Powersmart PS10 User manual

INSTRUCTION MANUAL
Electric Chipper
Shredder
Model # PS10
Have product questions or need technical support? Please feel free to contact us!
Website: www.Amerisuninc.com
Toll free: 1-800-791-9458 M-F 8-4 CST
Email: [email protected]

2

3
CONTENTS
Technical data…...………………………………………………………... 3
General safety rules…….………………………………………………... 4
Specific safety rules for chipper shredder………………………………. 6
Electrical information…………………………………………………... 7
Knowing your chipper shredder………………………………………… 9
Assembly and adjustments……………………………………………… 10
Operation………………………………………………………………... 13
Maintenance……………………………………………………………... 15
Troubleshooting…………………………………………………………. 16
Exploded view…………………………………………………………… 17
Parts list………………………………………………………………… 18
Warranty………………………………………………………………… 19
TECHNICAL DATA
Chipper Shredder Model # PS10
Motor: 120V, 60 Hz, 15A
Speed: 4500 RPM (no load)
Cutting capacity: 1 5/8" Dia.
Overall height: 37 inches
Weight: 33 lb.
Warning! We strongly recommend that this item not be modified and/or used for any application
other than that for which it was designed. If you have any questions relative to its application, do not
use the equipment until you have consulted us and we have advised you.
Contact PowerSmart at [phone] M-F 8am-5pm CST

4
GENERAL SAFETY RULES
Safety is a combination of common sense, staying alert, and knowing how your chipper shredder works.
SAVE THESE SAFETY INSTRUCTIONS.
WARNING: To avoid mistakes that could cause serious injury, do not plug in the chipper
shredder until the following steps have been read and understood.
1. READ and become familiar with this entire instruction manual. LEARN the tool’s applications,
limitations, and possible hazards.
2. AVOID DANGEROUS CONDITIONS. Do not use power tools in wet or damp areas or expose them
to rain. Keep work areas well-lit.
3. DO NOT use power tools in the presence of flammable liquids or gases.
4. ALWAYS keep your work area clean, uncluttered, and well-lit. DO NOT work on floor surfaces that
are slippery with sawdust or wax.
5. KEEP BYSTANDERS AT A SAFE DISTANCE from the work area, especially when the tool is
operating. NEVER allow children or pets near the tool.
6. DO NOT FORCE THE TOOL to do a job for which it was not designed.
7. DRESS FOR SAFETY. Do not wear loose clothing, gloves, neckties, or jewelry (rings, watches, etc.)
when operating the tool. Inappropriate clothing and items can get caught in moving parts and draw
you in. ALWAYS wear non-slip footwear and tie back long hair.
8. WEAR A FACE MASK OR DUST MASK as operation produces dust.
WARNING: Dust generated from certain materials can be hazardous to your health. Always
operate the chipper shredder in a well-ventilated area and provide for proper dust removal.
9. ALWAYS remove the power cord plug from the electric outlet when making adjustments, changing
parts, cleaning or working on the tool.
10. KEEP GUARDS IN PLACE AND IN WORKING ORDER.
11. AVOID ACCIDENTAL START-UPS. Make sure the power switch is in the OFF position before
plugging in the power cord.
12. REMOVE ADJUSTMENT TOOLS. Always make sure all adjustment tools are removed from the
chipper shredder before turning it on.

5
GENERAL SAFETY RULES (CONTINUED)
13. NEVER LEAVE A RUNNING TOOL UNATTENDED. Turn the power switch to OFF. Do not
leave the tool until it has come to a complete stop.
14. NEVER STAND ON A TOOL. Serious injury could result if the tool tips or is accidentally hit.
DO NOT store anything above or near the tool.
15. DO NOT OVERREACH. Keep proper footing and balance at all times. Wear oil-resistant
rubber-soled footwear. Keep the floor clear of oil, scrap, and other debris.
16. MAINTAIN TOOLS PROPERLY. ALWAYS keep tools clean and in good working order. Follow
instructions for lubricating and changing accessories.
17. CHECK FOR DAMAGED PARTS. Check for alignment of moving parts, jamming, breakage,
improper mounting, or any other conditions that may affect the tool’s operation. Any part that is
damaged should be properly repaired or replaced before use.
18. MAKE THE WORKSHOP CHILDPROOF. Use padlocks and master switches and ALWAYS
remove starter keys.
19. DO NOT operate the tool if you are under the influence of drugs, alcohol, or medication that could
affect your ability to use the tool properly.
20. USE SAFETY GOGGLES AT ALL TIMES—that comply with ANSI Z87.1. Normal safety glasses
only have impact resistant lenses and are not designed for safety. Wear a face or dust mask when
working in a dusty environment. Use ear protection, such as plugs or muffs, during extended periods
of operation.

6
SPECIFIC SAFETY RULES FOR CHIPPER SHREDDER
WARNING: Do not operate your chipper shredder until it is completely assembled and
installed according to the instructions.
1. Before starting the chipper shredder, make sure that the hopper inlet is empty.
2. Keep your face and body away from the opening.
3. Do not allow hands or any other part of the body or clothing near the hopper or discharge chute.
4. Never put your hands into the hopper while the chipper shredder is running. Always use the paddle
supplied with your shredder to push items into the hopper.
5. Do not try to force objects larger than the recommended diameter of 1-5/8" into the hopper.
6. Keep proper balance and footing at all times. Do not overreach. Never stand at a higher level than the
base of the tool when feeding material into chipper shredder.
7. Always stand clear of the discharge zone when operating the chipper shredder. Never reach under the
shredder until it has come to a complete stop.
8. When feeding material into the chipper shredder be careful to remove pieces of metal, rocks, bottles,
cans or other foreign objects that may damage the blades.
9. If the cutting mechanism strikes a foreign object or if the chipper shredder should start making any
unusual noise or vibration, turn it off and allow it to come to a complete stop. Disconnect from power
supply and take the following steps:
- Inspect for damage;
- Check for and tighten any loose parts.
WARNING: Never reach into the hopper until the chipper shredder has come to a complete
stop and is unplugged. The blades will continue to rotate for a few seconds after the shredder
is turned off.
10. Do not allow processed material to build up in the discharge zone; this may prevent proper discharge
and can result in kickback of material through the hopper.
WARNING: Never put your hands near the discharge chute. Failure to heed the warning
could result in serious injury.
11. If the shredder becomes clogged, turn it OFF and disconnect from power supply before clearing
debris. Keep the power source clear of debris and other accumulations to prevent damage to the
power source.
12. Keep all guards and deflectors in place and in good working condition.
13. Do not operate the chipper shredder on a paved or gravel surface where ejected material could cause
injury.
14. Turn off the chipper shredder and disconnect it from the power supply whenever you leave the work
area.
15. Do not tilt the chipper shredder while it is running.
16. Never reach into the hopper until the chipper shredder has come to a complete stop and has been
disconnected from the power supply.

7
ELECTRICAL INFORMATION
DOUBLE INSULATION
Double insulation is a concept in safety in electric power tools that eliminates the need for the usual
three-wire grounded power cord. All exposed metal parts are isolated from the internal metal motor
components with protecting insulation. Double insulated tools do not need to be grounded.
WARNING: The double insulated system is intended to protect the user from shock resulting from a
break in the tool’s internal insulation. Observe all normal safety precautions to avoid electrical shock.
NOTE: Servicing a product with double insulation requires extreme care and knowledge of the system.
This should be performed only by a qualified service technician. For service, we suggest you return the
product to your nearest authorized service center for repair. Always use original replacement parts
intended for your particular model of tool when servicing.
WARNING: This tool is for indoor use only. Do not expose to rain or use in damp locations.

8
ELECTRICAL INFORMATION (CONTINUED)
Guidelines for using extension cords
Make sure your extension cord is in good condition. When using an extension cord, be sure to use one
heavy enough to carry the current your product will draw. An undersized cord will cause a drop in line
voltage resulting in loss of power and overheating. The table below shows the correct size to be used
according to cord length and nameplate ampere rating. If in doubt, use the next heavier gauge. The
smaller the gauge number, the heavier the cord.
Minimum Gauge for Extension Cords (AWG)
(When using 120 V only)
Ampere Rating
Total Length of Cord in feet
More Than
Not More Than
25
50
100
150
0
6
18
16
16
14
6
10
18
16
14
12
10
12
16
16
14
12
12
16
14
12
Not Recommended
Make sure your extension cord is properly wired and in good condition. Always replace a damaged
extension cord or have it repaired by a qualified person before using it.
Protect your extension cords from sharp objects, excessive heat and damp or wet areas.
Use a separate electrical circuit for your tools. This circuit must not be less than a #12 wire and should be
protected with a 15 A time-delayed fuse. Before connecting the motor to the power line, make sure the
switch is in the OFF position and the electric current is rated the same as the current stamped on the motor
nameplate. Running at a lower voltage will damage the motor.
WARNING: This tool must be grounded while in use to protect the operator from electric
shock.

9
KNOWING YOUR CHIPPER SHREDDER
1
Power cord
2
ON/OFF switch
3
Overload protector
4
Hopper locking knob
5
Feeding chute / Hopper
6
Housing cover
7
Discharge chute
5
6
7
4
3
2
1

10
ASSEMBLY AND ADJUSTMENTS
Unpacking (Fig. 2)
Unpack the chipper shredder and all its parts, and compare against the list below. Do not discard the
carton or any packaging until the chipper shredder is completely assembled.
8
Wheel cover x2
16
Fixed screw x2
9
Wheel x2
17
Wrench
10
Wheel axle
18
Wrench with hex key
11
Wheel spacer x2
19
Left leg
12
Axle tube
20
End frame
13
Washer x2
21
Right leg
14
Washer x2
22
Paddle
15
Locknut x2
9
10
18
17
22
12
15
16
21
19 14 11 13
8 20

11
ASSEMBLY AND ADJUSTMENTS (CONTINUED)
Tools needed for assembly
Adjustable wrench
Screwdriver
Setup the stand and attach wheels
1. Insert the end frame (20) into each hole of the two legs (19 & 21).
2. Position the axle tube (12) between the two legs (19 & 21).
3. Slide the wheelaxle (10) through the hole in one of the legs (19) then through the axle tube
(12) and out through the hole in the other leg (21).
4. Position the washers (14) and wheel spacer (11) on each end of
the axle.
5. Push the wheels (9) onto each end of the wheelaxle (10).
6. Position the washers (13) and the locknuts on each end of the wheelaxle and tighten both the
wheelnutsusingawrench.
NOTE. The wheels must be fitted the correct way round to allow the nuts to tighten on each end of
the axle.
20
19
21

12
7. Press the wheel covers into the wheels to cover the ends of the axles. You may use a hammer to
seat them securely over the axles.
8. Lock the end frame (20) to 2 legs (19 & 20) using fixed screws (16).
Attach the stand to shredder main body
Turn the main body upside down, insert the two ends of the stand assembly into the housing.

13
OPERATION
Starting
Make sure the switch is in the OFF position. Plug the chipper shredder into a suitable outlet using an
approved extension cord if necessary. Push the ON/OFF switch to “ON” to turn the chipper shredder on.
Stopping
Push the ON/OFF switch to “OFF” to turn the chipper shredder off.
CAUTION: The chipper shredder will not operate if the hopper
locking knob is loose.
Overload protection
Your chipper shredder is designed with overload protection. If the shredder is
clogged during shredding, the overload protection will cut the power automatically to protect your
shredder. Wait at least 1 minute before restarting by first pressing the reset button and then the ON/OFF
switch.
Hopper locking knob
The chipper shredder is fitted with a safety interlock switch on the closure between the hopper and main
body. The switch is activated when the hopper is securely closed and tightened by the hopper locking
knob. When the hopper is opened or not fitted well, the shredder will not run. Always tighten the hopper
locking knob by turning it clockwise before operation.
Blades
The blades on the rotary plate are reversible. For quality and safety reasons, we recommend that only
identical replacement blades be used should it become necessary to replace them.
Shredding Material
WARNING! Before starting, ensure that the feed inlet is empty.
WARNING! Always wear ear and eye protection and wear gloves during operation.
CAUTION! Longer material standing out from the shredder could lash out when being pulled
in by the blades. Keep a safe distance.
CAUTION! When using the chipper shredder and feeding branches into the shredder,
sometimes the blades pull the material into the opening. Keep hands at a safe distance.
CAUTION! The ventilation slots must not be covered.
Hopper
locking knob

14
1. Only insert as much material as to prevent blockage of the feeding funnel. Chop chipper waste
that has been stored for a few days and is wilted and damp alternately with dry branches. This
prevents the cutting blades from blocking up. Widely branched material with leaves must be
completely chopped before new material is fed. Make sure that the chopped material can fall
freely from the ejection slot.
2. Keep hold of branches while feeding them into the chipper shredder until they are automatically
drawn in.
3. Keep to the working speed of the chipper shredder and do not overload it.
4. To protect the chipper shredder from clogging, shred wilted chipper waste that has been left for a
few days and shred thin twigs alternately with branches.
5. Before you shred roots, remove any remaining soil and stones from them.
6. Do not shred soft, damp material such as kitchen waste, take it straight to the compost.
7. Keep a few dry branches for the end, as they will help clean the chipper shredder.
8. Only switch the chipper shredder off after all of the shredding material has passed through the
discharge chutes. Otherwise, the discharge chutes may jam the next time the shredder is turned
on.

15
MAINTENANCE
WARNING! Always wear gloves when cleaning.
Cleaning chipper shredder
1. Unscrew the hopper locking knob counter clockwise and open the hopper.
2. Clean cutting blades and discharge area and remove wood sticks or objects that may clog the
blades.
3. The chipper shredder has two blades that are attached to a rotary plate with two screws. Before
any maintenance or cleaning is done on the blades, always turn the switch off and disconnect the
plug from the power source.
4. Check blades for damage. Use only identical replacement parts if it becomes necessary to replace
them.
5. Return the hopper to its upright position and tighten the knob before operating the chipper
shredder.
6. Use only a warm damp cloth and a soft brush to clean your chipper shredder. Always wear safety
glasses to protect your eyes during cleaning.
Caution: Never spray water on the chipper shredder or wash it with water. Do not use detergents or
solvents as these could cause irreparable damage to your shredder.
7. The fastening screws of the stand assembly should be checked from time to time. Periodically
check all nuts, bolts and screws to be sure the shredder is in safe working condition.
8. Make sure the ventilation slots are always kept clean and are free of debris.
9. To protect the chipper shredder from corrosion when storing for a long period, treat the cutting
blade with oil.
Cutting blade replacement
1. The reversible blade is fixed to the rotary plate with two screws. Before any maintenance or
cleaning of the blades, always turn the switch off and disconnect the plug from the outlet.
2. Turn the Hopper Locking Knob counterclockwise until the housing cover can be opened.
3. Lift up the housing cover to expose the two blades.
4. Align the slots on the board, the blade support and the main body and insert a metal rod like a
screwdriver into the slots to prevent rotating when removing the blade with the supplied hex key.
5. Remove the old blade. Either reverse the blade so the sharp edge is in the cutting position or insert
a replacement blade. Use the same method to replace the other blade.
6. Replace and tighten the two screws to secure the new blade to the support.

16
Troubleshouting
Problems
Cause
Solution
The motor does not run.
Power failure/unit not plugged
into a working receptacle.
Check to make sure unit is plugged into
a working outlet.
The overload protection has
responded.
Remove any chips and press the reset
button. Wait one minute before pressing
the ON/OFF switch to restart the unit.
The hopper is opened.
Check to make sure the hopper is
secured and the lock knob is tightened.
The material to be chopped
is not pulled in.
The material is jammed in the
feed inlet.
Disconnect the power supply and open
the hopper. Pull the material from the
feed inlet. Replace the hopper.
The cutting blade is blocked.
Disconnect the power supply and open
the hopper. Open the blade cover.
Remove the blocked material and
replace the blade cover and hopper.
The discharge chute is blocked.
Disconnect the power supply and open
the hopper. Open the plate of the
discharge chute to clear the blocked
material.
Blades become worn.
Reverse/Replace the blades.

17
EXPLODED VIEW

18
PARTS LIST
Item
Stock #
Description
Qty
Item
Stock #
Description
Qty
1
PS10-001
Screw
42
33
PS10-033
Cable sleeve
1
2
Ps10-002
Baffle
1
34
PS10-034
Switch
1
3
PS10-003
Screw
1
35
PS10-035
Overload protector
1
4
PS10-004
Nut cover
1
36
PS10-036
Motor cover
1
5
PS10-005
Locknut
1
37
PS10-037
Block
1
6
PS10-006
Block
1
38
PS10-038
Line board
1
7
PS10-007
Rotary plate
1
39
PS10-039
Air duct baffle
1
8
PS10-008
Blade
2
40
PS10-040
Fan cover
1
9
PS10-009
Screw
4
41
PS10-041
Snap ring
1
10
PS10-010
Cutter fixing block
1
42
PS10-042
Fan
1
11
PS10-011
Screw
8
43
PS10-043
Duct
1
12
PS10-012
Belt cover
1
44
PS10-044
Plate
1
13
PS10-013
V-belt
1
45
PS10-045
Screw
2
14
PS10-014
Wheel
1
46
PS10-046
Switch cover
1
15
PS10-015
tensioning wheel
1
47
PS10-047
Switch block
1
16
PS10-016
Motor assembly
1
48
PS10-048
Interlock switch
1
17
PS10-017
Wheel cover
2
49
PS10-049
Switch seat
1
18
PS10-018
Locknut
2
50
PS10-050
Fixing block
1
19
PS10-019
Flat washer
2
51
PS10-051
Nut
1
20
PS10-020
Wheel
2
52
PS10-052
Main housing
1
21
PS10-021
Wheel spacer
2
53
PS10-053
Switch key
1
22
PS10-022
Flat washer
2
54
PS10-054
Housing cover
1
23
PS10-023
Leg
2
55
PS10-055
Snap ring
1
24
PS10-024
End frame
1
56
PS10-056
Knob washer
1
25
PS10-025
Foot
2
57
PS10-057
Flat washer
1
26
PS10-026
Screw
4
58
PS10-058
Hopper locking knob
1
27
PS10-027
Axle tube
1
59
PS10-059
Rubber plate strip
1
28
PS10-028
wheel axle
1
60
PS10-060
Rubber sheet
1
29
PS10-029
Right septum
1
61
PS10-061
Feed panel
1
30
PS10-030
Left septum
1
62
PS10-062
Wrench w/hex key
1
31
PS10-031
Inner conductor
1set
63
PS10-063
Wrench
1
32
PS10-032
Power cord
1
64
PS10-064
Paddle
1

19
TWO (2) YEARS LIMITED WARRANTY
PowerSmart is committed to building tools that are dependable for years. Our warranties are consistent with our
commitment and dedication to quality.
TWO (2) YEARS LIMITED WARRANTY OF POWER SMART PRODUCTS FOR HOME USE.
PowerSmart (“Seller") warrants to the original purchaser only, that all PowerSmart consumer power tools will be
free from defects in material or workmanship for a period of two (2) years from date of purchase. Ninety (90) days
for all PowerSmart Products, if the tool is used for professional or commercial use.
SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Two (2) Years Limited
Warranty and, to the extent permitted by law, any warranty or condition implied by law, shall be the repair or
replacement of parts, without charge, which are defective in material or workmanship and which have not been
misused, carelessly handled, or misrepaired by persons other than Seller or Authorized Service Center. To make a
claim under this Limited Warranty, you must return the entire power tool product; transportation prepaid, to
PowerSmart Include a legible copy of the original receipt, which lists the date of purchase (month and year) and the
name of the company purchased from.
THIS LIMITED WARRANTY DOES NOT APPLY TO ANY ACCESSORY ITEMS INCLUDED WITH THE
TOOL SUCH AS CIRCULAR SAW BLADES OTHER RELATED ITEMS OR TO ANY REPLACEMENT
PARTS LISTED UNDER MAINTENANCE.
ANY IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO TWO (2) YEARS FROM DATE OF
PURCHASE. SOME STATES IN THE U.S. AND SOME CANADIAN PROVINCES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY
NOT APPLY TO YOU.
IN NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
(INCLUDING BUT NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS) ARISING FROM THE SALE
OR USE OF THIS PRODUCT. SOME STATES IN THE U.S. AND SOME CANADIAN PROVINCES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE
OTHER RIGHTS WHICH VARY FROM STATE TO STATE IN THE U.S., PROVINCE TO PROVINCE IN
CANADA AND FROM COUNTRY TO COUNTRY.
For questions / comments, technical assistance or repair parts –
Please call toll free at: 1-800-791-9458 (M-F 8am –5pm CST)
Email: [email protected]m
SAVE YOUR RECEIPTS. THIS WARRANTY IS VOID WITHOUT THEM.
