Precaster LDM60C User manual

NEW BENCHMARK OF MEASURING
LDM60C
LASER DISTANCE METER
OPERATION MANUAL
NEW BENCHMARK OF MEASURING
1
Specification
Inside the Box
a. Laser Distance Meter x 1
b. Carrying Case x 1
c. AAA Batteries x 2
d. Safety Strap x 1
e. Quickstart Card x 1
Model
Measuring Range
Resolution
Accuracy
Measuring Speed
Laser Type
Battery
Battery Life
Dimensions
Operation Temperature
Storage Temperature
Automatic Power-Off
LDM60
0.05m~60m
Display Color LCD
0.001m
±1.5mm
0.5 seconds
650nm, Class II, <1mW
2 * AAA Batteries
up to 10,000 measures
105 * 48 * 21 mm
-5°C~40°C
-20°C~60°C
-Laser 30 seconds
-Device 180 seconds
(*) For the measurement from the rear edge of the measurer, 90% reflectivity surface (e.g., a white
painted wall), low background illumination, operation temperature at 25ºC. The tolerances apply from
0.5 meters to 10 meters with a confidence level of 95%. The maximum tolerance must add ±0.15 mm/m
between 10 meters to 30 meters and ±0.25 mm/m for distances above 30 meters into the count.
(**) The measurement from the rear of the measurer, apply with a target with 18 to 100% reflectivity or
intense ambient illumination, measuring within temperature at 25ºC. The tolerances apply from
0.5-meters to 10-meters with a confidence level of 95%. The maximum tolerance may deteriorate to
±0.4mm/m between 10-meters to 30-meters and ±0.5mm/m for distances above 30 m and after.
(***) Apply with 100% reflective target, ambient light illumination is approximately 30,000 lux.
www.precaster.com.tw
2 3 4
Overview for device
A. LCD
B. Single measure
C. Addition
D. Subtraction
E. Clear / Power
F. Functions included Single
Measure, Continuous Measure,
Area, Volume, Six Indirectly
height measurements,
Stake-out, Level, Unit, and
Setting
G. Reference / Bluetooth
H. Receiving Lens
I. Laser Emitted Window
LCD
1. Battery Status
2. Measuring Reference
3. Memory
4. Bluetooth
5. Angle
6. Measuring Function
7. Addition/Subtraction
8. Measuring Result
1
4
5
6
8
23
7
A
I
H
B
D
G
C
E
F
LDM60C OPERATION MANUAL
www.precaster.com.tw
LDM60C OPERATION MANUAL
NEW BENCHMARK OF MEASURING
1. This laser distance meter uses 2 x AAA Batteries.
2. Remove the battery lid and install the batteries with the correct polarity.
3. The full battery icon indicates that batteries are full.
4. If the battery icon appears with one slot left, the laser distance meter can
still measure approximately 1000 times and prefer to place new batteries.
5. Replace batteries when the empty battery icon flash on the screen.
Battery & Power Management
Service Support
Please contact your local dealer or contact us through service email:
[[email protected]] for further assistance.
Our website: https://www.precaster.com.tw/eng/
Measurement & Functions
· Power On and Off
1. If the laser distance meter is off, tap the or to turn it on.
2. Tap and hold the for 3 seconds to turn the laser distance meter off.
· Area & Volume Measurements Mode
In Area and Volume mode, the laser distance meter calculates the result
automatically after measuring all lengths.
1. Find the icon in the application menu by tap or , to enable the
Area mode, press .
2. Follow instructions on the screen to measure all necessary length; the area
shows on the screen with length and width.
3. Tap to return to the previous step.
4. Tap to leave the Area mode.
5. Find the icon in the selections by tap or , to enable the Volume
mode, press .
6. Follow instructions on the screen to measure all necessary length; the area
shows on the screen with length, width, and height.
7. Tap to return to the previous step.
8. Tap to leave the Volume mode.
· Single Distance Measurement Mode
1. If the laser is off, tap the to turn on the laser.
2. Move the laser onto the target and hold the laser distance meter steady.
3. Hold your position and click to trigger the measurement.
4. After a beep, the measured length shows on the screen.
· Continuous Measurement Mode
When enables the mode, the laser distance meter keeps measuring. Using this
function to look for preferred distance quickly.
1. Find the icon in the application menu by tap or , to enter the
mode, tap .
2. Tap to start the continuous measurement, the MAX, and MIN length
display on the screen, on top of the current distance.
3. Tap or to stop the measurement.
4. Tap to leave this mode.
www.precaster.com.tw
· Stake-Out Measurement Mode
Stake-Out splits a distance into several lengths in equal.
1. Find the icon in the application menu by tap or , to enable the Area
mode, press .
2. Tap or to set up the length for the splits.
3. Tap and hold the or can speed up the change of numbers.
4. Tap to switch between integer and decimal places.
5. After finish set up, tap and hold for two seconds to enter Stake-Out Mode;
Tap to enable the measurement.
6. During the measuring,
a. The numbers on the top are the preset length.
b. The data in the middle is the multiple of the preset length.
c. The data at the bottom is the current distance.
d. There are two arrows on the top and bottom guide the moving direction to
the next stake.
7. Tap or to stop the measurement.
8. Tap to leave the stake-out mode.
LDM60C OPERATION MANUAL
PRECASTER ENTERPRISES CO., LTD.
Add: No. 204, Sec. 2, Fu-Hsing Rd., Taichung, Taiwan
Tel: [phone]. Fax: [phone]
Http://www.precaster.com.tw
Email: [email protected]
