Prestigio P190T User manual

Prestigio P190T

Eng
2www.prestigio.biz
U.S.A.
U.S.FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
INFORMATION TO THE USER
NOTE : This equipment has been tested and found to comply with the limitsfor a Class B
digital device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harm ful interference to
radio communications.
However, there is no guarantee that interference will not occur in a particular installa-
tion.
If this equipment does cause harmful interference to radio or television re ception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet of a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for assistance. Changes or
modication not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
Connecting of peripherals requires the use of grounded shielded signal cables.

Eng
3www.prestigio.biz
CONTENTS
1. INTRODUCTION.............................................................................................4
2. SAFETY INFORMATION ...............................................................................4
3. INSTALLING THE MONITOR ........................................................................5
3-1. PACKING LIST ............................................................................................5
3-2. SELECTING A SUITABLE LOCATION .......................................................6
3-3. CONNECTING THE MONITOR ..................................................................7
3-4. SETTING THE REFRESH RATE ................................................................8
PRESET TIMING TABLE ...................................................................................8
3-5. USER’S ENVIRONMENT ...........................................................................9
4. ADJUSTING THE PICTURE ........................................................................ 11
4-1. USING THE ON SCREEN DISPLAY ......................................................... 11
4-2. DIRECT ACCESS BUTTONS ...................................................................11
4-3. OSD ADJUSTMENTS ............................................................................... 12
5. DISPLAY POWER MANAGEMENT..............................................................14
REDUCING POWER CONSUMPTION ............................................................ 14
6. TROUBLESHOOTING ................................................................................. 15
7. SPECIFICATIONS.........................................................................................17

Eng
4www.prestigio.biz
1. Introduction
This manual contains instructions for installing and operating Prestigio P190T.
Prestigio P190T is a highly ergonomic color display unit.
• High quality screen re-scaling capability
• 100-240V AC input voltage
• VESA DPMS (Display Power Management Signaling)
• VESA DDC1/2B compatibility
• Advanced digital On-Screen-Display controls
• Fast and accurate auto adjustment
• Most advanced image scaling
• Supporting VESA Flat Panel Monitor Physical Mounting Interface
2. Safety Information
This Monitor has been engineered and manufactured to assure your safety. You can prevent
serious electrical shock and other hazards by keeping in mind the following:
Do not place anything wet on the monitor or the power cord. Never
cover the ventilation openings with any material and never touch them
with metallic or inflammable materials.
Avoid operating the monitor in extreme heat, humidity or areas af-
fected by dust.
• Temperature : 5~35°C • Humidity : 30~80RH
Be sure to turn the monitor off before plugging the power cord into
the socket. Make sure that the power cord and the other cords are
securely and rightly connected.
Overloaded AC outlets and extension cords are dangerous, as are
frayed power cords and broken plugs, which may cause electric shock
or fire. Call your service technician for replacement.
Do not use sharp tools such as a pin or a pencil near the monitor, as
they may scratch the LCD surface.
Do not use a solvent, such as benzene, to clean the monitor, as it will
damage the LCD surface.

Eng
5www.prestigio.biz
Cleaning and Maintenance
• To avoid risk of electric shock, do not disassemble the display unit cabinet. The unit
is not user-serviceable. Remember to unplug the display unit from the power outlet
before cleaning.
• Do not use alcohol (methyl, ethyl or isopropyl) or any strong dissolvent. Do not use
thinner or benzene, abrasive cleaners or compressed air.
• Do not wipe the screen with a cloth or sponge that could scratch the surface.
• To clean your antistatic screen, use water and a special microfiber screen cleaning
tissue used in optical lens cleaning, or lightly dampen a soft, clean cloth with water or
a mild detergent.
• If the instructions above do not help in removing stains, contact an authorized service
agent.
3. Installing the monitor
3-1. Packing List
The following items should be found in the packaging.
Above power cord can be changed upon different voltage areas. Please contact your
dealer if anything is missing or damaged.
Other power cord except the cord packed in the product or longer than 3m may affect
EMC of the product in operating condition.
Signal CableMain Unit Body
Compact Disk
Power Cord
Audio Cable

Eng
6www.prestigio.biz
3-2. Selecting a suitable location
• Place the monitor at least 30cm from other electrical or heat-emitting equipment and
allow at least 10cm on each side for ventilation.
• Place the monitor in a position where no light shines directly onto or is reflected on
the screen.
• To reduce eye strain, avoid installing the display unit against a bright background
such as a window.
• Position the monitor so that the top of the screen is no higher than eye level.
• Position the monitor directly in front of you at a comfortable reading distance (around
45 to 90cm).
Before you start cabling your monitor, check that the power is off on all units.
To avoid any possibility of electric shock, always connect your equipment to properly
earthed outlets.

Eng
7www.prestigio.biz
3-3. Connecting the monitor
1. Insert the 15-pin signal cable connector into the 15-pin VGA connection on your
computer and screw it down.
2. Plug the power cord connection to connection on the monitor.
3. Plug the other end of the power cord to your computer's main supply or to a 100V-
240V earthed electrical outlet.
4. Turn on the monitor using the power switch and check that the power LED is on. If not,
repeat steps 1,2,3 and 4 or refer to the Troubleshooting section of this guide.
5. Turn on the power to the computer. The picture will appear within about 10 seconds.
Adjust the picture to obtain optimum picture quality. See section Adjusting the picture
in this guide for more information.
Audio system
This monitor has an audio system including two micro loudspeakers. Each of two micro
loudspeakers has an 2Wrms (max.) output power. This system also supports a headphone
output jack.
When this monitor is turned on, audio is always set up as off mode.
Please use AUDIO direct access button on the front cover or On Screen Display to put
audio on.
Speaker

Eng
8www.prestigio.biz
3-4. Setting the refresh rate
Follow the instructions below to set your refresh rate in Windows 98/ME/XP/2000.
1. Go to the configuration window (Start-Settings-Configuration window).
2. Double click on the ‘Display’ icon.
3. Click on the ‘Settings’ tab.
4. Click on the ‘Advanced’ button.
5. Click on ‘Adapter’ and select 60Hz from the list.
6. Click on ’Apply’ to accept the selected value.
Preset Timing Table
If the signal from the system isn't equal to the preset timing mode, adjust the mode with
reference to the user guide of videocard because the screen may not be displayed.
The recommended setting is a resolution of 1024x768 and a refresh rate of 60Hz.
Horizontal
Frequency
31.5 KHz
31.5 KHz
37.5 KHz
37.9 KHz
46.9 KHz
48.4 KHz
56.5 KHz
60.0 KHz
63.9 KHz
80.0 KHz
Refresh Rate
70 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
70 Hz
75 Hz
60 Hz
75 Hz
No.
1
2
3
4
5
6
7
8
9
10
Resolution
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
800 x 600
800 x 600
832 x 624
1024 x 768
31.5 KHz
31.5 KHz
37.5 KHz
35.2 KHz
37.9 KHz
48.1 KHz
46.9 KHz
49.7 KHz
48.4 KHz
56.5 KHz
60.0 KHz
67.5 KHz
63.9 KHz *
80.0 KHz
70 Hz
60 Hz
75 Hz
56 Hz
60 Hz
72 Hz
75 Hz
75 Hz
60 Hz
70 Hz
75 Hz
75 Hz
60 Hz *
75 Hz
1
2
3
4
5
6
7
8
9
10
11
12
13
14
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
800 x 600
800 x 600
832 x 624
1024 x 768
1024 x 768
1024 x 768
1152 x 864
1280 x 1024 *
1280 x 1024

Eng
9www.prestigio.biz
3-5. User’s Environment
Recommended Ergonomic User’s Environment
• Viewing angle of the monitor should be between 0~20 degree.
Kensington Security (Locking) Slot
• This display unit supports a Kensington-type security device to secure your monitor.
Kensington lock is not included.
• To purchase and install the Kensington locking device, please refer to the following
contact information.
* Kensington Technology Group
· Address :
2000 Alameda de las Pulgas 2F san mateo,
California 94403-1289
· Tel : [phone]
· Fax : [phone]
· Web-site : www.kensington.com

Eng
10 www.prestigio.biz
Ergotron, Inc.
- Address : Ergotron Europe
Kuiperbergweg 50 1101 AG
Amsterdam The Netherlands
- Tel : [phone]
· Fax : [phone]
· E-mail : [e-mail]
VESA MOUNTING
• This display unit supports VESA FPMPMI standard for 100mmx100mm screw mounting
by giving 4 screw holes inside the base stand of the unit.
• To buy VESA Flat Panel Monitor Mounting Devices, please contact following infor-
mation.
Only M4 x12 size screw should be used for proper mounting.
(Using wrong size screw may cause damages to the device)
Desk Mount
Wall Mount
