Powerplay PJR2000 User manual

1 en
www.powerplaypro.com
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARNING: To reduce the risk of injury, the user must read and understand the instructions
before using this product.
Customer Help Line
1-855-770-7529
PJR2000-92739-LR
Instruction Manual
Model PJR2000/
Model PJR2000C

en 2
5. Attach high pressure
hose to spray gun.
2
3
12
7
11
11A
8
9
10
0° - Red
25° - Green
Soap - Black
4
6
1
5
13
Package content:
1. Power washer unit
2. Manual
3. Nozzle cleaning wire (may be
taped to the manual)
4. High pressure hose
5. Spray gun holder
6. Nozzle tray
7. Screws (2)
8. Rotary nozzle
9. Quick connect nozzles (0°, 25°,
Soap)
10.Lance
11. Spray gun (11A shows trigger lock
button)
12.Garden Hose Adapter (Connect
to Garden Hose)
13.Stabilizer Foot
Quick Start Guide
1. Slide Gun holder on side. 2. Snap in place and screw
lance tray.
4. Swivel bottom cord hook right or left to easily
remove the power cord.
6. Remove high pressure
hose to spray gun.
3. Snap in place and screw
stabilizer foot in place.

3 en
OFF/0ON/I
OFF/0ON/I
7. Press front button in to lock the trigger. Press back
button to unlock trigger.
8. Connect lances to spray
gun, insert lance into spray
gun, push together and
at the same time twist
clockwise to lock in place.
Removing push together
and twist counterclockwise
then pull apart.
11. Fill detergent tank. Do
NOT use thick detergent
as it can clog the power
washer.
12. Adjust detergent
concentration by turning
left or right between
minimum and maximum.
13. Attach the“silver”
collar directly to the power
washer water inlet and
hand tighten.
14. Remove washer
lter, then using an
allen wrench, tighten
until snug. DO NOT over
tighten.
15. Replace the washer
lter.
16. Attach garden hose
to the blue collar.
17. Plug machine into a
grounded outlet, push
reset button. (US unit only)
19. Switch ON and OFF
positions.
Trigger Lock Trigger Unlock
9. Attach nozzle to lance
by pushing into place.
10. Remove nozzle by
pulling collar back on
lance and pulling out
nozzle.
18. Turn on water.
Adjust for detergent
concentration

en 4
SPecificationS
Model Max PSI
(lbs/sq/in)
Max GPM
(gal/per/min)
Max Temp Volts Amps Weight (lbs)
PJR2000/
PJR2000C 2,000 1.4 122° F 120 14 34
Limited Warranty
This product is under warranty to the original retail consumer against defects in material and
workmanship for a period of 1 (one) year and is a complete “bumper to bumper” warranty including
the spray gun, the high pressure hose and all accessories from the date of purchase. The
warranty is not transferable or assignable. This warranty covers replacement parts. This limited
one year warranty applies only to products used in consumer applications and is void in rental
or any commercial application. Reasonable care must be used in conformity with operation and
maintenance instructions in the owner’s manual and quick start guide. Failure to follow these
instructions will void this warranty.
Warranty ProceSS
Keep your original receipt of purchase in case of warranty claim.
If your power washer develops a problem, contact Customer Service by one of the two methods:
1. Send an e-mail to [email protected] with your name, address the model of your power
washer, when and where you purchased it. Describe in the e-mail the problem you are having. A
Customer Service person will contact you to resolve the problem.
2. Call our toll-free number at 1-855-770-7529. Customer Service is available Monday - Friday 8:00
a.m. to 5:00 p.m. Central Standard Time (CST). The Customer Service person will work with you
to x the problem.
If the power washer needs to be returned for repair, shipping costs to the company must be paid by
the customer. A Return Merchandise Authorization (RMA) Number will be issued for the return.
Upon receiving the power washer, the company will repair or replace the unit. We will send unit back
to customer at no charge.
Please note: Power washers sent to the company without an RMA Number will NOT be accepted
and shipped back at the expense of the sender.
tabLe of contentS
Quick Start....................................................... 2
Specications .................................................. 4
Limited Warranty ............................................. 4
Warranty Process ............................................ 4
Introduction...................................................... 5
Safeguard, Warnings & Safety Tips................. 5
Package Content............................................. 7
Unpacking & Assembly.................................... 8
Operating Instructions ................................... 13
How to Clean................................................. 14
Operating Tips and Maintenance................... 14
Storage.......................................................... 16
Pump Saver................................................... 17
Replacement Parts........................................ 18
Troubleshooting and FAQ.............................. 19

5 en
introduction
Congratulations on the purchase of your POWERPLAYTM POWER WASHER!
Your POWERPLAYTM POWER WASHER is a power tool in every sense of the word that may be
used outside your house and in. It is one of the nest most powerful home-use power washers in the
marketplace today.
Please familiarize yourself with the following assembly, operating and safety information. Read this
manual before using the power washer. Failure to follow these instructions could cause personal
injury, property damage, or both. Save this manual for other users to read prior to using the power
washer.
If you have any questions about or problems with your power washer please call our toll-free number
1- 855-770-7529 and talk with our Customer Service Support Team at POWERPLAYTM. We are
available to talk with you Monday through Friday from 8 a.m. to 5 p.m. Central Standard Time (CST).
We can help you with questions regarding operation, warranty, replacement or optional parts, or
contact us at i[email protected].
For more information on the POWERPLAYTM POWER WASHERS go to www.powerplaypro.com.
Power washers, parts, and accessories can be ordered online 24 hours a day, 7 days a week for your
convenience.
SafeGuardS, WarninGS and Safety tipS
• To avoid personal injury and/or damage
to property and to maximize your power
washing experience, carefully follow all of
the safety tips, instructions, warnings and
safeguards and become familiar with all of
the controls. Be sure you know how to quickly
bleed off the pressure from all parts of your
power washer, and how to turn off the power
washer .
• This power washer conforms to CSA and
other safety and consumer standards. Do
not modify or rebuild any part of your power
washer.
• Do not use your power washer when you are
under the inuence of alcohol or drugs. Use
this power tool carefully and only when you
are alert .
• Watch your balance and footing while using
your power washer. Surfaces become
slippery when wet and are extra slippery when
using a detergent or cleaner.
• Never operate the power washer in bare feet,
sandals, or open-toed shoes.
• When using the power washer near children
make sure they are closely supervised by an
adult to avoid injury. Never let a child use the
power washer.
• Keep ngers, hands, feet and any part
of your body clear of the stream of high
pressure water. The powerful spray can cause
blindness or blast holes in the skin. It can
break a window if you are too close when you
pull the trigger on the spray gun .
• Always wear eye protection to prevent injury
to eyes when operating the power washer.
• To avoid mishaps or injury, always use the
trigger safety lock when not using the power
washer even if the spraying stops for a
moment.
• The power washer is equipped with a Ground
Fault Circuit Interrupter (GFCI) which greatly
reduces the chance of electric shock while the
unit is in use.
• Point the spray gun in a safe direction when
beginning a power washing session.
• When rst using the spray gun, hold the spray
gun and lance with two hands when pulling
the trigger until you get used to the “kick
back” from the spray gun (one hand to pull
the trigger and the other to stabilize the gun
assembly).

en 6
• When you press the power switch to turn off
the power washer, water pressure may remain
in the system. To discharge the pressure,
point the spray gun in a safe direction and
pull the trigger.
• Never spray ammable liquids.
• Never use the power washer in areas that
contain combustible dust, liquids or vapors.
• Avoid contact of the pressure hose with sharp
objects and examine the hose regularly.
Replace if damaged. Due to the high pressure
involved, it cannot be repaired if cut of
damaged.
• Only use detergent specically formulated
for power washers and follow instructions
on the detergent’s label. We have a selection
of power washer detergents to choose from.
Go to www.powerplaypro.com for more
information and to order the detergents.
Power washer detergents are also available
at your local hardware store.
• Protect eyes, lungs, and skin from exposure
to detergent. Dish or laundry soap is too thick
and will clog the nozzle of your detergent
tank.
• IMPORTANT: Store the power washer
indoors to prevent the water in the unit
from expanding under freezing conditions.
When the water freezes and expands, your
power washer will be damaged and become
inoperable. Or, if storing outdoors, it is
recommended you use Pump Saver. Pump
Saver can be purchased on our website:
www.powerplaypro.com. See details in the
Pump Saver section of this manual.
• Never use hot water with your power washer.
It will overheat and damage the high pressure
pump.
• Never leave the power washer unattended
while it is powered “on”.
• Always turn the water supply “on ” before
turning the power washer power to “on”.
Running the pump dry will cause damage to
the internal components.
• Never use a water supply to your power
washer that exceeds 150 psi maximum.
• Never disconnect the high pressure hose
from the power washer while the system is
pressurized.
• Never permanently engage the trigger
mechanisms on the spray gun.
• Never operate the power washer unless
all components are properly and securely
connected.
• Never allow the power washer pump to run
for more than one minute, after you have
turned off the water supply. This can cause
the motor and pump to overheat and fail.
• Never use lances or other parts that have not
been supplied with your power washer.
• Never use an extension power cord since it
defeats the effectiveness of the GFCI and
increases the chance of electrocuting the
operator.
• Never spray any electrical outlet with your
power washer.
• Inspect the power cord before using. Do not
use it if it is damaged.
Servicing of a Double-Insulated Appliance
In a double-insulated product, two systems of
insulation are provided instead of grounding.
Grounding means are not provided for a double-
insulated product, nor should grounding means
be added to the product.
Servicing a double-insulated product requires
extreme care and knowledge of the system,
and should only be done by qualied service
personnel.
Replacement parts for a double-insulated
product must be identical to the original parts.
A double-insulated product is marked with the
words “Double Insulation” or “Double Insulated”.
Product may also be marked with symbol shown
here. (US unit only)
Double Insulated Product

7 en
Package content:
1. Power washer unit
2. Manual
3. Nozzle cleaning wire (may be taped to
the manual)
4. High pressure hose
5. Spray gun holder
6. Nozzle tray
7. Screws (2)
8. Rotary nozzle
9. Quick connect nozzles (0°, 25°, Soap)
10.Lance
11. Spray gun (11A shows trigger lock button)
12.Garden Hose Adapter (Connect to
Garden Hose)
13.Stabilizer Foot
Note - tool(s) required for
assembly Philip Screwdriver
and Allen Wrench:
2
3
12
7
11
11A
8
9
10
0° - Red
25° - Green
Soap - Black
4
6
1
5
13

en 8
UnPacking & aSSembLy
• After unpacking the POWERPLAYTM POWER WASHER, lay out parts and accessories.
Familiarize yourself with the parts in the package by comparing them to those listed on the
“PACKAGE CONTENTS” page.
• The POWERPLAYTM POWER WASHER requires some minor assembly. You’ll need a Phillips
screwdriver to install the high pressure hose hook and the nozzle tray.
NOTE: Some parts may or may not be already assembled.
• High pressure hose is stored on the hose reel. With the front of the power washer facing towards
you, insert the un-threaded end of the high pressure hose into the square hole on the inner reel
and begin turning the handle away from you. When nished winding, push the handle in to lock it
in place.
NOTE: The hose reel is only for storing the high pressure hose. The hose must be completely
removed from the hose reel each time you use the power washer.
• Slide the spray gun holder onto the left side of the washer when facing it. This does not require
any screws. (Fig. 1)
• Slip tab into slot and screw the nozzle tray on the bottom portion of the unit. (Fig. 2) When
placing the gun with the lance attached the nozzle will rest in this tray.
• Slip tab into slot and screw the stabilizer foot on the bottom portion of the unit on the side of the
power cord. (Fig. 3)
Fig. 2
Fig. 1
Fig. 3

9 en
• Easily remove the power cord from side of unit by swiveling the bottom cord hook to the right or
left until it faces up. The power cord then can be easily slid off of the side of the power washer
unit. (Fig. 4)
• Swivel cord hook back down when ready to wrap the cord back into place for storage.
High Pressure Hose
• High pressure hose is tted to the hose reel and ready to use, it only needs to be attached to the
spray gun (Fig. 5).
• Connect the other end of the high pressure hose to the spray gun by inserting the brass metal tip
of the high pressure hose into the tting just ahead of the trigger guard. It will lock into the spray
gun with a “click” (Fig. 6). Conrm the hose is locked into the spray gun by pulling slightly on the
hose. The hose is now securely attached to the spray gun.
• To release the hose from the spray gun, press the button on the underside of the gun toward the
trigger guard. The hose will slide out from the connection (Fig. 7).
Fig. 4
Fig. 7
Fig.6
Fig. 5

en 10
Spray Gun
• To lock the trigger of the spray gun pointing the gun away from you and push the lock button front
to lock, (Fig. 8), after doing so, squeeze or pull the trigger to make sure it is locked and will not
move. Always leave lock button in lock position when not in use. This ensures the gun is in “safe”
mode until it is ready for use.
Lance
• While the spray gun is in the locked position, insert the lance into the end of the spray gun by
inserting and pushing together turning clockwise simultaneously. To remove push together and
turn counter clockwise (Fig. 9).
• Attach nozzles into the end of the lance by pressing selected nozzle into place, it will make a click
sound when rmly in place (Fig. 10). To remove nozzle, pull back on the collar on the lance and
pull out the nozzle (Fig. 11).
Remember to always push the safety lock button to lock the trigger when changing lances and
nozzles, to ensure that they do not accidentally eject with force during removal.
• When using the turbo lance, make sure the nozzle is snapped on tight at the end of the lance,
each time you use it. The Turbo nozzle is designed for high impact cleaning. Only use on hard
surfaces such as driveways, cement surfaces, patio bricks, etc.
Fig. 8
Trigger Lock Trigger Unlock
Fig. 9
Fig.10 Fig.11

11 en
Always test a small area to avoid chance of damaging the surface. (Fig. 12)
IMPORTANT NOTE: When applying detergent use the soap nozzle.
• When using the detergent, ll it with a properly formulated detergent or cleaner with water ratio
according to instructions on the container (Fig. 13). The detergent tank comes with a straw which
is tted into the screw-on top. If you don’t see the straw, look inside the tank and attach it to the
screw-on top, close detergent tank when done lling.
• When removing the detergent tank remove lid and place nger on both sides of the bottle and
squeeze to get past the knobs on each side and pull out, press down rmly when putting it back in
place.
• The power washer will pull a ratio of water to detergent of 10:1 or 10 parts water to 1 part
detergent. The detergent concentration can be adjusted by turning the detergent knob on the front
of the machine. Turn it right for more concentration or turn it left for less concentration. (Fig. 14)
Fig. 12
Fig. 13
Adjust for detergent
concentration
Fig. 14

en 12
Garden Hose Adapter
• Attach the “silver” collar directly to the power washer water inlet and hand tighten. (Fig. 15)
• Remove washer lter, then using an 8mm or 5/16 allen wrench, tighten until snug. DO NOT over
tighten. (Fig. 16)
• Replace the washer lter and attach garden hose to the blue collar. (Fig. 17 & 18)
• You have now completed the assembly of your POWERPLAYTM POWER WASHER and are now
ready to begin using your electric power washer. Read and observe all safety instructions.
Fig. 15 Fig. 16
Fig. 17 Fig. 18

13 en
OFF/0ON/I
OFF/0ON/I
oPerating inStrUctionS
*!Turn on the water supply at the faucet.!* (Fig. 19)
Powering Up
• Make sure the “ON/OFF” switch is in the “OFF” position. The power switch has international
symbols for ‘on’ and ‘off’: On (|) Off (O), (Fig. 20).
• Unwind the power cord completely and plug the GFCI into a grounded 120 volt outlet. Press the
‘reset’ button on the GFCI box (Fig. 21). The indicator window should show a red color. This must
be done each time the unit is plugged in. (US unit only)
• Release the safety lock button on the spray gun by pressing the safety lock in the back under
the handle (Fig. 22). While pointing the spray gun in a safe direction, squeeze the trigger on the
spray gun until there is a steady stream of water, letting the water and air out of the hose. Press
the button in front to lock the trigger.
• Turn the power switch to the ‘ON’ (|) position. The unit will turn on for 1 - 2 seconds and shut off,
this is a normal function of the (TSS) auto start feature. Squeeze the spray gun trigger to begin
pressure washing.
• Squeezing rapidly will cause the (TSS) feature to miss an on/off cycle that may prevent from
turning on while squeezing trigger after rapid squeezing. Use slow deliberate trigger pulls to
avoid such symptoms.
Fig. 20
Fig. 19
Fig. 21 Fig. 22
Trigger Lock Trigger Unlock

en 14
HoW tocLean
Cleaning nozzles
• A clogged or partially clogged nozzle can cause signicant reduction of water pressure coming out
of the nozzle and/or cause the unit to pulsate while spraying.
• Turn off the unit
• Turn off the water supply to the unit
• Relieve any pressure trapped in the hose by squeezing the trigger 2-3 times, and then lock the
spray gun by pushing the lock button from left to right.
• The screens inside the adapter should be cleaned periodically. Rinse it with clean water, and then
place it back in the adapter.
• Using the nozzle tip cleaner provided (or an unfolded paper clip), insert the wire into the nozzle
hole and move back and forth until debris is dislodged (Fig. 23). Back ush water through the
nozzles using garden hose and highest pressure available (either standard water nozzle or use
your thumb over the nozzle to create water pressure for back ush).
oPerating tiPS and maintenance
• If you hear the motor run intermittently when the trigger is not being squeezed, that is normal. The
pump is priming itself so it is ready to operate when the trigger is squeezed. Turn off the power
washer if not being used after ve minutes.
• The o-rings on the bayonet end of the lance should be cleaned regularly and lubricated with non-
water soluble grease such as petroleum jelly.
• Keep the nozzle cleaning wire, Which is taped to this manual for use in unclogging the lance
nozzle. If you lose the cleaning wire an unbent paper clip works ne.
How to Avoid Damaging Surfaces
• Damage to surfaces being cleaned occurs because the impact force of the water pressure
exceeds the durability of the surface. Bare wood can be penetrated; paint can be peeled off, etc.
You can vary the force of your power washer by controlling:
a. the angle of the surface being cleaned
b. the distance of the nozzle from the surface being cleaned
Fig. 23

15 en
• Never use a narrow high pressure stream of water or the turbo lance on soft surfaces susceptible
to damage.
• Use the 25° angle quick connect nozzle when cleaning windows. Be sure to place the nozzle
approximately four to ve feet away from the window with the nozzle at forty ve degree angle.
Squeeze the trigger and vary the spray pattern and angle until optimum cleaning efciency is
achieved.
Detergent Injector/Storage
• Use detergents designed for power washers. We offer four (4) power washer detergents,
Auto, Motorcycle, Boat and Universal. These can be purchased online at our website www.
powerplaypro.com. Hardware stores or home centers also have power washer detergents for
different cleaning projects. The cleaning solution should be the consistency of water in order to
prevent clogging your detergent tank and nozzle.
• This system applies detergent under low pressure. The cleaning power of the detergents
is enhanced when applied with low pressure; and time is allowed to break down the dirt
and grime. The combination of low pressure and chemical action is very effective and can
be better than scrubbing if applied properly. Always spray detergent on a dry surface, do
not pre-soak area. Wetting the surface rst dilutes the detergent and reduces its cleaning
ability. Do not allow detergent to dry on surface. On vertical surfaces being cleaned, apply
detergent to lower surfaces and work your way up to prevent detergent from causing
streaks in the dirt and grime. Rinse detergent by pressure washing from bottom up for
same reason.
• If a stain is particularly tough, it may be necessary to reapply the detergent and use a bristled
brush to scrub the stain. Subsequent power washing after brushing should successfully complete
your cleaning job.

en 16
Storage
• Remove lance from the gun and place in the accessory holder. Place the gun in the accessory
holder one the side. Lances are placed into any of the slots in the back of the unit. Make sure to
discard any remaining detergent from the tank. Flush the tank and nozzle head with fresh water
to prevent clogging.
• When your pressure washing session has been completed, turn off the power switch located on
the front of the power washer. Unplug the power cord from the outlet. Turn off the water supply.
Pull the trigger on the spray gun 2-3 times to drain out the excess water and to release any
remaining water pressure. Disconnect the garden hose adapter from the water inlet. Do not allow
the power washer to run with no water owing through it.
• Remove detergent tank and clean completely. Residual chemical will stick to the container and
can cause the detergent injector to clock and not function properly.
• Remove high pressure hose from spray gun and unscrew the other end of the high pressure hose
from the power washer.
• Wrap the power cord around the L-shaped tabs on the right side of the machine when facing it.
• The pressure hose is stored on the hose hook located on the back of the handle.
• DO NOT store the power washer where it is exposed to freezing temperatures unless
you use Pump Saver. It is recommended that you use Pump Saver for storing in freezing
temperatures. Freezing will damage the pump unless Pump Saver is added to the power washer.
If not using or if storing your power washer for more than one month, run Pump Saver through it.
See the section on Pump Saver for more information.

17 en
PUmP Saver
Pump Saver is a product that protects and prolongs the life of the pump. This will keep the internal
parts of the pump lubricated and protected from freezing while being stored in ALL climates. It also
assists with protection from internal corrosion.
Order online at www.powerplaypro.com
Pump Saver Instructions
Follow the previous storage instructions for your power washer. To prevent staining, protect the
surface under the power washer from any excess uid. Wear eye protection when using this product.
1. Turn off your power washer.
2. Disconnect garden hose.
3. Shake the bottle well before connecting to the power washer.
4. Screw the garden hose adapter to the Pump Saver Bottle.
5. Click onto pump inlet (clear quick connect lter).
6. Turn the valve on the bottle to the open position.
7. Turn the power washer on. Turn the power washer off as soon as the Pump Saver uid begins
to exit the water outlet - nozzle.
8. Turn the valve on the bottle to the off position and remove the Pump Saver bottle valve
assembly from the power washer.

en 18
rePLacement PartS
Pos. Description Part Number Qty.
1 Detergent Tank PW3440710 1
2 Hose (QC) PW4220670 1
3 Spray Gun PW4100782 1
4 Rotary Nozzle PW4220680 1
5 Quick Connect Nozzle 0° - Red PW4220700 1
6 Quick Connect Nozzle 25° - Green PW4220710 1
7 Quick Connect Nozzle Soap - Black PW4220690 1
8 Lance PW4220720 1
9 Garden Hose Adapter PW3084210 1
10 GFCI Assembly (US unit only) PW3084330 1
Pump Spare Part Kits
Water Seals & Valves PW4220640 1
Pre-Assembly TSS PW4220730 1
O-Ring Kit PW909104K 1
1
2
3
10
9
4
8
0° - Red
25° - Green
Soap - Black
5
6
7

19 en
troUbLeSHooting and faQS
Unit will not turn on. Make sure the power washer is in the “OFF” position. Plug in the
electrical cord to a grounded 120 volt outlet (no electrical extension
cord should be used). If the electrical cord will not plug into your
outlet, your electrical outlet is not properly grounded and should not be
used. Use another electrical outlet. Press the reset button on GFCI
power box. If the color of red is not visible in the little window on the
GFCI, unplug and plug in again. Press reset, and look for the red color
in the window, this should remain red in color. If the color is staying
red, turn the power switch on the power washer to “ON”. Squeeze the
trigger on the spray gun and try again.
If this did not correct the problem, try plugging into another electrical
outlet and repeat the above procedure. If it is still not working, call
Customer Service at 1-855-770-7529.
The high pressure (HP)
hose will not connect /
stay connected to the
spray gun. Is this a
spray gun problem?
In most cases, the spray gun is not the problem. The problem is the
rubber sleeve covering the tting at the end of the high pressure hose.
It has likely slipped up toward the metal tip. The x: wiggle, twist and/
or pull the rubber sleeve down until the entire tip is visible plus an 1/8”
of the metal tting below the tip. Now try to insert the hose tip into the
spray gun. It should “click” into place and will not come out until the
hose is released by pushing in the lever on the underside of the gun.
You may cut away the end of the sleeve with a sharp knife if unable to
move the sleeve down. Be careful not to cut or puncture the hose.
The unit is running but
there is not water ow.
Check the water source. Unclog the nozzle on the lance. (See nozzle
cleaning instructions under “Cleaning nozzles”.) Or take off the lance
and just spray out of the spray gun. This will indicate if the problem is
with the lance.
Why is water leaking
where the high pressure
hose connects to the
spray gun?
Make sure there is an o-ring at the end of the metal tip of the high
pressure hose. If no o-ring is present, the connection between the
hose and spray gun will leak. O-Ring Kits are available online at www.
powerplaypro.com or call Customer Service at 1-855-770-7529 to
place an order.
I can’t remove the lance
from the spray gun.
What should I do?
All lances and the detergent tank are attached and removed from the
spray gun in the same manner. Insert the quick-release end of the
lance/detergent tank into the spray gun. Press the spray gun and
lance together (about a 1/8”) and turn clockwise. The lance will lock
in place. Remove the lance by reversing this procedure. Press the
spray gun and lance together and turn counter clockwise. The lance
will slide out. Or, hold the spray gun and lance in an upright position
with the nozzle end on the oor. Push the whole assembly straight
down to loosen the connection, and then follow the removal process
again. You may also spray soapy water or a lubricant in the area
where the lance connects to the spray gun.
The power washer turns
on for 2 seconds, shuts
off, and will not turn
back on. Do I have a
defective unit?
It sounds like your power washer is working just ne. When the water
is connected, the accessories are assembled properly, and the power
switch is turned on, the power washer may turn on for 1 - 2 seconds to
prime the pump. It automatically shuts off and waits for the spray gun
trigger to be pressed. When the trigger is pressed, water starts owing
through the pump. The water sensor in the pump “senses” the moving
water and automatically turns the power washer on. Or, turn the power
switch to off, hold in the trigger on the spray gun, so that you have a
steady stream of water. While you are holding the trigger open on the
spray gun, at the same time, turn the power switch on.

en 20
www.powerplaypro.com
Customer Help Line
1-855-770-7529
Cleaning and troubleshooting tips, manuals and other helpful information are available on our
website. For parts and accessories for your POWERPLAYTM Washer, visit www.powerplaypro.com.
Ordering is easy and all major credit cards are accepted.
PowerPlay
117 Ave Gun
Pointe-Clare, QC H9R 3X3
Canada
Phone: [phone]
Email: [email protected]
Website: www.powerplaypro.com
Model PJR2000/
Model PJR2000C
