Dustbane Hurricane 400 XTT User manual

Dustbane Products Ltd., 1000 Last Mile Dr., Ottawa, ON K1G 6Y1 • Tel: [phone] Fax: [phone] www.dustbane.ca
Hurricane 400 XTT
Quick Guide
This guide is intended for quick consultation only and does not replace the user and maintenance
manual. Before using this machine, read the user maintenance manual contained in the machine’s
packaging and follow all the instructions.
PREPARATION AND OPERATION
This guide is intended for quick consultation only and does not replace the user and maintenance manual.
Before using the machine, read the user and maintenance manual contained in the machine’s packaging thoroughly and strictly follow all the
instructions.
PREPARATION & OPERATION
CT40-55-70 B Quick guide
1
5
2 3
64
PLDC01846
HO
2
ON
CHEM
H
2
O
+
HO
2
This guide is intended for quick consultation only and does not replace the user and maintenance manual.
Before using the machine, read the user and maintenance manual contained in the machine’s packaging thoroughly and strictly follow all the
instructions.
PREPARATION & OPERATION
CT40-55-70 B Quick guide
1
5
2 3
64
PLDC01846
HO
2
ON
CHEM
H
2
O
+
HO
2
This guide is intended for quick consultation only and does not replace the user and maintenance manual.
Before using the machine, read the user and maintenance manual contained in the machine’s packaging thoroughly and strictly follow all the
instructions.
PREPARATION & OPERATION
CT40-55-70 B Quick guide
1
5
2 3
64
PLDC01846
HO
2
ON
CHEM
H
2
O
+
HO
2
This guide is intended for quick consultation only and does not replace the user and maintenance manual.
Before using the machine, read the user and maintenance manual contained in the machine’s packaging thoroughly and strictly follow all the
instructions.
PREPARATION & OPERATION
CT40-55-70 B Quick guide
1
5
2 3
64
PLDC01846
HO
2
ON
CHEM
H
2
O
+
HO
2
1
4
2
5
3
6
Add water and chemical to tank.
Pull squeegee lever to lower.
Power on.
Pull lever to activate.
Press lever pedal to move the brush up
and down.
Press once to turn water ON or OFF.
This guide is intended for quick consultation only and does not replace the user and maintenance manual.
Before using the machine, read the user and maintenance manual contained in the machine’s packaging thoroughly and strictly follow all the
instructions.
PREPARATION & OPERATION
CT40-55-70 B Quick guide
1
5
2 3
64
PLDC01846
HO
2
ON
CHEM
H
2
O
+
HO
2
This guide is intended for quick consultation only and does not replace the user and maintenance manual.
Before using the machine, read the user and maintenance manual contained in the machine’s packaging thoroughly and strictly follow all the
instructions.
PREPARATION & OPERATION
CT40-55-70 B Quick guide
1
5
2 3
64
PLDC01846
HO
2
ON
CHEM
H
2
O
+
HO
2

REPLACING THE SQUEEGEE BLADES
ATTACHING/REMOVING THE BRUSHES
Open the clip (Ref. 1).
Remove the two blade retainers (Ref. 2) by pushing them outwards then extracting them.
Remove the blade.
Reuse the same blade by reversing the edge in contact with the oor until all four edges are worn out, or replace with a new blade, tting it onto the
screws on the body of the squeegee.
Reposition the two blade pressing devices by centering the wider part of the slots on the squeegee body fastening pins, then push the blade pressing
devices inwards.
Close the hook again.
Replace the squeegee on its support, following the instructions described previously.
Attaching the brush: rest the brush on the oor in front of the machine and centre it with the guard. Lower the head and operate the brush/drive lever repeatedly until the brush automatically
engages on the ange hub. If the operation is not successful, repeat by pressing on the lever again and repeating the centring.
Removing the brush: raise the machine head by pushing the head lift pedal down and then to the right and operate the brush/drive lever repeatedly. After operating the lever a few times, the brush
is released and falls to the ground.
DAILY MAINTENANCE
Clean the dirty
water tank.
Check the suction lter is
undamaged and clean.
Check that the
detergent outlet lter
is clean.
Check that the brush
is clean. Replace if
necessary.
Check that the
squeegee is clean
and the blades are not
worn.
PLDC01846
1
2
BATTERY CHARGER ON BOARD
24V
BATTERY CHARGER STAND ALONE
REPLACING THE SQUEEGEE BLADES
ATTACHING/REMOVING THE BRUSHES
Open the clip (Ref. 1).
Remove the two blade retainers (Ref. 2) by pushing them outwards then extracting them.
Remove the blade.
Reuse the same blade by reversing the edge in contact with the oor until all four edges are worn out, or replace with a new blade, tting it onto the
screws on the body of the squeegee.
Reposition the two blade pressing devices by centering the wider part of the slots on the squeegee body fastening pins, then push the blade pressing
devices inwards.
Close the hook again.
Replace the squeegee on its support, following the instructions described previously.
Attaching the brush: rest the brush on the oor in front of the machine and centre it with the guard. Lower the head and operate the brush/drive lever repeatedly until the brush automatically
engages on the ange hub. If the operation is not successful, repeat by pressing on the lever again and repeating the centring.
Removing the brush: raise the machine head by pushing the head lift pedal down and then to the right and operate the brush/drive lever repeatedly. After operating the lever a few times, the brush
is released and falls to the ground.
DAILY MAINTENANCE
Clean the dirty
water tank.
Check the suction lter is
undamaged and clean.
Check that the
detergent outlet lter
is clean.
Check that the brush
is clean. Replace if
necessary.
Check that the
squeegee is clean
and the blades are not
worn.
PLDC01846
1
2
BATTERY CHARGER ON BOARD
24V
BATTERY CHARGER STAND ALONE
REPLACING THE SQUEEGEE BLADES
ATTACHING/REMOVING THE BRUSHES
Open the clip (Ref. 1).
Remove the two blade retainers (Ref. 2) by pushing them outwards then extracting them.
Remove the blade.
Reuse the same blade by reversing the edge in contact with the oor until all four edges are worn out, or replace with a new blade, tting it onto the
screws on the body of the squeegee.
Reposition the two blade pressing devices by centering the wider part of the slots on the squeegee body fastening pins, then push the blade pressing
devices inwards.
Close the hook again.
Replace the squeegee on its support, following the instructions described previously.
Attaching the brush: rest the brush on the oor in front of the machine and centre it with the guard. Lower the head and operate the brush/drive lever repeatedly until the brush automatically
engages on the ange hub. If the operation is not successful, repeat by pressing on the lever again and repeating the centring.
Removing the brush: raise the machine head by pushing the head lift pedal down and then to the right and operate the brush/drive lever repeatedly. After operating the lever a few times, the brush
is released and falls to the ground.
DAILY MAINTENANCE
Clean the dirty
water tank.
Check the suction lter is
undamaged and clean.
Check that the
detergent outlet lter
is clean.
Check that the brush
is clean. Replace if
necessary.
Check that the
squeegee is clean
and the blades are not
worn.
PLDC01846
1
2
BATTERY CHARGER ON BOARD
24V
BATTERY CHARGER STAND ALONE
REPLACING THE SQUEEGEE BLADES
ATTACHING/REMOVING THE BRUSHES
Open the clip (Ref. 1).
Remove the two blade retainers (Ref. 2) by pushing them outwards then extracting them.
Remove the blade.
Reuse the same blade by reversing the edge in contact with the oor until all four edges are worn out, or replace with a new blade, tting it onto the
screws on the body of the squeegee.
Reposition the two blade pressing devices by centering the wider part of the slots on the squeegee body fastening pins, then push the blade pressing
devices inwards.
Close the hook again.
Replace the squeegee on its support, following the instructions described previously.
Attaching the brush: rest the brush on the oor in front of the machine and centre it with the guard. Lower the head and operate the brush/drive lever repeatedly until the brush automatically
engages on the ange hub. If the operation is not successful, repeat by pressing on the lever again and repeating the centring.
Removing the brush: raise the machine head by pushing the head lift pedal down and then to the right and operate the brush/drive lever repeatedly. After operating the lever a few times, the brush
is released and falls to the ground.
DAILY MAINTENANCE
Clean the dirty
water tank.
Check the suction lter is
undamaged and clean.
Check that the
detergent outlet lter
is clean.
Check that the brush
is clean. Replace if
necessary.
Check that the
squeegee is clean
and the blades are not
worn.
PLDC01846
1
2
BATTERY CHARGER ON BOARD
24V
BATTERY CHARGER STAND ALONE
REPLACING THE SQUEEGEE BLADES
ATTACHING/REMOVING THE BRUSHES
Open the clip (Ref. 1).
Remove the two blade retainers (Ref. 2) by pushing them outwards then extracting them.
Remove the blade.
Reuse the same blade by reversing the edge in contact with the oor until all four edges are worn out, or replace with a new blade, tting it onto the
screws on the body of the squeegee.
Reposition the two blade pressing devices by centering the wider part of the slots on the squeegee body fastening pins, then push the blade pressing
devices inwards.
Close the hook again.
Replace the squeegee on its support, following the instructions described previously.
Attaching the brush: rest the brush on the oor in front of the machine and centre it with the guard. Lower the head and operate the brush/drive lever repeatedly until the brush automatically
engages on the ange hub. If the operation is not successful, repeat by pressing on the lever again and repeating the centring.
Removing the brush: raise the machine head by pushing the head lift pedal down and then to the right and operate the brush/drive lever repeatedly. After operating the lever a few times, the brush
is released and falls to the ground.
DAILY MAINTENANCE
Clean the dirty
water tank.
Check the suction lter is
undamaged and clean.
Check that the
detergent outlet lter
is clean.
Check that the brush
is clean. Replace if
necessary.
Check that the
squeegee is clean
and the blades are not
worn.
PLDC01846
1
2
BATTERY CHARGER ON BOARD
24V
BATTERY CHARGER STAND ALONE
REPLACING THE SQUEEGEE BLADES
ATTACHING/REMOVING THE BRUSHES
Open the clip (Ref. 1).
Remove the two blade retainers (Ref. 2) by pushing them outwards then extracting them.
Remove the blade.
Reuse the same blade by reversing the edge in contact with the oor until all four edges are worn out, or replace with a new blade, tting it onto the
screws on the body of the squeegee.
Reposition the two blade pressing devices by centering the wider part of the slots on the squeegee body fastening pins, then push the blade pressing
devices inwards.
Close the hook again.
Replace the squeegee on its support, following the instructions described previously.
Attaching the brush: rest the brush on the oor in front of the machine and centre it with the guard. Lower the head and operate the brush/drive lever repeatedly until the brush automatically
engages on the ange hub. If the operation is not successful, repeat by pressing on the lever again and repeating the centring.
Removing the brush: raise the machine head by pushing the head lift pedal down and then to the right and operate the brush/drive lever repeatedly. After operating the lever a few times, the brush
is released and falls to the ground.
DAILY MAINTENANCE
Clean the dirty
water tank.
Check the suction lter is
undamaged and clean.
Check that the
detergent outlet lter
is clean.
Check that the brush
is clean. Replace if
necessary.
Check that the
squeegee is clean
and the blades are not
worn.
PLDC01846
1
2
BATTERY CHARGER ON BOARD
24V
BATTERY CHARGER STAND ALONE
REPLACING THE SQUEEGEE BLADES
ATTACHING/REMOVING THE BRUSHES
Open the clip (Ref. 1).
Remove the two blade retainers (Ref. 2) by pushing them outwards then extracting them.
Remove the blade.
Reuse the same blade by reversing the edge in contact with the oor until all four edges are worn out, or replace with a new blade, tting it onto the
screws on the body of the squeegee.
Reposition the two blade pressing devices by centering the wider part of the slots on the squeegee body fastening pins, then push the blade pressing
devices inwards.
Close the hook again.
Replace the squeegee on its support, following the instructions described previously.
Attaching the brush: rest the brush on the oor in front of the machine and centre it with the guard. Lower the head and operate the brush/drive lever repeatedly until the brush automatically
engages on the ange hub. If the operation is not successful, repeat by pressing on the lever again and repeating the centring.
Removing the brush: raise the machine head by pushing the head lift pedal down and then to the right and operate the brush/drive lever repeatedly. After operating the lever a few times, the brush
is released and falls to the ground.
DAILY MAINTENANCE
Clean the dirty
water tank.
Check the suction lter is
undamaged and clean.
Check that the
detergent outlet lter
is clean.
Check that the brush
is clean. Replace if
necessary.
Check that the
squeegee is clean
and the blades are not
worn.
PLDC01846
1
2
BATTERY CHARGER ON BOARD
24V
BATTERY CHARGER STAND ALONE
REPLACING THE SQUEEGEE BLADES
ATTACHING/REMOVING THE BRUSHES
Open the clip (Ref. 1).
Remove the two blade retainers (Ref. 2) by pushing them outwards then extracting them.
Remove the blade.
Reuse the same blade by reversing the edge in contact with the oor until all four edges are worn out, or replace with a new blade, tting it onto the
screws on the body of the squeegee.
Reposition the two blade pressing devices by centering the wider part of the slots on the squeegee body fastening pins, then push the blade pressing
devices inwards.
Close the hook again.
Replace the squeegee on its support, following the instructions described previously.
Attaching the brush: rest the brush on the oor in front of the machine and centre it with the guard. Lower the head and operate the brush/drive lever repeatedly until the brush automatically
engages on the ange hub. If the operation is not successful, repeat by pressing on the lever again and repeating the centring.
Removing the brush: raise the machine head by pushing the head lift pedal down and then to the right and operate the brush/drive lever repeatedly. After operating the lever a few times, the brush
is released and falls to the ground.
DAILY MAINTENANCE
Clean the dirty
water tank.
Check the suction lter is
undamaged and clean.
Check that the
detergent outlet lter
is clean.
Check that the brush
is clean. Replace if
necessary.
Check that the
squeegee is clean
and the blades are not
worn.
PLDC01846
1
2
BATTERY CHARGER ON BOARD
24V
BATTERY CHARGER STAND ALONE
DAILY MAINTENANCE
Clean the dirty water tank.
Make sure the squeegee is
clean and the blades are not
worn.
Make sure the suction filter
and debris filter is clean and
undamaged.
Plug in On Board charger to
charge batteries if equipped.
Make sure detergent outlet
filter is clean and free of
debris.
Make sure the brushes/drive
pad are clean and not worn
out. Replace if necessary.
REPLACING THE SQUEEGEE BLADES
Ref. 1 Ref. 2
Open the clip (Ref. 1).
Remove the two blade retainers (Ref. 2) by pushing them
outwards then extracting them.
Remove the blade.
Reuse the same blade by reversing the edge in contact with
the floor until all four edges are worn out, or replace with
a new blade, fitting it onto the screws on the body of the
squeegee.
Reposition the two blade pressing devices by centering the
wider part of the slots on the squeegee body fastening pins,
then push the blade pressing devices inwards.
Close the hook again.
Replace the squeegee on its support, following the
instructions previously described.
ATTACHING/REMOVING THE PAD DRIVER
Position the pad driver underneath the head, in the centre
(single-brush floor scrubber), position the pad driver
underneath the head on both sides (double brush scrubber),
switch the machine on.
Press the CLICK ON-OFF switch, once after starting the
machine releases the pad driver, pressing a button a second
time activates automatic pad driver attachment. The button
is only enabled when all the functions are deactivated
(suction motor and pad driver).
REPLACING THE SQUEEGEE BLADES
ATTACHING/REMOVING THE BRUSHES
Open the clip (Ref. 1).
Remove the two blade retainers (Ref. 2) by pushing them outwards then extracting them.
Remove the blade.
Reuse the same blade by reversing the edge in contact with the oor until all four edges are worn out, or replace with a new blade, tting it onto the
screws on the body of the squeegee.
Reposition the two blade pressing devices by centering the wider part of the slots on the squeegee body fastening pins, then push the blade pressing
devices inwards.
Close the hook again.
Replace the squeegee on its support, following the instructions described previously.
Attaching the brush: rest the brush on the oor in front of the machine and centre it with the guard. Lower the head and operate the brush/drive lever repeatedly until the brush automatically
engages on the ange hub. If the operation is not successful, repeat by pressing on the lever again and repeating the centring.
Removing the brush: raise the machine head by pushing the head lift pedal down and then to the right and operate the brush/drive lever repeatedly. After operating the lever a few times, the brush
is released and falls to the ground.
DAILY MAINTENANCE
Clean the dirty
water tank.
Check the suction lter is
undamaged and clean.
Check that the
detergent outlet lter
is clean.
Check that the brush
is clean. Replace if
necessary.
Check that the
squeegee is clean
and the blades are not
worn.
PLDC01846
1
2
BATTERY CHARGER ON BOARD
24V
BATTERY CHARGER STAND ALONE
Plug in Stand Alone charger
into red charge port to charge
batteries if not equipped with
On Board charger.
NOTE: Never stop charge until
cycle is complete (Green light).
