POWERPYE ELECTRONICS PPYPDZ12A WIFI Guide

Thank you for choosing this product.
Please read this instruction manual before using it.
INSTRUCTION MANUAL AND WARRANTY CARD
MODEL: PPYPDZ12A WIFI / PPYPD30 WIFI

Read the user manual before any use, refer to the corresponding section in
this user manual.
Recycle unwanted materials instead of disposing of them. All appliances and
packaging should be sorted and tendered at a regional recycling centre and
be
processed in an ecological manner.
The product conforms to the applicable European and other directives.
i
2

Figure1
Figure2
Figure3
27
28
2
13
4
5
7
11
10
8
9
6
17 18 19 21 22 23
20 25 26
16 15 14 13 12
24
3

Components
Control Panel
Drainage
27. Drainage Outlet
28. Drainage Pipe
Parts List
12. Power Button
13. Timer Off Button/WiFi Button
14. Up And Down Buttons
15. Fan Speed Button/Child Lock Button
16. Mode Button/Sleep Button
17. Air purification Indicator
18. Laundry Drying Indicator
19. Low Fan Speed Indicator
20. High Fan Speed Indicator
21. Humidity Reading Display
22. WiFi Indicator
23. Timer Indicator
24. On/Off Indicator
25. Tank Full Indicator
26. Defrost Indicator
1. Air Outlet
2. Front Cover
3. Control Panel
4. Handle
5. Water Tank
6. Casters
7. Top Cover
8. Air Inlet Grille
9. Drainage Outlet
10. Rear Cover
11. Power Cord
4

Safety Instructions...................................................................... 6- 7
Prior to Operation .......................................................................... 8
Continuous Drainage ..................................................................... 8
Operation Instructions............................................................... 9-12
Cleaning...................................................................................... 13
Storage........................................................................................14
Display Error Codes...................................................................... 14
Trouble Shooting.......................................................................... 15
Smart Connection Operation Guide............................................16-19
Table of Contents
5

Warning
Cautions Wet hands not allowed Warning
This appliance is intended for use in a domestic environment only. Any other use is not recommended
by the manufacturer and may cause fire, electrical shocks or other person injury and property damage.
6
Do not pull the power
cord in order to unplug
the device from the
socket.
Do not touch the plug with
wet hands in order to avoid
electric shock.
Do not put any heavy
objects on the power
cord in order to avoid
safety hazard.
Do not use the appliance in
overloaded extension cord.
Do not use the appliance
if its socket holes cannot
firmly hold a plug.
Do not attempt to change
the power cord, contact
the authorized service
centre for repair.
The socket has to be
earthed and
appropriately secured.
Please pull out the plug
during lightning storms.
Power Cord
Safety Instructions

Placement
During Use
7
Please turn off the
power and unplug the
power cord before
moving it.
Children should be
supervised to ensure
that they do not place
stick into the appliance.
Do not put hands on the
air outlet in order to avoid
injury or malfunction.
Do not push the appliance
over or let the appliance
suffer strong impact in
order to avoid malfunction.
Do not put any heavy objects
on the appliance in order
to avoid malfunction.
Do not use the appliance
in swimming pool or similar
facilities in order to avoid
safety hazard.
Do not put flammable
and explosive objects
around the appliance in
order to avoid fire.
Do not use the
appliance in a
draughty place.
Place the appliance on a
stable, flat surface.
The appliance must not be
covered when being used.
Please install the air filter
before using it.
Safety Instructions

8
Place the dehumidifier in an upright position on a stable, flat surface.
Ensure the dehumidifier is at a safe distance at least 50cm away from a wall or furniture.
Supply power should be in correspondence with the value on the nameplate, power outlet needs to be
grounded.
Ensure the tank is correctly fitted, if the tank is full or not in place, the tank full light comes on and
the dehumidifier will stop working.
Continuous Drainage
In general, water will be collected by tank, if you want continuous drainage, please do steps as follows
(refer to figure 3)
a.Remove the water tank.
b.Insert the drainage pipe with 14mm inner diameter through the drainage outlet.
c.Place the water tank back to the unit.
Please always make sure the pipe is going downhill, and is not blocked or kinked.
Turn on the power and run the machine as per instructions below.
Prior to Operation

Operation Instructions
Switch On / Switch Off The Unit [ Power button ]
Connect to the power supply and press the power button once to turn on the unit, the unit runs by
default mode on manual continuous dehumidifying with high fan speed, the on/off indicator will be on.
Humidity Setting [ Up and Down buttons ]
Press the up/down buttons to select your preferred humidity from CO-30%-35%-40%-45%-
50%-55%-60%-65%-70%-75%-80%-CO. CO means continuous dehumidifying regardless of
ambient humidity.
9
Press the power button to turn off the unit, it will stop working, fan will work for some seconds to
blow out the hot air inside the unit.
Auto Switch on / off Timer Function [ Timer button ]
At working mode, press
automatic switch off.
the timer button to select your preferred timer hour from 00-24-00 for
Auto timer off setting will be canceled if press timer button for 2 times in 3 seconds.
At standby mode , press the timer button to select your preferred timer hour
automatic switch on.
from 00-24-00 for
Auto timer off setting will be canceled if switch off the unit and switch on again.
Auto timer on setting will be canceled if switch on the unit by manual.
When use Tuya App to set the humidity, 25% = CO setting.

10
Operation Instructions
Fan Speed Option [ Fan Speed button ]
Press the fan speed button to select your preferred fan speed setting of low and high to meet the
different usage requirements.
Multifunction Optional [ Mode button ]
Laundry Drying Mode
Press the mode button once to select Laundry Drying mode, the unit runs in continuous dehumidification
with high fan speed for 6 hours then switch off automatically.
Air Purification Mode
Laundry Drying mode.Fan speed button is invalid at Defrost mode and
Press the mode button 2 times to select Air Purification mode, the unit runs with high fan without
dehumidifying.
Press the mode button 3 times to enter into the manual mode.
Fan speed button is valid.

Operation Instructions
11
Press the for 2s to lock all buttons with a beeping sound, the same operation can
unlock it.
Fan speed button
when water tank is full.
Safety childlock function can be set at standby mode and working mode but can’t be activated
Safety Childlock Function [ -2 seconds ]Fan Speed button
Sleeping Mode
Press and hold the Mode button for 2 seconds, the machine will enter into sleeping mode, all lights
turn off and machine works at low fan speed.
When tank is full, only the tank full indicator lights but without beeping sound.
WiFi Function [ Timer button-2 seconds]
Press the Timer button for 2s to activate WiFi function and enter the distribution network mode, during the
network configuration, the WiFi indicator flash quickly, after WiFi connected the indicator is on.
When the machine is in distribution network mode, press the Anion button for some seconds to
disconnect the WiFi connection.
Detailed operation, please refer to the manual ”Smart Connection Operation Guide”.

Memory Function:
a.When unplugged directly or power cut, then reconnect to the power supply, the dehumidifier will run
with the mode prior to the shutdown. The timer setting will be kept.
b.Press the power button to switch off the dehumidifier, and then press the power button to switch it
back on. The dehumidifier will run with the mode prior to the shutdown. The timer setting will be
canceled.
c.Switch off the dehumidifier and unplug the power cord, then reconnect the power supply and switch
on the dehumidifier. It will run as factory preset mode the first time you received the dehumidifier.
12
Operation Instructions
The unit will enter into the standby mode when water tank is full or the water tank is not installed properly.
After emptying the tank, or install the water tank properly the unit will go on to the previous mode.
Except for the power button, all other buttons are invalid.
Auto Shut off with Water Tank Full Indicator
When the ambient temperature is too low, dehumidifier will enter into the defrost mode, the unit runs
with high fan speed without dehumidifying.
Low Temperature Defrost Indicator

When used regularly , the filter may become clogged with dust and particles. Therefore the filter should
be cleaned at least every two weeks. Follow these steps:
1. Switch the device off and remove the plug from the socket before
cleaning.
2. Clean the housing with soft, dry cloth. If the device is extremely dirty,
use a mild cleaning agent. Wipe the dehumidifier with a slightly damp
cloth. Never spray the device with water.
3. Remove the filter, clean the filter with a vacuum cleaner or soapy
water no hotter than 40℃.
4. Rinse and dry the filter completely before installing back to the
device.
13
Cleaning

If the dehumidifier will not be used for a long period of time, take the following steps:
1. Remove the plug from the socket and empty the tank make the tank and the dehumidifier , dry
completely, this may take a couple of days.
2. Clean the air filter .
3. Check the dehumidifier for perfect condition to ensure a safe use of it after a long period of storage.
4. Pack the device with the suitable packaging.
5. Store the dehumidifier in a dust-free and out of direct sunlight location, preferably covered with a
sheet of plastic.
14
Please contact local distributor if any of the error codes below appears.
Storage
Display Error Codes
Display Code E1 E2
Error
Display
What is happening
L3 L4
Temperature sensor
error
Flash every 30
seconds
Machine works
normally
Humidity sensor
error
Flash every 30
seconds
Machine works
normally, but can't
set the humidity
Air inlet temperature
is too high＞42℃
Slowly flash L3
Compressor stop
working, fan works
at low fan speed.
10mins later, if the
temperature
decrease to below
40℃, machine will
work normally.
Compressor stop
working, fan works
at low fan speed.
10mins later, if the
temperature
increase to above
2℃, machine will
work normally.
Slowly flash L4
Air inlet temperature
is too low＜ ℃0

15
Check the following before contacting technical support .
PROBLEM POSSIBLE CAUSE SOLUTION
The device does
not work
The power is not connected Insert the plug into the wall outlet
The water tank is full Empty the tank
The tank has not
been replaced correctly Replace the tank
Runtime is too short Be patient and wait
Ambient temperature or
humidity is too low
It is normal that the device does not dehumidify in
these conditions
The room is too big We recommend using a dehumidifier with a
greater capacity
Water removal
capacity is too low
There is too much ventilation Reduce ventilation(e.g. close windows and shut
doors)
The air filter is clogged Clean the air filter
Set humidity is higher than
the ambient humidity Set the humidity lower than ambient humidity
Dehumidifier is
blowing out warm air This is normal, a dehumidifier is not an air cooler
The device works,
but reduces the
relative humidity
insufficiently
The dried air is passed over
heating coils before it is blown
into the room as part of the
dehumidifying process
The display is not
showing the humidity
set point
The display shows the room
relative humidity not the set
point
Press the humidity control button once to see the
target relative humidity
Water on floor
There is residual water in tank,
and the device is lurched too
much by moving
Be careful when move the tank
The dehumidifier is
noisy
The air filter is blocked or
the device is on an uneven
surface
Clean the filter or put the device on a flat surface
Trouble Shooting

Smart Connection Operation Guide
APP Binding Device
Step One
Make sure the phone is connected to the WIFI at home, and turn on the Bluetooth device, tap the upper
right corner of the home page + to add device.
16
Search an APP platform for “PowerPye” or scan the following QR code to download the APP.

Smart Connection Operation Guide
Step Two
Follow the guide to select the device to be configured, then enter the WiFi password.
Step Three
Complete the connection to set the dehumidifier with APP.
17
PPY PDZ12 A WiF i / PPYPD 30 WiFi
PPYPDZ12A WiFi / PPYPD30 WiFi
PPYPD
Z12A WiFi...

WARRANTY CARD
CUSTOMER CARE
[phone]
MON-SAT 11AM TO 5PM
MODEL & SERIAL NO.
Date of Purchase: Where Purchased:
Print Name:
Address:
E-mail:
My signature below acknowledges that I have read, fully understand, and accept this limited warranty agreement.
Signature: Date:
WARRANTY TERMS:
1.2 YEAR WARRANTY
2.ONSITE WARRANTY CHARGEABLE
3.GAS REFILL NOT INCLUDED IN WARRANTY
20
