Makita DTS130 User manual

DTS130
EN Cordless Oil-impulse Driver INSTRUCTION MANUAL 4
UK Акумуляторний
гідравлічний гвинтоверт
ІНСТРУКЦІЯ З
ЕКСПЛУАТАЦІЇ 10
PL Akumulatorowa wkrętarka
impulsowa INSTRUKCJA OBSŁUGI 16
RO
Maşină de înşurubat cu
impact pe bază de ulei fără
cablu
MANUAL DE INSTRUCŢIUNI 22
DE Akku - Impulsschrauber BEDIENUNGSANLEITUNG 28
HU Vezeték nélküli hidraulikus
ütvefúró-csavarhúzó HASZNÁLATI KÉZIKÖNYV 34
SK Akumulátorový olejový
impulzný skrutkovač NÁVOD NA OBSLUHU 40
CS Akumulátorový rázový
utahovák NÁVOD K OBSLUZE 46

3
2
1
1
1
2
1
1
AB
1
12
Fig.1
Fig.2
Fig.3
Fig.4
Fig.5
Fig.6
Fig.7
Fig.8
2

123
3
2
1
1
2
1
1
2
1
23
1
1
2
Fig.9
Fig.10
Fig.11
Fig.12
Fig.13
Fig.14
Fig.15
Fig.16
3

4ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model DTS130
Capacities Machine screw M4 - M8
Standard bolt M6 - M10
High tensile bolt M6 - M8
No load speed (min-1)0 - 2,400
Impacts per minute (min-1)0 - 1,600
Overall length 183 mm
Net weight 1.5 - 1.7 kg
Rated voltage D.C. 14.4 V
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsandbatterycartridgemaydifferfromcountrytocountry.
• Theweightmaydifferdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-
est combination, according to EPTA-Procedure 01/2014, are shown in the table.
Applicable battery cartridge and charger
Batterycartridge BL1415N / BL1430 / BL1430B / BL1440 / BL1450 / BL1460B
Charger DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF
• Someofthebatterycartridgesandchargerslistedabovemaynotbeavailabledependingonyourregionof
residence.
WARNING: Only use the battery cartridges and chargers listed above.Useofanyotherbatterycartridges
andchargersmaycauseinjuryand/orre.
Intended use
The tool is intended for screw driving in wood, metal
and plastic.
Noise
ThetypicalA-weightednoiseleveldeterminedaccord-
ing to EN62841:
Sound pressure level (LpA) : 79 dB (A)
Uncertainty(K):3dB(A)
Thenoiselevelunderworkingmayexceed80dB(A).
Wear ear protection
Vibration
Thevibrationtotalvalue(tri-axialvectorsum)deter-
mined according to EN62841:
Work mode : impact tightening of fasteners of the
maximumcapacityofthetool
Vibration emission (ah) : 17.5 m/s2
Uncertainty(K):2.0m/s2
NOTE: The declared vibration emission value has
been measured in accordance with the standard test
methodandmaybeusedforcomparingonetoolwith
another.
NOTE: The declared vibration emission value
mayalsobeusedinapreliminaryassessmentof
exposure.
WARNING: The vibration emission during actual
use of the power tool can differ from the declared
emissionvaluedependingonthewaysinwhichthe
tool is used.
WARNING:Besuretoidentifysafetymeasures
to protect the operator that are based on an estima-
tionofexposureintheactualconditionsofuse(taking
accountofallpartsoftheoperatingcyclesuchas
the times when the tool is switched off and when it is
running idle in addition to the trigger time).
EC Declaration of Conformity
For European countries only
TheECdeclarationofconformityisincludedasAnnexA
to this instruction manual.
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool. Failure to follow all instructions
listedbelowmayresultinelectricshock,reand/or
seriousinjury.

5ENGLISH
Save all warnings and instruc-
tions for future reference.
Theterm"powertool"inthewarningsreferstoyour
mains-operated(corded)powertoolorbattery-operated
(cordless) power tool.
Cordless impact driver safety
warnings
1. Hold the power tool by insulated gripping
surfaces, when performing an operation
where the fastener may contact hidden wiring.
Fastenerscontactinga"live"wiremaymake
exposedmetalpartsofthepowertool"live"and
could give the operator an electric shock.
2. Always be sure you have a rm footing.
Be sure no one is below when using the tool in
high locations.
3. Hold the tool rmly.
4. Wear ear protectors.
5. Do not touch the bit or the workpiece immedi-
ately after operation. They may be extremely
hot and could burn your skin.
6. Keep hands away from rotating parts.
7. Use auxiliary handle(s), if supplied with the
tool.Lossofcontrolcancausepersonalinjury.
8. Hold the power tool by insulated gripping
surfaces, when performing an operation where
the cutting accessory may contact hidden
wiring.Cuttingaccessorycontactinga"live"
wiremaymakeexposedmetalpartsofthepower
tool "live" and could give the operator an electric
shock.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product.
MISUSE or failure to follow the safety rules stated
in this instruction manual may cause serious
personal injury.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store the tool and battery cartridge in
locations where the temperature may reach or
exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Be careful not to drop or strike battery.
9. Do not use a damaged battery.
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
Forcommercialtransportse.g.bythirdparties,
forwarding agents, special requirement on pack-
aging and labeling must be observed.
For preparation of the item being shipped, consult-
inganexpertforhazardousmaterialisrequired.
Pleasealsoobservepossiblymoredetailed
national regulations.
Tape or mask off open contacts and pack up the
batteryinsuchamannerthatitcannotmove
around in the packaging.
11. Follow your local regulations relating to dis-
posal of battery.
12. Use the batteries only with the products
specied by Makita. Installing the batteries to
non-compliantproductsmayresultinare,exces-
siveheat,explosion,orleakofelectrolyte.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
havebeenaltered,mayresultinthebatterybursting
causingres,personalinjuryanddamage.Itwill
alsovoidtheMakitawarrantyfortheMakitatooland
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. Charge the battery cartridge if you do not use
it for a long period (more than six months).

6ENGLISH
FUNCTIONAL
DESCRIPTION
CAUTION:
• Alwaysbesurethatthetoolisswitchedoffand
thebatterycartridgeisremovedbeforeadjust-
ing or checking function on the tool.
Installing or removing battery
cartridge
►Fig.1: 1.Batterycartridge2. Button 3. Red indicator
• Alwaysswitchoffthetoolbeforeinstallingor
removingofthebatterycartridge.
• Toremovethebatterycartridge,slideitfromthe
tool while sliding the button on the front of the
cartridge.
• Toinstallthebatterycartridge,alignthetongue
onthebatterycartridgewiththegrooveinthe
housingandslipitintoplace.Alwaysinsertitall
thewayuntilitlocksinplacewithalittleclick.If
youcanseetheredindicatorontheuppersideof
thebutton,itisnotlockedcompletely.Installitfully
untiltheredindicatorcannotbeseen.Ifnot,itmay
accidentallyfalloutofthetool,causinginjuryto
youorsomeonearoundyou.
• Donotuseforcewheninstallingthebatterycar-
tridge.Ifthecartridgedoesnotslideineasily,itis
notbeinginsertedcorrectly.
Battery protection system (Lithium-
ion battery with star marking)
►Fig.2: 1. Star marking
Lithium-ion batteries with a star marking are equipped
withaprotectionsystem.Thissystemautomatically
cutsoffpowertothetooltoextendbatterylife.
Thetoolwillautomaticallystopduringoperationifthe
tooland/orbatteryareplacedunderoneofthefollowing
conditions:
• Overloaded:
The tool is operated in a manner that causes
ittodrawanabnormallyhighcurrent.
In this situation, release the trigger switch on
the tool and stop the application that caused
the tool to become overloaded. Then pull the
trigger switch again to restart.
Ifthetooldoesnotstart,thebatteryisover-
heated.Inthissituation,letthebatterycool
before pulling the trigger switch again.
• Lowbatteryvoltage:
Theremainingbatterycapacityistoolow
and the tool will not operate. In this situation,
removeandrechargethebattery.
Indicating the remaining battery
capacity
Only for battery cartridges with the indicator
►Fig.3: 1. Indicator lamps 2. Check button
Pressthecheckbuttononthebatterycartridgetoindi-
catetheremainingbatterycapacity.Theindicatorlamps
light up for a few seconds.
Indicator lamps Remaining
capacity
Lighted Off Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
Thebattery
mayhave
malfunctioned.
NOTE: Depending on the conditions of use and the
ambienttemperature,theindicationmaydifferslightly
fromtheactualcapacity.
Switch action
►Fig.4: 1. Switch trigger
CAUTION:
• Beforeinsertingthebatterycartridgeintothe
tool,alwayschecktoseethattheswitchtrigger
actuatesproperlyandreturnstothe"OFF"
position when released.
Tostartthetool,simplypulltheswitchtrigger.Tool
speedisincreasedbyincreasingpressureontheswitch
trigger. Release the switch trigger to stop.
Lighting up the front lamp
►Fig.5: 1. Lamp
CAUTION:
• Do not look in the light or see the source of light
directly.
Pull the switch trigger to light up the lamp. The lamp
keeps on lighting while the switch trigger is being pulled.
Thelightautomaticallygoesout10-15secondsafter
the switch trigger is released.
NOTE:
• Useadryclothtowipethedirtoffthelensof
lamp. Be careful not to scratch the lens of lamp,
oritmaylowertheillumination.

7ENGLISH
Reversing switch action
►Fig.6: 1. Reversing switch lever
This tool has a reversing switch to change the direction
of rotation. Depress the reversing switch lever from the
A side for clockwise rotation or from the B side for coun-
terclockwise rotation.
When the reversing switch lever is in the neutral posi-
tion, the switch trigger cannot be pulled.
CAUTION:
• Alwayscheckthedirectionofrotationbefore
operation.
• Usethereversingswitchonlyafterthetool
comes to a complete stop. Changing the direc-
tionofrotationbeforethetoolstopsmaydam-
age the tool.
• Whennotoperatingthetool,alwayssetthe
reversing switch lever to the neutral position.
Characteristics of Cordless Oil-
impulse Driver
TheMakitaCordlessOil-impulseDriverisahydrauli-
callyoperatedimpacttoolusingoilviscositytoproduce
impacts.Sinceoilviscositychangeswiththetempera-
ture, be aware of the following two points when operat-
ing the tool.
1. Avoid using the tool below -5 degrees of tempera-
ture. When the tool temperature goes down below
thedegrees,thismaycausedamagetothemotor
of tool due to poor impulse.
2. Whenthetoolbecomestoohot,itmaytakelonger
to set screws.
3. The tool can overheat, causing a failure or hand
burnifyouoperateitcontinuouslyforlonghours.
Let the tool cool off for more than 30 minutes
before changing batteries during a long, continu-
ousjob.
ASSEMBLY
CAUTION:
• Alwaysbesurethatthetoolisswitchedoffand
thebatterycartridgeisremovedbeforecarrying
outanyworkonthetool.
Installing or removing driver bit or
socket bit
►Fig.7
Useonlybitsthathasinsertingportionshowninthe
gure.
For tool with shallow bit hole
A=12 mm
B=9 mm
Use only these type of bit. Follow the
procedure (1).
(Note) Bit-piece is not necessary.
For tool with deep bit hole
To install these types of bits, follow
the procedure (1).
To install these types of bits, follow
the procedure (2).
(Note) Bit-piece is necessary for
installing the bit.
A=17 mm
B=14 mm
A=12 mm
B=9 mm
1. To install the bit, pull the sleeve in the direction of
the arrow and insert the bit into the sleeve as far
as it will go. Then release the sleeve to secure the
bit.
►Fig.8: 1. Bit 2. Sleeve
2. To install the bit, pull the sleeve in the direction of
the arrow and insert the bit-piece and bit into the
sleeve as far as it will go. The bit-piece should be
inserted into the sleeve with its pointed end facing
in. Then release the sleeve to secure the bit.
►Fig.9: 1. Bit 2. Bit-piece 3. Sleeve
To remove the bit, pull the sleeve in the direction of the
arrowandpullthebitoutrmly.
NOTE:
• If the bit is not inserted deep enough into the
sleeve, the sleeve will not return to its original
position and the bit will not be secured. In this
case,tryre-insertingthebitaccordingtothe
instructions above.
Hook
►Fig.10: 1. Screw 2. Hook 3. Groove
Thehookisconvenientfortemporarilyhangingthetool.
This can be installed on either side of the tool.
To install the hook, insert it into a groove in the tool
housing on either side and then secure it with a screw.
To remove, loosen the screw and then take it out.
OPERATION
►Fig.11: 1. Air vents 2. Cooling down oil unit
CAUTION:
• Never obstruct the air vents on the side of the
tool for cooling down oil unit and motor during
operation.Failuretodosomaycausethetool
excessivehotnessanddamage.

8ENGLISH
Theproperfasteningtorquemaydifferdependingupon
thekindorsizeofthescrew/bolt,thematerialofthe
workpiece to be fastened, etc. The relation between fas-
teningtorqueandfasteningtimeisshowninthegures.
M10
M8
M6
00.5 1.0
Fastening torque
Fastening time
Proper fastening torque
(S)
30
(306)
20
(204)
10
(102)
N m
(ft lbs)
Standard bolt
Fastening torque
Fastening time
Proper fastening torque
(S)
30
(306)
20
(204)
10
(102)
M8
M6
0 0.5 1.0
N m
(ft lbs)
High tensile bolt
Holdthetoolrmlyandplacethepointofthedriverbit
inthescrewhead.Applyforwardpressuretothetoolto
theextentthatthebitwillnotslipoffthescrewandturn
the tool on to start operation.
NOTE:
• Use the proper bit for the head of the screw/bolt
thatyouwishtouse.
• WhenfasteningscrewM8orsmaller,carefully
adjustpressureontheswitchtriggersothatthe
screw is not damaged.
• Hold the tool pointed straight at the screw.
• Ifyoutightenthescrewforatimelongerthan
showninthegures,thescreworthepointof
thedriverbitmaybeoverstressed,stripped,
damaged,etc.Beforestartingyourjob,always
perform a test operation to determine the proper
fasteningtimeforyourscrew.
• The fastening torque differs according to the
increase in the tool hotness.
• When driving wood screws, predrill pilot holes
with diameter smaller than the wood screws to
make driving easier and to prevent splitting of
the workpiece.
• The diameter of wood screws that are within
thetoolcapacityisnotalwaysthesameand
depends on the kind of material to be driven on.
Make trial driving with several screws before
actual operation.
Thefasteningtorqueisaffectedbyawidevarietyof
factorsincludingthefollowing.Afterfastening,always
check the torque with a torque wrench.
1. Whenthebatterycartridgeisdischargedalmost
completely,voltagewilldropandthefastening
torque will be reduced.
2. Driver bit or socket bit
Failuretousethecorrectsizedriverbitorsocket
bit will cause a reduction in the fastening torque.
3. Bolt
•
Eventhoughthetorquecoefcientandtheclass
of bolt are the same, the proper fastening torque
will differ according to the diameter of bolt.
• Even though the diameters of bolts are the
same, the proper fastening torque will differ
accordingtothetorquecoefcient,theclass
of bolt and the bolt length.
4. The manner of holding the tool or the material
of driving position to be fastened will affect the
torque.
5. Operating the tool at low speed will cause a reduc-
tion in the fastening torque.
MAINTENANCE
CAUTION:
• Alwaysbesurethatthetoolisswitchedoffand
thebatterycartridgeisremovedbeforeattempt-
ing to perform inspection or maintenance.
• Neverusegasoline,benzine,thinner,alcohol
or the like. Discoloration, deformation or cracks
mayresult.

9ENGLISH
Replacing carbon brushes
►Fig.12: 1. Limit mark
Replacewhentheyweardowntothelimitmark.Keep
the carbon brushes clean and free to slip in the holders.
Both carbon brushes should be replaced at the same
time.Useonlyidenticalcarbonbrushes.
Use a screwdriver to remove two screws then remove
the rear cover.
►Fig.13: 1. Rear cover 2. Screws
Raise the arm part of the spring and then place it in the
recessed part of the housing with a slotted bit screw-
driver of slender shaft or the like.
►Fig.14: 1. Spring 2. Arm 3. Recessed part
Use pliers to remove the carbon brush cap of the car-
bon brushes. Take out the worn carbon brushes, insert
the new ones and replace the carbon brush cap in
reverse.
►Fig.15: 1. Carbon brush cap
Makesurethatthecarbonbrushcaphavetintothe
holesinbrushholderssecurely.
►Fig.16: 1. Hole 2. Carbon brush cap
Reinstall the rear cover and tighten two screws
securely.
To maintain product SAFETY and RELIABILITY, repairs,
anyothermaintenanceoradjustmentshouldbeper-
formedbyMakitaAuthorizedServiceCenters,always
using Makita replacement parts.
OPTIONAL
ACCESSORIES
CAUTION:
• These accessories or attachments are recom-
mendedforusewithyourMakitatoolspecied
inthismanual.Theuseofanyotheraccessories
orattachmentsmightpresentariskofinjuryto
persons.Onlyuseaccessoryorattachmentfor
its stated purpose.
Ifyouneedanyassistanceformoredetailsregard-
ingtheseaccessories,askyourlocalMakitaService
Center.
• Screw bits
• Hook
• Plasticcarryingcase
• VarioustypeofMakitagenuinebatteriesand
chargers
• Bit piece
NOTE:
• Someitemsinthelistmaybeincludedinthe
toolpackageasstandardaccessories.They
maydifferfromcountrytocountry.

10 УКРАЇНСЬКА
УКРАЇНСЬКА (Оригінальні вказівки)
ТЕХНІЧНІ ХАРАКТЕРИСТИКИ
Модель DTS130
Діаметрсвердління Гвинтдляметалу M4 - M8
Стандартнийболт M6 - M10
Високоміцнийболт M6 - M8
Швидкістьбезнавантаження(хв-1)0 - 2400
Ударівзахвилину(хв-1)0 - 1600
Загальнадовжина 183мм
Чиставага 1,5-1,7кг
Номінальнанапруга 14,4Впост.Тока
• Оскількинашапрограманауковихдослідженьірозробоктриваєбезперервно,наведенітуттехнічні
характеристикиможутьбутизміненібезпопередження.
• Технічніхарактеристикиприладутакасетазакумуляторомможутьвідрізнятисяврізнихкраїнах.
• Вагаможевідрізнятисязалежновіддопоміжногообладнання,наприкладкасетизакумулятором.
Найлегшітанайважчікомплекти,відповіднодостандартуEPTA(Європейськаасоціаціявиробників
електроінструменту)відсічня01/2014року,представленовтаблиці.
Застосовна касета з акумулятором і зарядний пристрій
Касетазакумулятором BL1415N / BL1430 / BL1430B / BL1440 / BL1450 / BL1460B
Заряднийпристрій DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF
• Деякікасетизакумуляторомізарядніпристрої,яківказановище,можутьбутинедоступнимизалежно
відвашогорегіонуабомісцяперебування.
ПОПЕРЕДЖЕННЯ: Використовуйте лише касети з акумулятором і зарядні пристрої, перелічені
вище.Використаннябудь-якихіншихкасетзакумуляторомізаряднихпристроївможепризвестидотравму-
ванняй/абопожежі.
Призначення
Інструментпризначенодляукручуваннягвинтіву
деревину,пластмасутаметал.
Шум
РівеньшумузашкалоюАутиповомувиконанні,
визначенийвідповіднодоEN62841:
Рівеньзвуковоготиску(LpA):79дБ(A)
Похибка(K):3дБ(A)
Рівеньшумупідчасроботиможеперевищувати80дБ(A).
Користуйтеся засобами захисту слуху
Вібрація
Загальнавеличинавібрації(суматрьохвекторів)
визначеназгіднозEN62841:
Режимроботи:віброзакручуваннягвинтівіз
максимальноюпотужністюелектроприлада
Вібрація(ah):17,5м/с2
Похибка(K):2,0м/с2
ПРИМІТКА:Заявленезначеннявібраціїбуло
виміряноувідповідностідостандартнихметодів
тестуваннятаможевикористовуватисядляпорів-
нянняодногоінструментазіншим.
ПРИМІТКА:Заявленезначеннявібраціїможе
такожвикористовуватисядляпопередньоїоцінки
впливу.
ПОПЕРЕДЖЕННЯ:Залежновідумоввико-
ристаннявібраціяпідчасфактичноїроботиінстру-
ментаможевідрізнятисявідзаявленогозначення
вібрації.
ПОПЕРЕДЖЕННЯ:Забезпечтеналежні
запобіжнізаходидлязахистуоператора,щовідпо-
відатимутьумовамвикористанняінструмента(слід
братидоувагивсіскладовіробочогоциклу,такіяк
час,колиінструментвимкненотаколивінпочинає
працюватинахолостомуходіпідчасзапуску).
Декларація про відповідність
стандартам ЄС
Тільки для країн Європи
ДеклараціюпровідповідністьстандартамЄСнаве-
деновДодаткуAдоцієїінструкціїзексплуатації.
