Model Number: EMS1012UL
PowerVerter EMS Inverter/Charger - Reliable Mobile Power Source for Ambulance/EMS Vehicles
Highlights
UL458 / KKK-A-1822 listed
12V DC input, 120V AC output
2 hospital-grade GFI outlets; hospital-grade plug
2 Anderson DC connectors (1 on the unit and 1 included in the box) for quick
battery connection
1000 watts continuous output
Description
Tripp Lite's EMS1012UL inverter with integrated charging system provides automatic, uninterruptible DC-to-AC power for critical on-board
equipment. Ideal for installation by ambulance/EMS vehicle manufacturers, dealer or EMS service for OEM, replacements and upgrades. Supplies
up to 1000 watts of continuous 120V AC power to 2 AC outlets from any 12V battery or automotive DC source. When AC cable is connected to a
shore power source, commercial power passes through to connected equipment and the battery set is recharged via 3 stage, 15/55 amp selectable
charging system. This unit can also function as a UPS system, responding to blackouts and brownouts with an uninterrupted transfer to
battery-derived AC output. Convenient Anderson DC input quick connector on the unit with extra Anderson DC input connector included in the box
(user supplies batteries and cabling). Reliable large transformer design with efficient PWM sine wave output and frequency control powers resistive
electronic loads or large inductive motors, compressors and other items with high current needs on startup. Supports an unlimited amount of runtime
with any number of user-supplied batteries connected. Highly adaptable to a variety of applications and site conditions with adjustable charger
settings for wet/gel battery types and selectable line to battery power transfer voltages. Includes AC input surge suppression. Includes hospital
grade plug and outlets with GFI (ground fault interrupter) protection. UL458/KKK-A-1822 listed.
Applications
Connect to an emergency vehicle's (ambulance, rescue squad or police B.A.T. mobiles) electrical system to run on-board diagnostic and
emergency equipment.
Package Includes
EMS1012UL inverter/charger
Instruction manual with warranty information
APSRM4 remote switch
2 Anderson DC connectors (1 on the unit and 1 included in the box)
Features
Functions as an emergency vehicle inverter, extended run UPS system or standalone power source
1000 watts continuous output power; provides up to twice this rating for momentary startup of inductive loads
UL458/KKK-A-1822 listed
Battery runtime is dependent upon the size and number of user-supplied 12-volt batteries used
2 hospital-grade, GFI protected outlets; 3-ft. AC power cord with hospital grade plug; Two 175A rated Anderson DC input connectors (1 on
the unit and 1 included in the box) for 12V battery quick connection for use with user-supplied cables
Converts 12V DC to 120V AC
Frequency control for operating stability
Advanced 15/55 amp selectable, 3-stage battery charger and selector switch for gel or wet cell batteries

Advanced 15/55 amp selectable, 3-stage battery charger and selector switch for gel or wet cell batteries
Switch allows user to select between off, auto-invert and charge-only settings
6 diagnostic LEDs indicate AC present, on battery, overload, & battery voltage level (high, medium, & low)
Configuration switches to allow the user to select the high and low voltage for the unit to automatically transfer from AC power to battery
backup
Coated internal circuit boards offer continuous operation in humid environments (0-95%, non condensing)
RJ45 port allows connection of remote switch (part# External switch for wired remote control of APS unit (APSRM4) which is included
Included remote switch can be linked in a daisychain with a second remote switch (sold separately) for remote operation from multiple
locations. Multiple mounting options include recess panel mount or below dash.Ignition interlock feature can shut down unit when engine is
off, ending worries of accidental battery drain
Allows unlimited runtime capability by allowing the use of any number of user-supplied batteries
Specifications
OUTPUT
Frequency
compatibility
60 Hz
Output watts Continuous - 1000 watts, Overpower (up to 1 hour) - 1500 watts, Double-Boost wattage (up to 10 seconds) - 2000 watts
Output nominal
voltage
AC OUTPUT: 120VAC nominal, DC CHARGER OUTPUT (DC): 12VDC nominal
Output voltage
regulation
LINE POWER (AC): Maintains 120V nominal sine wave output. INVERTER POWER (AC): Maintains PWM sine wave
output voltage of 120 VAC (+/-5%). DC CHARGER OUTPUT (See battery recharge rate section)
Output frequency
regulation
60 Hz (+/- 0.3 Hz)
Overload
protection
Includes 12A input breaker dedicated to the charging system and 12A output breaker for AC output loads
Outlet quantity /
type
Includes 2 hospital-grade AC outlets with built-in GFI protection (NEMA 5-15R)
INPUT
Recommended
Electrical Service
DC INPUT: Requires 12VDC input source capable of delivering 95A for the required duration (when used at full
continuous capacity). For automotive applications, professional hardwire installation with 225A minimum battery system
fusing is recommended. A
Maximum input
amps / watts
DC INPUT: Full continuous load - 95A at 12VDC. AC INPUT: 12 amps at 120VAC with full inverter and charger load
Input connection
type
DC INPUT: 175A Anderson DC connector. AC INPUT: NEMA 5-15P hospital-grade input plug
Voltage
compatibility
(VAC)
120
Voltage
compatibility
(VDC)
12
BATTERY
Expandable
battery runtime
Runtime is expandable with any number of user supplied wet or gel type batteries
DC system
voltage (VDC)
15
Battery charge Includes selectable 14 / 55 amp DC charging system with selectable profiles for vented wet cell and sealed gel cell
batteries. Optional use battery equalize charge function equalizes the charge level when used with multiple batteries
(see manual for detailed charger information).
LEDS ALARMS & SWITCHES

Switches 3 position on/off/remote switch enables simple on/off power control plus "auto/remote" setting that enables distant on/off
control of the inverter system when used in conjunction with included External switch for wired remote control of APS
unit APSRM4 accessory when used in inverter mode. In AC uninterruptible power mode, "auto/remote" setting enables
automatic transfer from line power to battery power - to maintain continuous AC power to connected loads.
Front panel LEDs Set of 6 LEDs offer continuous status information on load percentage (6 levels reported) and battery charge level (7
levels reported). See manual for sequences.
SURGE / NOISE SUPPRESSION
AC suppression
joule rating
760
PHYSICAL
Shipping
Dimensions
(HWD/in)
13.5 x 15 x 21.5
Shipping
Dimensions
(HWD/cm)
34.3 x 38.1 x 54.6
Shipping weight
(lbs)
34.8
Shipping weight
(kg)
15.8
Unit Dimensions
(HWD/in)
7.25 x 8.5 x 16.25
Unit Dimensions
(HWD/cm)
18.4 x 21.6 x 41.3
Unit weight (lbs) 28.6
Unit weight (kg) 13.0
Cooling method Fan
Material of
construction
Polycarbonate
Form factors
supported
Mounting slots enable permanent placement of inverter on any horizontal surface (see manual for additional mounting
information)
ENVIRONMENTAL
Relative Humidity 0-95% non-condensing
LINE / BATTERY TRANSFER
Transfer time
from line power to
battery mode
4-6 milliseconds
Low voltage
transfer to battery
power
User configurable to 75V, 85V, 95V & 105V
High voltage
transfer to battery
power
User configurable to 135V, 145V
SPECIAL FEATURES
Appearance Attractive gray color scheme
Load Sensing Optional load sense function enables automatic inverter shutoff and startup as connected equipment is powered off and
on. Front panel load sense potentiometer can be set to shutoff or turn on inverter power in response to loads of any
level, up to 150 watts.

TVSS grounding Yes, includes rear panel grounding lug
CERTIFICATIONS
Certifications Tested to UL458 (mobile inverter), KKK-A-1822 (Ambulance), cUL (Canada)
WARRANTY
Product Warranty
Period
(Worldwide)
18-month limited warranty
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
http://www.tripplite.com/sku/EMS1012UL.
