PRAKTIK TC-1995 Guide

Instruction for installation of small
retractable drawers into Tool Cabinet
TC-1995
It is necessary to implement the installation of
the pre-assembled drawers into the cabinet’s
body starting from the lowest drawer. Pulled
out the main part of the slides, combine and
install the matching mounting elements into
the grooves of the drawer.
NOTES TO THE INSTRUCTION
1. Assembly sequence is specified by the ordinal number in the left upper corner of
each picture of the assembly operation.
2. Type and quantity of the mounting products (if they are necessary) for the
assembly operation are specified near the ordinal number of the assembly operation.
3. Note on the picture’s field specifies the name of the mounting element.
11
Small
retractable
drawer
Tool Cabinet TC
Revision level 24.02.14

Assembly of small drawer
Drawer’s bottom
Bend 90°
Bend
Front
panel
hook
View A
A
Front panel
Drawer’s
bottom
groove
End cap
Drawer’s bottom
Back panel
12
2
1
Front panel
2
1
3
х 4
5
7
Installation of drawer into cabinet
Bracket
Partition
Bracket
Spring rod
Side
panel
Bracket
Side
panel
2
1
8
х 4
Installation procedure of bracket:
1. Insert the rods into the holes of the side panel until it stops
2. Bring the bracket’s front part to the side panel, “drown” the rods
and mount the bracket. The rods should “click” in the side panel’s
holes.
Note.
1. Before the bracket installation, make sure that the rods go
freely into the holes, and if it’s necessary (a rod doesn’t go
into), clean the holes of the paint.
9
Tool Cabinet TC
10
Installation of bracket on side panel
Installation of bracket on partition
х 4 х 4
Installation procedure of brackets:
1. Install the bracket on the partition so
that the holes on it and on the partition
match each other.
2. Tighten the bolts as it’s shown on the
Bracket
Pic.А
Straighten, if bracket’s sides
are kinked
Bend, if bracket’s sides are
not completely bent
2. Also there is a possibility of mismatch of the rods with the holes in the side panels if the bracket’s
panels are kinked or not completely bent. Thus, if it’s necessary, bend or straighten the brackets in
the rods’ area. (see pic.A)
grooves under hooks of right slide
grooves under hooks of left slide
Top
21
Spring
pin
Bracket
of drawer
Attention: The correct position of the
bracket in the cabinet – the grooves
on the bracket’s sides must be on the
top.
Top
1
2
lock
Dismantling of ball-bearing slide
1. Pull out the slide until it stops
2. Turn the plastic lock back
3. Fully pull out the slide’s element
х 2
4
6
installation of the slide’s element onto the drawer
grooves under slide’s hooks
View А
hook
hook
View B
B
А
drawer with installed elements
1
2
