Prestige APS57Z User manual

1
2
3
4
1
2
3
4
5
6
1
2
3
4
14
Green/Orange Tach Input
13 Black/Yellow Pulse During Crank Output (-)
12 Green/Yellow Glow Plug Input (+)
11 Black/Red Pulse After Shutdown Output (-)
10 Dk. Blue Trunk Output (-)
9 Black/Blue Factory Disarm Output (-)
8 Brown/Black Brake Input (+)
7 Black/Lt. GreenFactory Arm Output (-)
6 Dk. Blue/Black External Activation Input (-)
5 Lt. Blue Remote Start Status Output (-)
4 GreenUnlock Output (-)
3 Gray/Black Hood Input (-)
2 Red Lock Output (-)
1 Black/White Horn Output (-)
14 Pin Main Input/Output
4 Red
Battery 12V (+)
3 Blue Data TX
2Black Ground (-)
1White Data RX
DBI
4 Red
Battery 12V (+)
3 Black Ground (-)
2White Data RX
1Blue Data TX
CarLink
6 Empty
Empty
5 Blue LED (-)
4 Red Valet Switch
3 Black Ground (-)
2 GreenData RX
1 Pink Battery 12V (+)
Antenna
1 Yellow
Starter Output (+)
2 GreenIgnition 2 Output (+)
3 Red Battery 12VInput (+)
4 Red/White Battery 12VInput (+)
5 Purple Accessory Output (+)
6 Blue Ignition Input / Output (+)
6 Pin RS Harness
P
P
1 White
Parking Light (30) Output
2 White/Red Parking Light (87)Input
3 Yellow/Black Ignition Output For Alarm (+)
4 Black Ground Input (-)
4 Pin Light
P
Replacement Part #4120463
Replacement Part #4120467
Replacement Part #4120465
Replacement Part #4120476
Replacement Part #4360847
Not Included
Not Included
VOXX
1 2
3
5
7
9
11
13
4
6
8
10
12
14
1 3
2 4
1 3 5
246
Replacement Part #183BP
Replacement Part #4180070
APS57Z
Remote Start
System Layout
2018 Voxx Electronics. All Rights Reserved.

APS57Z
Remote Start w/Keyless
Quick Installation Guide
For Complete Installation Guide and Technical Support Visit
www.voxxuniversity.com
Or Call
1-800-225-6074
Notications
1Runtime Expired
2 Remote Shutdown
3 Brake On
4 Manual Mode
5 Hood Open
6Low / No Tach
7 Tach Programming
8High Tach
1 Chirp 2 Chirp
3 Chirp 4 Chirp 5 Chirp 6 Chirp
1
Lock / Unlock Function500ms3.5sec 500ms L, DBL UL DBL L, 500ms UL DBL L, DBL UL 500ms L, 350ms UL
2Accessory Lock NA
3Accessory Unlock NA
4ExteriorIlluminationNA
5Auto Relock NA
6Auto ArmingNA
7Notification SoundNA
8Horn Timing 16ms30ms
40ms 50ms 10ms
9Valet Override MethodNA
10 Driver Priority Unlock NA
11 Silent Choice OFFFrom Transmitter
OEM Style
12 Park Light / Trunk Swap NA
13 AUX Ch. 4NA
14 AUX Ch. 5NA
15 AUX Ch. 6NA
16 AUX Ch. 7NA
17 Security ProfileOFFOEM Security
18 Data Port Protocol ADSDBI
1 Chirp 2 Chirp
3 Chirp 4 chirp 5 Chirp 6 Chirp
1 Defrost OutputNA
2 RS Start Notification ON OFF
3 RS Runtime 5min 10min
15min 20min 45min 60min
4 RS Parking Lights Steady Flashing
5 Engine Confirmation TachVoltage
Data Hybrid
6 Voltage Level >0.5v B4 Start <0.5v B4 Start
7 Ignition 2 OutputIgnition Accessory
Start
8 Ignition 3 OutputN/A
9 Accessory OutputAccessory Ignition
Start
10
Transmission NA
11 Max Crank Time 0.8sec1.0sec
1.5sec 2.0sec 3.0sec 4.0sec
12 Diesel Delay OFF Diesel 10
Diesel 15 Diesel 20 Diesel 30
13 Temperature Start NA
14 Crank Duration Averaging Preset
15 RS Shock Override NA
16 Turbo Timer NA
17 Start Activation Two PressOne Press
Three Press
18 RS Lock Function No ChangeUL Before L After
UL Before Start Lock After Start
19 Factory Disarm OutputSingle Pulse 350ms
500ms 800ms Same As Bank 2, F1
20 Pulse During CrankDuring Crank GWR
Ignition Accessory
21 Factory Arm OutputAfter Start GWR
Ignition Accessory Start
22 Pulse After Shutdown After Shutdown GWR
Ignition Accessory Start
23 Additional Unlock Pulse No Pulse IGN, ACC, GWR
IGN,ACC,GWR,PASD
Features
Feature Bank 2
Options
Features
Feature Bank 3
Options
Feature Programming
Remote Programming
Tach Programming
2018 Voxx Electronics. All Rights Reserved.
Chirp Delete
System ARM/DISARM chirps can be toggled ON or OFF without
entering the Feature Bank programming.
1. Turn the ignition key ON/OFF.
2. Press and release the valet button 3x.
The system will respond with one (1) chirp for ON and two
(2) Chirps for OFF. This feature will not affect alarm trigger or
programming.
User Programmable LED
System LED notications can be turned ON or OFF without
entering Feature Bank programming.
1. Turn the ignition key ON/OFF, ON/OFF.
2. Press and hold valet button for ve (5) seconds.
The LED will ash 1x for ON, 2x for OFF. This feature will not
affect LED ash during programming.
Remote Start
If the remote start fails to start the vehicle, the system will ash
the vehicle parking lights to indicate the cause.
The installer must manually congure the Engine Conrmation
method in Feature Bank 3, Feature 5. The default method is
“Tach”. This method requires using the Green/Orange tach input
wire. When using the default “Tach” method, the vehicle tach rate
must be programmed. To enter tach rate programming:
1. Turn the ignition key ON.
2. Press and release the valet button 3x.
3. Turn the ignition key OFF.
4. Press and hold valet button.
5. While holding valet button, start the engine using the key.
6. Hold the valet button for approximately ten (10) seconds. If
connected to the vehicle Tach source, the system will ash the
parking lights 1x every second.
7. Release the valet button. The system will turn on the
parking lights for two (2) seconds to indicate the tach rate is
programmed.
The APS57Z includes two (2) programmed remotes. If required,
additional remotes can be programmed to the system. Remote
Programming is located in Feature Bank 1. To enter Remote Auto
Programming:
1. Turn the ignition key to ON.
2. Press and release the valet button 3x. System will beep and
ash the parking lights 1x.
Press the lock button on each remote. The system will beep 1x to
indicate the remote has been programmed. If programming one (1)
button remotes, press the Start button.
The APS57Z Feature Banks can be programmed by using the
valet button and remote. To enter Feature Bank programming:
1. Turn the ignition key to ON.
2. Press and release the valet button 3x. System will beep and
ash lights 1x for Feature Bank 1, Remote Programming.
3. Cycle ignition key OFF/ON. System will beep and ash lights
2x for Feature Bank 2.
4. Press valet button to cycle features. LED will ash to display
feature number.
5. Press lock button to cycle options. System will beep to indicate
option number.
6. Cycle ignition key OFF/ON. System will beep and ash lights
3x for Feature Bank 3.
7. Press valet button to cycle features. LED will ash to display
feature number.
8. Press lock to cycle options. System will beep to indicate option
Number.
To exit Programming cycle ignition key OFF and wait ten (10)
seconds. The System will also automatically exit programming
after sixty (60) seconds of no activity.
The Feature Banks below can also be programmed using the FlashLogic Weblink.
Please visit www.FlashLogic.com for more detail.
OEM Security Important Update
The default Data Port Protocol of this system is ADS. If
using an FLCAN or other external integration module
be sure to choose iDatalink 2-Way when ashing.
This system will also support DBI. This will require
programming Feature Bank 2, Feature 18 to DBI.
This system can provide OEM level security. The system will
monitor and trigger by the analog hood input and all entry zone
inputs from the FLCAN or other integration modules. When an
entry zone is detected the system will beep the vehicle horn and
ash the parking lights. This feature must be activated in Feature
Bank 2, Feature 17.
Operation
To arm the system, press lock button.
To disarm the system, press unlock button.
Valet Override Procedure
To disarm the system without the use of a remote, turn the ignition
key to ON and press the valet button 1x.
