Premio SIO-200 Series User manual

USER’S
MANUAL
SIO-200 Series
Stainless Steel Panel PCs

SIO Series l User’s Manual
Table of Contents
2
Prefaces …………………………………………………….……………………………………………. 04
Revision ………………………………………………..……………….…........................…….. 04
Disclaimer ………………………………….………………………….…………………............... 04
Copyright Notice ………………………………………………………………………............... 04
Trademarks Acknowledgment …………..………………………………....................... 04
Environmental Protection Announcement ………………….………………….......... 04
Safety Precautions …………………………………….…………….…………………………….. 05
Technical Support and Assistance ………………….…………….………………........... 06
Conventions Used in this Manual ……………………………….….……………............ 06
Package Contents ……………………………………………………….……………............... 07
Ordering Information …………………………………….……….…………….................... 07
Available Models …………...………………........................................................... 08
Chapter 1 Product Introductions ………………………………………………………..… 09
1.1 Overview ……………………….………………………………..………….…………………..…….. 10
Key Feature ………….……………………………………….……….…..……………............... 10
1.2 Hardware Specification ….………………………….....…………….…………..…………..… 11
1.3 System I/O ……………………………..……………………..…………………………………..…… 13
1.4 Mechanical Dimension …………………………..…………………………..………….………. 15
Chapter 2 Front Panel Controls ………………………………………..……………..….. 17
2.1 Users Controls ………………….………….…………………………………………………….….. 18
2.1.1 Power Button …………………………...………………………………………………...…. 18
2.1.2 LED ………………….………….…………………………………………………...…………….. 18
2.1.3 Reset ………………………..……………………………….....……………………………….. 18
2.1.4 Native touchscreen enable/disable ………………………………………...……… 18
Chapter 3 BIOS Setup ……………………..…………………………………………………… 19
3.1 BIOS Introduction ………………………………………..…….………………………………….... 20
3.1.1 ACPI Settings ………………..………….……….………………..….…….................... 21
3.1.2 F81866 Super IO Configuration ……………….......................................... 21
3.1.3 Hardware Monitor ………………..………….……….………………..…................. 23
3.1.4 Serial Port Console Redirection ………………..………….……….…................ 23
3.1.5 CPU Configuration ………………..………….……….....................…................ 24
3.1.6 SATA Configuration ………………..………….……….....................…................ 25
3.1.7 Miscellaneous Configuration ………………..………….………........................ 25
3.1.8 LPSS & SCC Configuration ………………..………….………............................. 26
3.1.9 Network Stack Configuration ………………..………….………........................ 26
3.1.10 CSM Configuration …………….………….……….......................................... 27

SIO Series l User’s Manual
3
3.1.11 SDIO Configuration ………………..………….………..................................... 28
3.1.12 USB Configuration …………….………….………...........................................29
3.1.13 Security Configuration ………………..………….……….................................30
3.2 Chipset ………..………….………..................................................................... 31
3.2.1 Northbridge Configuration ……..……………………………………..………………. 31
3.2.2 Southbridge Configuration …….…………………………………..………………….. 33
3.3 Security ………………………………………………………..…………………………………………. 34
3.3.1 Security Boot Menu ……..………………………………………….…..………………. 35
3.4 Boot …………...……….……………….…….…..….…..…………..…………………………..….... 36
3.5 Save and Exit …………...……….……………..….…..………………………………..…………... 36
Chapter 4 Address Map ………………………………………………….……………..….… 37
4.1 I/O Port Address Map …………...……….……………..…………..…..…………... 38
4.2 Interrupt Controller (IRQ) Map …….…………………………..….…….…….………….... 41
4.3 Memory Map ……………………………………………………….…………………………………. 49

SIO Series l User’s Manual
4
Revision
Disclaimer
All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio
Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The
information in this document is subject to change without notice and does not represent a commitment on
the part of Premio Inc.
Premio Inc. disclaims all warranties, express or implied, including, without limitation, those of
merchantability, fitness for a particular purpose with respect to contents of this User’s Manual. Users must
take full responsibility for the application of the product.
Copyright Notice
All rights reserved. No part of this manual may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording, or information storage and retrieval systems,
without the prior written permission of Premio Inc. Copyright © Premio Inc.
Trademarks Acknowledgment
Intel®, Celeron® and Pentium® are trademarks of Intel Corporation.
Windows® is registered trademark of Microsoft Corporation.
AMI is trademark of American Megatrend Inc.
IBM, XT, AT, PS/2 and Personal System/2 are trademarks of International Business Machines Corporation
All other products and trademarks mentioned in this manual are trademarks of their respective owners.
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. Please recycle to minimize pollution
and ensure environment protection.
Prefaces
Revision
Description
Date
1.0
Manual Released
2023/09/06
Preface

SIO Series l User’s Manual
5
Safety Precautions
Before installing and using the equipment, please read the following precautions:
⚫Put this equipment on a reliable surface during installation. Dropping it or letting it fall could
cause damage.
⚫The power outlet shall be installed near the equipment and shall be easily accessible.
⚫Turn off the system power and disconnect the power cord from its source before making any
installation. Be sure both the system and the external devices are turned OFF. Sudden surge
⚫of power could ruin sensitive components. Make sure the equipment is properly grounded.
⚫When the power is connected, never open the equipment. The equipment should be opened
only by qualified service personnel.
⚫Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
⚫Disconnect this equipment from the power before cleaning. Use a damp cloth. Do not use
liquid or spray detergents for cleaning.
⚫Avoid the dusty, humidity and temperature extremes.
⚫Do not place heavy objects on the equipment.
⚫If the equipment is not used for long time, disconnect it from the power to avoid being
damaged by transient over-voltage.
⚫The storage temperature shall be above -20°C and below 70°C.
⚫The computer is provided with a battery-powered real-time clock circuit. There is a danger of
explosion if incorrectly replaced. Replace only with the same or equivalent type
recommended by the manufacturer.
⚫If one of the following situation arises, get the equipment checked be service personnel:
•The power cord or plug is damaged.
•Liquid has penetrated into the equipment.
•The equipment has been exposed to moisture.
•The equipment does not work well or it cannot work according the user’s manual.
•The equipment has been dropped and damaged.
•The equipment has obvious signs of breakage.
Preface

SIO Series l User’s Manual
6
Technical Support and Assistance
1. Visit the Premio Inc website at www.premioinc.com where you can find the latest information about
the product.
2. Contact your distributor, our technical support team or sales representative for technical support if
you need additional assistance. Please have following information ready before you call:
⚫Model name and serial number
⚫Description of your peripheral attachments
⚫Description of your software (operating system, version, application software, etc.)
⚫A complete description of the problem
⚫The exact wording of any error messages
Conventions Used in this Manual
Preface
This indication alerts operators to an operation that, if not strictly observed,
may result in severe injury.
WARNING
This indication alerts operators to an operation that, if not strictly observed,
may result in safety hazards to personnel or damage to equipment.
CAUTION
This indication provides additional information to complete a task easily.
NOTE

SIO Series l User’s Manual
7
Preface
Package Contents
Before installation, please ensure all the items listed in the following table are included in the package.
Item
Description
Q’ty
1
SIO
-200 Series Stainless Steel Panel PC 1
2
Waterproof Connector Cover Set
7
3
Waterproof M12 S
-CODE 4P PWR Cable(SUS316L) Type_US L=3M 1
Ordering Information
Model No. Description
1-TPWR00092 Waterproof M12 S-CODE 4P PWR Cable(SUS316L) Type_US L=3M
1-TCOM00032 Waterproof M12 A-CODE 8P COM Cable(SUS316L)_DB9 L=1.5M
1-TLAN00024 Waterproof M12 X-CODE 8P LAN Cable(SUS316L)_CAT 5E_RJ45 L=1.5M
1-TUSB00057 Waterproof M12 A-CODE 8P USB 2.0 Cable(SUS316L)_Type A*2 L=1.6M

SIO Series l User’s Manual
8
Preface
Available Models
Model No. Description
SIO
-215CB-J1900
15" XGA Capacitive Touch Stainless Steel Panel PC with
Celeron Processor J1900, AC IN, M12 US PWR Cord ,
Optical bonding
SIO
-215RB-J1900
15" XGA Resistive Touch Stainless Steel Panel PC with
Celeron Processor J1900, AC IN, M12 US PWR Cord ,
Optical bonding
SIO
-W215CB-J1900
15.6" FHD Capacitive Touch Stainless Steel Panel PC with
Celeron Processor J1900, AC IN, M12 US PWR Cord ,
Optical bonding
SIO
-W215RB-J1900
15.6" FHD Resistive Touch Stainless Steel Panel PC with
Celeron Processor J1900, AC IN, M12 US PWR Cord ,
Optical bonding
SIO
-W221CB-i5-8365UE
21.5" FHD Capacitive Touch Stainless Steel Panel PC with
Intel CPU i5
-8365UE, AC IN, M12 US PWR Cord ,
Optical bonding
SIO
-W221RB-i5-8365UE
21.5" FHD Resistive Touch Stainless Steel Panel PC with Intel
CPU i5
-8365UE, AC IN, M12 US PWR Cord ,Optical bonding
SIO
-W224CB-i5-8365UE
23.8" FHD Capacitive Touch Stainless Steel Panel PC with
Intel CPU i5
-8365UE, AC IN, M12 US PWR Cord ,
Optical bonding
SIO
-W224RB-i5-8365UE
23.8" FHD Resistive Touch Stainless Steel Panel PC with Intel
CPU i5
-8365UE, AC IN, M12 US PWR Cord ,Optical bonding

Chapter 1
Product Introductions

SIO Series l User’s Manual
10
Chapter 1: Product Introductions
Key Features
J1900 Series: SIO-215-J1900 or SIO-W215-J1900
⚫Resistive 5-wire / projected capacitive touch
⚫Intel® Celeron® processor J1900, 2.0 GHz
⚫1x 8GB DDR3L SODIMM, 1x 128GB mSATA
⚫2x M12 for 4x USB 2.0, 2x M12 for LAN, 2x M12 for COM
⚫1x Full-size Mini PCIe for expansion
⚫Support 110V to 240V AC power input
⚫Fanless Operation from -20°C to 55°C
⚫Full system IP66/IP69K with Stainless Steel SUS316 construction
⚫Scratch-resistant and Wear-resistant 7H Tempered Glass
⚫Optical Bonding for ultimate clarity
⚫Pressure Valve SUS316 VENT
1.1 Overview
The SIO-200 series full IP66/IP69K Waterproof Touchscreen Computer for High-Pressure, High-
Temperature Waterproof and Reliable connections resistant to humidity, water, dust, dirt and corrosion.
The Rugged Stainless Steel Display for Hygienic Environments.
FHD Resistive / Capacitive Touch Stainless Steel Panel PC with
Intel® Celeron® Processor J1900 or Intel® Core™i5-8365UE Processor
8365UE Series: SIO-W221-8365UE or SIO-W224-8365UE
⚫Resistive 5-wire / projected capacitive touch
⚫Intel® Core™i5-8365UE Processor, 4.10 GHz
⚫1x 8GB DDR4 SODIMM, 1x 128GB mSATA
⚫2x M12 for 4x USB 2.0, 2x M12 for LAN, 2x M12 for COM
⚫1x Full-size Mini PCIe for expansion
⚫Support 110V to 240V AC power input by M12 Power Connector
⚫Fanless Operation from -10°C to 50°C
⚫Full system IP66/IP69K with Stainless Steel SUS316 construction
⚫Touch Function ON/OFF Switch
⚫Scratch-resistant and Wear-resistant 7H Tempered Glass
⚫Optical Bonding for ultimate clarity
⚫Pressure Valve SUS316 VENT
