PR Lighting RC-7 Installation instructions

READ AND SAVE THESE INSTRUCTIONS
Please read and understand this entire manual before attempting to install or operate the product.
Make sure that all electrical connections comply with local codes, ordinances and the National Electrical Code.
If you are unfamiliar with proper electrical wiring connections, obtain the services of a qualified electrician.
Refer to your Ceiling fan instruction manual for safety and installation instructions.
WARNING: Do not exceed MAX rating power 50W for fan and 100W for ceiling fan light.
www.rplighting.com | 4931 Paseo Nel Norte NE, Albuquerque, NM 87113 | 800.937.6925
MAKING WIRE CONNECTIONS
IMPORTANT: Before installing the receiver, make sure the power on your fan is OFF.
Connect wires by using wire connectors supplied.
The remote controller is to be used for control of DC ceiling fan and fan light only.
WARNING:To avoid the risk of electrical shock, turn the power off at the main fuse box or circuit breaker before wiring.
NOTE:Fan installation must be complete including assembly of fan blades before testing remote control.
WARNING: To reduce the risk of fire or injury, do not use this product in conjunction with any variable (Rheostat) wall control.
- Connect the Black wire(marked AC IN L) from receiver to the Live (Black wire) from house.
- Connect the White wire (marked AC IN N) from receiver to the Neutral (White white) from house.
- Connect yellow/green grounded wire to grounded wire from outlet box.
- Connect the motor wire (Red, Gray, Pink wire) from the fan to the receiver (Red, Gray, Pink wire) .
- Connect the Light wire L (Blue wire) from fan to light Live (Blue wire) from receiver.
- Connect the Light wire N (White wire) from fan to Light Neutral (White wire) from receiver.
Live In (Black)
Neutral (White)
Ground
MOTOR
MOTOR
MOTOR AC IN L
AC IN N
L FOR LIGHT
N FOR LIGHT
Receiver
(Yellow/ Green)
RED
GRAY
PINK
WHITE
BLUE
WHITE
BLACK
Power Supply
120V AC 60Hz
RC-7,RC-9
DC CEILING FAN RF REMOTE CONTROL
INSTALLATION AND OPERATION INSTRUCTIONS
FOR FAN MODELS: 1070W,1080W
- Connect the White wire (marked AC IN N) from receiver to the Neutral (White white) from house.
- Connect yellow/green grounded wire to grounded wire from outlet box.
- Connect the motor wire (Red, Gray, Pink wire) from the fan to the receiver (Red, Gray, Pink wire) .
- Connect the Light wire L (Blue wire) from fan to light Live (Blue wire) from receiver.
Connect the Light wire N (White wire) from fan to Light Neutral (White wire from receiver.
RF ANT
RECEIVER
Power Supply
120V AC 60Hz
RECEIVER
RP.03252022
Ground

www.rplighting.com | 4931 Paseo Nel Norte NE, Albuquerque, NM 87113 | 800.937.6925
Remote Control Operation
Learning Process
RP.04282022
Turn light ON/OFF.
Timer Function:
1H
The fan will turn off after 1 hour.
2H The fan will turn off after 2 hours.
4H The fan will turn off after 4 hours.
8H The fan will turn off after 8 hours.
Press and release this button to turn off fan.
Press this button to set fan wind direction up or down
.
NOTE: It will take a few seconds for fan to slow down and change rotation direction.
1 = Highest Speed
2 = High Speed
3 = Medium Speed
4 = Low Speed
5 = Lowest Speed
LIGHT
ON/OFF
FAN
OFF
1
42
3
5
F/R
Summer Mode(Forward)- Fan runs counterclockwise.
Airflow provides a downward cooling breeze.
Winter Mode(Reverse) - Fan runs clockwise.
Airflow will force warm air downward without a noticeable breeze.
Check to see that all connections are tight, including
To avoid the risk of fire or shock, make sure the electrical wires
are completely tuck inside of the outlet box and not pinched
between the ceiling and canopy.
ground, and that no bare wire is visible at the wire
connectors, except for the ground wire. Do not operate
fan unless blades are completely installed in place.
WARNING
WARNING
Step 1: Install two(2) AAA Alkaline (1.5V) batteries(NOT INCLUDED).
Step 2: Turn on the power on the fan, within 30 seconds turn the transmitter toward the receiver,
press “FAN OFF” button and hold for 3-4 seconds, once the receiver has detected the frequency, the receiver will make
”Beep sound”, the digital paring is done and you can;
a. Control the fan with this transmitter.
b. Re-match two ceiling fans with one transmitter with the same process.
If the fan is not responding to the transmitter, turn the power off to fan and turn it back on again and within 30 seconds repeat Step-2.
The digital paring will not function 30 seconds after the receiver is powered on.
NOTE: After the AC power is on, do not press any other button on the transmitter before doing a digital paring.
NOTE:Remove batteries if not used for a long period of time to prevent damage to the transmitter.
NOTE: When controlling two fans simultaneously, the installation distance between two fans must not exceed 49 ft.
- Connect the White wire (marked AC IN N) from receiver to the Neutral (White white) from house.
- Connect the motor wire (Red, Gray, Pink wire) from the fan to the receiver (Red, Gray, Pink wire) .
- Connect the Light wire L (Blue wire) from fan to light Live (Blue wire) from receiver.
Connect the Light wire N (White wire) from fan to Light Neutral (White wire from receiver.
TO LIGHT L (BLUE)
TO LIGHT N (WHITE)
LIGHT NEUTRAL (WHITE)
LIGHT LIVE (BLUE)
Earth
Insert the receiver into the mounting bracket
and store all wires neatly. Install the canopy
to the mounting bracket using screws provided.
RC-7,RC-9
DC CEILING FAN RF REMOTE CONTROL
INSTALLATION AND OPERATION INSTRUCTIONS
FOR FAN MODELS: 1070W, 1080W
1
42
3
5
OFF
FAN
1H 2H
8H
4H
F/R
LIGHT
ON/OFF
Setting up when the fan turn on.
Mount the transmitter holder onto the wall
using screws provided.
Place the transmitter into the holder.
Operation buttons on the panel of the transmitter.
Waterproof Gasket
Mounting
Bracket
CEILING
Canopy
Waterproof Gasket
placed between
Mounting Bracket
and Ceiling
Receiver
