Prestige Platinum+ APS-875 User manual

Model APS-875
Owner’s Manual
IMPORTANT ! In order to provide you with the highest level of security to your
vehicle, this system is equipped with selectable manual override circuitry. It is
possible that you will need to override you security system if the transmitter
becomes lost, or inoperative due to battery failure. Reading the sections on
"Manually Overriding Your System" is necessary to fully understand the procedure
required to enable your vehicle in such situations. In addition, the chart on the last
page of this manual has a section for the particular features and options installed in
your vehicle as well as the override method selected. Although the default mode is
"Valet Switch" operation, the system can be configured for "Custom Code"
operation for enhanced security. Confirm the override mode selected on the last
page of this manual, and familiarize yourself with the section on it's operation.
FEATURES :
w2 Four Button S.A.W. Anti-Code Grabbing Transmitters
wSix Channel Code Learning Programmable Receiver
wExternal Superheterodyne Receiver Antenna
wSingle Or Two User Programmable W/Separate Control Outputs
wSingle Button Lock/Unlock or Separate Button Lock/Unlock or Both
wRemoteKeylessEntryWithOptionalAccessGuard(musthavepowerdoorlocks)
wSelectable Manual Override Mode
wNew Enhanced Panic Feature (Any button other than unlock stops siren, no
change to the units state)
wSmart Disarm (If triggered, elect to shut off siren, or disarm entire unit )
wSelectable Automatic Timed Start Mode
wAdjustable Shock Sensor Via The Transmitter (Pre-Detect Off, Pre & Full Detect
Off, City Mode)
wSafe Start Output Controlled From Channel 3 (Option Channel 3 For Trunk, Or
For R/S)
wRemote Panic In All Modes (Press & Hold Lock /Unlock Button For 3 Seconds
To Engage)
wImproved Custom Code Override, User Selectable and Programmable
wProtected Push Button Valet/Override Switch
w7-Function LED-Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming
4 Button Remote Start Security System With
Plug-In Shock Sensor & Starter Disable

Page 2
wIntrusion Alert With Memory
wInstant Siren Activation
wStarter Disable Output
wAdditional Engine Immobilizer Output, (Optional Relay Required)
wTrue Last Door Arming (Hardwire Only)
wDefective Zone By-Pass
wDefective Zone Chirp Confirmation (Unit Chirps To Report Zone Cleared)
w6 Tone Mini Siren (New AS-9903)
wCar Horn Output For Additional Alarm Response (Improved Timing To Minimize
RF Interference.)
wAdditional Negative Trigger Input (Hood & Trunk)
wRF Inhibit With Ignition On
wParking Light Flasher (Relay On Board)
wPlug In Dual Stage Shock Sensor (Pre-detect, Full Trigger, and “City Mode”)
wAudible Arm, Disarm, Defect, And Tamper Chirp Indications
wHeadlight Control Output
wIlluminated Entry Control Output
wActive or Passive Arming Selectable
wProgrammable Auto Lock On / Off
wProgrammable Auto Unlock On / Off/Drivers Door/All Doors
wProgrammable Door Lock Pulse Duration 1 Second / 3.5 Seconds/1 Sec
L/ Dbl. U/L
wProgrammable Active or Passive Door Locks
wUser Programmable Permanent Chirp Delete
wOn Command RF Chirp Delete from Transmitter Or Selectable Through
Software
OPTIONS :
wRemote Trunk Release (must have electronic trunk release)
wRemote Keyless Entry (must have power door locks)
wMultiple Vehicle Capable
wRemote Starter
wRemote Power Window Roll Up
wRemote Garage Door Interface
CAUTION! Be certain that the vehicle is outdoors before using this or any remote
vehicle starting device. A running engine produces dangerous carbon
monoxide fumes which can be harmful or fatal if prolonged exposure
occurs. DO NOT remote start the vehicle if it is garaged.

Page 3
YOUR “ANTI CODE GRABBING“ TRANSMITTERS
The transmitters included with your new security system use the most advanced
and secure form of radio frequency transmission available on any current automo-
tive security system. Some of today’s sophisticated auto thieves use a device
known as a code grabber, which will receive and store the signal from your key-
chain transmitter, and re transmit at a later time to disarm your system.
Your Keeloq Code Hopping transmitters will change their signal every time the
button is pressed, so when a thief grabs then re-transmits your signal, the alarm
system
will not respond.
If your transmitter button is pressed more than fifty times while it is out of range of
the vehicle (children playing with your keys), the transmitter will not operate when
you return to the vehicle, and will need to be re aligned to the receiver. To do this,
simply press button 1 two times within a one second time period. The system will
now respond to that transmitter each time a button is pressed.
NOTE: This system is custom configurable and can be set up to operate with a
number of options controlled from any transmitter button or button combi-
nation. For reference, we will describe operation assuming that your sys-
tem is programmed for separate lock and unlock buttons. Also reference
will be made to the icons as shown on the buttons below.
Consult your installation center if your system has been configured differently.
NOTE:Your system has the option of using a siren, the vehicle horn, or both for
the sounding device. Where the siren is referenced below, the horn or
both may in fact chirp, or beep.
ARMING THE SYSTEM - ACTIVE
1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid.
2. Press and release button Lock/Arm button on the keychain transmitter.
þThe dash mounted LED begins to flash slowly.
þParking Lights flash one time.
þSiren sounds one chirp.
If the siren sounds 3 chirps, then you have left a door, trunk, or
hood lid ajar. Simply close the opened entry point to provide full
protection.Ifthe siren didnotsound when arming,thenthe chirps
have been turned off, and you should refer to the section titled
“ELIMINATING THE ARM / DISARM CHIRPS“ in this manual.
oDoors Lock - Optional
Note: If the optional Headlamp illumination feature has been added, and has been
selected for operation when arming, as an added convenience, the system
will turn on the headlights when the system is armed.
SILENT ARMING - ACTIVE (Must be activated during programming)
1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid.

Page 4
2. Press and hold button the Lock/Arm button on the keychain transmitter
for 2 seconds.
þThe dash mounted LED begins to flash slowly.
þParking Lights flash one time.
þSiren will not sound.
If the siren sounds 3 chirps, then you have left a door, trunk, or
hood lid ajar. Simply close the opened entry point to provide full
protection
oDoors Lock - Optional
Note: Ifthe optionalHeadlamp illumination feature has beenadded, andhas been
selected for operation when arming, as an added convenience, the system
will turn on the headlights when the system is armed.
ARMING THE SYSTEM - PASSIVE (AUTOMATIC)
1. Turn off the engine, exit the vehicle, and close and lock all doors, hood lid, and
trunk lid.
þThe dash mounted LED begins to flash rapidly, indicating 30 second
passive arming has begun.
2. Opening any protected entry point during the 30 second passive arming cycle
will immediately suspend automatic arming, and the 30 second passive arming
cycle will re-start when all doors are closed. At the end of the passive arming
cycle;þThe dash mounted LED begins to flash slowly.
þParking Lights flash one time.
þSiren sounds one chirp
If the siren did not sound when arming, then the chirps have
been turned off, and you should refer to the section titled
“ELIMINATING THE ARM / DISARM CHIRPS“ in this manual.
oDoors Lock - Optional
Door locking during passive arming is a selectable feature. The
alarm can be programmed to allow the doors to lock only when
arming using the keychain transmitter, and they will not
automatically lock during passive arming.
PROTECTION WHILE THE SYSTEM IS ARMED
þOpening any protected door, hood, or trunk lid will cause the alarm to
immediately sound. The alarm will continue to sound for 30 seconds, then
stop and continue to monitor all protected entry points. If the thief left a door
opened, the alarm will sound for six 30 second cycles, remain armed and
ignore that triggered zone.
þWhenever the system is armed, the red dash mounted LED indicator will
slowly flash. This serves as a visual deterrent to the potential thief. The
LED is a very low current bulb, and will not cause the vehicle’s battery to

Page 5
drain, even when left unattended for extended periods.
þWhenever the system is triggered, the vehicle’s parking lights will flash for
the full 30 second alarm cycle, attracting visual attention to the vehicle.
þOptional - Whenever the system is armed, the vehicle’s starting circuit will
be bypassed. If the thief should choose to ignore the siren, the vehicle can
not be started.
þAny mild impact to the vehicle’s glass will cause the alarm to sound a short
series of warning tones.
þAny strong impact to the vehicle’s glass will cause the alarm to trigger for the
full 30 second alarm cycle.
Note: If the optional interior illumination circuit was installed, the interior light will
flash as well for the full 30 second alarm cycle.
DISARMING THE SYSTEM
Note: If the optional 2 step door unlock circuit is installed, when the unlock
transmitter button is activated, the drivers door only will unlock, pressing the
unlock button a second time will cause all doors to unlock.
Note: If your transmitter has been configured with single button Lock/Unlock as
shown, to activate the all door unlock feature operate the Lock/Unlock
button a second time within 3 seconds of the first unlock command.
1. As you approach the vehicle, press and release the Unlock/Disarm button on the
keychain transmitter.
þThe dash mounted LED turns off.
The LED will start flashing rapidly, indicating that the system is
re-arming automatically. Open any door to suspend the automatic
arming.
þParking Lights flash two times.
If the parking lights flashed three times, then the alarm was
triggered in your absence. Before turning the key on, examine
the LED to identify which zone was triggered.
þSiren sounds two chirps.
If the siren sounds 4 chirps, then the alarm was triggered in your
absence. Before turning the key on, examine the LED and refer
to the INTRUSION WARNING SIGNALS section of this manual
to identify which zone was triggered.
If the siren did not sound when disarming, then the chirps have
been turned off, and you should refer to the section titled
“ELIMINATING THE ARM / DISARM CHIRPS“ in this manual.
oDoors Unlock - Optional
o2 Step Doors Unlock - Optional
Note: If the optional Headlamp illumination feature has been added, and has been
selected for operation when disarming, as an added convenience, the
system will turn on the headlights when the system is disarmed.

Page 6
SILENT DISARMING (Must be activated during programming)
Note: If the optional 2 step door unlock circuit is installed, when the unlock
transmitter button is activated, the drivers door only will unlock, pressing
the unlock button a second time will cause all doors to unlock.
Note: If your transmitter has been configured with single button Lock/Unlock as
shown, to activate the all door unlock feature operate the Lock/Unlock button
a second time within 3 seconds of the first unlock command.
1. Press and hold button the Unlock/Disarm button on the keychain transmitter for
2 seconds.
þRed dash mounted LED turns off.
The LED will start flashing rapidly, indicating that the system is
re-arming automatically. Open any door to suspend the
automatic arming.
þParking Lights flash two times.
If the parking lights flashed three times, then the alarm was
triggered in your absence. Before turning the key on, examine
the LED to identify which zone was triggered.
þSiren will not sound.
If the siren sounds 4 chirps, then the alarm was triggered in
your absence. Before turning the key on, examine the LED and
refer to the INTRUSION WARNING SIGNALS section of this
manual to identify which zone was triggered.
oDoors Unlock - Optional
o2 Step Doors Unlock - Optional
Note: If the optional Headlamp illumination feature has been added, and has been
selected for operation when disarming, as an added convenience, the
system will turn on the headlights when the system is disarmed.
WHILE THE SYSTEM IS SOUNDING
If during a triggered state, you wish to shut off the siren without disarming your
security system, simply press and release any transmitter button other than the
Unlock/Disarm button. This action will turn off the siren yet leave the vehicle fully
armed and protected. This feature is particularly useful if you are aware of children
playing near your vehicle that may accidently trigger your security system. In this
case you can cancel the siren sounding without disarming your alarm.
INTRUSION WARNING SIGNALS
This system will inform you if an intrusion attempt has occurred while you were
away from the vehicle. If an intrusion attempt has occurred, the siren will
chirp 4 times and the parking lights will flash 3 times when disarming the system.
Enter the vehicle and observe the red dash mounted LED to identify which
zone was triggered.
If the LED is flashing one time...pause...one time...pause...etc., then an
intrusion attempt was made to the shock sensor, or an accessory triggering

Page 7
device that may have been added to the system.
If the LED is flashing two times...pause...two times...pause...etc., then
an intrusion attempt was made to a hood or trunk pin switch that was
added to the system, or to a light activated entry point if the alarm was
installed using the voltage sensing feature.
If the LED is flashing three times...pause...three times...pause...etc.,
then an intrusion attempt was made through one of the vehicle’s doors.
These intrusion warning indicators are stored in the system’s memory, and will
only be erased when the ignition key is turned on.
VALET SWITCH
The valet switch allows you to temporarily bypass all alarm functions, eliminating
theneed to handyour transmitterto parking attendantsor garage mechanics.When
the system is in valet mode, all alarm functions are bypassed, however the remote
panic feature and remote door locks will remain operational. In addition, the park-
ing lights will flash to indicate locking and unlocking. To use the valet mode, the
system must first be disarmed either by using your keychain transmitter, or by
activating your personalized manual override code.
1. Enter the vehicle, and turn the ignition key to the on position.
2. Press and hold the valet pushbutton switch until the dash mounted
LED turns on solid. The system will remain in the valet mode.
3. To return to normal operation, press and release the pushbutton switch
any time the ignition is on.
NOTE: Always remember to return the system to normal operation. This will
ensure that the vehicle remains protected at all times.
MANUALLY OVERRIDING YOUR SYSTEM:
USING THE VALET SWITCH MANUAL OVERRIDE
Your Security System can be disarmed without the use of the keychain transmitter.
This is necessary, since you will need the ability to operate your vehicle if the
transmitter is lost or its battery fails. If your system has been selected for Valet
Switch manual override as indicated on the last page of this manual, to bypass
the alarm system;
1. Open the vehicle door. The alarm will sound.
2. Turn the ignition key to the on position.
3. Within 5 seconds, press and release the valet pushbutton switch.
The alarm system will stop sounding and enter the (bypass) mode. You can now
start and operate the vehicle normally.
Typically this override mode is used only if the transmitter has become inopera-
tive.
Programming Your Custom Override Code:
Unlike override switches easily found, and defeated, this security system allows

the consumer to program a personal override code, offering a higher level of
security. To take advantage of this option, programmable feature # 10 must be
selected for the Custom Code Option. Consult your installation center for
programmingdetails. The system comes from the factory with a pre-programmed
override code of 11. To change this default override code, do the following:
1. Disarm the system by use of the transmitter, or by use of the emergency
override sequence. Turn the ignition switch to the on position.
2. Within 10 seconds, press and release the valet/override switch, 3 times.
3. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(The siren or horn will beep and the lights will flash one time.)
4. Within 10 seconds, begin to enter your chosen 10ths digit by pressing and
releasing the pushbutton switch from 1up to 9 times.
5. Within 10 seconds of the last entered 10ths digit, turn the ignition switch off
then on.
6. Within 10 seconds, begin to enter your chosen units digit by pressing and
releasing the pushbutton switch from 1 up to 9 times.
7. Finish by turning the ignition switch to the off position.
If the new code was accepted, the unit will report back the newly entered code, by
flashing the LED, first indicating the 10ths digit, pause and then the units digit. The
unit will report the new code three times with a one second pause between each
code, then the system will begin arming. If the LED flash pattern
reportsthe previouslystored code,the newcode wasnot enteredcorrectly. Please
repeat steps 1 through 7 above considering the following.
NOTE: Acceptable digits 10ths or units are 1 through 9. The unit will not
recognize a 0 (Zero), or no digit entered in any place, units or tenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for
more then 5 seconds during any of the above steps, the unit will revert
back to the last successfully stored code.
Custom Code Programming Example:
To Change the code from the factory pre-assigned code of 11 to “52” you would do
the following:
1. Disarm the system by use of the transmitter, or by use of the emergency
override sequence.
2. Turn the ignition switch to the on position.
3. Within 10 seconds, press and release the valet/override switch, 3 times.
4. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(The siren or horn will beep and the lights will flash one time.)
5. Within 10 seconds, begin to press and release the pushbutton switch to set
the tenths digit.
(As per the example, press and release 5 times to set the tenths digit to 5)
6. Within 10 seconds of the last press of the pushbutton, turn the ignition switch
off then on.
Page 8

7. Within 10 seconds, begin to press and release the pushbutton switch to set
the units digit.
(As per the example, press and release 2 times to set the units digit to 2).
8. Turn the ignition switch to the off position. Immediately observe the LED flash
pattern.
You will note the LED flashing five times, pause, and then flash two times, pause.
This pattern will be repeated three times indicating the new code (52) has been
accepted and stored in memory.
NOTE: If after step 7, the LED flashes a code other than what was just entered,
this indicates that the code has not been changed. You will have to repeat
steps 1 through 7 above being certain to note the following:
Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0
(Zero), or no digit entered in any place, units or tenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for
more then 5 seconds during any of the above steps, the unit will revert
back to the last successfully stored code.
MANUALLY OVERRIDING YOUR SYSTEM:
USING THE CUSTOM CODE OVERRIDE
Assuming the override code programmed has not been changed, and the default
override code of 11 is in the system's memory.
1. Enter the vehicle and turn the ignition switch to the on position.
Note: The siren will sound.
2. Within 5 seconds, press and release the pushbutton switch 1 time.
3. Within 5 seconds, turn the ignition switch off then on.
4. Within 5 seconds, press and release the pushbutton switch 1 time.
5. Turn the ignition switch off then on and start the vehicle.
Note: If you have changed the programmed override code then substitute your
new code tenths for step 2 above, and units for step 5 above.
ELIMINATING THE NORMAL ARM / DISARM CHIRPS
As explained earlier in the manual, you can eliminate the chirps selectively any
time you arm or disarm the system simply by holding the ARM or DISARM button
for two seconds. If you find the normal arming and disarming chirps annoying,
they can be turned off permanently, eliminating the need to hold the ARM / DIS-
ARM button for 2 seconds. To do this,
1. Turn the ignition key on then off.
2. Within 10 seconds, press and release valet switch three times.
3. If the chirps were on before you started, then you will hear two chirps indicat-
ing they have been turned off.
If the chirps were off before you started, then you will hear one chirp indicating
they have been turned on.
Page 9

NOTE: Whenever the chirps are bypassed, the 4-chirp intrusion indicator and 3
chirpdefectivezoneindicator will alwaysoperate.Since these areimportant
warningsto you thatsomething has happened,theycannot beeliminated.
REMOTE PANIC OPERATION
The Lock or Unlock button on your keychain transmitter also functions as a panic
switch for use in emergency situations. To use remote panic,
1. Press and hold the Lock or Unlock button on the keychain transmitter for 3 or
more seconds. The alarm will immediately sound.
2. To stop the alarm, press and hold the Lock or Unlock button on the transmitter
again for 3 seconds. If the button is not pressed, the alarm will automatically
stop after 30 seconds. Also if any transmitter button other than the Lock or
Unlock button is pressed and released, the Panic mode will be turned off
immediately. The normal function of this transmitter button will be suspended
during the Panic sounding period.
3. During the panic mode, the Lock and Unlock buttons can be used to lock and
unlock the doors, (if the option is installed), however once the unlock/disarm
button is pressed, the vehicle's starter inhibit device, (where installed) will be
disabled allowing the vehicle to start.
NOTE: While in the Panic mode, pressing and releasing the Lock or Unlock
buttons will, if the option is installed, lock and unlock the doors respectively. While
in the panic mode, anytime the Unlock button is pressed, the panic feature will
continue for the allotted 30 seconds, however, the security system will be dis-
armed allowing the vehicle to start.
R.F.SHOCKSENSORMODE SELECTION
The way in which your alarm system reacts to threatening vibrations, created by
attempts to enter the vehicle by breaking a window, is adjustable by the transmitter
immediately after arming. There are 4 modes of operation that can be selected
by the operator.
1. Normal Operation (default mode)
In this mode, any strong vibrations will cause the siren to sound (full
detect) for 30 seconds. Any lesser vibration will cause the siren to emit about
6 short warn away chirps, (pre-detect).
2. Stage 1 (Omit pre-detect)
In this mode, the warn away chirps created by the lesser vibration will be
deleted. If strong vibration occurs, the siren will sound.
3. Stage 2 (Omit pre & full detect)
In this mode, both the pre-detect stage, and the full trigger stage of the sensor
are defeated. The unit will not react to vibration of any magnitude.
4. Stage 3 (City Mode)
In this mode, the pre-detect chirps will change from six pre-warning tones to
a full 10 seconds of warning chirps.
Page 10

The full detect trigger duration will be reduced from 30 seconds to 15 seconds.
NOTE: Setting the stage of the shock sensor will be effective for one arming
cycle only. Once the system has been disarmed, the very next arming
cycle will cause the sensor to default to the normal operation stage.
To change or adjust the shock sensor, press and release the ARM button of you
keychain transmitter.
1.Within 2 seconds of arming, press and release the ARM button 1 time, to
defeat the pre-detect stage of the shock sensor. (The lights will flash and the
siren will chirp once.)
2.Within 2 seconds of step 1, press and release the ARM button 2 times, to
defeat the pre and full detect stages of the shock sensor. (The lights will
flash and the siren will chirp twice.)
3.Within 2 seconds of step 1, press and release the ARM button 3 times to
enter the "City Mode" of operation. (The lights will flash and the siren will chirp
three times.)
SAFETY(Red Handled ) CONTROL SWITCH
The control switch allows you to temporarily disable the remote starting function
of your APS-875. To disable the unit, move the red handled control switch to the
off position.
The control switch also allows you to select between 2 hour start up and 4 hour
start up when using the automatic start up timer mode. The factory preset start
up time for this mode is every 4 hours. To select between 2 or 4 hour start-up
timer:
1. Begin with the control switch in the on position
2. Turn the ignition switch on then off
3. Within 10 seconds, move the control switch off, on, off, on (2 switch cycles) to
select a 2 hour start timer. After 10 seconds expire, the parking lights will
flash and the siren will chirp 2 times confirming that the two hour start cycle is
set. Or, within 10 seconds move the control switch off, on, off, on, off, on,
off, on (4 switch cycles) to select a 4 hour start timer. The parking lights will
flash and the siren will chirp 4 times confirming that the 4 hour start timer is
set.
REMOTESTARTINGTHEVEHICLE
The APS-875 WILL NOT start the vehicle if any one of the following conditions
exists:
1. The Vehicle Hood Is Opened.
2. The Gear Selector Is In Any Gear Other Then Park.
3. The Brake Is Depressed.
4. The Safety Control Switch Is In The Off Position.
Page 11

WARNING! Be certain that the vehicle is outdoors before using this or any remote
vehiclestarting device. A running engineproducesdangerouscarbon
monoxide fumes which can be harmful or fatal if prolonged exposure
occurs. DO NOT remote start the vehicle if it is garaged.
To Remote Start The Vehicle:
Press and release the programmed channel of your keychain transmitter two
times within 2 seconds. The vehicle will start and remain running for the pre-
programmed 5, 10, 15, or 20 minutes. As a visual indication, the parking lights
will flash or turn on depending on the programming set up by your installation
center.
When you arrive at your vehicle, disarm the alarm system by pressing and re-
leasing the arm/disarm button of your keychain transmitter. Enter the vehicle and
turn the ignition key to the on position.
CAUTION! Do not turn the key to the start position. This will cause the
starter motor to engage with the already running engine which could result in
damage. Step on the brake pedal to disengage the remote start unit. The vehicle
will continue to run but now on it's own power.
NOTE: The engine will stop running before the expiration of the pre-programmed
run timer if you complete any of the following:
1. Press and release the programmed channel of your keychain transmitter two
times within 2 seconds.
2. Depress the brake pedal.
3. Open the hood.
4. Move the red handled control switch to the off position.
5. Race the engine to above 4000 RPM.
Page 12

OPERATING ON AUTOMATIC START UP TIMER MODE
TheAPS-875has the abilitytoautomaticallystart the vehicleevery2 or 4hoursovera
48hourperiod. This feature is especiallyusefulincold climates wheretheonlymeans
tokeep the engineand engine fluidswarm isto periodically startthe engine.
CAUTION! Be certain that the vehicle is outdoors before using this or any remote
vehicle starting device. A running engine produces dangerous carbon
monoxide fumes which can be harmful or fatal if prolonged exposure
occurs. DO NOT remote start the vehicle if it is garaged.
TOBEGINTHE AUTOMATIC START UPTIMER
1.Turn the ignition key on then off.
2.Within 10 seconds, activate the RF start command two times. (Push the
programmed channel button of your keychain transmitter 4 times).
The parking lights will flash and the siren will chirp 4 times indicating the timed
start mode is activated.
The vehicle, on a 2 or 4 hour interval basis, will automatically start, run for the
pre-programmed time (5,10,15 or 20 minutes), and then shut off. This will
continue for 48 hours.
NOTE: The automatic start up timer can also be initiated from the keychain
transmitter. To do this:
1.Start the vehicle using the keychain transmitter by pressing and releasing the
second channel transmitter button 2 times.
2.Shut off the vehicle using the keychain transmitter by pressing and releasing
the second channel transmitter button 2 times.
3. Within 10 seconds of step 2, activate the RF start command two times. (Push
the second channel button of your keychain transmitter 4 times).
The parking lights will flash and the siren will chirp 4 times indicating the timed
start mode is activated.
CANCELINGTHEAUTOMATICSTART UPTIMER
To cancel the automatic start up timer do one of the following;
1. Start the vehicle manually with the use of the ignition key and depress the brake
pedal.
2. Remote start the vehicle using your keychain RF transmitter.
OPTIONAL DEVICE OUTPUT ( CHANNEL 3 )
Controlled By: oTrunk/Key Button oOption Button oLock + Unlock Buttons o
Lock + Trunk/Key Buttons oLock + Option Buttons oUnlock + Trunk/Key Buttons
oUnlock + Option Buttons oTrunk/Key + Option Buttons
Other Transmitter button configurations are also available. Consult your installation
center for other configurations not listed above that may have been programmed to
operate a specific feature of your system.
Thissecurity system isequipped with anoutput which willactivatewhen theappropri-
Page 13

Page 14
ate transmitter button is depressed for 4 seconds. Optional devices that may be
connectedto this channelare;
oRemoteElectric TrunkRelease
oRemote Car Starter
oRemote Window Closure
oRemoteGarage Door Interface
NOTE:Inadditiontheremaybeasecondoptionalfeatureconnectedtoyoursystemthat
when the same transmitter button is pressed and released 2 times within 3
seconds(doublepressed), the secondoptionalfeature will activate. Thisout-
putis typically usedfora remote startoption and willlikelyprevent inadvertent
activation ofthe remotestart deviceif youngchildren areplaying with the hand
heldtransmitter.
Ifyour vehicle isnot equippedwith an electronictrunk releaseswitch, or otheroption
listed,this feature may have been connected toanother accessory. Please ask your
dealerforfurther information.
ADDITIONAL REMOTE FUNCTION ( CHANNEL 4 )
Controlled By: oTrunk/Key Button oOption Button oLock + Unlock Buttons o
Lock + Trunk/Key Buttons oLock + Option Buttons oUnlock + Trunk/Key Buttons
oUnlock + Option Buttons oTrunk/Key + Option Buttons
Other Transmitter button configurations are also available. Consult your installation
center for other configurations not listed above that may have been programmed to
operate a specific feature of your system.
This security system has an additional feature that can be connected to a number
of different optional accessories. Some of the more common uses for this channel
are;
oRemote Car Starter
oRemote Window Closure
oRemote Garage Door Interface
To remotely operate the device indicated, momentarily press, or press and hold the
appropriate transmitter button(s) as indicated above.
ADDITIONAL REMOTE FUNCTION ( CHANNEL 5 )
Controlled By: oTrunk/Key Button oOption Button oLock + Unlock Buttons o
Lock + Trunk/Key Buttons oLock + Option Buttons oUnlock + Trunk/Key Buttons
oUnlock + Option Buttons oTrunk/Key + Option Buttons
Other Transmitter button configurations are also available. Consult your installation
center for other configurations not listed above that may have been programmed to
operate a specific feature of your system.
This security system has an additional feature that can be connected to a number
of different optional accessories. Some of the more common uses for this chan-
nel are; oRemote Car Starter

Page 15
oRemote Window Closure
oRemote Garage Door Interface
To remotely operate the device indicated, momentarily press, or press and hold
the appropriate transmitter button(s) as indicated above.
ADDITIONAL REMOTE FUNCTION ( CHANNEL 6 )
Channel 6 is an alternate output that can be controlled by the unlock button of the
transmitter, or by and independent button or combination of buttons. For your ve-
hicle this output is
Controlled By: oTrunk/Key Button oOption Button oLock + Unlock Buttons o
Lock + Trunk/Key Buttons oLock + Option Buttons oUnlock + Trunk/Key Buttons
oUnlock + Option Buttons oTrunk/Key + Option Buttons
Other Transmitter button configurations are also available. Consult your installa-
tioncenter for otherconfigurationsnot listed abovethat may havebeenprogrammed
to operate a specific feature of your system.
This security system has an additional feature that can be connected to a number
of different optional accessories. Some of the more common uses for this channel
are; oRemote Car Starter
oRemote Window Closure
oRemote Garage Door Interface
To remotely operate the device indicated, momentarily press, or press and hold the
appropriate transmitter button(s) as indicated above.
ADDITIONAL REMOTE FUNCTION ( CHANNEL 7 )
Channel 7 is an alternate output that can be controlled by the unlock button of the
transmitter, or by and independent button or combination of buttons. For your ve-
hicle this output is
Controlled By: oTrunk/Key Button oOption Button oLock + Unlock Buttons o
Lock + Trunk/Key Buttons oLock + Option Buttons oUnlock + Trunk/Key Buttons
oUnlock + Option Buttons oTrunk/Key + Option Buttons
Other Transmitter button configurations are also available. Consult your installa-
tioncenter for otherconfigurationsnot listed abovethat may havebeenprogrammed
to operate a specific feature of your system.
This security system has an additional feature that can be connected to a number
of different optional accessories. Some of the more common uses for this channel
are; oRemote Car Starter
oRemote Window Closure
oRemote Garage Door Interface
To remotely operate the device indicated, momentarily press, or press and hold the
appropriate transmitter button(s) as indicated above.

APS 875
SYSTEM FUNCTIONS AT A GLANCE
DASH LED INDICATORS
RAPID FLASHING = PASSIVE ARMING/ACTIVE
REARMING
SLOW FLASHING = ARMED
OFF = DISARMED
ON SOLID = VALET MODE
3 FLASH...PAUSE = INTRUSION ZONE 3
2 FLASH...PAUSE = INTRUSION ZONE 2
1 FLASH...PAUSE = INTRUSION ZONE 1
SIREN CHIRP INDICATORS
1 CHIRP * = ARM
2 CHIRPS * = DISARM
3 CHIRPS = ARM / DOOR OPENED
4 CHIRPS = DISARM / INTRUSION
* These chirps are optional, and can be de - activated.
PARKING LAMP INDICATORS
1 FLASH = ARM
2 FLASHES = DISARM
3 FLASHES = DISARM / INTRUSION
Your System Has These Features Activated
oStarter Disable
oRemote Keyless Entry
oAuto Lock with ignition key
oAuto Unlock with ignition key
oPassive Arming
oNo Lock in passive mode
oHardwire doors, hood, and trunk
oCustom Code Override
oValet Switch Override
© 2001 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY 11788 128-5893A
