PowerTraveller spidermonkey User manual

Designed and developed in the UK
Engineered and made in China
Powertraveller limited
Ceratech House, Omega Park,
Wilsom Road, Alton,
Hampshire GU34 2QE, UK
t [phone]
[e-mail]
www.powertraveller.com
9V mains charger supplied
All brands and trademarks
belong to their respective owners.
spidermonkey is a registered trademark
of Powertraveller Limited registered in
the UK and Europe.
For customer support, email us at
[e-mail]
comPact
aluminium
four way
usb hub
sPidermonkey
user Guide
can be Powered from
Powertraveller mains
charGer, ac charGer with
micro usb, from laPtoP
usb or Powertraveller
Products from the monkey
to the Gorilla ranGe
Parameters
•Input: 5V~30V
•Output: 5V 1000mA max / USB port
•Input sockets: Micro USB, DC3.5 x 1.1,
DC5.5 x 2.1mm
•Output: USB1 and USB2 supports iPhone/
iPad and other tablets, USB3 is normal USB
port, USB4 supports Nokia and it is
permanently on
•Protection current limitation: 1.5A
•Max power: 25 watts
•Dimensions: 100 x 39 x 15mm
•Weight: 105g
contents
• 1xspidermonkeyunit
• 1xmainschargerwith
universal plugs (9V 1.3A)
comPact and
manufactured
from aluminium
suPPorts most
smartPhones,
mobile Phones
and 5v devices
includinG
tablets
usb shutdown
activates when
overloaded and
auto-turn on
when the load
is decreased
charGe
confirmation
liGhts
four
indePendent
outPut
channels
AW_PLT_spidermonkey_userguide.indd 1 12/10/2012 16:40

charGe confirmation liGhts
The power output is determined by the
input current. If the input current is 5V (like
some mobile phone chargers using a micro
USB) you may not be able to charge four
devices simultaneously. If this is the case,
the green lights (see below) will indicate
the number of devices that you can charge
at one time. If the input current is 12V
and above, all devices connected can be
charged.
dc 5 – 30v
usb3 is
normal
usb Port
dc 5v
usb4
suPPorts
nokia and it is
Permanently
on
micro usb
Power in
Power out usb1 and usb2
suPPorts iPhone/
iPad and tablets
all Ports are charGinG (9v-30v) Ports 1 and 4 are charGinG
Ports 1, 2 and 4 are charGinG Port 4 is charGinG only
Powered by the powergorilla
Powered by the minigorilla
Powered by computer USB
