Prestigio P199 User manual

1PRESTIGIO P199
ENG
Prestigio P199
User’s Manual

2 PRESTIGIO P199
ENG
Safety Instructions
1.Please read these safety instructions carefully.
2.PleasekeepthisUser‘sManualforlaterreference.
3.Pleasedisconnectthisequipmentfromconnecterbeforecleaning. Don‘tuseliquidorsprayed detergent for cleaning.
Use moisture sheet or cloth for cleaning.
4. Make sure the voltage of the power source when you try to connect the equipment to the power outlet.
5. All cautions and warnings on the equipment should be noted.
6. Never pour any liquid into opening, this could cause fire or electrical shock.
7. Never open the equipment. For safety reason, the equipment should only be opened by qualified service personnel.
8. If one of the following situations arises, get the equipment checked by a service personnel :
a. Liquid has penetrated into the equipment.
b. The equipment has been exposed to moisture.
c. The equipment has not work well or you can not get it work according to user‘s manual.
d. The equipment has dropped and damaged.
e. If the equipment has obvious sign of breakage.
9.DO NOT LEAVETHIS EQUIPMENT IN AN ENVIRONMENT UNCONDITIONED,STORAGETEMPERATURE ABOVE 40?C,IT MAY
DAMAGETHE EQUIPMENT.

3PRESTIGIO P199
ENG
View of Monitor
Front View (1) Front View (2)
Back View (3) Side View (4)

991POIGITSERP4
ENG
Unpacking
Thank you for your purchase.Please first check the following package content of the 19”LCD monitor.Contact your
dealer or store whereyou purchased the LCD monitor if anything is missing.
1. 19” TFT LCD Monitor
2. External Univ15 pin D-sub (RGB Analog) input signal cable *DVI. and Video are optional*
3. Audio Cable with Stereo Phone Jack
4. Power Cord
5. Quick Start Guide
6. CD User’s Manual
7. Quick Stand

5PRESTIGIO P199
ENG
Warning
1. Make sure that the system power is turned off.
2. Plug the signal cable to the signal connector at the rear of PC.
3.Plug adapter output cable to the jack at the rear of LCD monitor and the power cord to the adapter.
4. Connect the power cord to power source.
5.Turn on the computer and the monitor.
6.For the best display quality,we suggest that you set the resolution as shown page Display Mode.
Cleaning Notes
1. Be gentle to clean the screen.
2. Never use any kind of corrosiveness chemical dissolvent to clean the screen, it may hurt your screen surface.
3. We suggest that a camel hair brush or a soft, lint-free cloth be used to clean the screen.
4.Don’t exert any pressure directly to the LCD screen.
Precaution
1. Do not expose the monitor to direct sunlight or heat.
2.Do not spill liquid on the monitor.
3.Do not attempt to open the monitor.You may be hurt by electric shock.For service,call your place of purchase.
4.Do not use your monitor when magnets or electronic products are operating nearby.
5. Do not use harsh chemicals or strong cleaning solvents to clean the monitor screen. Wipe it with clean, soft clothes
applied with mild solution.
6.Do not place anything on your monitor.Bad ventilation may elevate temperature in the monitor.
7.Don’t use your fingers to touch the LCD screen,directly.Fingerprint contains oil and may be difficult to clean.

6 PRESTIGIO P199
ENG
Features
Power Saving:
Thepower management complies withVESA DPMS standard. Whenthesystem is idle (OffMode), the monitor automati-
cally cut its power consumption to a level less than 5w.
Auto Adjustment Key Function:
With“AUTO”key,you can automatically adjust the display for your best view.
Wide Viewing Angle:
The horizontal 160°and vertical 150° offer you great screen view.
Plug and play compatibility:
With DDC1/DDC2B compliance,the monitor is plug and plays compatible to Windows 95/98/me/2000/XP.
Space Saving:
The monitor is designed with 220 mm in-depth to provide you with more hand room for desk working space.
Side-by-Side :
The monitor comes with 26.59 mm trimmed down frame to offer side-by-side operation

7PRESTIGIO P199
ENG
Hardware Installation
BecarefultoyourLCDmonitor.It’svery delicateandeasytobreak.TurnoffLCD’sandPC’spowerbeforeinstallation.Follow
the installation step by step described below.
Input
1. DC-IN: This is for connecting the power cable
2. AUDIO-IN: This can be connected to the audio-out connector of any sound resource.
3. VGA-IN : This can be connected with the D-Sub 15 pin signal cable.
4. DVI-I input: This is the connector for digital video signal inputs (option)

991POIGITSERP8
ENG
Hardware Installation Step by Step
1. Get ready with your Quick-Stand and hold your monitor firmly but gentle with your hands and let the panel
facing you to pedestal the monitor on the Quick-stand. When you hear the “Click” that means you have set up your
monitor in the first place successfully.
2. Turn your monitor upside down carefully with panel facing you to locate all connector port.
3.Plug in signal cable to VGA-IN of the monitor and the other side of the cable to the computer.
Hardware Installation Step by Step

9PRESTIGIO P199
ENG
4.Connect the audio cable to AUDIO-IN on the monitor, and the other side to computer line out.
5. Plug power cord onto the Power jack of the monitor.
6. Congratulations! You have just completed the hardware installation.
How to Remove Quick-Stand of Monitor
Remove Quick-Stand of the monitor by unlocking the six hooks as the illustration shows below when you need
to deliver the monitor for any reason.

991POIGITSERP01
ENG
Monitor Setup Button
Menu control button
There 5 keys for user to set up the monitor,including “Power”,“MENU“,“AUTO”,”<-> Down”,” <+> Up”.Please refer
to the introduction below.
1.“Power”:Turn the LCD power on and off.When the power is on, the light turns green,and standby in the color of
orange.
2.“AUTO”: Exit and save thesetting.Hot key for auto adjustment.
3. “MENU”: Press the button to display OSD main menu and select OSD Option.
4.“Up”:Increasethevaluein theOSD option.HotkeyforPC/Video/S-Video/TV mode.You canuse thebuttontoswitch
between PC,Video,S-Video,andTV modescreen.
5. “ Down”: Decrease the value in the OSD option. Hot key for volume adjustment.

11PRESTIGIO P199
ENG
Troubleshooting
If you encounter any trouble in using the monitor, make sure your monitor is properly installed according to the
following steps before you call for service.
There is no picture on the screen.
Check:
1. Power saving mode. Press any key and move the mouse to deactivate the mode.
2. Signal Cable Connector Pins. If there are bent or missing pins, consult your dealer or store where you purchased the
monitor.
Characters look too dark or too bright
Check:
1.Using OSD Menu to adjust the Contrast.
When shall your monitor be adjusted?
Check:
1. After “ reset”
2. If the resolution of frequency is being changed.
The text on the screen is unclear.
Check
1. Make sure the resolution matches with the display mode.

12PRESTIGIO P199
ENG
OSD (On-Screen Display) Menu (PC Mode)
Option select
1. Press the MENU button to access menu.
2. Using MENU again for advanced adjustment selection.
3. Press Down and Up for choosing different OSD function.
Press MENU as enter to select the function you want.
Main Menu Setting
Contrast
Adjust the contrast ratio of the display.
BRIGHTNESS:
Adjust the difference between light and dark area.

13PRESTIGIO P199
ENG
COLOR ADJUST:
AdjusttheRED,GREEN,and BLUEcolors of the display.Click
“ENTER”to adjust the R.G.B.color separately.
RED:
Adjust the RED color of the display.
BLUE:
Adjust the BLUE color of the display.
COLOR TEMP:
Adjust the color temperature of the display.
BACK :
Return to the Main Menu Screen
COLOCK:
Adjust the re-flash ratio of the vertical scanning area.

14PRESTIGIO P199
ENG
PHASE:
Adjust the re-flash ratio of the horizontal scanning area.
AUTO ADJUST:
Automaticallyadjust the re-flash ratio of both vertical and
horizontal scanning areas of the display.
H. POSITION:
Adjust the horizontal viewing area of the display.
V. POSITION:
Adjust theVertical viewing area of the display.
BACK :
Return to the Main Menu Screen
OSD H. POS:
Adjust the Horizontal position of the OSD.

15PRESTIGIO P199
ENG
OSD V. POS:
Adjust the Vertical position of the OSD.
OSD TIME:
Adjust the displaying time of the OSD.
OSD COLOR:
Change the displaying color of the OSD.
OSD ALPHA:
Adjust the Alpha volume of the OSD displaying.
BACK:
Return to the Main Menu Screen.
LANGUAGE:
Change the language support to the language displaying
of the OSD.

16PRESTIGIO P199
ENG
RESET:
Reload the factory default setting of the display.
VOLUME:
Adjust the sound volume of the embedded speaker of the
display.
MUTE:
Silence the embedded speaker of the display.
BACK :
Return to the Main Menu Screen
VGA / DVI:
Switch to theVGA / DVI Signal inputs of the display.

17PRESTIGIO P199
ENG
Display Mode
Incoming Display Mode
Resolution Horizontal Frequency (KHz) Vertical Frequency (Hz)
640X480 (50Hz) 31.5KHz 50.0Hz
640X480 (60Hz) 31.5KHz 59.9Hz
640X480 (66Hz) 35.0KHz 66.7Hz
640X480 (72Hz) 37.9KHz 72.8Hz
640X480 (75Hz) 37.5KHz 75.0Hz
720X480 (60Hz) 15.7KHz 59.9Hz
720X576 (50Hz) 15.6KHz 50.0Hz
800X600 (56Hz) 35.2KHz 56.3Hz
800X600 (60Hz) 37.9KHz 60.3Hz
800X600 (72Hz) 48.1KHz 72.2Hz
800X600 (75Hz) 46.9KHz 75.0Hz
832X624 (75Hz) 49.7KHz 75.0Hz
1024X768 (60Hz) 48.3KHz 60.0Hz
1024X768 (70Hz) 56.5KHz 70.1Hz
1024X768 (72Hz) 57.7KHz 72.1Hz
1024X768 (75Hz) 60.0KHz 75.0Hz
1280X960 (60Hz) 60.0KHz 60.0Hz
1152X864 (75Hz) 67.5KHz 75.0Hz
1280X1024 (60Hz) 64.0KHz 60.0Hz
1280X1024 (75Hz) 80.0KHz 75.0Hz
1. We offer you 20 Windows compatible modes.
2. If any interference occurs on your screen while you modulating your PC or OSD. It is normal.
3.To obtain best display quality,remember to upgrade your video card driver.We strongly recommended you choose
a mode listed in the above-mentioned table.
4. The modes not listed on the table above may be supported.
5.You may use the power management on your computer.It’s good for extending the service life of the product.

18 PRESTIGIO P199
ENG
Specification
LCD Panel
Type
19.0”TFT Active Matrix LCD Display
ViewingAngle
H:160° , V:150°
Contrast Ratio
700:1(MAX),500 :1(Typical)
Brightness
250 cd/m2(Typical)
Response Time
8ms(Typical)
Display Colors
16.2M colors
MaxResolution
1280X1024(SXGA)
PixelPitch
0.294mm(H)x0.294mm(V)
Input Signals
RGBAnalog
VGA Level:0.7Vp-p(75Ohm)
Sync TTL with 75Ohm internal pull-up resistors
Frequency FH:30~79KHz / FV:56~75Hz
Compatibility
PC
Up to 1280X1024@75Hz(Non-interlaced)
Connector
RGBAnalog
D-sub 15-pins
Audio IN
Stereo Phone Jack
DVI-D
D-sub 24-pin DVI-D connector(optional)
Power
AC input Voltage
100-240V, 50/60Hz(universal)
Consumption
Active < 48Watt Max
Power saving mode
Standby < 5Watt
Internal Speaker
3Wx2(Stereo)
User Interface
LED Indicator
Active- Green
Off - Turn off
Standby - Orange
Operating Condition
Temperature
0°C~45°C
AirHumidity
10% ~ 80% R.H.
Dimensions
Physical
460mm(H) x 430mm(W) x 210mm(D)
Net Weight
4.8kg
Gw Weight
5.5kg
DDC
DDC1/DDC2BCompliant
Power Management
VESA DPMS,EPA Energy Star
Regulation (Certifications)
CE, FCC, CB,TU V, UL

1PRESTIGIO P199
CZ
Prestigio P199
Návod k použití

2 PRESTIGIO P199
CZ
Bezpečnostní instrukce
1. Prosíme, přečtěte si pečlivě tyto bezpečnostní instrukce.
2. Uschovejte si tento návod k použití pro možnost pozdějšího nahlédnutí do něj.
3. Před čištěním výrobku jej odpojte od elektrické sítě. Nepoužívejte pro jeho čištění tekuté čistící prostředky nebo sprejové čističe.
Používejte pouze navlhčenou utěrku.
4. Před připojením monitoru do elektrické sítě se ujistěte o tom, zda odpovídá napětí ve vaší zásuvce pracovnímu napětí monitoru.
5. Všemi bezpečnostními upozorněními a varováními byste se měli řídit.
6.Dbejte, abyse dovětracích otvorůmonitoru nikdynedostala žádnátekutina, neboťmůže dojítk požárunebo kúrazu elektrickým
proudem.
7. Monitor nikdy nerozebírejte. Z bezpečnostních důvodů by měl být monitor opravován pouze kvalifikovanou osobou.
8. Pokud nastane některá z těchto níže popsaných situací, nechte monitor zkontrolovat v odborném servisu:
a.Do monitoruse dostala tekutina.
b. Monitor byl vystaven vlhkosti.
c. Monitor nepracuje správně nebo je jeho chování odlišné od chování popsaného v tomto návodu k obsluze.
d. Monitor vám spadl a byl poškozen.
e. Monitor nese známky poškození.
9. NEPONECHÁVEJTE MONITOR V PROSTŘEDÍ S TEPLOTOU VYŠŠÍ NEŽ 40°C, NEBOŤ VYŠŠÍ TEPLOTA JEJ MŮŽE POŠKODIT.
