Premio VCO-6100 Series User manual

USER’S
MANUAL
VCO-6100 Series
Superior Machine Vision System

VCO-6100 Series
Table of Contents
2
Prefaces ……………………………………………………………………………………………….. 04
Revision ………………………………………………………..……………………………..……………….……….. 04
Disclaimer ……………………………………………………….…….……………….………………….………….. 04
Copyright Notice …………………………………….…….….………………………………….………………… 04
Trademarks Acknowledgment …………..………….………………………………………................... 04
Environmental Protection Announcement ……………………………………..……..……………….. 04
Safety Precautions ……………………………………………………………………………………….….…….. 05
Technical Support and Assistance ………………………………...……………………..…….…….……. 06
Conventions Used in this Manual …………………………………..……………………......….……….. 06
Package Contents ……………………………………………………………………..…..…………………….… 07
Ordering Information …………………………..……………………………………..………..….….………… 07
Optional Accessory …………...……………………………………................................................. 08
Chapter 1 Product Introductions ……………………………………………………..… 09
1.1 Overview ………………….………………………………..………….…………..………………... 10
Key Feature ………….…………………..…………….……….…..…..………….................. 10
1.2 Hardware Specification ….………..………….....…………….……..……..…….………… 11
1.3 System I/O ………..……………..……………………..……………………..………….………… 14
1.3.1 VCO-6122 ………..…………….…………………………..………………………..………. 14
1.3.2 VCO-6133 …………………………………..…………………….……….……………..…… 16
1.3.3 VCO-6144 …………………………………..…………………….……….……………..…… 18
1.3.4 VCO-6155 …………………………………..…………………….……….……………..…… 20
1.3.5 VCO-6122C-2PWR ………………………………………….……….……………..……… 22
1.3.6 VCO-6133E-2PWR …………………………………..…………………….………..…..… 24
1.4 Mechanical Dimension ……………………..………………………..…..………….……….. 26
1.4.1 VCO-6122 ………..…………….…………………………..………………………..………. 26
1.4.2 VCO-6133 …………………………………..…………………….……….……………..…… 27
1.4.3 VCO-6144 …………………………………..…………………….……….……………..…… 28
1.4.4 VCO-6155 …………………………………..…………………….……….……………..…… 29
1.4.5 VCO-6122C-2PWR ………………………………………….……….……………..……… 30
1.4.6 VCO-6133E-2PWR …………………………………..…………………….………..…..… 31
Chapter 2 Switches and Connectors …………….…………………………………….. 32
2.1 Switch and Connector Locations ………………………………………..…….….….….... 33
2.1.1 Top View ………………………………………………………………………..…..….…… 33
2.1.2 Bottom View ……………………………………………………………..……..………... 34
2.2 Connector / Switch Definition ……………………………….……….…….……............. 35
2.3 I/O Interface Descriptions ........................................................................... 36
2.3.1 LPC Debug Con.................................................................................... 36
2.3.2 Power Con .......................................................................................... 37
2.3.3 DC IN/IGN IN (+9V ~ +48V) ................................................................. 38
2.3.4 COM Con ............................................................................................. 39
2.3.5 SF100 SPI Con ..................................................................................... 41

VCO-6100 Series
3
3.7 Installing SODIMM………...........................…………...…….….……………………....... 80
3.8 Installing CPU………........................................................................................ 81
3.9 Installing Mini PCIe card / mSATA.….………………….……………………..…………..... 86
3.10 Installing M.2 2280 NVMe SSD …………..…………………………………………………... 87
3.11 Installing WiFi Module.…………...…….………………….……………………..…………...... 88
3.12 Installing Mini PCIe card / 4GLTE...….………………………………………..…………..... 91
3.13 Installing Antenna........................................…...…….…………………..….……….... 92
3.14 Installing graphic Card……………………..……….................................................. 94
Chapter 4 BIOS Setup …………………………………………..……………..……………. 103
4.1 BIOS Introduction …….……….……………………………………….…….…..….…………... 104
4.2 Main Setup ……..……….………………….…………………………..….….………………...... 105
4.3 Advanced Setup …………………………………………..…………………………………………. 106
4.3.1 CPU Configuration ..…………...………………………………………..………………. 107
4.3.2 PCH-FW Configuration ……..……………….………..………..……………..…....... 108
4.3.3 SATA and RST Configuration ………………..……………….………………..…..... 109
4.3.4 RST (UEFI RAID) Configuration ……………………………………….………......... 110
4.3.5 Trusted Computing ……………………………..……………….………………..…...... 112
4.3.6 ACPI Settings ……………………………………………………….……………….......... 113
4.3.7 Super IO Configuration……………………….………………..…………………....... 114
4.3.8 Hardware Monitor………………………………………......………………..…......... 121
4.3.9 Serial Port Console Redirection ……………..………….………….….………..... 123
4.3.10 Network Stack Configuration ……………..…………………………..………..... 124
4.3.11 CSM Configuration ……………………………..……………..……..………………… 125
4.3.12 USB Configuration …………………………..………………………….………..…….. 126
4.4 Chipset ………..………………….…..….…..…………………………………………………........ 127
4.4.1 System Agent (SA) Configuration ………….…………………..…………………. 127
4.4.2 PCH-IO Configuration ………….……………………….………………..……………. 131
4.5 Security …………...….………………….…..….………………………………………..………..... 136
4.6 Boot …………...……….….………………….…..………………………..…………..…………..... 139
4.7 Save & Exit …...……….….………………….…..….…..……………………………………….... 140
Appendix WDT & GPIO ………………………………………………………………………….. 141
WDT Sample Code …….……………………….……………….……………..….…….…….…………... 142
GPIO Sample Code ………………………………………………………..…………………………………. 143
Chapter 3 System Setup …………………………..…………………………….…………… 71
3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and
unscrewing …………………………………………………………………………………………….. 72
3.2 Removing heat sink cover………………...………………………………………................ 72
3.3 Disconnecting expansion module from computing module........................ 74
3.4 Removing chassis bottom cover…….......………………………….….………………...... 75
3.5 Install HDD/SSD on the internal SATA bay……………..…….………………………..... 76
3.6 Installing HDD on removable SATA HDD bay……...………………………………....... 78

VCO-6100 Series
4
Revision
Disclaimer
All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio
Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The
information in this document is subject to change without notice and does not represent a commitment on
the part of Premio Inc.
Premio Inc. disclaims all warranties, express or implied, including, without limitation, those of
merchantability, fitness for a particular purpose with respect to contents of this User’s Manual. Users must
take full responsibility for the application of the product.
Copyright Notice
All rights reserved. No part of this manual may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording, or information storage and retrieval systems,
without the prior written permission of Premio Inc. Copyright © Premio Inc.
Trademarks Acknowledgment
Intel®, Celeron® and Pentium® are trademarks of Intel Corporation.
Windows® is registered trademark of Microsoft Corporation.
AMI is trademark of American Megatrend Inc.
IBM, XT, AT, PS/2 and Personal System/2 are trademarks of International Business Machines Corporation
All other products and trademarks mentioned in this manual are trademarks of their respective owners.
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. Please recycle to minimize pollution
and ensure environment protection.
Revision
Description
Date
1.0
Manual Released
2021/1/27
Prefaces

VCO-6100 Series
5
Safety Precautions
Before installing and using the equipment, please read the following precautions:
Put this equipment on a reliable surface during installation. Dropping it or letting it fall could
cause damage.
The power outlet shall be installed near the equipment and shall be easily accessible.
Turn off the system power and disconnect the power cord from its source before making any
installation. Be sure both the system and the external devices are turned OFF. Sudden surge
of power could ruin sensitive components. Make sure the equipment is properly grounded.
When the power is connected, never open the equipment. The equipment should be opened
only by qualified service personnel.
Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
Disconnect this equipment from the power before cleaning. Use a damp cloth. Do not use
liquid or spray detergents for cleaning.
Avoid the dusty, humidity and temperature extremes.
Do not place heavy objects on the equipment.
If the equipment is not used for long time, disconnect it from the power to avoid being
damaged by transient over-voltage.
The storage temperature shall be above -30°C and below 85°C.
The computer is provided with a battery-powered real-time clock circuit. There is a danger of
explosion if incorrectly replaced. Replace only with the same or equivalent type
recommended by the manufacturer.
If one of the following situation arises, get the equipment checked be service personnel:
•The power cord or plug is damaged.
•Liquid has penetrated into the equipment.
•The equipment has been exposed to moisture.
•The equipment does not work well or it cannot work according the user’s manual.
•The equipment has been dropped and damaged.
•The equipment has obvious signs of breakage.
Preface

VCO-6100 Series
6
Technical Support and Assistance
1. Visit the Premio Inc website at premioinc.comwhere you can find the latest information about the
product.
2. Contact your distributor, our technical support team or sales representative for technical support if
you need additional assistance. Please have following information ready before you call:
Model name and serial number
Description of your peripheral attachments
Description of your software (operating system, version, application software, etc.)
A complete description of the problem
The exact wording of any error messages
Conventions Used in this Manual
Preface
This indication alerts operators to an operation that, if not strictly observed,
may result in severe injury.
WARNING
This indication alerts operators to an operation that, if not strictly observed,
may result in safety hazards to personnel or damage to equipment.
CAUTION
This indication provides additional information to complete a task easily.
NOTE

VCO-6100 Series
7
Package Contents
Before installation, please ensure all the items listed in the following table are included in the package.
Preface
Item
Description
Q’ty
1
VCO
-6100 Series Fanless Embedded System 1
2
Utility DVD Driver
1
3
Wall Mount Kit
1
4
Accessory Kit
1
5
DVI to VGA Adapter
1
Ordering Information
Model No. Product Description
VCO-6122E Superior Machine Vision System with LGA 1151 for Intel 8th/9th Gen CPU
& Q370 PCH, 2x PCIe x8
VCO-6122P Superior Machine Vision System with LGA 1151 for Intel 8th/9th Gen CPU
& Q370 PCH, 2x PCI
VCO-6122C Superior Machine Vision System with LGA 1151 for Intel 8th/9th Gen CPU
& Q370 PCH, 1x PCIe x16, 1x PCI
VCO-6133E Superior Machine Vision System with LGA 1151 for Intel 8th/9th Gen CPU
& Q370 PCH, 2x PCIe x1, 1x PCIe x16
VCO-6133P Superior Machine Vision System with LGA 1151 for Intel 8th/9th Gen CPU
& Q370 PCH, 3x PCI
VCO-6133C Superior Machine Vision System with LGA 1151 for Intel 8th/9th Gen CPU
& Q370 PCH, 1x PCIe x16, 2x PCI
VCO-6144P Superior Machine Vision System with LGA 1151 for Intel 8th/9th Gen CPU
& Q370 PCH, 4x PCI
VCO-6144C Superior Machine Vision System with LGA 1151 for Intel 8th/9th Gen CPU
& Q370 PCH, 2x PCIe x4, 1x PCIe x8, 1x PCI
VCO-6155C Superior Machine Vision System with LGA 1151 for Intel 8th/9th Gen CPU
& Q370 PCH, 2x PCIe x4, 1x PCIe x8, 2x PCI
VCO-6122C-2PWR GPU Computing System with LGA 1151 for Intel 8th/9th Gen CPU & Q370
PCH, 1x PCIe x16, 24V Power for GPU
VCO-6133E-2PWR GPU Computing System with LGA 1151 for Intel 8th/9th Gen CPU & Q370
PCH, 1x PCIe x16, 2x PCIe, 24V Power for GPU

VCO-6100 Series
8
Preface
Model No. Product Description
1
-E09A22801
Adapter AC/DC 24V/11.67A 280W with 3pin Terminal Block Plug
5.0mm Pitch
1
-E09A22102
Adapter AC/DC 24V 9.2A 220W with 3pin Terminal Block Plug
5.0mm Pitch
SFICBL022
Power Cord, 3
-pin US Type, 180cm
1
-TPCD00002
Power Cord, European Type, 180cm
1
-TPCD00001
Power Cord, 3
-pin UK Type, 180cm
Optional Accessories

Chapter 1
Product Introductions

VCO-6100 Series
VCO-6155
VCO-6144VCO-6133
VCO-6122
10
1.1 Overview
The VCO-6100 series support 9th Gen. Intel® Core™ i7-9700E (4.4GHz, 8 Cores) / i5-9500E (4.2GHz, 6
Cores) / i3-9100E (3.7GHz, 4 Cores) / i7-9700TE (3.8GHz, 8 Cores) / i5-9500TE (3.6GHz, 6 Cores) / i3-
9100TE (3.2GHz, 4 Cores) or 8th Gen. Intel® Core™ i7-8700T (4.0GHz, 6 Cores) / i5-8500T (3.5GHz, 6
Cores) / i3-8100T (3.1GHz, 4 Cores) or Pentium® G5400T (3.1GHz, Dual Cores)/ Celeron® G4900T
(2.9GHz, Dual Core) Desktop processor (LGA 1151) which promises breakthrough performance and
power efficiency over previous micro-architectures for high performance graphics, dramatic high-
resolution video playback, outstanding system performance and responsiveness, and stronger security.
It is designed with customers in mind to deliver an excellent system performance, higher reliability and
robustness in a compact construction.
Chapter 1: Product Introductions
Key Features
Support 8th/9th Gen Intel® CFL-R S Processor (LGA 1151, 65W/35W TDP)
Intel® Q370 Chipset
Triple Independent Display by 1x DVI-I and 2x DisplayPort
2x Intel® GbE supporting Wake-on-LAN and PXE
2x Full-size mini PCIe (shared by 1x mSATA), and 2x SIM socket
4x 2.5” SATA HDD Bay with RAID 0, 1, 5, 10 support, 1x mSATA (Shared by 1x Mini PCIe)
1x M.2 (M Key, NVMe PCIe x4, 2280), 1x M.2 (E Key, PCIe x2, USB 2.0, 2230)
6x RS-232/422/485 (4x internal)
4x USB 3.2 Gen 2 (10 Gbps), 4x USB 3.2 Gen 1 (5 Gbps, internal)
8x DI + 8x DO with isolation
9 to 48V DC Wide Range Power Input Supporting AT/ATX Mode
Wide Operating Temperature (-25°C to 70°C)
TPM 2.0 Supported
VCO-6122C-2PWR
(GPU Computing System ) VCO-6133E-2PWR
(GPU Computing System )
Premio GPU Computing System is your great solution for Machine Vision, Embedded System, Traffic
Vision, Telemedicine, Intelligent Control, Deep Learning, Artificial Intelligence, Voice Reorganization and
any graphics performance driven Industry 4.0/IIoT applications.

VCO-6100 Series
11
1.2 Hardware Specification
Chapter 1: Product Introductions
System
Processor
Support
8th/9th Gen Intel® CFL-R S Processor (LGA 1151, 65W/35W TDP)
Intel® Core™ i7
-9700E, 8 Cores, 12MB cache, up to 4.4 GHz (24V)
Intel® Core™ i7
-9700TE, 8 Cores, 12MB cache, up to 3.8 GHz
Intel® Core™ i7
-8700T, 6 Cores, 12MB cache, up to 4.0 GHz
Intel® Core™ i5
-9500E, 6 Cores, 9MB Cache, up to 4.2 GHz (24V)
Intel® Core™ i5
-9500TE, 6 Cores, 9MB Cache, up to 3.6 GHz
Intel® Core™ i5
-8500T, 6 Cores, 9MB Cache, up to 3.5 GHz
Intel® Core™ i3
-9100E, 4 Core, 6MB Cache, 3.7 GHz (24V)
Intel® Core™ i3
-9100TE, 4 Core, 6MB Cache, 3.2 GHz
Intel® Core™ i3
-8100T, 4 Cores, 6MB Cache, 3.1 GHz
Intel® Pentium® G5400T, 2 Cores, 4MB Cache, up to 3.1 GHz
Intel® Celeron® G4900T, 2 Cores, 2MB Cache, up to 2.9 GHz
System Chipset
Intel® Q370 Express Chipset
LAN Chipset
GbE1: Intel I219LM (Support Wake
-on-LAN and PXE)
GbE2: Intel I210
-AT (Support Wake-on-LAN and PXE)
Audio
Code
Realtek
ALC888S
System Memory
2x 260
-Pin DDR4 2400/2666MHz SODIMM.
Max. up to 64GB (Un
-buffered and Non-ECC)
BIOS
AMI 256Mbit SPI BIOS
Watchdog
Software Programmable Supports 1~255 sec. System Reset
TPM
TPM 2.0
Display
Graphics
Intel® UHD Graphics 610/630
DVI
1x DVI
-I, support resolution 1920 x 1200
VGA
Yes (by optional split cable)
Display
Port
2x DisplayPort, support resolution 4096 x 2304
Multiple Display
Triple Display
Storage
SSD/HDD
2x Internal 2.5" SATA HDD Bay (support H=9mm)
2x
Removable 2.5" SATA HDD Bay
(support H=7mm, hot
-swappable) Support RAID 0, 1, 5, 10
mSATA
1x mSATA (Shared by 1x Mini PCI Express)
M.2
1x M.2 (M Key,
NVMe PCIe x4, 2280)
1x M.2 (E Key,
PCIe x2, USB 2.0, 2230)
SIM
Socket
2x External SIM socket
Expansion
Mini PCI Express
2x Full
-size Mini PCIe (1x shared by 1x mSATA)
Model:
VCO-6122
VCO
-6122E : 2x PCIe x16 (8-Lane)
VCO
-6122P : 2x PCl
VCO
-6122C : 1x PCle x16, 1x PCI
Model:
VCO-6133
VCO
-6133E : 1x PCIe x16, 2x PCIe x4 (1-Lane)
VCO
-6133P : 3x PCl
VCO
-6133C : 1x PCle x16, 2x PCI
Model:
VCO-6144
VCO
-6144P : 4x PCl
VCO
-6144C : 2x PCIe x4, 1x PCIe x16 (8-Lane), 1x PCI
Model:
VCO-6155
VCO
-6155C : 2x PCIe x4, 1x PCIe x16 (8-Lane), 2x PCl

VCO-6100 Series
12
Chapter 1: Product Introductions
I/O
COM
2x RS
-232/422/485, 4x RS-232/422/485 (internal)
USB
4x USB 3.2 Gen 2 (10
Gbps), 4x USB 3.2 Gen 1 (5 Gbps, internal))
LAN
2x RJ45
DIO
8 in / 8 out (Isolated)
Universal I/O Bracket
2x
Universal I/O Bracket (By mini PCIe interface)
Others
4x
WiFi Antenna Holes, 1x Power Switch, 1x Remote Power On/Off
Operating
System
Windows
Windows 10
Linux
Linux
kernel 5.X
Power
Power Mode
AT, ATX
Power
Supply Voltage
9~48 VDC
Power Ignition Sensing
Power Ignition Management
Power Connector
3-
pin Terminal Block,
4-
pin Terminal Block (for GPU Series)
Power Adaptor
Optional AC/DC 24V/9.2A, 220W, Optional AC/DC 24V/11.67A, 280W
Power Protection
OVP (Over Voltage Protection
); OCP (Over Current Protection), Reserve Protection
Environment
Operating Temp.
-25
°C to 70°C (35W CPU) ; -25°C to 60°C (65W CPU)
Storage Temp.
-30
°C to 85°C
Relative Humidity
10% to 95% (non
-condensing)
Vibration
With SSD: 3
Grms, 5 - 500 Hz, 0.5 hr/axis, With HDD: 1 Grms, 5 - 500 Hz, 0.5 hr/axis
Shock
With SSD:
20G, half sine, 11ms
Standards / Certification
CE, FCC Class A
Physical
Construction
Extruded Aluminum
with, Heavy Duty Metal
Dimension
VCO
-6122: 137 (W) x 340 (D) x 240 (H) mm
VCO
-6133: 157 (W) x 340 (D) x 240 (H) mm
VCO
-6144: 177 (W) x 340 (D) x 240 (H) mm
VCO
-6155: 197 (W) x 340 (D) x 240 (H) mm
VCO
-6122C-2PWR: 137 (W) x 340 (D) x 240 (H) mm
VCO
-6133E-2PWR: 157 (W) x 340 (D) x 240 (H) mm
Model:
VCO-6122C-2PWR
1x
PCIe x16, 1x PCl
Model:
VCO-6133E-2PWR
1x PCIe x16
, 2x PCIe x4 (1-Lane)
Card Dimension
310 (L) x 112 (H) mm

VCO-6100 Series
13
Chapter 1: Product Introductions
Weight
VCO
-6122: 4.21 kg
VCO
-6133: 4.26 kg
VCO
-6144: 4.31 kg
VCO
-6155: 4.36 kg
VCO
-6122C-2PWR: 7.83 kg
VCO
-6133E-2PWR: 8.34 kg
Mounting
Wall Mounting / Book mounting (Optional)

VCO-6100 Series
14
1.3 System I/O
1.3.1 VCO-6122
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
DC IN
Used to plug a DC power input with terminal
Block
Digital I/O Terminal Block
The Digital I/O terminal block supports 8 digital
input and 8 digital output
HDD port
Removable 2.5" SATA HDD Area
COM port
COM1 & COM2
support RS232/422/485 serial device
DVI-I port
Used to connect a DVI monitor or connect
optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
LAN Port
Used to connect the system to a local area
network
USB 3.2 Gen 2 port (10 Gbps)
Used to connect USB 3.2 device
Antenna hole
Used to connect an antenna for optional
Mini-PCIe WiFi module
USB 3.2 Gen 2
Remote Power On/Off
Antenna Hole
LAN 1
LAN 2
DisplayPort
DVI-I
COM 1, COM 2
Removable HDD
Digital I/O
DC IN
Power
Antenna Hole
VCO-6122E
•PCIe x16 (8 lane)
•PCIe x16 (8 lane)
VCO-6122P
•PCI
•PCI
VCO-6122C
•PCI
•PCIe x16

VCO-6100 Series
13
Chapter 1: Product Introductions
Top ViewRear Panel
Rear Panel & Top View
ATX power on/off switch
2x Universal I/O Bracket (By mini PCIe interface)
Universal I/O Bracket
1.3.1 VCO-6122

VCO-6100 Series
16
1.3 System I/O
1.3.2 VCO-6133
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
DC IN
Used to plug a DC power input with terminal
Block
Digital I/O Terminal Block
The Digital I/O terminal block supports 8 digital
input and 8 digital output
HDD port
Removable 2.5" SATA HDD Area
COM port
COM1 & COM2
support RS232/422/485 serial device
DVI-I port
Used to connect a DVI monitor or connect
optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
LAN Port
Used to connect the system to a local area
network
USB 3.2 Gen 2 port (10 Gbps)
Used to connect USB 3.2 device
Antenna hole
Used to connect an antenna for optional
Mini-PCIe WiFi module
USB 3.2 Gen 2
Remote Power On/Off
Antenna Hole
LAN 1
LAN 2
DisplayPort
DVI-I
COM 1, COM 2
Removable HDD
Digital I/O
DC IN
Power
Antenna Hole
VCO-6133E
•PCIe x4 (1 lane)
•PCIe x4 (1 lane)
•PCIe x16
VCO-6133P
•PCI
•PCI
•PCI
VCO-6133C
•PCI
•PCI
•PCIe x16

VCO-6100 Series
13
Chapter 1: Product Introductions
Top ViewRear Panel
Rear Panel & Top View
ATX power on/off switch
2x Universal I/O Bracket (By mini PCIe interface)
Universal I/O Bracket
1.3.2 VCO-6133

VCO-6100 Series
18
1.3 System I/O
1.3.3 VCO-6144
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
DC IN
Used to plug a DC power input with terminal
Block
Digital I/O Terminal Block
The Digital I/O terminal block supports 8 digital
input and 8 digital output
HDD port
Removable 2.5" SATA HDD Area
COM port
COM1 & COM2
support RS232/422/485 serial device
DVI-I port
Used to connect a DVI monitor or connect
optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
LAN Port
Used to connect the system to a local area
network
USB 3.2 Gen 2 port (10 Gbps)
Used to connect USB 3.2 device
Antenna hole
Used to connect an antenna for optional
Mini-PCIe WiFi module
USB 3.2 Gen 2
Remote Power On/Off
Antenna Hole
LAN 1
LAN 2
DisplayPort
DVI-I
COM 1, COM 2
Removable HDD
Digital I/O
DC IN
Power
Antenna Hole
VCO-6144P
•PCI
•PCI
•PCI
•PCI
VCO-6144C
•PCI
•PCIe x4
•PCIe x4
•PCIe x16 (8 lane)

VCO-6100 Series
13
Chapter 1: Product Introductions
Top ViewRear Panel
Rear Panel & Top View
ATX power on/off switch
2x Universal I/O Bracket (By mini PCIe interface)
Universal I/O Bracket
1.3.3 VCO-6144

VCO-6100 Series
20
1.3 System I/O
1.3.4 VCO-6155
Chapter 1: Product Introductions
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
DC IN
Used to plug a DC power input with terminal
Block
Digital I/O Terminal Block
The Digital I/O terminal block supports 8 digital
input and 8 digital output
HDD port
Removable 2.5" SATA HDD Area
COM port
COM1 & COM2
support RS232/422/485 serial device
DVI-I port
Used to connect a DVI monitor or connect
optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
LAN Port
Used to connect the system to a local area
network
USB 3.2 Gen 2 port (10 Gbps)
Used to connect USB 3.2 device
Antenna hole
Used to connect an antenna for optional
Mini-PCIe WiFi module
USB 3.2 Gen 2
Remote Power On/Off
Antenna Hole
LAN 1
LAN 2
DisplayPort
DVI-I
COM 1, COM 2
Removable HDD
Digital I/O
DC IN
Power
Antenna Hole
VCO-6155C
•PCI
•PCI
•PCIe x4
•PCIe x4
•PCIe x16 (8 lane)
