Powtran PS9500 Series User manual

Table of contents
1.Foreword.......................................................................................... 1
2.Product model instruction................................................................ 1
3.PS cabinet input and output wire terminal instruction..................... 1
4.PS9500 series specification and dimension..................................... 1
5.Selection Guide................................................................................ 2
6.Precautions....................................................................................... 2
Appendix PS cabinet customer order questionnaire........................... 3

PS9500 series vector control inverter operating manual
1
1.Foreword
Thank you for choosing POWTRAN Frequency Inverter, This product (hereinafter
referred to as PS cabinet) is based on Powtran Technology PI9000 series high-performance
vector inverter, based on the modular design to the frequency inverter and configure
corresponding peripheral integrated control cabinet control circuit and display control. The
user can choose to order our standard configuration function, also can choose according to
the requirements of field use peripheral control devices and the panel control, customized
according to customer's requirements. After customers buy PS cabinet, as long as the correct
plugged into a power supply and motor output line can be normal use, to avoid the secondary
wiring for the inconvenience.PS inverter cabinet integrated, not only appearance is concise
and beautiful, also improves the safety and reliability of the secondary distribution, simple
manipulation, and reduce the cost of user input.
2.Product model instruction
P S 95 0 0 132 G 3
POWTRAN product Input voltage level *
Inverter cabinet 3：three phase 380V 4：three phase480V
Series code: 6：three phase690V
95：inverter series
52：soft starter series
Derivative code Function code:
0：normal keyboard G：constant torque general load
3：MCU keyboard H：heavy load
F：cooling fan, pump type load
Type code Rated output capacity:
0:standard configuration 132:132kW
1:special 1 configuration
2:special 2configuration
*Remark: Please consult our company if you need other voltage grade
3.PS cabinet input and output wire terminal instruction
power supplier motor DC chock earth
The input and output terminal is located in the bottom of cabinet, left in and right out.
If equipped with in and out of the reactor, the terminal extends to the reactor in and out of
the terminal; "〨" earthing terminal is located in the cabinet at the bottom right. Note that "
〨" terminal must connect with the earth, never mix zero line, the inverter and motor
earthing respectively, the actual terminal arrangement will be subject to physical terminal
label tag please.
4.PS9500 series specification and dimension
PS model
Power
（kW）
Voltage
（V）
Current
(A)
Seat
No.
Size （W*L*H）
mm
Wire
diameter mm
N.W.
kG
PS9500 037G3
37
380V
75
3N4
600*600*2200
16
PS9500 045G3
45
90
25
PS9500 055G3
55
110
35
PS9500 075G3
75
150
50
PS9500 093G3
93
170
50
R
S
T
U
V
W
P
P+
〨

PS9500 series vector control inverter operating manual
2
PS9500 110G3
110
210
70
PS9500 132G3
132
250
3N5
800*600*2200
70
PS9500 160G3
160
300
95
PS9500 187G3
187
340
120
PS9500 200G3
200
380
120
PS9500 220G3
220
415
3N6
800*600*2200
150
PS9500 250G3
250
470
150
PS9500 280G3
280
380V
520
95*2
PS9500 315G3
315
600
3N7
1000*600*2200
120*2
PS9500 355G3
355
660
120*2
PS9500 400G3
400
750
150*2
PS9500 450G3
450
840
150*2
PS9500 500G3
500
930
3N8
1200*600*2200
150*2
PS9500 560G3
560
1040
185*2
PS9500 630G3
630
1170
150*3
PS9500 710G3
710
1300
150*3
5.Selection Guide
1). According to the type of load dragged by the motor, start and stop frequency and load
inertia overload conditions, we can select the appropriate PS cabinet models. Firstly we need
to get the following information: motor nameplate data (rated voltage, rated power, rated
current, rated frequency, rated speed) in order to select the appropriate level of PS cabinet.
According to the type of load, overload situation to choose the right margin. For light load
such as general fan and pump, we can consider by 1.1 times the rated current of the motor to
select PS cabinet capacity. For constant torque and the inertia load, we can consider by 1.1 to
1.2 times to select. For the impact load and the more volatile occasion, we can consider to
select maximum current.
2). The general protection rating of PS cabinet is IP20. If users need special protection class,
please inform us in advance.
3). Cabinet form structure includes GGD, rittal, welding cabinet set.c. We generally use the
welding cabinet as our standard production for users.
4). The standard color is RAL7035 (or PANTONE425C). If users need special requests,
please inform us to provide and confirm the special color in advance.
5).We produce PS cabinet with user-friendly design to meet the requirements based on the
end-user to avoid secondary processing site and wiring,so we need confirm site-specific
requirements, use of the environment, on-site installation conditions, EMC requirements
design elements, including special packaging requirements. Please check the enclosed PS
cabinet customer order inquiry form in detailed.
6). PS cabinet are usually equipped with circuit breakers, panel voltmeter, universal switch
(toggle the display of three-phase voltage), ammeter, power / run / fault indicator, run / stop /
fault reset button and frequency adjustment potentiometer. Both parties agreed in writing to
the contract shall prevail.
6.Precautions
Visual inspection to confirm whether product during transport caused loosening,
deformation, bump after unpacking. For example whether panel, lights, buttons, keyboard on
the instrument damage. After opening the door to see visually whether the cable, copper,
terminal screws fasten and to see whether the apparent overall structural deformation or not.
After confirmation, connect the power and electrical cable and connect to the ground before
the cabinet secure transmission. Energizing test should be done under the manufacturer's
instructions after the examination, if user need secondary wiring, please pay attention to the
line of control requires the use of shielded wire and separated from the main cable wiring.

PS9500 series vector control inverter operating manual
3
Appendix PS cabinet customer order questionnaire
1. The information needed from user：
Motor nameplate parameters：rated power ；rated current ；rated voltage ；
rated frequency ；rated rotate speed
The load description :
.
If start frequently：Yes No
2. Ps cabinet spare parts drawing：
A
A
A
V
R
S
T
E
P NP+
Power
connection
terminal MCCB or
ELCB Input reactor Input EMI filter MC
DC reactor
Brake unit
Output filter
Output reactor
Output terminal
PA
PV
U
V
W
Inverter
L1
L2
L3
N
PE
Device boundary
3. Ps cabinet spare parts list：
No.
Part name
Symbol
QTY
Advice brand
Customer use brand
Note
1
Power input terminal
1
2
Breaker
MCCB\ELCB
1
Chint/Tianshui
3
Input reactor
ACL
1
Eagtop/Sudun
4
Input EMI filter
EMI
1
Eagtop/Sudun
5
AC contactor
MC
1
Chint/Tianshui
6
Ampere meter
PA
3
Chint/Tianshui
7
Voltmeter
PV
1
Chint/Tianshui
8
DC reactor
DCL
1
Eagtop/Sudun
9
Brake unit
1
Powtran
10
Output filter
1
Eagtop/Sudun
11
Output reactor
OCL
1
Eagtop/Sudun
12
Output terminal
1
13
14
15
16
4. Control loop requirements：
1) With power frequency switch circuit, change to origin starting circuit
2) With power frequency switch circuit, and have matched soft starter or star triangle
start-up circuit.
3) Control button, indicator light designed according to standard circuit
4) Customer special Requirements：
PS cabinet protection degree requirements：
Ps cabinet packing requirements：
Order quantity：
