge, congee, sticky liquids, soup, etc.) can clog the Pressure Release Valve.
Steps: Keep the Pressure Release Valve in the CLOSED position. Wait until the Float Valve
drops down. This may take 15 – 20 minutes.
When the Float Valve has dropped, wearing oven gloves,
use tongs to turn the Pressure Release Valve from the
CLOSED position to the OPEN position.
Holding the Handles, give the appliance a few gentle shakes
to release any residual steam.
Switch off the wall switch and unplug the power cable from the wall socket.
Turn the Lid Handle clockwise and lift the Lid off the Main Body.
DO NOT use force to open the Lid.
(Note: the Lid should be opened only when the pressure has decreased sufficiently as high
pressure could cause personal injury and damage to surroundings. If the unit is difficult to
open, this indicates that the appliance is still pressurised.)
Food can be scooped out of the Inner Pot.
Pressure Release
Valve in “OPEN”
Position
PRESSURE COOKER PROGRAM LIST
Quick Select
Cooking
programs
Button
Ingredients Default
Time
Timer
Range
Default
Temp.
°C
Wide varieties of Meat,
e.g. Stew Lamb, Beef, Tendons, etc.
30 mins 1 min
~
2 hours
150
Wide varieties of soup and broth. 25 mins 1 min
~
40 min
150
Domestic birds, e.g. chickens, turkeys,
ducks, geese, guinea fowl, pigeons, quail
and pheasants.
13 mins 1 min
~
60 min
150
7

PRESSURE COOKER PROGRAM LIST
Quick Select
Cooking
programs
Button
Ingredients Default
Time
Timer
Range
Default
Temp.
°C
Add oil inside the Inner Pot. Temperature
many be adjusted between 30~180°C.
DO NOT cover Main Body with Lid.
30 mins 1 min
~
60 min
160
Rice, porridge and multigrain. 12 mins 1 min
~
20 min
150
Pour milk inside the cooking pot and it will
slowly turn into yoghurt in around 8 hours.
8 hours 6 hours
~
12 hours
40
Ideal for breaking down tough cuts of meat
or vegetables that would be accomplished
with long and slow cooking times.
2 hours 30 mins
~
24 hours
95
Vegetables (e.g. broccoli/ cauliflower/
green beans 8-10 min), fish fillets (12 min),
dumplings, egg & pasta (10 min) and
reheating.
10 mins 1 min
~
25 mins
150
Softening and caramelizing garlic, onions
and small pieces of food prior to pressure
or slow cooking. Add butter or oil, chopped
vegetables or meat inside the Inner Pot.
It can also be used to pre-heat the pot so
that other functions will begin more rapidly.
Temperature many be adjusted between
30~180°C.
DO NOT cover Main Body with Lid.
10 mins 1 min
~
60 min
150
Time/Temperature Button
Set or change the cooking time for all Quick Select Cooking programs and
temperature for Fry and Saute only.
Time Adjustment Button
Use to imput manually the required cooking time for all
Quick Select Cooking programs and temperature between 30~180°C for
Fry and Saute only.
Start/Delay Button
Use to start cooking.
Press for 5 seconds to delay cooking for up to 24 hours.
Keep Warm Button / Cancel Button
8

1.
2.
3.
4.
5.
6.
7.
Ensure that the power cable is unplugged from the wall socket and wait until the appliance
has cooled down completely.
Always clean cooking appliances soon after use. This will prevent food from sticking to the
appliance and reduce the possibility of bacterial growth. It will also reduce the likelihood of
the utensils being stained or discoloured.
Remove the Inner Pot and detach the Aluminium Plate from the Lid.
Disassembly of Aluminium Plate
Grip the Rubber Knob in the middle of the Aluminium Plate and pull outwards.
The Inner pot is covered with a non-stick coat. DO NOT use metal kitchen wares or abrasive
cleaning materials as these will damage the non-stick coat. Wash the Lid, Aluminium Plate
and Seal Ring, and Inner Pot using warm water with some dishwashing liquid on a
non-abrasive sponge to remove the oil and food residues. DO NOT use detergents or
chemicals like benzene, thinner, polishing powder, bicarbonate of soda, bleach etc.
The exterior of the Main Body, as well as the inside surface, can be cleaned with a damp cloth
making sure oily food residues are removed. Never immerse the Main Body in water or any
other liquid. Never use abrasive cleaning agents. Dry thoroughly with a soft dry cloth.
Keep the heating element at the bottom of the inside surface of the Main Body clean and
free from food debris.
Never run water over the appliance as malfunctions may occur if water seeps inside the
appliance.
Assembly of Aluminium Plate
Refit the Seal Ring around the edge of the Aluminium Plate.
Slot the Aluminium Plate back onto the post in the middle of the Lid.
Slot the Rubber Knob back onto the post on the Aluminium Plate.
Water Storage box
On the back of the Main Body under the hinge you will find the Water Storage Box.
Pull the Water Storage Box outwards off the mounting under the hinge.
Wash the Water Storage Box out with warm soapy water then dry with a soft cloth.
Slot the Water Storage Box back onto the underside of the hinge.
HOW TO CLEAN
Aluminium Plate
Rubber Knob Seal Ring
Aluminium Plate
Lid
Pull out the Aluminium Plate from the Lid. Pull the Seal Ring from the sides of the Aluminium Plate.
9

PROBLEM SOLVING
CODE
ERROR CODES
Action
E1
Open circuit for
sensor
E2
Short circuit of
sensor
E3
Overheating
occurred
E4
Signal switch
failure
Problem Possible Causes
Seal Ring not correctly
positioned around the
Aluminium Plate
How to Solve
Adjust the Seal RingLid does not close
properly.
No.
1.
Float Valve has not fallen to its
lowest position yet.
Ensure the pressure has
dropped to normal.
NEVER FORCE THE LID OPEN.
High pressure remains in pot Press the Pressure Release
Valve until pressure is lowered
Lid is difficult to
remove.
2.
Seal Ring absent Attach Seal Ring to Aluminium
Plate
Foreign matter on Seal Ring Clean the Seal Ring
Pressure cooker not tightly
closed
Close the Pressure cooker
(see steps 5 – 6 of ‘Using your
Appliance’)
Steam is released
under the Lid during
cooking.
3.
Foreign matter on Float Valve Clean the Float Valve
Abraded Float Valve gasket Replace Float Valve gasket
(by Service centre)
Air leaks from Float
Valve
4.
Too little food/liquid in Inner
Pot
Fill the Inner Pot with
food/liquid to a volume
between 1/5 & 4/5 of the
volume of the Inner Pot
Air leaked from Pressure
Release Valve
Repair Pressure Release Valve
(by Service centre)
Float Valve cannot
rise
5.
Pressure Release Valve not in
the correct position
Turn the Pressure Release Valve
in any direction to lower the
knob slightly
Pressure control is not working
correctly
Send appliance to Service
centre
Continuous leakage
of steam from
Pressure Release
Valve while in
operation
6.
Plug not tightly inserted the
grounded socket
Insert the plug into the d wall
socket firmly
Power light goes off7.
10

In the case where the installed thermostat malfunctions, the power supply will stop automatically
to prevent the pressure cooker from overheating. Numerous other safety devices are installed in
your pressure cooker, such as:
Anti-block safety device which prevents food from blocking the air outlet;
Pressure-control safety device automatically cuts the electric supply when the pressure reaches
pre-set parameters;
Temperature-control safety device automatically cuts the electric supply when the temperature
is abnormal and the inner pot becomes empty of fluids;
Over-heat safety device automatically cuts the electric supply when the thermostat reads an
unusually high temperature;
Limited-pressure safety device automatically discharges the excess pressure if the thermostat or
pressure-control device is not working; and
Pressure-relief safety device which prevents explosions when all other safety devices do not work.
In these cases, the pressure cooker has to be repaired by the service centre.
AUTOMATIC ELECTRICITY CUT-OFF FOR SAFETY
11

This appliance, along with all other electronic appliances, should, when it is no longer capable of
functioning, be disposed with the least possible environmental damage according to the local
regulations in your area. In most cases you can discard the appliance at your local recycling centre.
DISPOSAL: Do not dispose this appliance as unsorted municipal waste.
Collection of such waste separately for special treatment is necessary.
Risk of child or animal entrapment
Before you discard this appliance, please remove all doors and leave the shelves inside so that
children or animals may not easily get trapped inside.
ENVIRONMENTAL TIP
Warranty Conditions
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
This warranty provides against defective materials and manufacturing faults throughout for
two years from the date of purchase of the appliance. The warranty on the Compressor is 10
years subject to the same conditions as above.
This warranty also does not cover normal wear and tear, replacement of consumable
materials and accessories, and the cost of maintenance of the appliance.
This warranty does not cover the repair or replacement of part/s damaged by misuse,
accidents, negligence, alterations, or modifications in any way, or repairs done by any repair
organisation without the prior consent of PowerPac Electrical Pte Ltd.
Repair and service are to be performed at: 5 Changi South Lane #03-01 Singapore 486045.
A transport fee will be charged for personal doorstep service.
The original purchaser of the appliance must furnish proof of purchase to our Service Centre
with the email or number as registered during submission of warranty when this appliance is
sent for repair/service. Failure to do so may delay the receipt of said repair/service by the
customer.
Under no circumstances whatsoever shall the serial number be erased, defaced or altered by
the customer and/or his representatives, or the dealer and/or his agents. Failure to ensure
this shall invalidate the warranty.
This warranty is deemed to be void if the defect is cause by the attack of household pests,
fire, lightning, natural disasters, pollution, abnormal voltage or the usage of generators.
This warranty is valid in Singapore only.
This warranty will be honoured subject to the customer’s registration of the warranty
inclusive of original invoice or valid purchase receipt. Failure to present these documents will
result in denial of service. However, if the customer still requests that the defective appliance
be repaired, PowerPac Electrical Pte Ltd may, at its discretion, repair the appliance but impose
a labour charge, as well as the costs of the replacement parts, to be borne solely by the
customer.
Please refer to the attached picture for the location of one of our appliance’s serial number,
as an example.
Please complete the on-line registration warranty form available
on our website. There is no further requirement to send us any
hard copy as part of our efforts to save the environment.
In accordance with the terms and conditions of this limited
warranty as stated above, PowerPac Electrical Pte Ltd, at its
expense shall provide free services for the appliance within the
warranty period from its date of purchase from our Authorised
dealers.
WARRANTY
E-Register scan
12

MODEL PPC566
VOLTAGE 220-240V
FREQUENCY 50/60Hz
POWER 900 W
CAPACITY 5 Litre
PRESSURE 60 – 110 kPa
SPECIFICATION
13
