PRASTEL TCO7RX User manual

Transceiver system for mechanical safety and
8,2K resistive edges
TRANSMITTER : TCO7TX
TCO7RX / TCO7TX
Notified Body
Directive 98/37/EC
EC ident. N°1844
PRASTEL FRANCE
ZI Athélia II, 225 Impasse du Serpolet, 13704 LA CIOTAT Cedex, FRANCE
Tel : [phone] - Fax : [phone]
RECEIVER : TCO7RX
Bidirectional
communication

FRA ENG ITA ESP DEU POR
2 / 6
Programming / test key
Dip switch
Programming / test keyDip switch
The system is intended as safety device for gates and includes a receiver (connected to the control unit) and a maximum of 8 transmitters (4 for each
of the two relays of the receiver) connected to the sensitive edges. It can work both with the clean NC contact mechanical edges, and with the 8,2K
edges. The two contacts of the receiver (normally closed with the powered device) are independent and can be connected to the relative input of the
control unit, put in series to the stop of the control unit, or in series to the photo devices contacts. Two contacts are also present on the receiver to be
able to carry out the self – test system.
The transmission of the signals between transmitter and receiver happens on 868 MHz band in bidirectional way.
The installation and the maintenance of the system must be carried out by qualified personnel. The manufacturer can not be considered
responsible for any damages caused by an improper, incorrect or irrational use of the product.
Warning: this device can block the automation if the batteries of the mobile part is flat.
Transceiver system
1. DESCRIPTION
2. CONFIGURATION AND ELECTRICAL CONNECTIONS
NOTE: The signal given on output (clean contact or 8,2K) to
the relay 1 and 2 depends on the position of the selection
output signal jumper.
2.1 Receiver TCO7RX
Jumper of selection power supply tension.
Right : 12Vac/dc Left: 24Vac/dc
Dip switch
Programming / reset key
WARNING: if the power supply of the TCO7RX is carried
out in alternating current (Vac), the power supply must
be got through an insulation transformer (of security,
SELV tensions) which has a limited power or almost a
protection against the short circuit.
Jumper of selection
output signal
Output relay
0.5A at 42.4Vac
1A at 30Vdc
NOTE: The level of acoustic pressure generated by the
device is less then 70 dBA.
MECHANICAL
(N.C) EDGE
2.3 Transmitter TCO7TX + 8,2K resistive edge
2.2 Transmitter TCO7TX + mechanical edge
Resistive edge
Resistance 8,2K
WARNING:
DIP1 OFF: mechanical safety edge
If you want to connect a NON-resistive
element (normally closed contact),
you must set dipswitch 1on "OFF".
WARNING: this application does not
comply with the automatic doors security
norm for use EN 12453 because the
connection of the non-resistive component
connected to the transmitter is not checked.
WARNING:
DIP1 ON: resistive safety edge 8,2K
If you want to connect a resistive element
(8k2 resistor), you must set dipswitch 1on
"ON".

FRA ENG ITA ESP DEU POR
3 / 6
2
3
4
Fix the device as much higher than possible in such way as there are
no obstacles on the direction of the receiver and in such a way as the
maximum distance between the two devices is less than 30 meters.
Set the dip switch relative to the utilized frequency (dip 3 and dip 4)
which will have to correspond to the one of the receiver.
4. CONNECTIONS
4.1 Transmitter connection
1Connect the safety edge to the terminals of the transmitter. Direct
and place the device as shown on the figure.
Give power to the system connecting the two batteries AA – 1,5 V to
the battery holder. Pay attention to the polarity .
2
3
4
Connect the test inputs to the control unit, in case they are utilized (*).
Set the 2 little bridges Mec/8K2 (Jumper of selection output signal ) in
such a way as the state of functioning or of alarm is correctly
signaled, according to whether the control unit has an input of
mechanical type (with contact) or 8,2KΩ.
1
4.2 Receiver connection
Put the receiver in such a way to minimize the distance from the
transmitters associated and close the to the automation’s control unit
or inside the box of the motor. If fixed to a wall, utilize suitable screws
and plugs so that it can resist to a force of 50N downwards.
Set the little bridge of power supply (24V o 12V)
Set the dip switch relative to the utilized frequency (dip 3 and dip 4)
which will have to correspond to the one of the transmitters.
5
(*) The inputs are handled in the same way as the photocells test: the control unit, to carry out the photocells test, switches off the power supply of the
receiver and check that the relays of the correspondent receiver opens itself. In this device, the input TEST1 and TEST2 are for testing the security
devices (see chapter 12).
MIN: 20 cm
WARNING : The manufacturer can not be considered
responsible for any damages caused by an improper,
incorrect or irrational use of the product.
WARNING: keep free the areas of access to the devices
and clean periodically them from eventual dirtiness
which can settle on them during the normal functioning.
It is possible to associate up to a maximum of 4 transmitters (4 different edges) to each relay. For this reason, to each receiver can be associated a
maximum of 8 transmitters.
Warning: for a correct functioning of the system, every transmitter part must have the frequency dip put on the same way as the
correspondent receiver part.
In order to avoid any interferences on installations which need a higher number than 4 security channels it is advisable to distinguish the frequencies
utilized among the various receivers and their transmitters associated transmitters.
N° DIP Function
1Mechanical or resistive
safety edge.
2Energy saving
3Selection frequency of
functioning
4
N° DIP Function
1Test device
2Buzzer ON / OFF
3Selection frequency of
functioning
4
TRANSMITTER TCO7TX RECEIVER TCO7RX
3. SETTINGS
DIP
ON
OFF
DIP
ON
OFF
1 2 3 4 1 2 3 4

FRA ENG ITA ESP DEU POR
4 / 6
5.2 Learning of the transmitter on the second relay of the receiver
3
4
6Release the key of the transmitter
Press and keep pressed the key present on
the receiver.
DO NOT release the key on the receiver.
The receiver emits 2 bips.
The learning ended correctly.
1
Check that the DIP 3 and 4 of the
transmitter and of the receiver are set in the
same way.
Press and keep pressed the key present on
the transmitter.
The receiver emits 2 bips.
5
Release the key on the receiver.
NOTE: in case in which instead 4 BIP are reproduced, it means that the maximum number of transmitters for the selected channel has been
reached and that no new devices on the same relay can be memorized.
In case in which a device previously memorized is then associated to the other relay, it will be automatically removed from the previous relay.
For example, if a device memorized on the relay 1 is memorized on the relay 2 it will be automatically removed from the relay 1.
Acoustic signalling during the learning phase
Number of BIP Meaning
2Transmitter correctly memorized
4Mistake : the maximum number of transmitter for selected channel has been reached
1Maximum time up for the memorization of the transmitter (10 second)
5.3 Summary of the acoustic signalling during the learning phase
Beside the two receiver relays a jumper for the selection of the type signal to give on output is present. This signal can be:
1. A clean contact : open contact in case of alarm and close if the alarm is not present
2. A contact type 8,2K : resistance of the contact = 0 or ∞ (Open loop) Ohm in case of alarm and 8,2KΩ if the alarm is not present. The control
unit connected to the device must be able to handle this type of signal.
The selection of the type of signal is carried out in the following way:
Jumper Pos. 1 Jumper Pos. 2
Position 1 : clean contact functioning (Mec)
Position 2 : 8K2 functioning (8,2K)
6. SELECTION OF THE TYPE OF SIGNAL ON OUTPUT RELAY
2
MEC. 8K2
2
3
4
Press and keep pressed the key present on
the receiver.
Release the key on the receiver.
1
5. LEARNING
5.1 Learning of the transmitters on the first relay of the receiver
Check that the DIP 3 and 4 of the transmitter
and of the receiver are set in the same way.
Press and keep pressed the key present on
the transmitter.
Release the key of the transmitter
5
The receiver emits 1 bip
The receiver emits 1 bip
The receiver emits 2 bips.
The learning ended correctly.
For the successive learning, repeat the operation from point 1.

FRA ENG ITA ESP DEU POR
5 / 6
Through to the button present on the receiver it is possible, further than to carry out the programming of the transmitters (see section 5), to carry out
the reset of the device deleting all the associated transmitters. Proceed as follows to carry out the reset:
On each transmitter a key said “programming/test key” is present and a led. The pressure of the same key during the normal functioning (so not in
programming) produces a signal that is sent to the receiver which close the contact of the relay and answers to this signal with:
Acoustic signaling during the normal functioning
Number of
BIP / BLINK
Meaning What to do
1Regular functioning, no mistake found.-
2One or more sensitive edge on alarm Check the sensitive edges connected
3One or more 8K2 safety sensitive edges under
desactivated
Check the sensitive edges connected
4Battery tension under the level of attention.Substitute the batteries of the indicted device
5Battery tension under the minimum level.Substitute the batteries of the indicted device
6One or more associated devices disconnected Check each associated device
9. RECEIVER RESET
10. PROGRAMMING / TEST KEY OF THE TRANSMITTER
2
3
The receiver emits 1 bip.
5Release the key of the receiver.
Press and keep pressed the key present on
the receiver.
DO NOT release the key on the receiver.
The reset is ended.
1
The receiver emits 2 bips.
4
DO NOT release the key on the receiver. The same receiver emits a series of close bip.
DO NOT release the key on the receiver. The same receiver emits one uninterrupted bip.
N.B.: If one transmitter is in alarm but it necessary to open or close the automation in any case, it’s necessary to press and keep pressed the
programming / test button of the indicted transmitter of the indicated and in the same time to move the automation.
WARNING: If the batteries are completely flat, it will be necessary to change them.
The battery life is of about 2 years (5 years in power save modality). The transmitter keeps constantly under control the state of its batteries. When the
tension gets down under a pre – set value, this state is signaled to the associated receiver which signals it (if the buzzer is active) with 4 BEEP. If the
battery is not substituted, the receiver will continue to regularly work until the tension of the batteries won’t get down under the minimum safety
threshold. If this happens, the receiver will signal it with 5 BEEP putting itself in state of alarm .
The device will remain in state of alarm until the battery of the transmitter won’t be substituted.
The substitution of the battery must be carried out by qualified personnel being necessary to open the receiver.
For each receiver and relative transmitters it is possible to select a frequency of work. This allows to be able to utilize up to a maximum of 4 receivers
on the same range of action without interferences.
For a correct functioning of the system it is indispensable that the frequency set on the receiver corresponds to the frequency set on the associated
transmitters.
The selection of the frequency happens with DIP 3 and 4 as reported on the following table:
DIP 3 DIP 4
Frequency 1 ON ON
Frequency 2 ON OFF
Frequency 3 OFF ON
Frequency 4 OFF OFF
7. SELECTION OF THE WORKING FREQUENCY
8. FLAT BATTERY

FRA ENG ITA ESP DEU POR
6 / 6
GUARANTEE - In compliance with legislation, the manufacturer’s guarantee is valid from the date stamped on the product and is restricted to the
repair or free replacement of the parts accepted by the manufacturer as being defective due to poor quality materials or manufacturing defects. The
guarantee does not cover damage or defects caused by external agents, faulty maintenance, overloading, natural wear and tear, choice of incorrect
product, assembly errors, or any other cause not imputable to the manufacturer. Products that have been misused will not be guaranteed or repaired.
Printed specifications are only indicative. The manufacturer does not accept any responsibility for range reductions or malfunctions caused by
environmental interference. The manufacturer’s responsibility for damage caused to persons resulting from accidents of any nature caused by our
defective products, are only those responsibilities that come under European law.
Caratteristiche tecniche Technical features
Frequenza Frequency 868,3 Mhz
Portata del sistema in campo libero Range of the system in free space 30 m
Alimentazione trasmettitore Transmitter power supply 2 batterie / battery AA
Alimentazione ricevitore Receiver power supply 12/24 Vac-dc
Durata batteria Battery duration 2 anni (modalità funzionamento normale)
5 anni (modalità risparmio energetico)
2 years (normal functionning mode)
5 years (power saved mode)
Coste compatibili Compatible ribs Meccaniche e/o 8,2K
Mechanical and/or 8,2K
Numero di uscite Number of output 2
Numero di costa associabili per
ogni ricevitore Number of ribs for receiver 4 per ogni uscita. 4 for each output.
13 TECHNICAL FEATURES
By the dip switch Low Power present on the transmitter device it is possible to limit the frequency with which the transmitter device transmits its state
of functioning (period of interrogation): but in this case it will be necessary to keep in consideration the condition of dangerous that can be created if
the power supply (battery) is taken off to the transmitter during the interval of time before the successive transmission of its state and successively the
sensible edge goes on alarm: in this case the receiver will signal the alarm only after the period of interrogation.
With the dip 2 of the transmitter on OFF: energy saving deactivated, check the state of the transmitter each second (low power deactivated)
With the dip 2 of the transmitter on ON: energy saving activated, check state of transmitter each 15 seconds (low power activated)
11. SAVING OF ENERGY (LOW POWER)
12. DEVICES TEST
By the dip switch 1 of the receiver it is possible to select if the device test must be carried out with a high logic signal (so the test will activate itself if
between the terminals TEST1 and TESTC will be present a tension from 10V dc to 24 Vdc) or with a low logic signal (so the test will activate itself if
between the terminals TEST1 and TESTC will be present a tension of 0Vdc). In this case, the test will be for the device memorized to the relay 1. The
same is for TEST2 and TESTC for the device memorized to the relay 2.
During this test, the receiver sends a signal to all the associated transmitter with the request of their state. If all the devices answer positively, the test
is passed and the correspondent relay (which was previously open) re – closes itself.
With the dip 1 of the receiver on OFF position: the test of the device is executed by applying a high logic signal 10-24 Vdc at the input.
With the dip of the receiver on ON position: the test of the device is executed by applying a low logic signal 0 Vdc at the input.
Note : in case you don’t want to use the test of the device, place the dip 1 on OFF position.
WARNING:
TCO7TX DIP1 OFF: mechanical safety edge (normally closed contact)
This application does not comply with the automatic doors security norm for use EN 12453 because the
connection of the NON-resistive component connected to the transmitter is not checked.
ISTCO7KIT_EN_12-17.pdf
