Precaster Ldm60 User manual

NEW BENCHMARK OF MEASURING

NEW BENCHMARK OF MEASURING www.precaster.com.tw

www.precaster.com.tw

1 2

Error Code

Speciﬁcation

Please contact your local dealer or contact us through service email :

[ [email protected] ] for further assistance.

Service Support

Safety Information

Inside the Box

a. Laser Distance Meter x 1

b. Carrying Case x 1

c. AAA Batteries x 2

d. Safety Strap x 1

e. Quickstart Card x 1

Overview

A. LCD

B. Single measure / Tap and hold

continuous measure

C. Addition

D. Subtraction / Tap and hold to

change unit

E. Clear / Power

F. Distance Measurement (Area ->

Volume -> Stake out -> Single

measure) / Tap and hold to set

up (volume -> 20 measurement

records)

G. Indirectly height (Indirectly

height measure I -> II -> III ) /

Tap and hold to set up the

measure (the top of device ->

the end of device)

H. Receiving Lens

I. Laser Emitted Window

LCD

1. Measuring Reference

2. Area/Volume

3. Memories

4. Laser Indicator

5. Addition/Subtraction

6. Indirect Measuring

7. Min and Max Display

8. Stake out

9. Timer

10. Battery Status

11. Units

2 3 9

a. This is a Class 2 laser tool, laser radiation is emitted from this product and is manufactured to

comply IEC 60825-1: 2007, EN 60825-1:2007, EN 61326-1:2013 and CRF21, parts 1040.10 and

1040.11.

b. Product complies with EMC Test according to EN61000-6-3:2001+A11:2004,

EN61000-6-1:2001, EN61326-1:2013, IEC 61326:2012 and FCC Test according to PART 15.

c. Use of controls, adjustment procedures other than those speciﬁed herein may result in laser

radiation exposure.

d. Never stare directly into beam or aim the laser beams at others.

e. Product contains semiconductor laser diodes with wavelengths of 650 nanometers.

f. The total continuous output of the beams never exceeds 1.0 milli-watts.

LDM60

LASER DISTANCE METER

OPERATION MANUAL

Err01

Err02

Err03

Out of measuring range Measuring in a proper range

Reﬂected signal is too weak

Pythagorean calculation error

Low Battery

Out of working temperature

Ambient light is too strong

Check and verify values and

steps are correct

Install new batteries

Measure in an environment

within speciﬁed working

temperature

Measure in a darker place

(shadow target)

Select a better surface

Out of display range (Max Value:

99999), e.g: result of area or

dimension is out of display range.

Divide caculation into

intermediate steps

Err04

Err05

Err06

Err07

Code Description Solution

Model

Measuring Range

Resolution

Accuracy

Measuring Speed

Laser Type

Battery

Battery Life

Dimensions

Operation Temperature

Storage Temperature

Automatic Power-Oﬀ

LDM60

0.05m~60m

0.001m

±1.5mm

0.5 seconds

650nm, Class II, <1mW

2 * AAA Batteries

up to 10,000 measures

105 * 48 * 21 mm

-5°C~40°C

-20°C~60°C

-Laser 30 seconds

-Device 180 seconds

LDM60 OPERATION MANUAL

PRECASTER ENTERPRISES CO., LTD.

Add: No. 204, Sec. 2, Fu-Hsing Rd., Taichung, Taiwan

Tel: 886-4-2262 1000. Fax: 886-4-2261 6565

Http://www.precaster.com.tw

Email: [email protected]
