TACTIVO™ for iPhone 4S and iPhone 4
User Reference Guide

Trademarks: Tactivo™ and PRECISE BIOMETRICS™
Design: registered community design and pending design patent in USA
Patent: patents pending in EU and USA
©Precise Biometrics 2012-2013

INDEX
1. Introduction
2. General Information
3. System Requirements
4. Card Reader
5. Installation
6. Maintenance
7. Using Tactivo
7.1 Correct nger placement
7.2 Enhancing ngerprint image quality
8. Synchronizing & Charging
9. Apps for Tactivo
10. Electromagnetic Compatibility
11. Environment

1. Introduction
Tactivo™ smart card and ngerprint reader makes strong authentication
easy and convenient using a smart card, ngerprint, or both.
For more information on Tactivo and available apps, visit www.idApps.com.
2. General Information
Tactivo should only be used with iPhone 4 and iPhone 4S. It adds smart card
and ngerprint functionality to an iPhone and should not be used for any
other purpose. Although Tactivo covers a major physical part of the iPhone,
it should not be considered a protective case.
Always keep the top cover of Tactivo connected when using the device.
Do not allow Tactivo to get in contact with water or other uids. If this
happens immediately disassemble Tactivo from the iPhone and let it dry
thoroughly. Do not dry Tactivo using any external sources, such as hair
dryers and microwave ovens.
Tactivo is designed to work in the temperature range 32-95°F (0-35°C) and
can be stored in the range -4-113°F (-20-45°C )
Handling of Tactivo is the user’s responsibility and any action that can
damage the product is the user’s own responsibility. Do not paint, drop or
disassemble Tactivo and do not put it in places or in devices where it can be
damaged such as in a clothes dryer.
Tactivo may contain small parts which may present a choking hazard for
small children. Keep such parts away from small children.

3. System Requirements
Usage of Tactivo requires an iPhone 4S or iPhone 4 with iOS 6.0 or higher.
4. Card Reader
The card reader in Tactivo supports non-embossed ISO 7816-4 compatible
smart cards including US credentials PIV, PIV-I, TWIC, and CAC. Do not
use the card reader for other cards or for storage of other things such as
business cards.

5. Installation
Always slide the iPhone in or out when connecting and disconnecting
Tactivo. Bending while connecting or disconnecting might damage Tactivo
and the 30-pin connector to the iPhone.
1. Slide o the
top cover.
2. Slide in your
iPhone.
3. Slide on the
top cover.
4. If you have a
smart card, slide
it in.
5. The first
time you install
Tactivo, you will
be directed to
available apps on
App Store.
6. To disassemble,
gently push in and
up.
(mm)

6. Maintenance
Protect Tactivo™ from any kind of physical damage. Tactivo should not
be considered as a protective case for your iPhone.
Ensure that you are electrostatically discharged before putting your
nger on the sensor. High electrostatic discharges might damage the
ngerprint sensor.
Keep the sensor surface clean or there is an increased risk that the
ngerprint can’t be successfully matched.
If necessary, clean the sensor surface with a clean cotton cloth. You can
dampen the cloth slightly with a cleaner.
Do not use paper tissues for cleaning purposes as they may scratch the
surface.
Do not spray cleaner directly onto the device.
Do not use chlorine-based cleaners, non-chlorine bleach, or chlorine-
based bathroom or mildew cleaners.
Do not use any solvents, such as acetone, paint thinners, turpentine, etc.

7.1 Correct Finger Placement
Correct and consistent nger placement is crucial for good performance.
1. Fingerprint sensor 2. Make sure to capture
this area on you nger
3. Swipe your nger
at on the sensor
in a rm downward
movement
4. Do not rotate your nger and
make sure it is not misaligned
5. Do not lift nger when swiping
and do not use only the ngertip

7.2 Enhance Fingerprint Image Quality
If your nger is very dry:
Try to press more rmly when swiping.
Breathe on your nger.
If your nger is very damp:
Try to press less rmly when swiping.
Wipe your nger dry.
More tips
See the “Maintenance”section to learn how to keep the sensor
surface clean.
If your ngerprint is still not recognized, please consider
re-enrollment to get a better reference image.

8. Charging & Synchronizing
Your iPhone can be charged through your computer using the micro USB
cable included with your Tactivo, or through a wall outlet using an AC
adapter without disconnecting your Tactivo from the iPhone.
Your iPhone can be synchronized using the micro USB cable included with
your Tactivo without disconnecting Tactivo from the iPhone.
Tactivo should be used exclusivly with supported iPhone models, and
should only be connected to a computer with the micro USB cable for
synchronizing and charging. Do not connect it to any other device
Do not bend or twist the micro USB cable while connected to Tactivo.
When synchronizing and charging through your computer, only use the
micro USB cable provided with Tactivo.
Only use approved iPhone chargers.
Do not attempt to use 30-pin connector-based docking stations without
removing Tactivo from the iPhone
Never force a connector into a port. This might damage the product.
Note that Tactivo smart card and ngerprint functionality is disabled while
synchronizing the iPhone through your computer.
9. Apps for Tactivo
The use of apps for Tactivo is entirely at the user’s sole risk. Precise Biometrics
has no liability whatsoever and disclaims all responsibility for the usage of
apps for Tactivo.

10. Elecromagnetic Compatibility
Electromagnetic compatibility (EMC) is the ability of electronic equipment to
function properly together in the electronic environment.
CE Notice (Europe)
Tactivo meets the following technical standards:
• EN 301 489-1:2011 • EN 61000-4-2:2008
• EN 55022:2006 – A1:2007 • EN 61000-4-3:2006 – A1:2008
FCC Information (USA)
Tactivo for iPhone 4 and iPhone 4S (P/N SAA 123 1000) complies with Part 15 (Class
B) of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
CONTACT: Precise Biometrics Inc.,11951 Freedom Drive, 13th Floor, Reston, VA 20190
Telephone: + 1 (800)) 609-0578

11. Environment
RoHS compliant
WEEE compliant
The top cover is recyclable plastics
The black bottom piece should be recycled as an electrical waste
