Presto Flipside Belgian 03510 User manual

8
• Professional-style rotating design
bakes extra-thick Belgian waffles in
minutes.
• Flips 180° to evenly spread batter for
waffles that are crispy outside and
fluffy inside.
• Unique dual function base assures
convenient rotation and locks waffle
maker in vertical position for compact
storage.
• Countdown timer with digital
display signals when
baking time is up.
FlipsideBelgian
Waffle Maker
INSTRUCTIONS
2017 National Presto Industries, Inc. Form 76-392B
Visit us on the web at www.GoPresto.com
Estas instrucciones también están disponibles en español. Para obtener una copia
impresa:
• Descargue en formato PDF en www.GoPresto.com/espanol.
• Envíe un correo electrónico a [email protected].
• Llame al 1-800-877-0441, oprima 2 y deje un mensaje.
Consumer Service Information
If you have any questions regarding the operation of your Prestoappliance or need parts for
your appliance, contact us by any of these methods:
• Call 1-800-877-0441 weekdays 8:00 AM to 4:00 PM (Central Time)
• Email us through our website at www.GoPresto.com/contact
• Write: National Presto Industries, Inc.
Consumer Service Department
3925 North Hastings Way, Eau Claire, WI 54703-3703
Inquiries will be answered promptly by telephone, email, or letter. When emailing or writing,
please include a phone number and a time when you can be reached during weekdays if possible.
When contacting the Consumer Service Department, please indicate the model and series
numbers for the waffle maker. These numbers can be found on the bottom of the waffle maker
near the cord. Please record this information:
Model _______________ Series _______________ Date Purchased _________
The Presto Factory Service Department is equipped to service Prestoappliances and supply
genuine Prestoreplacement parts. Genuine Prestoreplacement parts are manufactured to
the same exacting quality standards as Prestoappliances and are engineered specifically to
function properly with its appliances.
Presto can only guarantee the quality and performance of genuine Prestoreplacement parts.
“Look-alikes” might not be of the same quality or function in the same manner. To ensure that
you are buying genuine Prestoreplacement parts, look for the Prestotrademark.
Canton Sales and Storage Company
Presto Factory Service Department
555 Matthews Drive, Canton, MS 39046-3251
(Applies only in the United States)
This quality Prestoappliance is designed and built to provide many years of satisfactory performance under
normal household use. Presto pledges to the original owner that should there be any defects in material or
workmanship during the first year after purchase, we will repair or replace it at our option. Our pledge does
not apply to damage caused by shipping. Outside the United States, this limited warranty does not apply.
To obtain service under the warranty, please call our Consumer Service Department at 1-800-877-0441. If
unable to resolve the problem, you will be instructed to send your Prestoappliance to the Presto Factory
Service Department for a quality inspection; shipping costs will be your responsibility. When returning an
appliance, please include your name, address, phone number, and the date you purchased the appliance as
well as a description of the problem you are encountering with the appliance.
We want you to obtain maximum enjoyment from using this Prestoappliance and ask that you read and
follow the instructions enclosed. Failure to follow instructions, damage caused by improper replacement parts,
abuse, misuse, disassembly, alterations, or neglect will void this pledge. This warranty gives you specific legal
rights, and you may also have other rights which vary from state to state. This is Presto’s personal pledge to
you and is being made in place of all other express warranties.
NATIONAL PRESTO INDUSTRIES, INC., EAU CLAIRE, WI 54703-3703
PrestoLimited Warranty

32
This is a Listed appliance. The following important safeguards are recommended by most
portable appliance manufacturers.
IMPORTANT SAFEGUARDS
To reduce the risk of personal injury or property damage, when using electrical appliances,
basic safety precautions should always be followed, including the following:
1. Read all instructions before using the waffle maker.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against the risk of electrical shock, never put the cord, plug, or unit in water
or other liquids.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on
or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or in the event the appliance
malfunctions or has been damaged in any manner. Return the appliance to the Presto Fac-
tory Service Department for examination, repair, or electrical or mechanical adjustment.
7. The use of accessory attachments not recommended or sold by the appliance manufacturer
may cause injuries. Use only genuine Prestoaccessories and replacement parts.
8. Do not let cord hang over edge of table or counter or touch hot surfaces.
9. Do not use outdoors.
10. Do not place on or near a hot gas or electric burner or in a heated oven.
11. It is recommended that this appliance not be moved when it contains hot oil or other hot
liquid.
12. Do not use appliance for other than intended use.
SAVE THESE INSTRUCTIONS
THIS PRODUCT IS FOR HOUSEHOLD USE ONLY.
Important Cord Information
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of
electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does
not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician.
Do not attempt to modify the plug in any way.
A short power supply cord (or cord set) is provided to reduce the risk resulting from becoming
entangled in or tripping over a longer cord. Extension cords may be used if care is properly
exercised in their use. If an extension cord is used, the marked electrical rating of the extension
cord should be at least as great as the electrical rating of the appliance. The extension cord
should be arranged so that it will not drape over the countertop or tabletop where it can be
pulled on by children or tripped over unintentionally.
Connect the power supply cord to a 120VAC electrical outlet only.
Getting Acquainted
Before using for the first time, become familiar
with the waffle maker features (Fig. A). Wipe the
waffle grids with a damp cloth before initial use.
Timer Operating Instructions
NOTE: The timer works independently from the
unit; it does not turn the unit on or off.
1. Activate the timer by holding the button down
(Fig. A) until 00 is visible in the display screen.
2. Press the button once for each individual
minute or hold the button down to increase
the display time rapidly until you have reached the desired time. The timer can be set for
1 to 30 minutes. The timer will automatically begin counting down approximately two
seconds after it is set. To reset the timer to zero, press and hold the timer button for about
two seconds.
NOTE: Shortly after you depress the button, the time remaining will flash on the screen.
It will continue to flash until the time has elapsed.
3. When there is just one minute left on the timer, you will hear two beeps to alert you that
time is almost up. In addition, the seconds remaining will now be displayed. When the
set time has expired, the timer will beep five times. After about one minute, the display
screen will go blank.
NOTE: If the timer does not beep, this can be corrected by simply removing the battery,
wiping it clean, and then reinserting it. See page 7 for battery removal instructions.
How To Use
1. Place the unit on the countertop so the timer display is facing towards you and the cover
is closed (Fig. B). Plug the cord into a 120VAC electrical outlet and preheat the waffle
maker in the closed position. The signal light will glow (Fig. A).
When the unit has reached the correct temperature, the light will
go out indicating the unit is ready for use. Preheat time is short—
approximately 3 to 5 minutes. During cooking, the light will go
on and off indicating temperature is being maintained.
NOTE: When using the waffle maker for the first time, a slight
odor or smoking may occur as manufacturing residue burns off.
This is normal during initial use.
2. While unit is preheating, prepare waffle batter.
NOTE: Because the grids are covered with a ceramic non-
stick finish, there should be no need to apply vegetable oil.
No-stick cooking sprays are not recommended.
3. Pour ¾ to 1 cup batter into the center of the bottom waffle
grid (Fig. C). The amount of waffle batter needed may vary
with the recipe or brand of batter mix used.
Waffle
grids Timer
display
Signal
light
Fig. A
Timer
button
Hinged
base
Fig. B
Red locking
lever
Fig. C

54
If using the recipes in this booklet, refer to them for the rec-
ommended amount of batter.
4. Set the timer by pressing the button (Fig. A) to the desired
time. See the recipes below and opposite for recommended
cooking times. Most waffle recipes will take about 4 minutes.
NOTE: The timer has a delay start; it will automatically
begin counting down approximately 2 seconds after it is set.
To reset the timer to zero, simply press and hold the timer
button for about two seconds.
NOTE: The timer works independently from the unit; it does
not turn power to the unit on or off.
5. Close the waffle maker (Fig. D). While grasping both handles,
flip the unit over 180° (Fig. E and Fig. F).
6. The waffle maker will beep five times when the set time has
expired. Open the waffle maker and, using a fork, spear the
side of the waffle and lift it from the grids.
7. Repeat steps 4 through 6 for additional waffles.
8. Unplug waffle maker when cooking is completed.
Recipes
Classic Waffles
2 cups all-purpose flour
1¾ cups milk
1 tablespoon sugar
2 eggs
1 tablespoon baking powder
2 tablespoons vegetable oil
¼ teaspoon salt
Combine our, sugar, baking powder, and salt in a large bowl. Whisk milk, eggs, and oil
in medium bowl. Whisk milk mixture into dry ingredients just until thoroughly moistened.
Preheat wae maker. Pour 1 cup batter onto the center of the bottom grid. Close top and ip
wae maker. Bake until brown, about 4 minutes.
Makes 4 waffles
Flavorful Whole Grain Waffles (both delicious and healthy)
1 cup all-purpose flour
¼ teaspoon salt
¾ cup whole wheat flour
2 cups milk
½ cup quick cooking oats
2 eggs
1 tablespoon brown sugar
2 tablespoons vegetable oil
1 tablespoon baking powder
Combine ours, oats, brown sugar, baking powder, and salt in large bowl. Whisk milk, eggs,
and oil in medium bowl. Whisk milk mixture into dry ingredients just until dry ingredients
are thoroughly moistened. Allow batter to rest 5 minutes. Preheat wae maker. Pour scant
1 cup batter onto the center of the bottom grid. Close top and ip wae maker. Bake until
wae is brown, about 4 minutes.
Makes 4 waffles
Fluffy Waffles
1¾ cups all-purpose flour
1¾ cups milk
1 tablespoon baking powder
2 eggs, separated
¼ teaspoon salt
2 tablespoons vegetable oil
Combine our, baking powder, and salt in a large bowl. Whisk milk, egg yolks, and oil in
a medium bowl. Whisk milk mixture into dry ingredients just until thoroughly moistened.
Using an electric mixer, beat the egg whites in small bowl until sti. Fold whites into batter,
leaving a few us. Preheat wae maker. Pour 1 cup batter onto the center of the bottom
grid. Close top and ip wae maker. Bake until brown and crisp, about 4 minutes.
Makes 4 waffles
Pecan Waffles
2 cups all-purpose flour
¼ cup chopped pecans
2 tablespoons brown sugar
2 cups buttermilk
2 teaspoons baking powder
2 eggs
1 teaspoon baking soda
3 tablespoons vegetable oil
¼ teaspoon salt
½ teaspoon maple flavoring
Combine our, brown sugar, baking powder, baking soda, and salt in a large bowl. Stir in the
pecans. Whisk buttermilk, eggs, oil, and maple avoring in medium bowl. Whisk milk mix-
ture into dry ingredients just until dry ingredients are thoroughly moistened. Preheat wae
maker. Pour 1 cup batter onto the center of the bottom grid. Close top and ip wae maker.
Bake until brown, about 4 minutes.
Makes 4 waffles
Helpful Hints
♦If desired, packaged waffle mixes may be prepared and baked in the Prestowaffle maker.
Batter made from some packaged mixes may have a shorter baking time, so it is recom-
mended that you check for doneness after 2 minutes. A good indication that the waffle is
done is when steam escaping from the waffle maker stops.
♦Waffle batters, whether using mixes or homemade recipes, will vary and therefore the
amount of batter needed for an evenly filled waffle, without overflow, will vary. It is rec-
ommended that when making the first waffle you use a measuring cup to gauge how much
batter is needed. Generally between ¾ and 1 cup works best. Never use more than 1 cup of
batter. If you get some overflow, be sure to use less batter for the next waffle.
♦For batters that don’t flow when poured onto the waffle grid, use a heat-resistant spatula
and spread out the batter evenly to the edges of the grid.
♦Dessert batters may require an application of vegetable oil to the waffle grids before cooking
the first waffle and as needed for additional waffles. Excessive use of oil can damage the
nonstick coating and over time may even cause sticking.
♦No-stick cooking sprays are not recommended for seasoning the waffle maker as they may
leave a tacky residue. In addition, the waffle may have a mottled appearance instead of the
even brown appearance as when using vegetable oil.
♦Keep waffles warm and crisp until serving by placing them in a single layer directly on a
rack in a 200°F oven.
Fig. D
Fig. E
Fig. F

76
♦If you have leftover waffles, freeze them. Cool extra
waffles to room temperature. Place them between layers
of waxed paper in a resealable plastic freezer bag. When
ready to serve, pop the frozen waffles into your toaster
or reheat them in an oven at 350°F for about 10 minutes.
Care, Cleaning, and Storage
1. Unplug unit and allow to cool completely before clean-
ing. Never immerse waffle maker in water or other liquid
or wash in a dishwasher.
2. Brush any loose crumbs from the waffle grids. Then wipe
the grids with a paper towel or cloth.
3. Should any batter become baked onto the grids or the
outside of the unit, apply a small amount of cooking oil
to the batter. Allow it to sit for a few minutes to soften
and wipe off with a paper towel or cloth.
4. Wipe the outside of the waffle maker with a damp cloth.
Do not use steel wool scouring pads or abrasive kitchen
cleaners on the unit.
5. For compact vertical storage, rotate waffle maker to
upright position (Fig. G). While holding the handles
together, lock in position by carefully flipping up one
of the red locking levers from the grooves in the hinged
base (Fig. H and Fig. I).
Before the next use, remember to unlock the waffle
maker from its storage position (Fig. I) by dropping
the red locking levers (Fig. H) back in towards the
base.
Replacing the Timer Battery
The battery used in the waffle maker is a CR2032 3V lithium
battery which will seldom need to be replaced. If you ever
need to replace the battery, follow the instructions below.
1. On the left and right side of the timer is an undercut.
Use your fingernail or insert a thin object, such as a
butter knife, in the undercut (Fig. J) on the left side of
the timer and lift that side of the timer away from the
waffle maker.
Hold that side of the timer with your finger to prevent it from
slipping back in the waffle maker and insert your fingernail
or the knife in the undercut on the right side of the timer
and lift that side away from the waffle maker. Now pull the
timer out completely from the opening in the waffle maker
(Fig. M).
2. Turn the timer over so the back side is facing up. Using a
small Phillips screwdriver, loosen the large screw on the
battery compartment cover. (Screw is not intended to be
removed.) Lift the cover off (Fig. K).
3. Using a small paring knife, or some other narrow object,
carefully press near the top of the interlock spring towards
the wall of the timer to release the battery from under the
hooks (Fig. L). Use the tip of the knife to remove the battery
and discard.
4. Position the new CR2032 3V lithium battery, with writing
facing up, in compartment (Fig. L) fitting it underneath
the plastic edge. Push battery down on the side by the
interlock spring until the battery snaps into position
under the hooks.
5. Replace the battery compartment cover. Fit the tab
opposite the screw in the slot on the timer and align
the screw with the screw hole. Tighten the screw. Turn
the timer over and press the button to make sure it is
operating.
6. Place the timer back in the waffle maker by aligning
the rib on the timer with the notch in the opening on
the side of the waffle maker (Fig. M). Push the timer in so it is securely positioned.
Red
locking
lever
Red
locking
lever
Fig. G
Groove in
hinged base
Red locking lever in
LOCKED position
Red locking lever in
UNLOCKED position
Fig. H
Fig. I
Fig. K
Fig. L
Interlock
spring Hooks
Plastic
edge
Battery
compartment
cover
Fig. M
Rib
Notch
Undercut
Timer
Fig. J
Large
screw
Screw
hole
