Precaster TIO30 Installation manual

THE NEW BENCHMARK OF MEASURING
OPERATION MANUAL
PRECASTER ENTERPRISES CO., LTD.
Add: No. 204, Sec. 2, Fuxing Rd, South Dist., Taichung, 40252, Taiwan
TEL: [phone] FAX: [phone]
http://www.precaster.com.tw
email:[e-mail]
Error Code
Table of Contents Overview
Safety Instruction
Battery and Status
Inside Box
1 2
Service, Support and Warranty
Please contact your local dealer for further assistance, thank you.
Code Description
Err01 Target is located at out of eective range
Err02 Reected signal is too weak or lack reected signal
Err03 Measured value is overfolw (max valume: 99999)
Err04 Pythagoras parameter error
Err05 Low power, replace the batteries
Err06 Deviece temperature is too high or too low
Specication
Err07 Ambient noise is too strong
Model NO.
Measuring Range*
Resolution
Accuracy*
Measuring Speed*
Laser Type
Beam Size
Battery
Battery Life*
Dimension
Operation Temperature
Storage Temperature
Automatic Power
TIO30
0.05M~30M
0.001M
±2mm
0.5 Sec.
650nm, Class II, <1mW
25mm@30M
2 x AAA Batteries
Up to 10,000 Measures
94 x 83 x 33mm
-5°~40°C
-20°~60°C
-Laser 30 Seconds -Device 180 Seconds
THE NEW BENCHMARK OF MEASURING
•Before Using
•Battery and Status
•Overview
•Overview of Screen
•Specication
•Power on and o
•Single measure
•Continuously measure
•Addition of your measurements
•Subtractction of your measurements
A. Screen
B. Measure Button
C. Function Button:
Area, Vloume, Indirect Measuring I
D. Power/ Clear Button
E. Battery Cover
•Please read safety instruction carefully before using.
•Laser radiation is emitted from this product.
Use of controls, adjustment procedures other than those specied herein
may result in laser radiation exposure. Never stare directly into beam or aim
the laser beams at others.
•This device contains semiconductor laser diodes with wavelengths of 650
nanometers.
•The total continuous output of the beams never exceeds 1.0 milli-watts.
•This Device complies with EMC Test according to EN61000-6-3 :
2001+A11:2004, EN 61000-6-1:2001, EN 61000-4-2, EN 61000-4-3, EN 60825,
FCC Test according to PART 15.
*The working range and accuracy depend on how well the energy of laser is reected from surface
(mostly comes from scattered light) and the target reectivity.
The brightness of laser point to ambient light intensity or use a target plate (Kodak White) may helps for
increasing the working range and the stability of accuracy.
‧This device is powered by 2 x AAA Batteries.
‧Battery status could be check through icon on the screen as .
‧means the battery has 100% power.
‧means the battery has about 60% power.
‧means the battery has about 25% left.
‧means the battery has 5% left and a new full lled battery replacement
is suggested.
a. Carrying Case b. Batteries c. Safety Strap
•Measuring Functions
-- Area Calculation
-- Dimension Calculation
-- Indirectly Measuring
•Settings
-- Measuring Reference Setting
-- Unit Setting
•Error Code Sheet
•Service, Support and Warranty
A
B
C
D
E
Overview for Screen
1. Laser Emitting Indicator
2. Measuring Reference
3. Previous Measure
4. Current Measure
5. Battery Status
6. Indirect Measuring
7. Area/ Dimension
8. Measuring Mode Indicator
1
2
3
4
5
6
7
8

3 4
5 6
THE NEW BENCHMARK OF MEASURING
THE NEW BENCHMARK OF MEASURING
•Press measure button (B) one time to turn on.
•Screen will be lled out by icons during internally checking.
•Device will get into standby screen and ready for measuring.
•Hold power button (D) for 3 seconds at any screen to turn o device.
•Press measure button (B) to turn on laser then aim at proper target.
•Hold steady and press measure button (B) to measure.
•Result will be displayed on the screen with a beep.
•Hold measure button (B) to active continuous measuring.
•Measuring results will be vary upon movement and showed on the Main screen.
The Maximum and Minimum distance will be displayed on Sub screen.
•Press measure button (B) to stop.
•Press Power button (D) to quit this mode.
•To add rst measurement with later one, press function button (C) to make rst number as summand.
•Then take another measurement and the sum will be displayed on the screen.
•To subtract rst measure with later one, press function button (C)
twice to make rst number as minuend.
•Then take another measurements the subtraction will be displayed on the screen.
Power On and O
Single Measure
Continuiusly Measure
Addition of Your Measuremnets
Subtraction of Your Measuremnets
De-Assembly:
1. Put the TIO30 upside down and hold the laser distance meter part.
2. Slide the nob (A) to left and hold.
3. Pull down the tape.
4. Finished.
1. Hold the Tape part and Laser Distance Meter part in two hands, and align the notches on the chute.
2. Slide the tape up to the end and against the LDM.
3. The nob (A) will lock automatically when the tape hit the end of LDM.
4. Finished.
Assembly:
Assembly and De-Assembly of TIO30
•TIO30 has three commonly used functions for measuring, you could make select by pressing function
button (C).
•By pressing and holding button (C), functions will be popped up in loop from
AREA -> DIMENSION -> INDIRECT MEASURING.
•Release button to stop looping and make the selection of functions.
•Follow the instructions to measure width and length.
•Area will be calculated and showed on the screen.
•Follow the instructions on the main screen to measure width, length and height.
•Dimension will be calculated and displayed on the screen.
•All the calculations are based on Pythagorean theorem (a+b=c) for height.
•Press function button (C) for 3 times to enable indirect measuring
Follow the instructions on the screen to measure slang lengths and leveling length.
•Measured Results will be displayed on the screen.
Measuring Function Selection
a. Area Measurement
b. Volume Measurement
c. Indirect Measurement
•Tio30 has two settings in outer menu. The Two settings are“Unit”and“Reference”.
•Follow the instructions below to access to the outer menu.
•Long-pressing function button (C ).
•Press measure button (B) together.
•Access to Unit and Measuring reference point settings.
•Press Function button(C) and select Unit settings.
•Press measure button(B) and select preferred unit.
•Press red button two times to restart.
•Long-pressing function button (C ).
•Press measure button (B) together.
•Access to Unit and Measuring reference point settings.
•Press Function button(C) and select measuring settings.
•Press measure button(B) to select preferred measuring point.
•Press red button two times to restart.
Measuring Function Selection
a. Unit Switch Reference
b. Measuring Reference
