PowerPoint P21390XBSS Installation and operating instructions

Cod:0103089649-00.01
P21390XBSS
Extractors
Installation, use and maintenance

3
Using your Extractor
For best performance, you should switch on the extractor 15 minutes before starting to cook and leave it to run
for approximately 15 minutes after the end of cooking.
Control Panel
B – Speed level buttons
C – Light button
Press button C.
To switch on the extractor or change the motor speed at any time when the extractor is running
Press the relevant speed button (B) for the first, second or third speed as required.
Press button A.
Fig. 1 A B C

Care and Maintenance
IMPORTANT : DO NOT PERFORM MAINTENANCE OR CLEANING
OF THE EXTRACTOR WITHOUT FIRST SWITCHING OFF THE
ELECTRICITY SUPPLY.
Cleaning
You should use a nonabrasive cleaner. Any abrasive cleaner (including
Cif) will scratch the surface and could erase the control panel markings.
solution of water and mild detergent and drying to a shine with a clean
cloth.
The grease filter should be kept clean to minimise the risk of fire.
At least once a month you should remove and clean the grease
filter with hot soapy water. You can also wash the grease filter in a
dishwasher, ensuring that you place it in an upright position to prevent
damage from other items in the dishwasher. After rinsing and drying,
replace the filter.
To remove the grease filter, push in the button on the handle and then
pull down on the filter at the front. When you have released it at the
front, then you can pull out the filter. To replace the grease filter, repeat
the steps in reverse.
Please note:
Cleaning the grease filter in the dishwasher may lead to discolouration.
This is normal and does not constitute a fault with the appliance.
Fig. 2
4

In re-circulating mode, air is vented back into the kitchen through the
opening in the cooker hood.
This method is advised if you are not using your hob intensively.
Re-circulated air requires the use of charcoal filters to remove odours.
Charcoal filter installation
Care and Maintenance
IMPORTANT: DO NOT ATTEMPT TO MAINTAIN OR CLEAN THE
EXTRACTOR WITHOUT FIRST SWITCHING OFF THE ELECTRICITY
SUPPLY.
Fig. 3-I
Fig. 3-II
Fig. 3-III
To ensure the best performance from your cooker hood, the charcoal
filter should be replaced every 3-6 months, dependent on use.
Check with your local retailer or dealer for information on how to obtain
replacement charcoal filters.
Note: This charcoal filter is non-washable and must be replaced as
required. To install a new charcoal filter, first remove the grease filter,
as shown in Fig.3.
5

6
IMPORTANT: DO NOT PERFORM MAINTENANCE
OR CLEANING OF THE EXTRACTOR WITHOUT FIRST
SWITCHING OFF THE ELECTRICITY SUPPLY.
The light is designed for use during cooking and not for general room
illumination. Extended use of the light can reduce the life span of the
lights.
Please contact your local retailer or dealer in order to purchase a new
LED lamp when replacing a damaged or faulty lamp.
Please note that the LED lamp is not covered by the guarantee.
Remove the lamp using a flat-head screwdriver(Fig.4-I).
NOTE: LED lights replacement must be done by a
qualified electrician.
Pull out the lamp. Unplug the lamp wire connector. Replace the lamp
(Fig.4-II).
Plug wire connector with new lamp. Put the new lamp into lamp holder.
Push the LED lamp into the hole with sound of snap (Fig.4-III).
1X1.5W LED MAX
Fig. 4-I
Fig. 4-II
Fig. 4-III

7
FUSE 3A
PROTECTION LINE
3A Fuse is installed inside the plug to protection line.
26.5W
230-240V ac, 50Hz

8
Warranty Information
Registering Your 2 Year Guarantee
Exclusions
Your standard one year guarantee is extended for an additional 1 year when you register the product within 28 days of
purchase with the supplier Shomar Ltd. If you do not register the product with Shomar Ltd within 28 days, your product is
guaranteed for 1 year. To validate your 2 year guarantee register with us by visiting www.powerpointappliances.ie .
One Year Guarantee
It is important to retain the retailer’s receipt as proof of purchase. Staple your receipt to this back cover for future reference.
Subject to the exclusions set out below (see Exclusions), the faulty appliance will then be repaired or replaced. If for any
reason, this item is replaced during the guarantee period, the guarantee on the new item will be calculated from original
purchase date. Therefore it is vital to retain your original till receipt or invoice to indicate the date of initial purchase.
To qualify for the 1 year guarantee, the appliance must have been used according to the instructions supplied.
Contact Details
The After Sales Division for PowerPoint Appliances is located at the oces of the Brand owner and Distributor –
Shomar Ltd, Unit 9 Western Industrial Estate, Dublin 12, Republic Of Ireland.
Helplines (oce hours) & Spare Parts contact number is 01-450 5327 or email [email protected]
Shomar Ltd shall not be liable to replace or repair the goods under the terms of the guarantee where:
1. The fault has been caused or is attributable to accidental use, misuse, negligent use or used contrary to the manufacturer’s
recommendations or where the fault has been caused by power surges or damage caused in transit.
2. The appliance has been used on a voltage supply other than that stamped on the products.
3. Repairs have been attempted by persons other than our service sta.
4. The appliance has been used for hire purposes or non-domestic use.
5. The appliance is second hand.
This guarantee does not confer any rights other than those expressly set out above and does not cover any claims for
consequential loss or damage. This guarantee is oered as an additional benefit and does not aect your statutory rights as a
consumer. This guarantee is valid in Ireland and the UK only.
PowerPoint appliances products are intended for household use only. See usage limitations in “safety instructions”. Shomar
Ltd has a policy of continuous improvement in product quality and design. The company, therefore reserves the right to
change the specification of its models at any time.

5
6
A
B
C*
D
E
F
P21390XBSS
15.5
94
79
86.5
75
Height dependent
For best performance and lowest noise output, we recommend
use of 150mm ducting for P21390XBSS models.
9
5
C
E
F
D
Centre
B
A
Gas: 750mm recommend
Electric: 650mm recommend

INSTALLATION
)2elbatees(deriuqersallawkraMderiuqerslooT
sgnixfiynatahterusnE-swercspotdnasgnixfillawtiFselohllirD
you use are appropriate for the wall type.
)swercsllanethgit(dooheruceS
IMPORTANT SAFETY WARNING: ONLY USE THE SCREWS PROVIDED WITH THE EXTRACTOR TO MOUNT
THE DUCTING ADAPTOR. THE USE OF LONGER SCREWS MAY CAUSE DAMAGE TO THE INTERNAL WIRING
WHICH WILL NOT BE COVERED BY THE WARRANTY.
8
10mm
10

Fig. 13
)tniojlaes(gnitcudxiFstekcarbyenmihctnuoM
yenmihcehterucesdnatsujdAyenmihcehttnuoM
Fig. 12
The metal casing of this appliance has been coated with a preservative to protect it during transport and storage.
This should be removed during installation by using a non-abrasive stainless steel cleaner. Always follow the
instructions given with the cleaner being used.
11

Attribute Symbol Value Units
Model identification P21390XBSS
Annual Energy Consumption AECHood kWh
Time increase factor f
FDEHood
EEIHood
Measured airflow at Best QBEP m3/h
Measured Pressure at Best PBEP Pa
Maximum airflow QMAX m3/h
Measured electric power at Best WBEP W
Nominal lighting power WL W
Average illumination of the
lighting system on the cooking
surface
EMiddle Lux
Measured power consumption in
standby
PSW
Measured power consumption POW
Sound power level LWA dBA
GFEHood %
LEHood %
12
16.2
1.7
9.2
54.9
158.4
51
277.9
24.3
1.5
98
---
0
65
61.2(E)
65(A)
