Matrix MEH Reference manual

Cod:0103086542-00.03

Declarations of Conformity:
This appliance has been manufactured to comply with all EU & UK
statutory requirements and complies with all applicable legislation
and the following European Directives:
t5IF-PX7PMUBHF%JSFDUJWF&6
t&MFDUSPNBHOFUJD$PNQBUJCJMJUZ%JSFDUJWF&6
5IFQSPEVDUIBTCFFONBSLFEXJUIUIF6,$"BOE$&TZNCPMT

3
Parts intended to come into contact with food conform to 1935/2004/
EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both
energy and resources. As a reminder of the need to dispose of
household appliances separately, the product is marked with a
crossed-out wheeled dustbin.
Please note:
• Under no circumstances should the extractor be connected to any
gas ventilation system, flue system or hot air ducting system.
• Do not vent the extractor into an attic or loft space.
• Only house the extractor in rooms with adequate ventilation.
Remember that the extractor is powerful and whatever air is
extracted needs to be replaced.
• Do not tile the extractor in. It should be removable for service or
maintenance.
• Do not use silicone sealant to secure the hood to the wall.
• You must be able to isolate the extractor from the mains electrical
supply after installation.
• Steam cleaners must not be used when cleaning this appliance.

4
• The performance of your extractor will vary depending on a
number of factors. These include: type of extraction, length of
ducting, room volume, ventilation available and cleanliness of the
filters.
Using your extractor
For best performance, you should switch on the extractor 15 minutes
before starting to cook and leave it to run for approximately 15 minutes
after the end of cooking.
Control Panel
A = Power off button B = Speed level buttons C = Light button
To switch the extractor light on or off
• Press button C.
To switch on the extractor or change the motor speed at any time
when the extractor is running
• Press the relevant speed button (B) for the first, second or third speed
as required.
To switch the extractor off
• Press button A.
Fig. 1 A B C

5

6
Replaceable (LED only) light
source by an end-user
LED LED
E14 LED 4Wx2
DR-4-H-E14-37

7

8
Mains Electricity Connection
THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY
A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE
SWITCHED FUSE SPUR OUTLET AND PROTECTED BY A 3A FUSE.
Warning! This appliance must be earthed
We recommend that the appliance is connected by a qualified
electrician, who is a member of the N.I.C.E.I.C. and who will comply
with the I.E.T. and local regulations.
The wires in the mains lead of this appliance are coloured in
accordance with the following code:
Green &Yellow = Earth, Blue = Neutral, Brown = Live.
As the colours of the wires in the mains lead for the appliance may
not correspond
to the coloured markings identifying the terminals connecting to the
fuse spur,
proceed as follows:
• The wire which is coloured green and yellow must be connected to
the
terminal marked E (Earth) or coloured green.
• The wire which is coloured blue must be connected to the terminal
marked
N (Neutral) or coloured black.
• The wire which is coloured brown must be connected to the terminal
marked
L (Live), or coloured red.

9
Note: Use a 3A Fuse
Assembly and electrical connection should be carried out by
specialised personnel.
When installing this product we recommend you seek the help of
another individual.
Do not mount the isolation switch behind the chimney section. It is a
requirement that you must be able to isolate the extractor from the
mains electrical supply after installation.
This appliance is intended to be connected to the mains electrical
supply by means of an isolation switch and fused spur and is
intended to be protected by a 3A fuse. The use of a 13A fuse can
cause damage to the internal wiring in the event of a fault, and may
also invalidate the warranty.
DOUBLE POLE SWITCHED
FUSE SPUR OUTLET
USE A 3 AMP FUSE
Fig. 3

10
Mounting your extractor
When the extractor is to be installed
above an electric hob, the minimum
distance between the hob and
extractor must exceed 600mm (650mm
is recommended).
When the extractor is to be installed
above a gas hob, the minimum
distance between the hob and
extractor must exceed 700mm (750mm
is recommended).
* The actual height of C depends
on the height of the ceiling and the
position of the hob.
Iftheinstructionsprovided with yourgas
hob state that the required distance
between the hob and extractor must
be greater than 700mm, then that is the
distance that should be observed; this
is a legal requirement and may lead to
your hob being disconnected from the
gas supply and the installation being
reported under RIDDOR (The height
should be measured from the top of
the burners).
Fig. 4
Gas: 750mm recommended.
Electric: 650mm recommended.
MEH601 MEH901 MEP601/901
A60.5 60.5 53.5
B120.5 120.5 169.5
C* 725 max 725 max 550
D175 200 105
E75 75 75
F80 80 73
Fig. 5

11
IN THE ABSENCE OF ANY INSTRUCTIONS SUPPLIED WITH THE GAS
HOB, THE MINIMUM DISTANCE BETWEEN THE HOB AND EXTRACTOR
MUST BE AT LEAST 760mm.
The width of any hob must not be greater than the width of the extractor
installed above it (Fig. 4).
Ducting and Ventilation
For best performance and lowest noise output, we recommend the
use of 125mm ducting. You can also use 100mm ducting but this will
reduce performance.
Wherever possible utilise rigid circular pipe which has a smooth
interior, rather than the expanding concertina type ducting. The
lengths of the ducting without performance being affected are as
follows:
• 4 metres with 1 x 90° bend.
• 3 metres with 2 x 90° bends.
• 2 metres with 3 x 90° bends.
Longer ducting can be used but the performance of the extractor will
likely be reduced.
Please note: Ducting components and ducting kits are optional
accessories and have to be ordered, they are not automatically
supplied with the hood. Use of ducting less than 125mm in diameter
will affect performance and increase the noise produced by the
extractor.

12
Installation steps
Fig. 6 Fig. 7
Fig. 9
Fig. 10 Fig. 11
Tools required Mark wall as required (see table 2)
Fit wall fixings and top screws -
Ensure that any fixings you use are
appropriate for the wall type.
Secure hood (tighten all screws)
IMPORTANT SAFETY WARNING: ONLY USE THE SCREWS PROVIDED
WITH THE EXTRACTOR TO MOUNT THE DUCTING ADAPTOR. THE USE
OF LONGER SCREWS MAY CAUSE DAMAGE TO THE INTERNAL WIRING
WHICH WILL NOT BE COVERED BY THE WARRANTY.
Drill holesDrill holes
Fig. 8
Fit ducting adaptor

13
9
Fig. 13
Fig. 14 Fig. 15
Fix ducting (seal joint)
Mount the chimney Adjust and secure the
chimney
Fig. 12
The metal casing of this appliance has been coated with a
preservative to protect it during transport and storage. This should
be removed during installation by using a non-abrasive stainless
steel cleaner. Always follow the instructions given with the cleaner
being used.
Fix ducting (seal joint)
Mount the chimney Adjust and secure the chimney
Mount chimney brackets
st an

14
NOTES:

15
Attribute Symbol Units
noitacifitnedIledoM
Annual Energy Consumption AECHood kWh
Time increase factor f 1.6 1.6 1.7
Fluid Dynamic Eciency FDEHood
Energy Eciency Index EEIHood 84.1
Measured airflow at Best Eciency
Point
QBEP m3/h
Measured Pressure at Best Eciency
Point
PBEP 172.0 200 184.0 Pa
QwolfriamumixaM MAX 382.3 372.1 m3/h
Measured electric power at Best
Eciency Point
WBEP 91.8 91.6
Nominal lighting power WL 8
Average illumination of the lighting
system on the cooking surface
EMiddle
Measured power consumption in
standby
PSNA NA NA W
Measured power consumption o
mode
PO0.0 0.0 0.0 W
Sound power level LWA 67.0 70.0 69.0 dBA
Grease Filter Eciency GFEHood 63.4 (E) 64.2 (E) 66.4 (D) %
ELycneiciffepmaL Hood
Energy Efficiency Information
Value
MEH601 MEH901 MEP601/901
59 58.8 64.2
11.5 11.6
181.8
9.6
83.9 88.1
190.3220.9
336.4
96.6 W
W8 8
Lux114 114 114
14.3(D) 14.3(D) 14.3(D) %
