P+L Flypod User manual

Flypod®is an insect control unit with patented* hygienic
glueboard removal system, utilising a pheromone
impregnated glueboard and a high powered Actinic UV
tube.
ELECTRONIC INSECT KILLERS
Flypod®is the modern answer to glueboard flying insect
control where hygiene is an important consideration.
The instructions given here are intended to help you
operate the Flypod®equipment at maximum efficiency.
WARNING
FLYPOD®IS ONLY SUITABLE FOR INDOOR USE AND IS NOT
SUITABLE FOR USE IN BARNS, STABLES AND SIMILAR
LOCATIONS.
IF THE SUPPLY CORD IS DAMAGED IT CAN NOT BE REPLACED
AND THE UNIT SHOULD BE SAFELY DESPOSED OF AND
REPLACED.
INSTALLATION
Your Flypod®unit requires certain conditions to ensure the
effective control of flying insects in your premises:
1. It should be correctly sited.
2. It should be the correct model for the area to be
protected.
3. It should be in operation for 24 hours a day.
4. Tubes must be replaced every 12 months.
5. The glueboard should be replaced every 4 weeks.
POWER REQUIREMENTS
Flypod®units are designed to operate from the following
power supply:
220V - 240V ~ 50Hz
Therefore, please ensure that your unit is compatible with
the electricity supply in your premises. Make sure the unit is
connected to an earthed electrical supply via a socket
outlet of compatible rating.
WARNING - THIS APPLIANCE MUST BE EARTHED
SITING
Applications of Flypod®obviously vary depending on the
location. Should any queries arise on siting, etc. please
contact your supplier. As a general rule, the UV light from the
Flypod®unit should be visible from every part of the room.
ASSEMBLY
When you first receive your Flypod®, check that you have all
the correct parts. You should have:
- 1 x Product
- 1 x Glueboard
- 1 x 18Watt Tube
To assemble, first attach the tube to the base, by lining up
the four connector pins and pushing into place. Then peel
back the protective paper from the glueboard (1) and
discard. Then slide the glueboard into the runners (2).
SERVICING
BEFORE ANY FORM OF SERVICING, ENSURE THAT THE UNIT IS
DISCONNECTED FROM THE MAINS SUPPLY.
To maintain the units efficiency, replace the UV fluorescent
tubes every 9 to 12 months, making sure the replacement
tubes are of the correct type - obtainable from the supplier
or P+L Systems Ltd. The glueboard should be changed every
4 weeks.
GUARANTEE
Your Flypod®unit is guaranteed for one year (excluding
tubes.) If a fault occurs within twelve months P+L Systems Ltd
will replace your unit, provided the unit is returned.
This guarantee only applies if genuine P+L Systems Ltd spare
parts are used.
N. B. TUBES ARE NOT GUARANTEED
Glueboard Installation
1. 2.
HYGIENIC GLUEBOARD INSECT CONTROL
Brighter Hygiene Solutions...
*Patent Applied

MAINTENANCE
BEFORE ANY FORM OF MAINTENANCE, ALWAYS ENSURE THAT
THE UNIT IS DISCONNECTED FROM THE MAINS SUPPLY.
GLUEBOARD REPLACEMENT
The Flypod®utilises a patented* hygienic glueboard removal
system.
The glueboard should be replaced every four weeks.
To replace the glueboard (see adjacent diagram):
1. Position the Flypod®so the back is facing you.
2. Using one hand to support the unit use your thumb and
forefinger of your other hand to gently pull the
glueboard out through the oval slot in the back of the
unit. As you pull the glueboard out through the slot it will
close up on itself sealing in the flies.
3. Once the glueboard is free from the unit discard into a bin.
4. Slide a new glueboard into position as described on the
first page of this instruction sheet.
CLEANING
It is recommended that you clean your Flypod®every time you
replace the glueboard. Once the glueboard is removed,
thoroughly wipe down your Flypod®with a soft damp cloth,
removing any build up of dust or dirt.
TUBE REPLACEMENT
To ensure the optimum effectiveness of your Flypod®,the UV
tubes should be replaced every 9 months.
To replace the tube, remove the old tube by pulling it gently
out from the base (1) and push the new tube into the four
connection holes (2).
STARTER REPLACEMENT
The starter should be replaced at the same 9-month interval
as the tube.
To replace the starters release the used starter by turning
anti-clockwise and pulling free. Insert the new starters and
turn clockwise until locked in position.
R2 12/08
Glueboard Replacement
Tube Replacement
Starter Replacement
Unit Flypod
Voltage 240V - 50Hz
Dimensions (mm) W - 190 x H - 300 x D - 140
Coverage 50m2
Weight 2kg
Light Output 18W
Tubes 1 x 18w PL (I815)
Starter 1 x S2 (I154)
Glueboard X6 White (INF252)
SPECIFICATION / REPLACEMENT PARTS
1. 2.
*Patent Applied
C2008
P+L Systems Ltd
Information provided on these instructions is modified and
updated from time to time. This is due to the constant
redevelopment of our products. As such, it is not intended that
you should rely on it or that it should form part of any contract.
P+L Systems Ltd
Ten St James Business Park
Grimbald Crag Court
Knaresborough
HG5 8QB UK
T [phone]
F [phone]
W www.pandlsystems.com
E [email protected]
