Powersolve RKW Series User manual

www.powersolve.co.uk
Powersolve Electronics Ltd, Units 8, 9 and 12 The Paddock, Hambridge Road, Newbury, Berks RG14 5TQ
Tel: [phone] Fax: [phone] Email: [email protected]
Input: 85-264 VAC, 47-66Hz
Input Current: 4.4A max 300W models
8.4A max 600W models
22A max 1500W models
Inrush Current: 40A 300W, 60A 600W & 40A 1500W
Earth Leakage Current: 0.38mA 300W, 0.75mA 600W, 1.6mA 1500W
Power Factor: 0.99 typical
Efficiency: See table
DC Output: See table
Output Voltage Adjust: See table
Overvoltage Protection: Voltage shutdown type, tracking V out
Over Current Protection: Rectangular type, recovers on reset
Line Regulation: 0.2% max
Load Regulation: 0.6% max
Ripple & Noise (pk-pk): 3.3V& 5V 120mV max, 12V-15V 150mV max
24V-28V 200mV max & 48V 300mV max
Start Up Time: 500mS max
Hold Up Time: 20mS minimum
Indicator: LED Indicator indicates V out present
Remote On/Off: Standard
Remote Sense: Standard
Fan Alarm: Voltage shut-down type
Overtemperature Protection: Voltage shut-down type
Current Sharing: Standard
Output Voltage Programming: Continuously variable 0-120% by voltage input (48V 0-110%)
Master Slave Operation: Standard
Safety Approvals: UL,cUL60950, TUV(EN60950)
EMC: FCC Class’B’, VCCI Class’B’,
EN55011’B’, EN55022’B’
Immunity: EN50082-2, EN61000-4-2,3,4,5,6,8,11
Operating Temperature: -20 to +71 °C, see derating curve
Humidity: 10-95% non condensing
Withstand Voltage: Input to Case 2.0kV AC
Input to Output 3.0kV AC
Output to Case 500V AC
Mechanical: Fully enclosed with integral cooling fan
Warranty: Standard 5 years, 10 years with long life fan ‘F’ prefix.
Electrical Specification
AC-DC Converters
RKW 300 to 1500W Series
300/600/1500 Watts Single Output
Power Factor Correction
Voltage Programmable
Features
•85-264 VAC Universal Input
•DC output continuously variable 0-120% V out
•High Quality Industrial Grade Product
•Optional conformal coating
•5 years warranty (optional 10 year with long life fan)
•Full safety approvals
•EMC meets FCC ‘B’ & EN55011 & EN55022 ‘B’
•Immunity meets EN50082-2, EN61000-4-2,3,4,5,6,8,11
•Conforms to EN61000-3-2 for Harmonic Distortion

www.powersolve.co.uk
Powersolve Electronics Ltd, Units 8, 9 and 12 The Paddock, Hambridge Road, Newbury, Berks RG14 5TQ
Tel: [phone] Fax: [phone] Email: [email protected]
AC-DC Converters
MODEL DC OUTPUT V ADJUST V ADJUST MAX POWER EFFICIENCY
(Trim) (External Programming) (typical @200V Input)
RKW03-70R 3.3V 70A 1.8-3.6V 0-120% V out 231W 72%
RKW05-60R 5V 60A 3.5-6.0V 0-120% V out 300W 78%
RKW12-27R 12V 27A 7.2-14.4V 0-120% V out 324W 80%
RKW15-22R 15V 22A 10.5-18V 0-120% V out 330W 81%
RKW24-14R 24V 14A 16.8-28.8V 0-120% V out 336W 84%
RKW28-12R 28V 12A 19.6-33.6V 0-120% V out 336W 84%
RKW48-7R0 48V 7A 33.6-52.8V 0-110% V out 336W 85%
RKW03-150 3.3V 150A 1.8-3.6V 0-120% V out 495W 78%
RKW05-120 5V 120A 3.5-6.0V 0-120% V out 600W 81%
RKW12-53R 12V 53A 7.2-14.4V 0-120% V out 636W 84%
RKW15-43R 15V 43A 10.5-18V 0-120% V out 645W 85%
RKW24-27R 24V 27A 16.8-28.8V 0-120% V out 648W 86%
RKW28-23R 28V 23A 19.6-33.6V 0-120% V out 644W 86%
RKW48-13R 48V 13A 33.6-52.8V 0-110% V out 624W 87%
RKW03-375 3.3V 375A 1.8-3.6V 0-120% V out 1237.5W 77%
RKW05-300 5V 300A 3.5-6.0V 0-120% V out 1500W 82%
RKW12-125 12V 125A 7.2-14.4V 0-120% V out 1500W 84%
RKW15-100 15V 100A 10.5-18V 0-120% V out 1500W 86%
RKW24-65R 24V 65A 16.8-28.8V 0-120% V out 1560W 86%
RKW28-55R 28V 55A 19.6-33.6V 0-120% V out 1540W 86%
RKW48-32R 48V 32A 33.6-52.8V 0-110% V out 1536W 88%
A full technical manual is available on this product – consult sales office for details

www.powersolve.co.uk
Powersolve Electronics Ltd, Units 8, 9 and 12 The Paddock, Hambridge Road, Newbury, Berks RG14 5TQ
Tel: [phone] Fax: [phone] Email: [email protected]
AC-DC Converters
•
8-M4 Together with both side (for mounting)
4-M4 Tap(for mounting)
26.7
4.5 46
32.81
71
8.02
26
31
31
12
5.5 33.05
99.
2
1
(40)
)5.34()5.8
4
(
14max.
1920
175
(35)
11
29
)
1
1()51(
08
5
1
(15) 20
140±0.5
5
.
0
±
05
120±0.5
07
±
5
.0
AIR FLOW
(40)
[Function connector][Input connector]
6
4
.6
2
6
.7
9.011.0
8.6
10.0
[Output connector]
M3x6L
M4x8L M4x8L
Dimensions in mm
±1mm : without specified dimensions
RKW300W
SHAPES AND DIMENSIONS
Do not insert M4
tap installation
screws more than
6mm into the
power supply.
OUTPUT POWER-AMBIENT TEMPERATURE (DERATINGS)
RKW300W, 600W RKW1.5kW
Ambient temperature
(
˚C
)
20
40
60
80
100
–20 –10 0 10 20 30 40 50 60 71
)
%(
re
w
optu
ptu
O
Available operating range
(outside of warranty)
65
∗1
∗1
(F)type Ambient temperature(˚C)
20
40
60
80
100
–20 –10 0 10 20 30 40 50 60 71
)%(rewoptuptuO
Available operating range
(outside of warranty)
92.5
65
70
3V output
∗1
∗1
(F)type

www.powersolve.co.uk
Powersolve Electronics Ltd, Units 8, 9 and 12 The Paddock, Hambridge Road, Newbury, Berks RG14 5TQ
Tel: [phone] Fax: [phone] Email: [email protected]
RKW1.5kW
SHAPES AND DIMENSIONS
AIR FLOW
Rating label(Part No.)
[Function connector][Input connector]
18max.
2-ø9
2-M5 Tap
8-M4 Together with both side (for mounting)
4-M4 Tap(for mounting)
25±0.7 238±0.7
300
(37)
238±0.725
23max.
(40)(
37)(18)(87)
190
(43.4)
M4×8L
With FW,SW
M3×6L
With SQUARE
6.5
7.62
(5.7 )
5.0±77
(01 )
(8.16 )
(21 )
29
(1
.8
1)
0
1
3
1
5
.
0±
071
01
02
52
4
4
5.0±5
.
7
40
+1
–2
Dimensions in mm
±1mm : without specified dimensions
•Do not insert M4 tap
installation screws
more than 6mm into
the power supply.
RKW600W
SHAPES AND DIMENSIONS
•
Safety standard labelRating label(Part No.)
[Function connector][
Input connector]
AIR FLOW
160±0.5
20014max.
45
7.62 10
100±0.5 (55)
(6.4)(8.6)
35 20 (20)
(62)(
58)
8-M4 Together with both side
(for mounting)
4-M4 Tap(for mounting)
2-M4 Tap
2-ø8.2
(61 )
(01 )
(9.9)
(71.7)
(2
1)( 3
1)(5.
3
4)( 5.
8
4)
5.0±06
2±16
2±5.122±1.38
5.
0±
001
021
0
1
33
2±
5
1
29
61
M3×6L
9P 3P
M4×8L
With FW,SW
(19)
(12.5)
(33)
Dimensions in mm
±1mm : without specified dimensions
Do not insert M4 tap
installation screws
more than 6mm into
the power supply.

www.powersolve.co.uk
Powersolve Electronics Ltd, Units 8, 9 and 12 The Paddock, Hambridge Road, Newbury, Berks RG14 5TQ
Tel: [phone] Fax: [phone] Email: [email protected]
AC-DC Converters
TERMINAL DESIGNATIONS AND FUNCTIONS
300W TYPE 600W TYPE 1.5kW TYPE
INSTALLATIONS
RKW300W RKW600W RKW1.5kW
Terminal No. Designations and functions
1 Frame ground terminal(G) Connect to earth ground. This is connected to the case.
2 AC input terminals(L, N) Connect to AC.100 to 120V or AC. 200 to 240V input line.
3 DC output terminals(+, –) Connect to load.
4 Remote sensing terminals(+S, –S)
These terminals are used to compensate voltage loss from the output terminal to a load.
For the 1.5kW Type, they are shorted with a metal bar. For the 600W Type,
they are coupled to DC output terminals.
5 DC output monitor terminals(+M, –M)
This terminal is used to monitor DC current output. Load lines should not be connected to
these monitor terminals. These monitor terminals should be jumpered when the remote moni-
toring feature is not in use.
6 Output voltage reference terminal (REF)
This terminal is for a reference voltage for controlling an output voltage and used for a
master-slave operation or when using an output voltage adjustment function. Normally it is
shorted with a metal bar to an RV terminal.
7 Output voltage adjustment terminal(RV) This terminal is used for controlling output voltage from outside.
8 Current balance terminal(CB) This terminal is used when several power supplies are connected in parallel to connect
the respective CB and –S terminals in parallel.
9 Power failure terminal (PF)
These terminals output an open mode signal if an output voltage drops to 80 % or lower
of a set voltage. They also output the signal if an output voltage is shut down due to an
operation of an error detecting circuit for over output voltage protection, fan alarm overheat
protection, or overcurrent protection.
10 Remote ON-OFF terminals(+RC, –RC)
Output is turned ON-OFF by disconnecting-connecting the RC terminals (output ON
when open).
RC terminals are floating. Normally, ±RC terminals are shorted with a metal bar.
11 Output voltage adjustment trim(V.ADJ) Adjusts output voltage.
12 Operation indicator LED(Green) This Green LED becomes indicated when voltage is output.
(–) (+)
4
6
7
8
9
10
12
11
33
211
23
46789
11
12
10
10
1
2
3
9876 54 1112
•Maintain a 50mm min. distance between the fan, front panel and surrounding
equipment, etc. and install so as to provide heat-outside air exchange.
1)2)
3)
1)2)
3)
1)
2)3)
Fixing screw direction
• Maintain a 30mm min. distance between the ventilation
holes, fan surface and surrounding equipment, etc.
and install so as to provide heat-outside air exchange.
