Powers P3500 User manual

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

DO NOT OPERATE THE P3500 TOOL UNTIL YOU HAVE

READ THIS MANUAL AND RECEIVED THE PROPER

TRAINING ACCORDING TO ANSI STANDARD A 10.3-1995.

WARNING

;

R2200

;;

;

200

OPERATING INSTRUCTION

MANUAL

WARNING!

PRIOR TO OPERATING THE P3500 TOOL, STUDY THIS MANUAL CAREFULLY AND DEVELOP A THOROUGH

UNDERSTANDING OF THE CONTENTS.

PROPER TRAINING ACCORDING TO THE CURRENT ANSI STANDARD A 10.3, SAFETY REQUIREMENTS FOR POWDER

ACTUATED FASTENING SYSTEMS MUST BE COMPLETED AND A POWERS FASTENERS QUALIFIED OPERATOR CARD

MUST BE OBTAINED PRIOR TO OPERATION OF THE TOOL. STATE, LOCAL, OR OTHER REGULATIONS SHOULD ALSO BE

FOLLOWED. LAWS, REGULATIONS, AND STANDARDS REGARDING THE USE OF POWDER ACTUATED TOOLS MAY

PERIODICALLY BE REVISED. ANY SUCH REVISIONS MAY CHANGE THE SAFETY AND OPERATING PROCEDURES

DESCRIBED IN THIS MANUAL. POWERS FASTENERS, INC. IS NOT RESPONSIBLE FOR ANY SUCH REVISIONS WHICH

OCCUR AFTER PUBLICATION OF THIS MANUAL. IT IS THE RESPONSIBILITY OF THE USER TO MAINTAIN FAMILIARITY

WITH THE CURRENT LAWS, REGULATIONS, AND STANDARDS THAT APPLY TO THE POWDER ACTUATED TOOL.

DANGER! - TO AVOID SERIOUS INJURY OR DEATH:

NEVER CLOSE TOOL WITH ANY PART OF HAND OVER MUZZLE END.

OPERATORS AND BYSTANDERS MUST WEAR EYE AND HEARING PROTECTION.

ALWAYS ASSUME TOOL IS LOADED. DO NOT PLACE A FINGER ON THE TRIGGER OF LOADED TOOL UNTIL MUZZLE

END IS AGAINST WORK SURFACE AND YOU ARE READY TO MAKE A FASTENING. NEVER PLACE YOUR HAND OVER

THE MUZZLE WITH A POWDER LOAD IN THE TOOL. IF THE TOOL ACCIDENTALLY DISCHARGES THE PISTON OR

FASTENER MAY PENETRATE YOUR HAND RESULTING IN SERIOUS INJURY.

IT IS VERY IMPORTANT THAT THE OPERATOR OF THIS TOOL COMPLETELY READS AND UNDERSTANDS THE ENTIRE

TOOL MANUAL AND COMPLETES THE OPERATOR’S EXAM ON THE LAST PAGE. THE WARRANTY WILL NOT BE VALID

UNTIL THE TEST IS RECEIVED, WITH A COPY OF YOUR RECEIPT,

AND REVIEWED BY POWERS FASTENERS, INC.

Low Velocity Powder Actuated

Fastening Tool

P3500 MANUAL CAT. NO. 52036 9/03

Introduction

Thank you for purchasing the Powers P3500 low velocity powder actuated tool. This tool will

provide you with excellent performance provided the steps for proper operation and

maintenance are followed. Powder actuated fastening systems can provide a cost effective

method of attaching fixtures for light duty, static load conditions. The systems provided by

Powers Fasteners consist of specially designed fasteners, installation tools, and powder loads

which are designed to function in combination to provide optimum performance. While powder

actuated tools can provide one of the fastest and economical means of fastening, they can also

be dangerous if they are not operated properly.

Prior to operating the P3500 tool, you must be properly trained in the operation and

maintenance of this tool and be issued a Powers Fasteners Qualified Operator Card. When using

the tool, you must have this card in your possession. As part of the training process, you should

read and understand the contents of this instruction manual especially the safety precautions.

Powder actuated tools may be operated only by properly trained operators as described in ANSI

Standard A 10.3, Safety Requirements for Powder Actuated Fastening Systems. For complete

tool operation details, contact your local Powers Fasteners Branch office or distributor

for training.

Remember, safety begins with you! It is your primary responsibility when operating this tool.

Failure to follow the proper operating, maintenance, and safety procedures can result in serious

injury or death to yourself or bystanders. In addition to the training provided, you should be

familiar with any local, state, and federal regulations. If you have any questions which are not

covered in this manual, contact your local Powers Fasteners Branch office or distributor.

SIZE RANGE

1/2" to 3" pin lengths, .27 caliber

TOOL DESCRIPTION

The P3500™ is a low velocity, semi-automatic .27 caliber tool which can be used to install .300

head drive pins, 8mm head drive pins and 1/4"-20 threaded studs, up to 3" in total length. The

P3500™ is designed for high speed and repetitive volume applications.

TECHNICAL DATA

TOOL BODY PIN LENGTH TOOL LENGTH

Precision Cast Aluminum 1/2" to 3" Total Length 13-5/8"

LOAD TYPE TOOL WEIGHT POWER LEVEL

.27 Caliber in a 10 Load Strip 5 lbs. Brown (2), Green (3), Yellow (4), Red (5)

PIN TYPE

Ballistic Point Drive Pin, .300 Head Drive Pin, 8mm Head Drive Pin, 1/4"-20 Threaded Stud

Warranty

All warranties of the products described herein, expressed or implied, including the warranties of

merchantability and fitness for particular purposes are specifically excluded, except for the

following: Powers Fasteners will repair or replace at its sole option any tool part, or fastener

which within five years after sale by Powers Fasteners or its distributors, is found by Powers

Fasteners to be defective in material or workmanship, normal wear and tear excluded.

This is the sole warranty of Powers Fasteners and the sole remedy available to distributor

or buyer.

NOTE — JUST AS NO ONE CAN MERELY READ A BOOK ABOUT DRIVING AN AUTOMOBILE AND THEN HOPE TO RUN IT SAFELY, NO ONE SHOULD

ATTEMPT TO USE ANY POWDER TOOL WITHOUT ADEQUATE, COMPETENT, PERSONAL INSTRUCTION. AND, JUST AS NO AUTOMOBILE

INSTRUCTION BOOK OR INSTRUCTOR CAN FOREWARN A LEARNER AGAINST ALL CONTINGENCIES AND EMERGENCIES, NEITHER CAN POWERS

FASTENERS INSTRUCTORS OR PRINTED INFORMATION DETAIL ALL POSSIBLE CONDITIONS SURROUNDING THE USE OF POWERS TOOLS AND

PRODUCTS. THE MANUFACTURER DISCLAIMS RESPONSIBILITY FOR INJURIES TO PERSONS OR PROPERTY WHICH MAY RESULT FROM DISREGARD

OF THESE OPERATING INSTRUCTIONS.

2P3500

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

3P3500

CAT NO. DESCRIPTION STD CTN.

52000 P3500 Powder Tool (Deluxe Kit) 1

52001 P3500 Powder Tool (Blister Pack) 1

52102 P3500 Piston Flat End w/ring 1

52108 Guide 2/F-3 1

52110 Base Plate 2/S-13 1

52120 Shear Clip 1

52112 Piston Stop 1

52122 Steel Annular Ball 1

The piston for installing 8mm drive pins is listed in the following table. For applications in tight

areas, a limited access base plate/guide is also available.

CAT NO. DESCRIPTION STD CTN.

52100 Piston 2/DN-1 1

52114 Guide 2/F-4 Limited Access 1

52116 Baseplate 2/F-14-1 Limited Access 1

For fastening ceiling clips overhead, 6' and 8' di-electric pole tools are available.

CAT NO. DESCRIPTION STD CTN.

50065 6' Di-electric Pole Tool 1

50066 8' Di-electric Pole Tool 1

FASTENER FUNCTIONING

Prior to learning the safe operating procedures for this tool, it is important to understand how a

powder actuated fastener works. A powder actuated fastener is considered to be a direct drive or

forced entry type of fastener because it is driven directly into the base material. The driving action

causes tremendous forces to be applied to the fastener. Powers powder actuated fasteners are

specially designed and manufactured using an austempering process to withstand the forces

imposed during the driving operation. Only fasteners manufactured or supplied by Powers

Fasteners should be used in this tool.

FUNCTIONING IN CONCRETE

The performance of a powder actuated fastener when installed into concrete or masonry base

materials is based on the following factors:

1. Strength of the base material

2. Hardness and concentration of the aggregate

3. Shank diameter of the fastener

4. Depth of embedment into the base material

5. Fastener spacing and edge distance

In addition to these factors, installation tool accessories such as a stop spall which reduces the

tendency of the concrete surface to spall during the driving action can increase the performance

of the fastener.

When a powder actuated fastener is driven into concrete, it displaces the volume of concrete

around the embedded area of the fastener shank. As this occurs, the concrete directly

surrounding the fastener is compressed and in turn presses back against the shank of the

fastener. Additionally, the driving action generates heat which causes particles within the

concrete to fuse to the shank of the fastener. This combination of compression and fusion holds

the fastener in the concrete base material. A similar action occurs when fastening into

block masonry.

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

yyy

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

;;;;

@@@@



ÀÀÀÀ

;;;;

@@@@



ÀÀÀÀ

;;;;

@@@@



ÀÀÀÀ

;;;;

@@@@



ÀÀÀÀ

;;;;

@@@@



ÀÀÀÀ

;;;;

@@@@



ÀÀÀÀ

;;;;

@@@@



ÀÀÀÀ

;;;;

yyyy

;;;;@@@@ÀÀÀÀ

;;;;yyyy

Washer

;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;

;;;;

@@@@



ÀÀÀÀ

;;;;

@@@@



ÀÀÀÀ

;;;;

@@@@



ÀÀÀÀ

;;;;

@@@@



ÀÀÀÀ

;;;;

@@@@



ÀÀÀÀ

;;;;

@@@@



ÀÀÀÀ

;;;;

@@@@



ÀÀÀÀ

;;;;

yyyy

;;;;@@@@ÀÀÀÀ

;;;;yyyy

Stop

Spall

4P3500

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

yyyyyy

Point

Flattens

Indent

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

yyyyyy

Surface

Shatters

Material

Cracks

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

@@@@@@



ÀÀÀÀÀÀ

;;;;;;

yyyyyy

Fastener Sinks in

with Average

Hammer Blow

Generally, the performance of the fastener in a given concrete strength will increase with

greater embedment depths in a certain range. Depending on the fastener style and base

material strength, embedment depths range from 5/8” to 1-1/2”. For depths greater than this

range, there is the possibility of fastener bending or fishhooking which may decrease expected

load capacities and create a safety hazard.

During the driving action, some localized surface spalling of the concrete may occur. Normally,

this is a surface effect which does not effect the performance of the fastener. However, it may

pose an aesthetic problem for exposed applications where a fixture is not used. In cases such as

this, two methods can be used to improve the appearance of the fastening. A stop spall adapter

mounted on the powder actuated tool can help to reduce surface spalling. Another method used

is to drive the fastener through a steel washer to improve the appearance of the application.

FUNCTIONING IN STEEL

The load performance of a powder actuated fastener when installed into steel base materials is

based on the following factors:

1. Thickness of the steel

2. Tensile strength of the steel

3. Shank diameter of the fastener

4. Depth of point penetration through the steel

5. Fastener spacing and edge distance.

When a powder actuated fastener is driven into steel, it displaces the steel laterally 360˚ around

the shank of the fastener. Since steel is an elastic material, it presses back against the shank of

the fastener to hold it in place. As the diameter of the fastener shank is increased, the load

capacity obtained will generally increase provided the steel thickness is sufficient to accept the

fastener. To further increase fastener performance in steel, some fasteners have a knurled shank

which allows the steel to form a key lock into the grooves to provide higher capacities than

those obtained with a smooth shank. For optimum performance, the fastener point should

completely penetrate the steel. Normally, a minimum of 1/4” is allowed for the point length. An

increase in performance can be expected until the fastener no longer completely penetrates

through the steel. At this point, the elastic properties of the steel cause a compression force to

be developed at an angle against the fastener point which reduces load capacity. In thicker steel

base materials, adequate load capacities may be obtained for applications in which the point of

the fastener does not fully penetrate the steel. Job site performance tests are recommended.

Fasteners should not be used in areas that have been welded or cut with a torch as these

procedures may have caused local hardening of the steel. Over driving of the fastener should be

avoided as the rebound created may reduce the load capacity or cause damage to the fastener.

When fastening into unsupported long steel members, it may be necessary to provide support in

the area of the fastening to prevent spring action which can cause inconsistent penetration and

a reduction in load capacity.

SUITABLE BASE MATERIAL

While powder actuated fasteners can be used successfully in concrete, certain masonry

materials, and A 36 steel, some materials are completely unsuitable. Fasteners should never be

fired into hard or brittle materials such as cast iron, tile, glass, or rock. These materials can

shatter easily resulting in a potential safety hazard. In addition, soft base materials such as

wallboard, plaster, or wood are not appropriate as the fastener could pass completely through

these materials. The user should never guess when fastening into any base material. Failure to

follow the recommended installation and safety guidelines can result in severe injury or death to

the tool operator and/or bystanders.

CENTER PUNCH TEST

A center punch test should always be performed to determine the suitability of the base

material for a powder actuated fastening. This test is relatively simple and can help to insure a

safe, successful fastening. Be sure to wear the appropriate eye protection when performing this

test. To begin, select the fastener to be used for the job. Then, place the point of the fastener

against the proposed base material. Strike the fastener with a single hammer blow, then

examine the point. If the point of the fastener is not blunted and the base material has a clear

point indentation, it is acceptable to proceed with the first test installation.

;;@@ÀÀ

;;yy

;;@@ÀÀ

;;yy

;;@@ÀÀ

;;yy

;;@@ÀÀ

;;yy

;;@@ÀÀ

;;yy

;;@@ÀÀ

;;yy

;

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

5P3500

Use of a powder actuated system is not recommended if the following occurs during the center

punch test:

1. The fastener point has been blunted. This indicates that the base material is too hard.

2. The base material cracks or shatters. This indicates that the base material is too brittle.

3. When using an average hammer blow, the fastener penetrates the base material easily. This

indicates that the base material is too soft.

FASTENER INSTALLATION REQUIREMENTS

It is important to understand the required minimum base material thickness requirements along

with the minimum spacing and edge distance requirements. Failure to follow these

requirements can result in an unsuccessful fastening and create a safety hazard.

BASE MATERIAL THICKNESS

Concrete base material should be at least three (3) times as thick as the fastener embedment

penetration. If the concrete is too thin, the compressive forces forming at the fasteners point

can cause the free face of the concrete to break away. This can create a dangerous condition

from flying concrete and/or the fastener and also results in a reduction of fastener holding

power. For applications in the face shell of concrete masonry block, select a fastener length

which will not exceed the thickness of the face shell.

FASTENER PENETRATION GUIDE

The following table lists typical embedment or penetration depths expected in the base

materials listed. The penetration will vary depending on the density of the material. This

table should be used as a guide since the consistency of these materials varies. When in

doubt, a job site performance test should be conducted.

DENSITY TYPICAL BASE MATERIAL PENETRATION

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

yyy

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

@@@



ÀÀÀ

;;;

yyy

;;;;;

;

;;;

;

;;;

;

;;;;;

@@@@@

@@@

@@@@@















ÀÀÀÀÀ

ÀÀÀ

ÀÀÀÀÀ

;;;;;

;

;;;

;

;;;

;

;;;;;

@@@@@

@@@

@@@@@















ÀÀÀÀÀ

ÀÀÀ

ÀÀÀÀÀ

;;;;;

;

;;;

;

;;;

;

;;;;;

@@@@@

@@@

@@@@@















ÀÀÀÀÀ

ÀÀÀ

ÀÀÀÀÀ

;;;;;

;

;;;

;

;;;

;

;;;;;

@@@@@

@@@

@@@@@















ÀÀÀÀÀ

ÀÀÀ

ÀÀÀÀÀ

;;;;;

;

;;;

;

;;;

;

;;;;;

@@@@@

@@@

@@@@@















ÀÀÀÀÀ

ÀÀÀ

ÀÀÀÀÀ

;;;;;

;

;;;

;

;;;

;

;;;;;

@@@@@

@@@

@@@@@















ÀÀÀÀÀ

ÀÀÀ

ÀÀÀÀÀ

;;;;;

;

;;;

;

;;;

;

;;;;;

@@@@@

@@@

@@@@@















ÀÀÀÀÀ

ÀÀÀ

ÀÀÀÀÀ

;;;;;

;

;;;

;

;;;

;

;;;;;

yyyyy

yyy

yyyyy

;@À

Fixture

Embedment

;;;;;

@@@@@



ÀÀÀÀÀ

;;;;;

@@@@@



ÀÀÀÀÀ

;;;;;

@@@@@



ÀÀÀÀÀ

;;;;;

@@@@@



ÀÀÀÀÀ

;;;;;

@@@@@



ÀÀÀÀÀ

;;;;;

@@@@@



ÀÀÀÀÀ

;;;;;

@@@@@



ÀÀÀÀÀ

;;;;;

yyyyy

Thread Length

Embedment

Penetration

Soft Masonry Concrete block 1" -1-1/4"

Average concrete Poured concrete 3/4" - 1"

Dense concrete Pre-stressed/pre-cast concrete 5/8" - 3/4"

EDGE DISTANCE

Do not fasten closer than 3" from the edge of concrete. If the concrete cracks, the fastener may

not hold. Closer edge distances for applications such as sill plates may be permitted if specific

fastener testing has been conducted.

SPACING

Setting fasteners too close together in concrete or masonry can cause cracking. The

recommended minimum distance between fasteners is 3" center to center.

FASTENER LENGTH SELECTION IN CONCRETE

For permanent applications using pins in concrete, first determine the thickness of the fixture to

be fastened. To this, add the required embedment or penetration into the base material. This

will be the fastener shank length required. For applications in the face shell of masonry block,

select a fastener length which will not exceed the thickness of the face shell.

For removable applications with threaded studs, the shank length required is equal to the

embedment depth required. To determine the minimum threaded length, add the thickness of

the fixture and the nut / washer thickness. The nut and washer thickness is equal to the

nominal thread diameter. Do not over tighten threaded parts. Maximum tightening torque

values are listed in the table below. Use of a nut setter is recommended to reduce the

possibility of over tightening the fasteners. For critical applications, perform a job site test.

MAXIMUM TORQUE FOR 1/4" STUD (FT.-LBS.) MAXIMUM TORQUE FOR 3/8" STUD (FT.-LBS.)

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

6P3500

;;

1/8"

;;

1/2"

;;

1-1/2"

;;;

;

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

INSTALLATION IN STEEL

The following guidelines are based on the installation of a fastener in ASTM A 36 structural

steel with the point fully penetrating the steel member. Recommended steel material thickness

ranges from a minimum of 1/8" to a maximum of 3/8". For use in higher strength structural

steel, applications where the point does not penetrate the steel member, or a thickness of steel

greater than 3/8", job site performance tests are recommended.

BASE MATERIAL THICKNESS

Steel base materials should be a minimum of 1/8" in thickness.

EDGE DISTANCE

For installations in A 36 steel, 1/2" is the recommended minimum edge distance.

SPACING

The recommended minimum distance between fastenings is 1-1/2" center to center for

installations in ASTM A 36 steel.

FASTENER LENGTH SELECTION IN STEEL

For permanent applications when using pins in steel, first determine the thickness of the

fixture to be fastened. To this, add the thickness of the steel base material plus a minimum of

1/4" to allow for proper point penetration. This will be the minimum fastener shank length

required. Do not select a fastener length longer than that required for the application. An

excessively long shank can burnish or polish the hole created in the steel resulting in a

reduction in load capacity.

For removable applications with threaded studs, the shank length required is equal to the

thickness of the steel base material plus a minimum of 1/4" to allow for proper point

penetration. This will be the minimum fastener shank length required. Do not select a shank

length longer than that required for the application. An excessively long shank can burnish or

polish the hole created in the steel resulting in a reduction in load capacity. To determine the

minimum threaded length, add the thickness of the fixture and the nut / washer thickness. The

nut and washer thickness is equal to the nominal thread diameter.

Do not over tighten threaded studs, the maximum tightening torque is listed in the table below.

Use of a nut setter is recommended to reduce the possibility of over tightening the fasteners. For

critical applications, perform a job site test.

7P3500

Powder Load

Selection Guide

.27 CALIBER SAFETY STRIP®

CAT. POWER LOAD STD. STD. MASTER WT./

NO. LEVEL COLOR SIZE BOX CTN. CTN. 100

50620 2 Brown .27 strip 100 1000 20000 .33

50622 3 Green .27 strip 100 1000 20000 .33

50626 4 Yellow .27 strip 100 1000 20000 .33

50630 5 Red .27 strip 100 1000 20000 .33

.27 CALIBER SAFETY STRIP® MASTER PACK

CAT. POWER LOAD STD. STD. MASTER WT./

NO. LEVEL COLOR SIZE BOX CTN. CTN. 100

50624 3 Green .27 strip 1000 - 20000 .33

50628 4 Yellow .27 strip 1000 - 20000 .33

50632 5 Red .27 strip 1000 - 20000 .33

Fastener

Selection Guide

.300 HEAD DIAMETER DRIVE PINS

CAT. STD. STD. HEAD SHANK WT./

NO. SHANK LENGTH BOX CTN. DIA. DIA. 100

50012 1/2" K 100 5000 .300 .143 .5

50016 5/8" K 100 5000 .300 .143 .5

50022 3/4" 100 5000 .300 .143 .5

50026 1" 100 5000 .300 .143 .6

50030 1-1/8" 100 1000 .300 .143 .7

50032 1-1/4" 100 1000 .300 .143 .8

50034 1-1/2" 100 1000 .300 .143 .9

50036 1-3/4" 100 1000 .300 .143 1.1

50038 2" 100 1000 .300 .143 1.2

50040 2-1/4" 100 1000 .300 .143 1.2

50042 2-3/8" 100 1000 .300 .143 1.3

50044 2-1/2" 100 1000 .300 .143 1.4

50046 2-3/4" 100 1000 .300 .143 1.6

50048 3" 100 1000 .300 .143 1.9

.300 HEAD DIAMETER DRIVE PINS WITH TOP HAT

CAT. STD. STD. HEAD SHANK WT./

NO. SHANK LENGTH BOX CTN. DIA. DIA. 100

50136 1/2" K 100 5000 .300 .143 .5

50138 5/8" K 100 5000 .300 .143 .5

50140 3/4" 100 5000 .300 .143 .5

50144 1" 100 5000 .300 .143 .6

.300 HEAD DIAMETER STEP SHANK PINS

CAT. STD. STD. HEAD SHANK WT./

NO. SHANK LENGTH BOX CTN. DIA. DIA. 100

50158 3/4" Step Shank 100 1000 .300 .143/130 .5

50159 1" Step Shank 100 1000 .300 .143/130 .6

.300 HEAD DIAMETER DRIVE PINS -MASTER PACK

CAT. STD. STD. HEAD SHANK WT./

NO. SHANK LENGTH BOX CTN. DIA. DIA. 100

50980 1/2" K 1000 5000 .300 .143 .5

53300 5/8" K 1000 5000 .300 .143 .5

51040 3/4" 1000 5000 .300 .143 .5

51100 1" 1000 5000 .300 .143 .6

51160 1-1/4" 1000 5000 .300 .143 .8

51340 1/2" K TH 1000 5000 .300 .143 .5

53400 5/8" K TH 1000 5000 .300 .143 .5

51400 3/4" TH 1000 5000 .300 .143 .5

51520 1" TH 1000 5000 .300 .143 .6

.300 HEAD DIAMETER DRIVE PINS WITH 3/4" WASHER

CAT. STD. STD. HEAD SHANK WT./

NO. SHANK LENGTH BOX CTN. DIA. DIA. 100

50070 3/4" 100 1000 .300 .143 1.6

50080 2-1/2" 100 1000 .300 .143 2.5

50082 3" 100 1000 .300 .143 2.8

.300 HEAD DIAMETER DRIVE PINS WITH 7/8" WASHER

CAT. STD. STD. HEAD SHANK WT./

NO. SHANK LENGTH BOX CTN. DIA. DIA. 100

50090 1" 100 1000 .300 .143 1.9

50092 1-1/4" 100 1000 .300 .143 2.0

50094 1-1/2" 100 1000 .300 .143 2.1

50096 2" 100 1000 .300 .143 2.4

50098 2-1/2" 100 1000 .300 .143 2.7

50100 3"* 100 1000 .300 .143 3.0

.300 HEAD DIAMETER DRIVE PINS WITH 1" WASHER

CAT. STD. STD. HEAD SHANK WT./

NO. SHANK LENGTH BOX CTN. DIA. DIA. 100

50108 1-1/4" 100 1000 .300 .143 2.2

50110 1-1/2" 100 1000 .300 .143 2.3

50112 2" 100 1000 .300 .143 2.6

50114 2-1/2" 100 1000 .300 .143 2.9

50116 3" 100 1000 .300 .143 3.2

.300 HEAD DIAMETER DRIVE PINS WITH 1-7/16" INSULATION WASHER

CAT. STD. STD. HEAD SHANK WT./

NO. SHANK LENGTH BOX CTN. DIA. DIA. 100

50122 1-1/2" 100 1000 .300 .143 2.1

50126 2-1/2" 50 500 .300 .143 2.7

50132 3" 50 500 .300 .143 3.0

1/4"-20 THREADED STUDS

CAT. THREAD SHANK STD. STD. HEAD SHANK WT./

NO. LENGTH LENGTH BOX CTN. DIA. DIA. 100

50320 1/2" 1/2"K 100 5000 1/4" .143 .8

50322 3/4" 1/2"K 100 1000 1/4" .143 1.1

50326 3/4" 3/4" 100 1000 1/4" .143 1.2

50328 1/2" 1" 100 1000 1/4" .143 1.2

50330 3/4" 1" 100 1000 1/4" .143 1.4

50334 1/2" 1-1/4" 100 1000 1/4" .143 1.4

50336 3/4" 1-1/4" 100 1000 1/4" .143 1.5

50338 1-1/4" 1-1/4" 100 1000 1/4" .143 1.7

.300 HEAD DIAMETER PINS WITH CEILING CLIPS

CAT. SHANK STD. STD. HEAD SHANK WIRE WT./

NO. LENGTH BOX CTN. DIA. DIA. HOLE 100

50363 1" 100 1000 .300 .143 0.278" 3.4

50364 1" 100 1000 .300 .143 0.278" 3.5

50368 1" 100 1000 .300 .143 0.278" 3.0

50370 1-1/4" 100 1000 .300 .143 0.278" 3.7

50374 1-1/4" 100 1000 .300 .143 0.278" 3.2

.300 DIAMETER HEAD DRIVE PINS WITH BX CABLE STRAPS AND CONDUIT

CLIPS

CAT. STD. STD. HEAD SHANK WT./

NO. DESCRIPTIONBOX CTN. DIA. DIA. 100

50150 1" 100 1000 .300 .143 3.5

50152 1-1/4" 100 1000 .300 .143 3.7

50380 1/2" EMT 1-1/4" pin 100 1000 .300 .143 3.4

50381 1/2" EMT 1" pin TH 100 1000 .300 .143 3.3

50382 1/2" EMT 1" pin 100 1000 .300 .143 3.3

50384 3/4" EMT 1-1/4"pin 100 1000 .300 .143 3.5

50385 3/4" EMT 1" pin TH 100 500 .300 .143 3.4

50386 3/4" EMT 1" pin 100 1000 .300 .143 3.3

50388 1" EMT 1" pin TH 25 250 .300 .143 3.2

.300 HEAD DIAMETER PIN WITH REBAR BASKET CLIP

CAT. STD. STD. HEAD SHANK WT./

NO. DESCRIPTION BOX CTN. DIA. DIA. 100

50702 32mm w/ basket clip 100 100 8mm .143 4.0

50704 37mm w/ basket clip 100 100 8mm .143 4.1

50710 47mm w/ basket clip 100 1000 8mm .143 4.3

50712 52mm w/ basket clip 100 1000 8mm .143 4.4

50716 62mm w/ basket clip 100 1000 8mm .143 4.6

50718 72mm w/ basket clip 100 1000 8mm .143 4.8

FORMING PIN

CAT. STD. STD. HEAD SHANK WT./

NO. DESCRIPTION BOX CTN. DIA. DIA. 100

50790 62mm - 2-1/2" 100 1000 .205 .143 1.4

50789 44mm - 1-3/4" 100 1000 .205 .143 1.1

K=Knurled TH=Top Hat

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

8P3500

Safety Precautions

Safety is your primary responsibility when operating any

powder actuated tool. You must read and understand

the contents of this manual. You must be familiar with

all functional and safety requirements of the tool. It is

your responsibility to obtain proper training and a

Powers Fasteners operator card prior to using this tool in

compliance with the current American National Standard

A10.3 Safety Requirements for Powder Actuated

Fastening Systems and the Federal Occupational Safety

and Health Administration Standards (OSHA). Existing

state or local regulations should also be followed. When

using this tool, you must have the qualified operators

card in your possession.

Revocation of card - Failure to comply with any of the

rules and regulations for safe operation of powder

actuated tools shall be cause for the immediate

revocation of your qualified operator card.

The following is a summary of safety precautions to be

followed when operating a Powers Fasteners powder

actuated tool. Failure to follow these safety instructions

can result in serious injury or death to operators

or bystanders.

PRIOR TO OPERATING THE TOOL

1. Warning signs should always be posted within the area

in which a powder actuated tool is to be used. These

signs should be at least 8" x 10" in size with boldface

type that is not less than 1" in height. The sign should

state "Powder Actuated Tool In Use".

2. Approved safety goggles should always be worn by

operator or bystander, to protect their eyes from flying

particles. Hearing protection should always be worn by

the operator and bystanders when using a powder

actuated tool. Other personal safety protection as

required should also be used.

3. Never modify or fabricate parts for use in your Powers

tool. Use only Powers fasteners, loads, and tool parts.

4. Hands or other body parts must never be placed in front

of muzzle/barrel. Accidental discharge can cause piston

and/or fastener to pass through the operator’s hand.

5. Never compress the tool against any part of the body.

Serious injury or death may result in the event of an

accidental discharge.

6. Always point tool in a safe direction at all times.

7. Use the tool for its intended purpose only.

PREPARATION FOR LOADING THE TOOL

1. Tools must be checked prior to operating to make sure

they are not fully or partially loaded with a powder load

or fastener.

2. To insure safe operation, perform the daily function test

described in this manual. Be sure the tool is not loaded

prior to performing this test.

3. Do not operate this tool unless all its parts are in place

and operating appropriately. Never attempt to use a

malfunctioning tool. Call 1-800-524-3244 for assistance.

4. Never guess about the suitability of a base material. If

you are uncertain about the suitability of a base

material, perform a center punch test.

5. Do not operate the tool until you learn and understand

the color code / numbering system used to identify the

power level of powder loads.

OPERATING THE TOOL

1. Only use fasteners and powder loads designed for this

tool as supplied by Powers Fasteners.

2. Do not use powder actuated tools in a flammable or an

explosive atmosphere.

3. Do not fire a tool without a fastener. The piston will

impact the work surface possibly causing serious injury

to the operator or bystanders along with damage to

the tool.

4. Do not load the tool until you are ready to make a

fastening. Check the power load level before inserting it

into the tool chamber.

5. Fastener must be loaded prior to loading the powder

load, to prevent injury to operator or bystander in the

event of an accidental discharge.

6. Do not close tool against work surface. The tool should

be manually closed, with hand away from muzzle/barrel

to prevent accidental discharge.

7. Hold the tool perpendicular to the work surface at all

times. Use a spall guard wherever possible. This will limit

the possibility of fastener ricochet which could cause

serious injury or death to the operator or bystanders.

8. Always perform a test fastening with the lightest load

level designed for use in the tool. If the lightest load

fails to set the fastener, try the next highest load until

the proper level is attained. Failure to follow this

procedure may cause the fastener to be overpowered.

If this occurs, the fastener may fully penetrate the base

material causing serious injury or death to someone.

Overpowering the fastener can also damage the tool,

creating a safety hazard to both the operator

or bystanders.

9. Do not fasten into cast iron, tile, glass, or other types of

brittle materials. These materials can shatter and create

sharp fragments which may cause injury.

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

10. Do not fire tool within 3" (three inches) of the edge of

a concrete base material or within 1/2" (one-half inch)

of the edge of a steel base material.

11. Do not attempt to install a fastener closer than 3"

(three inches) to another previously inserted fastener in

concrete or 1-1/2" (one and one-half inch) in steel.

12. Do not fasten into a concrete base material less than 3

times as thick as the fastener penetration or into a steel

base material thinner than 1/8”.

13. Never attempt to install a fastener in a cracked or

spalled area in concrete. Place fastener at least 3”

(three inches) away from a spalled area to prevent the

possibility of the fastener bending and striking an

operator or bystander.

14. Do not attempt to install fasteners in areas that have

been welded or cut with a torch as these procedures

may have caused local hardening of the steel.

15. Do not fasten through a predrilled hole unless proper

guidance is provided.

16. If you decide not to make a fastening after the tool has

been loaded, you must always remove the powder load

first followed by the fastener.

17. Never attempt to override the safety features of this tool.

HANDLING THE TOOL AND POWDER LOADS

1. Never leave a loaded tool unattended. Once the tool

is loaded, make the fastening immediately or unload

the tool.

2. Always unload the tool before work breaks, changing

parts, cleaning or servicing, and when storing.

3. To prevent accidental discharge of loads, never carry the

powder loads in the same container as the fasteners or

other hard objects.

4. Always store the powder loads in the containers

provided or in an enclosure provided for them. Never

intermix the various power levels. Keep them

segregated in clearly identified containers.

5. Powder loads should never be used in firearms. They are

normally more powerful that the cartridges supplied

with the firearms.

6. Powder actuated tools and powder loads should always be

stored under lock and key. Tools must be unloaded when

not in use.

TOOL MALFUNCTION

1. In the event that a load fails to discharge after the

trigger is pulled, the tool must be kept depressed

against the work surface for a minimum of 30 (thirty)

seconds in case of a delayed load discharge. Then

carefully remove the entire load strip. and dispose of it

in a can of water or other nonflammable liquid. Never

attempt to force or pry a load out of a tool chamber.

2. Never discard unfired powder loads into a trash container.

3. Do not attempt to unload or disassemble a jammed,

stuck or broken tool as improper handling may cause it

to discharge and strike operator and/or bystander. A

jammed tool must be pointed in a safe direction at all

times. Tag the tool and lock it up. Call your Powers

Fasteners representative for proper assistance.

9P3500

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

10 P3500

R3500

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

Tool Operation

CAUTION:

— Be sure to read and understand all of the safety precautions and training in

this manual before attempting to operate the tool. (Check to be sure the tool is not loaded, the

piston moves freely within the barrel, and no foreign objects or fasteners are in the barrel.)

Perform the daily function test before using the tool.

OPERATION

1. Always load the fastener before inserting powder load to prevent injury to the operator or

bystanders in the event of an accidental discharge. Place the fastener, point out, into the end of

the guide until the fluted tip fits inside. Do not use excessive force when inserting the fastener. If

excessive force is required, stop and determine why the fastener can not be inserted. Correct the

problem before proceeding.

Note: Do not use fasteners longer than 3" as listed in the fastener selection section of this

manual. Pins longer than 2-1/2" require pre-driving.

2. Always point the tool in a safe direction away from bystanders and the operator. In one

movement, slide the barrel forward then close it against the stop. The barrel should be pulled

fully forward to reset the piston for the next fastening. Loss of power may result from an im-

properly positioned piston.

Do not attempt to close the tool by exerting force on the front of the barrel. Never place your

fingers or hands over muzzle end of the tool. The safe position for hands and fingers are as

shown in the diagram. Hands must never be placed in front of the tool muzzle or barrel.

In the event of an accidental discharge, the piston and/or fastener can pass through the

operator's hand.

3. Insert the powder load strip into the bottom of the tool handle starting with the lowest power

level, 2/Brown. The strip should be inserted completely and should be flush with the bottom of

the handle. Always insert the strip from the bottom of the handle.

If this load does not fully set the fastener, try the next higher power level until the proper

level is found.

Note: Over driving or over powering a fastener can cause a safety hazard.

4. To make a fastening, place the tool against the work surface. Hold the tool firmly with two

hands and completely depress the barrel. Then squeeze the trigger. Always hold the tool

perpendicular to the work surface. Hold the tool firmly against the work surface to avoid

excessive recoil. Never depress the tool against anything except the work surface. Note: In the

event that the load does not discharge after the trigger is pulled, continue to hold the tool

depressed against the work surface for at least 30 (thirty) seconds in case of a delayed load

discharge. Then carefully remove the entire load strip and dispose of it in a can of water or other

non flammable liquid. Never attempt to force or pry a load out of a tool chamber. Do not

discard unfired loads into a trash container.

5. To prepare for the next fastening, point the tool in a safe direction. Always insert a new fastener

before loading or advancing the powder load strip. Insert the fastener as described in step 1.

Once the fastener is inserted, cycle the tool as described in step 2. Repeat this procedure for

subsequent fastenings. When the ten load strip has been completely fired, remove it by pulling it

from the top of the tool body.

Note: Do not attempt to unload or disassemble a jammed, stuck or broken tool as improper

handling may cause it to discharge and strike the operator and/or bystander. A jammed tool

must be pointed in a safe direction at all times. Tag the tool and lock it up. Call your Powers

Fasteners representative for proper assistance.

11 P3500

Proper Maintenance and Cleaning

MAKE SURE THE TOOL IS NOT LOADED. BE SURE THE TOOL IS NOT HOT PRIOR TO

ATTEMPTING DISASSEMBLY OR CLEANING.

DAILY FUNCTION TEST

Check the functioning of the tool, without a powder load or fastener in the tool, by pushing down against the work

surface, pulling the trigger, and releasing the tool from the work surface. Function the unloaded tool several times and

insure that the breech parts and firing mechanism operate freely before fastening with the tool.

Your Powers Fasteners Authorized representative should be asked to assist the first time you disassemble and clean

your tool.

If you ever have any trouble reassembling the tool, or have any doubt about worn parts, call your Powers Fasteners

Authorized Powder Distributor.

CLEANING

AIl parts should be cleaned with detergent oil and the wire brushes supplied with your tool kit. Remove heavy dirt

build-up with the brush. After cleaning with oil, all parts should be wiped thoroughly dry. Excess oil will tend to collect

dirt and dust. Wear eye protection when cleaning the tool. The piston rod, barrel assembly, and receiver should all be

cleaned of excess dirt on a daily basis. Check the condition of the piston for damage from wear and deformation.

To maintain this tool in good working condition, it is necessary to disassemble and clean the entire tool if dirt is

evident in the breech face, or if the tool appears to lose power. All parts should be cleaned with oil and wire brushes.

Remove heavy dirt. All parts should be wiped thoroughly dry after cleaning with oil.

General tool maintenance should be performed at six month intervals or more frequently as required by the frequency

of tool use.

LEVER

GUIDE

KIT

P3500 Spare Parts Listing

CAT. NO. NO. DESCRIPTION

52100 1 Piston 2/DN-1 w/ring

52144 22 Rear Spring Kit

52102 2 Piston Flat End w/ring - standard

52146 23 Sear

52106 3 Piston Ring

52148 24 Firing Pin

52108 4 Guide 2/F-3 - standard

52150 25 End Cap

52110 5 Baseplate 2/S13 - standard

52152 26 Pressure Pin

52112 6 Piston Stop

52154 27 Compression Spring

52114 7 Guide 2/F-4 Limited Access

52156 28 Firing Pin Nut

52116 8 Baseplate 2/S-14-1 Limited Access

CAT. NO. NO. DESCRIPTION

52158 29 Front Allen Cap Screw (2)

52118 9 Trigger

52160 30 Piston Guide

52120 10 Shear Clip

52162 31 Steel Liner Assembly

52122 11 Steel Annular Ball

52164 32 Housing

52124 12 Release Lever Pin

52166 33 Stablizer

52126 13 Lever Guide Kit*

52168 34 SupportStrip Assembly

52128 14 Threaded Pin

52170 35 Release Lever

52130 15 Advance Lever

52172 36 Retaining Ring

CAT. NO. NO. DESCRIPTION

52132 16 Advance Lever Guide

52174 37 Trigger Return Spring

52134 17 Sear Spring

52176 38 Advancer Lever Bushing

52136 18 Annular Ball Spring

52178 39 Spring Guide

52138 19 Firing Pin Return Spring

52180 40 Spring Detent

52140 20 Strip Pressure Ball & Spring

52182 41 Cheese Head Screw (2)

52142 21 Advancer Lever Spring

52184 42 Handle Allen Screw

52186 43 Rubber Grip

52181 44 Firing Pin Assembly*

P3500

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

Troubleshooting

ALWAYS CHECK INSTRUCTION MANUAL FOR PROPER ASSEMBLY OF PARTS

PROBLEM POSSIBLE CAUSE SOLUTION

Fastener Overdriving Power level too high / Pin too short Use a lower powder load level number or a longer pin

Soft base material Check base material suitability section

Tool does not fire Tool not depressed completely See "Tool does not depress completely" section below

Firing pin damaged Replace damaged part(s)

Tool does not depress completely Damaged firing pin parts, ejector, Check the parts for damage or improper assembly

etc. Parts assembled improperly

Power reduction or inconsistent Barrel is not pulled fully Barrel must be pulled out completely to properly

fastener penetration forward when cycling tool. reset the piston

Worn or damaged piston Replace piston or piston ring

or piston ring

Load strip cannot be Improper loading Insert strip from the bottom of the tool handle

inserted into tool

Wrong caliber strip Use proper strip

Load strip will not advance Worn advance lever guide Replace advance lever guide.

This should be performed by qualified individuals

Load will not fire when Tool is not fully depressed Follow safety procedure for misfired load then

trigger is pulled attempt to fully depress tool before pulling trigger

Load will not fire when Load is already fired Cycle tool

tool is fully depressed

and trigger is pulled

Load misfire Follow safety procedure

Broken firing pin Replace firing pin nut. This should be performed by

qualified individuals

Broken or missing Replace firing pin nut. This firing pin nut should be

performed by qualified individuals

12 P3500

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

Troubleshooting

ALWAYS CHECK INSTRUCTION MANUAL FOR PROPER ASSEMBLY OF PARTS

PROBLEM POSSIBLE CAUSE SOLUTION

Tool cannot be opened Lack of proper cleaning Clean tool thoroughly

or cycled Damaged or bent piston Remove and replace piston

Broken or damaged parts Tag tool with warning "Defective - Do Not Use" place

in locked container and contact your Powers Fasteners

Authorized representative for service

Piston stuck in the forward Piston has been overdriven and is Tap the piston against a hard surface

position jammed against piston reset pin

Chipped or damaged piston Tool not held on work surface Machine piston as shown on page 11.

squarely. This allows the piston to Piston regrinding may be performed only by

slip off the head of the pin and qualified individuals

cause damage to the piston

Piston guide will not Bent shear clip Remove and replace shear clip

open easily

Excessive build-up of dirt Disassemble and clean tool

Piston stop is damaged Replace piston stop

Foreign material jammed Disassemble and remove foreign particles

between the piston guide

and steel liner assembly

Piston guide opens Annular ball spring or Remove and replace with a new spring and/or ball

too easily steel annular ball have worn

13 P3500

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

14 P3500

REPLACING OR REPAIRING THE PISTON

The piston is an expendable part and must be replaced periodically. Typical signs of a worn out

piston are: breaking, bending or mushrooming.

Prior to servicing the tool make sure there is no powder load in the tool. Use caution and do

not lose or damage any tool parts.

1. Using a pin, lift the end of the annular ball spring and rotate toward the top of the tool body.

Pull the piston stop back and out of the tool.

2. Slide the piston guide and baseplate assembly out of the tool.

3. Using a fastener, pry the shear clip off the baseplate. Replace the shear clip if it is damaged.

4. Remove the baseplate from the piston guide, then pull the piston out of the guide.

REASSEMBLY:

5. Tilt the baseplate and slide the fastener guide out. Press the guide out of the baseplate using a

piston if it does not slide out freely. Replace the guide if it is damaged.

6. Clean the piston using a wire brush. Inspect it for worn or damaged piston ring, chipped end, or

bending. Apply lubricant to the piston shank to minimize piston sticking from an overdrive con-

dition. Wipe the piston dry.

7. If a piston tip is damaged, it can be shortened a maximum of 0.20 inches. The tip of the piston

should be ground flat and at 90 degrees to the shank of the piston. The chamfer of the piston

must also be reground as shown. Piston grinding should be performed by qualified personnel

using the proper equipment.

8. Press the piston into the end of the piston guide. Be sure to push it all the way back into the

guide. Ensure piston is positioned correctly in piston guide.

9. Insert the fastener guide into the baseplate.

10. Align the groove in both the piston guide and baseplate. Slide the baseplate (with fastener

guide) onto the piston guide. Press the shear clip into place. Insert the piston guide and

baseplate assembly into the liner in the tool body. Be sure to align the groove with the opening

for the piston stop.

11. Replace the piston stop and rotate the annular spring into place.

Upon reassembly of the tool perform the following test. Depress the tool against a flat, hard

surface and pull the trigger. The barrel assembly should slide smoothly inside the tool housing

assembly. The firing pin should release after the trigger has been pulled.

CAUTION:

THIS TEST SHOULD BE PERFORMED WITHOUT A PIN OR

POWDER LOAD IN THE TOOL.

10°

0.120"

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

15 P3500

■■✓Check the correct answer.

1It is necessary to read the Operator’s Manual

prior to operating a Powers Fasteners low

velocity tool.

■■ True ■■False

2When fastening into concrete, the base

material should be greater than the shank

penetration by at least:

■■ 1 time

■■ 2 times

■■ 3 times

3When operating a powder actuated tool, your

hand should never be placed:

■■ around the tool body

■■ in front of the tool muzzle

■■ over the tool handle

4To determine the suitability of a base

material, use the fastener as a center punch.

• If the fastener is blunted, do not fasten; the

material is too:

■■soft ■■hard ■■brittle

• If the fastener penetrates easily, do not

fasten; the material is too:

■■soft ■■hard ■■brittle

• If the material cracks or shatters, do not

fasten; the material is too:

■■soft ■■hard ■■brittle

5Unsafe applications for powder actuated tools

may be caused by which of the following?

■■a soft base material

■■improper powder load

■■fastening too close to

an unsupported edge

■■a malfunctioning tool

■■fastening into a spalled area

■■fastening through a

pre-existing hole

■■all of the above

6Which one of the following building materials

is not suitable as a receiving material (base

material) for powder actuated fasteners?

■■ sheet rock

■■wood

■■ fiberglass

■■ sheet metal

■■ all of the above

7When considering the safety of a particular

application, the operator must think about:

■■the base material

■■the powder load power level

■■the operator’s safety

■■the safety of bystanders

and fellow workers

■■all of the above

8The proper loading procedure is: insert fastener

first, powder load second. The fastener should

always be placed in the tool prior to the load.

■■ True ■■False

9Which one of the following materials is

usually suitable for powder actuated

fastenings?

■■poured concrete

■■hollow tile

■■surface hardened steel

■■glazed brick

10 In concrete, a fastener should be

driven no closer to an unsupported

edge than:

■■1/2" ■■1-1/2" ■■3"

11 Fishhooking is a condition which

can occur when a powder actuated

fastener strikes a piece of hard aggregate or

very hard concrete, bends and comes out of the

work surface. A fishhook can cause a serious

injury or death.

■■ True ■■False

12 Placing a hand over the muzzle bushing of a

loaded tool can result in serious injury from

piston overdrive or an escaping fastener if the

tool is discharged accidentally.

■■ True ■■False

13 Piston overdrive is caused by overpowering of

the tool or by discharging the tool against a

soft surface.

■■ True ■■False

14 Malfunctioning tools cannot be used and

must be removed from service immediately.

■■ True ■■False

15 After conducting a Center Punch Test,

the best way to check the base material

is to set several fasteners using the least

powerful load.

■■ True ■■False

16 Safety goggles and hearing protection should

not be worn by the operator and any

necessary bystanders when using the tool.

■■ True ■■False

17 A powder actuated tool cannot be safely used

in an explosive or flammable atmosphere.

■■ True ■■False

18 List the proper powder load level number

(1-6) next to each

color listed.

Red ___ Brown ___

Green ___ Yellow ___

Gray ___ Purple ___

19 The weakest power level should

be used when making the first fastening.

■■ True ■■False

20 You can fasten into welded areas

of steel.

■■ True ■■False

P3500

• The proper procedure if a powder load fails to

ignite is to hold the tool against the work

surface and wait 30 seconds, then proceed

exactly as directed in the Operator’s Manual.

■■ True ■■False

• Powers Fasteners powder loads for the P3500

are .22 caliber, "A" tapered, neck down, rim

fire, short crimped cartridges. No other

powder load may be used in this tool.

■■ True ■■False

• Operators should never compress the P3500

or any other powder actuated tool against

any part of their body.

■■ True ■■False

• If a piston buffer for the P3500 becomes

deformed, simply remove it, and use the tool

without the buffer?

■■ True ■■False

OPERATOR’S NAME DATE

HOME ADDRESS

AGE DATE OF BIRTH

COMPANY NAME

COMPANY ADDRESS

COMPANY PHONE

SIGNATURE DATE

QUALIFIED TOOL OPERATOR EXAMINATION

TRIM ALONG DOTTED LINE, PLACE IN ENVELOPE, ADDRESS AS SHOWN AND AFFIX POSTAGE



MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

LICENSE AND WARRANTY ACTIVATION

THE P3500 TOOL IS WARRANTED FOR 5 YEARS FROM DATE OF PURCHASE.

I certify that I have read and understand the P3500 Tool Operating Instruction Manual and have taken the Operator’s exam. I understand

the importance of following all safety procedures and that failure to read, comprehend, and follow the detailed rules and warnings

regarding the safe operation of powder actuated tools can result in serious injury or death to the tool operator or bystanders. I agree to

conform to all the rules and regulations regarding the use of powder actuated tools. (Please print clearly)

THE SERIAL NUMBER ON MY TOOL IS:

PLEASE SEND MY TOOL LICENSE TO:

NAME

ADDRESS

CITY STATE ZIP PHONE

MAIL TO:

Tool License Coordinator

Powers Fasteners, Inc.

2 Powers Square

New Rochelle, NY 10801

16 P3500

MODEL P3500 CAT. NO.52000/Deluxe Kit 52001/Blister Pack

TRIM ALONG DOTTED LINE, PLACE IN ENVELOPE, ADDRESS AS SHOWN AND AFFIX POSTAGE



Gebruiksaanwijzing Powers P3500 schiethamer

Veiligheidsmaatregelen

Veiligheid is de voornaamste prioriteit bij gebruik van een schiethamer. De gebruiker moet

deze aanwijzing lezen en begrijpen. Hij moet vertrouwd zijn met alle functionele en

veiligheidsaspecten van deze handleiding. Het is de verantwoordelijkheid van de gebruiker de

juiste training te krijgen voor gebruik van de schiethamer.

Het onderstaande is een samenvatting van de veiligheidsmaatregelen die gevolgd moeten

worden bij het gebruik van een Powers Fasteners schiethamer. Het ingebrekeblijven kan

leiden tot ernstige verwondingen of zelfs dood van gebruiker of omstanders.

Alvorens de schiethamer te gebruiken

1. Waarschuwingsborden moeten aangebracht zijn binnen het gebied waarin de schiethamer

wordt gebruikt. Deze borden moeten minstens 20 x 25 cm zijn. De tekens moeten

minstens 2,5 cm hoog zijn. Het teken moet vermelden: “Schiethamer in gebruik”.

2. Goedgekeurde veiligheidsbrillen moeten gedragen worden door de gebruiker en

bijstanders, om de ogen te beschermen tegen rondvliegende delen. Gehoorbescherming

moet ook altijd gedragen worden door gebruiker en bijstanders. Andere persoonlijke

veiligheidsmiddelen die vereist zijn, moeten ook gebruikt worden.

3. Verander nooit zelf onderdelen van uw schiethamer. Gebruik alleen originele Powers

onderdelen. Werk alleen met Powers ladingen en nagels.

4. Handen en andere lichaamsdelen mogen nooit voor de loop geplaatst worden. Indien de

schiethamer afgaat kan dit leiden tot het door de hand dringen van nagel en plunjer.

5. De neus van de hamer mag nooit tegen een lichaamsdeel ingedrukt worden. Ernstige en/of

dodelijke verwondingen kunnen ontstaan door het afgaan van de schiethamer.

6. Richt de schiethamer te allen tijde in een veilige richting.

7. Schiethamers moeten onderhouden en schoongemaakt worden zoals aangegeven.

8. Gebruik de schiethamer alleen voor doeleinden waarvoor hij is ontworpen.

Het laden van de schiethamer voorbereiden

1. De schiethamer moet voor gebruik gecontroleerd worden om zeker te stellen dat ze niet

met een nagel of een lading geladen is.

2. Om veilig gebruik zeker te stellen, moet de dagelijkse functioneringstest uitgevoerd

worden die verderop beschreven wordt. Zorg er voor dat de schiethamer niet geladen is.

3. Gebruik de schiethamer niet tenzij alle onderdelen juist zijn aangebracht en juist

functioneren. Gebruik geen slecht functionerende of geblokkerde schiethamer.

4. Gebruik de schiethamer niet zonder kennis van de kleurcodering ter indicatie van het

krachtnivau van schietladingen.

Gebruik van de schiethamer

1. Gebruik alleen originele Powers nagels en schietladingen voor de schiethamer

2. Gebruik geen schiethamer in een ontvlambare of een explosieve omgeving

3. Vuur de schiethamer niet af zonder nagel. De plunjer zal inslaan op het werkoppervlak en

mogelijk letsel veroorzaken aan gebruiker en omstanders en kan de schiethamer

beschadigen.

4. Laad de schiethamer niet voordat u een bevestiging wilt aanbrengen. Controleer het kracht

niveau van de lading alvorens aan te brengen in de kamer van de schiethamer.

5. Bevestiging moet ingebracht worden voordat de hamer geladen wordt, om letsel te

voorkomen indien een lading onvoorzien afgaat.

Gebruiksaanwijzing Powers P3500 schiethamer

6. De schiethamer moet niet gesloten worden door de neus tegen het werk oppervlak te

drukken. Het sluiten moet handmatig gebeuren, met de palm naar de loop gericht om

letsel te voorkomen

7. Gebruik de schiethamer altijd loodrecht op het oppervlak. Gebruik de rubberen kap om

het risico van wegspattend materiaal te verminderen.

8. Maak altijd een testbevestiging met de lichtste lading. Indien de bevestiging niet goed

geïnstalleerd is, gebruik dan de eerstvolgende sterkere lading totdat het juiste krachtniveau

is bereikt. Het niet volgen van deze procedure kan ertoe leiden dat een bevestiging te

krachtig geïnstalleerd wordt. Dit kan leiden tot volledige penetratie door het materiaal en

tot verwonding of dood van gebruiker of omstanders. Teveel kracht kan ook leiden tot

beschadiging van de schiethamer, wat ook tot veiligheidsrisicos leidt.

9. Bevestig niet in gietijzer, tegels, glas of andere soorten broos materiaal. Deze materialen

kunnen verbrijzelen en scherpe splinters kunnen verwonding veroorzaken.

10. Schiet geen bevestiging binnen 8 (acht) centimeter van de rand van beton of 13 (dertien)

millimeter van de rand van staal.

11. Installeer geen bevestiging binnen 8 (acht) centimeter van een eerdere bevestiging in

beton of binnen 13 (dertien) millimeter in staal.

12. Bevestig niet in beton dat minder dik is dan drie maal de plaatsingsdiepte van de nagel of

in staal dat minder dik is dan 3 mm.

13. Probeer geen bevestiging te installeren in gescheurd beton of in een spleet in beton. Plaats

de bevestiging minstens 8 (acht) centimeter van een spleet vandaan om te voorkomen dat

de nagel buigt of de gebruiker of omstander treft.

14. Probeer geen bevestiging aan te brengen in plaatsen die gelast of met een snijbrander

bewerkt zijn omdat deze handelingen tot lokale harding kan leiden.

15. Bevestig niet door voorgeboorde gaten.

16. Indien u besluit de bevestiging niet aan te brengen nadat de schiethamer geladen is, moet

u eerste de lading verwijderen voor de nagel te verwijderen.

17. Volg de veiligheidsaanwijzingen altijd strict op.

Omgaan met schiethamer en schietladingen

1. Laat nooit een geladen schiethamer onbewaakt achter. Nadat de schiethamer geladen is,

moet de bevestiging direct aangebracht worden of moet de schiethamer ontladen worden.

2. Ontlaad de schiethamer altijd voor pauzes, voor het uitwisselen van onderdelen,

schoonmaken of reparatie en voor het opbergen.

3. Teneinde onbedoeld afgaan van ladingen te voorkomen, mogen schietladingen niet in

dezelfde kist opgeborgen worden als de nagels of andere scherpe voorwerpen.

4. Berg de schietladingen altijd op in de bijbehorende verpakking. Meng de verschillende

krachtniveaus niet in een verpakking. Berg ze gescheiden op in duidelijk gemarkeerde

verpakking.

5. Schietladingen mogen niet in vuurwapens gebruikt worden. Schiethamer ladingen zijn

krachtiger dan ladingen voor gewone wapens.

6. Schiethamers en schietladingen moeten afgesloten door een slot opgeborgen worden.

Schiethamers moeten ontladen zijn als zij niet gebruikt worden.

Schiethamer storingen

1. In het geval een lading niet afgaat nadat de trekker is overgehaald, moet de schiethamer

gedurende 30 seconden vastgedrukt blijven op de oppervlakte omdat het een vertraagd

afgaande lading kan betreffen. Verwijder vervolgens de strip voorzichtig en dompel deze

in een niet brandbare vloeistof, zoals water. Probeer nooit een lading uit de kamer te

peuteren.

Gebruiksaanwijzing Powers P3500 schiethamer

2. Gooi nooit ongebruikte ladingen weg met gewoon afval.

3. Probeer niet een geblokkeerde of kapotte schiethamer te ontladen, omdat onjuiste

handeling ertoe kan leiden dat de lading afgaat en de gebruiker of omstanders kan

verwonden. Een geblokkeerde schiethamer moet altijd in een veilige richting wijzen.

Markeer de schiethamer en neem contact op met uw Powers Fasteners vertegenwoordiger

voor assistentie.

Schiethamer gebruik

Waarschuwing:

Alvorens de schiethamer te proberen, dient een Powers vertegenwoordiger u alle

veiligheidsmaatregelen uit te leggen. (Controleer voor de zekerheid dat de schiethamer niet

geladen is, de plunjer vrijelijk in de loop kan bewegen en er geen vreemde voorwerpen in de

loop zijn). Voer de dagelijkse functioneringstest uit voor de schiethamer te gebruiken.

Gebruik

1. Laad de nagel altijd voor het aanbrengen van de lading om verwonding te voorkomen aan

gebruiker of omstanders door het onvoorzien afgaan van een lading. Plaats de nagel met

punt naar buiten in de opening tot de nagel geheel is ingebracht. Gebruik niet teveel kracht

bij het inbrengen. Indien veel kracht nodig is, stop en bepaal waarom veel kracht nodig is.

Corrigeer het probleem alvorens verder te gaan

Opmerking: Gebruik geen nagels die langer zijn dan 75mm. Nagels langer dan 60mm

moeten voorgemonteerd worden.

2. Richt de schiethamer altijd in een veilige richting, weg van omstanders en de gebruiker.

Schuif de loop voorwaarts in één beweging, en sluit deze weer tegen de stop. De loop

moet in zijn geheel naar voren gebracht worden om de plunjer volledig in positie te

brengen voor de volgende bevestiging. Verlies van kracht kan het gevolg zijn van een

onjuist gepositioneerde plunjer.

Probeer niet de schiethamer te sluiten door druk op de punt van de schiethamer uit te

oefenen. Plaats nooit vingers of hand over het einde van de schiethamer. De veilige

positie voor handen is aan de grip en bovenop de schiethamer. Bij het onverwacht afgaan

van de schiethamer kan de plunjer dwars door de hand gaan.

3. Breng de strip lading van onder aan, beginnend met het laagste krachtniveau, groen. De

strip moet geheel ingebracht worden en moet vlak zijn met de onderkant van de opening.

Breng de strip altijd van onder in.

Indien de nagel niet volledig geïnstalleerd wordt, gebruik dan de eerstvolgende sterkere

lading totdat de bevestiging juist geïnstalleerd is.

Opmerking: het te krachtig inschieten van een bevestiging kan een veiligheidsgevaar

opleveren.

4. Om een bevestiging aan te brengen, plaats de schiethamer tegen het oppervlak. Houd de

schiethamer met 2 handen stevig vast. Haal de trekker over. Houd de schiethamer stevig

tegen het oppervlak om terugslag tegen te gaan. Druk de schiethamer alleen tegen het

bevestigingsmateriaal in.

Gebruiksaanwijzing Powers P3500 schiethamer

Opmerking: In het geval een lading niet afgaat, houd de schiethamer 30 seconden op

dezelfde plaats voor het geval van een vertraagde ontsteking. Verwijder vervolgens de

strip voorzichtig en plaats deze in water of een andere niet vlambare vloeistof. Gooi nooit

onafgevuurde ladingen weg met gewoon afval.

5. Om de volgende bevestiging voor te bereiden, richt de schiethamer in een veilige richting.

Breng eerst de nagel in voor de hamer opnieuw te spannen. Zodra de strip leeggeschoten

is, verwijder deze dan door deze boven uit de schiethamer te trekken.

Opmerking: Probeer niet een beschadigde of geblokkeerde schiethamer te ontladen

omdat onjuist handelen kan leiden tot afgaan van een lading. Dit kan gebruiker en

omstanders verwonden. Label een beschadigde of geblokkeerde schiethamer. Neem

contact op met uw Powers vertegenwoordiger voor juiste ondersteuning.

Other manuals for P3500

Table of contents

Other Powers Power Tools manuals

Powers

Powers P3X Instruction Manual

Powers

Powers PA3500 Administrator Guide

Powers

Powers P3500 Instruction Manual

Powers

Powers P3801 Instruction Manual

Powers

Powers P3600 Instruction Manual

Popular Power Tools manuals by other brands

Rhin-O-Tuff

Rhin-O-Tuff EWC-8370 Instruction book

Central Pneumatic

Central Pneumatic 93048 Assembly and operating instructions

NUTOOL

NUTOOL NJ450 Original instructions

Sherman + Reilly

Sherman + Reilly SRK6X Operation manual

Power Tec

Power Tec BJ600 owner's manual

Power Fist

Power Fist 8043598 owner's manual

Power Fist

Power Fist 8095903 owner's manual

BLACK DECKER

BLACK DECKER MT218 Original instructions

Tripp Lite

Tripp Lite PDUMH15NET owner's manual

Yard Works

Yard Works LSS10163-1 owner's manual

Gema

Gema OptiGun GA03-E Operating instructions and spare parts list

CO/Tech

CO/Tech SK-3000-UK manual

Parkside

Parkside PFBS 9.6 V - 3 Operation and safety notes

Powerfix Profi

Powerfix Profi PLPRS A1 operating instructions

Makita

Makita DTS130 instruction manual

Bosch

Bosch 0 986 612 997 operating instructions

Hitachi

Hitachi H 65SD3 instruction manual

Skil

Skil 1475 instructions
