Prevue Hendryx Prevue Pet Products 465 User manual

FRIEND ME!
5...
6...
7... 8...
9...
10...
EASY AS 1-2-3 !
465—05/20— A4.1 Made in China for Prevue Pet Products, Inc., 224 N Maplewood Ave, Chicago IL 60612 USA • 1 [312 243-3624 • www.prevuepet.com • customerservice @ prevuepet.com
465
ODEL #
Instructions online at www.prevuepet.com
READTHESEINSTRUCTIONS!
Follow the enclosed Assembly Steps for a successful outcome. If you still have
questions, we’re here to help. Please contact our Prevue Customer Service
team via email at :
[e-mail]
HELPFULTOOLS
o assemble the coop, you will require a phillips-head screw driver or power
tool with phillips head bit, and a rubber mallet.
FINDAFRIEND
A second person’s assistance is a necessity during several stages of assembly
and for moving the assembled coop to your desired location.
REVIEWALL PARTS &HARDWARE
After unpacking all components, review all parts against the Parts List. Count
the contents of the screw and dowel packets and compare the counts against
the Parts List. here should be one spare for each packet.
If any packets are short, please contact Prevue or use your own appropriate-
size replacements. Please contact Prevue if any problems or issues arise.
READ!
READ!
READ!
1
2
3
4
5
For successful assembly of your 4–6 hen Chicken Coop
Follow this pecking order
NEEDED
CAREADVISORY To maintain the longevity of your purchase,
we recommend that you periodically treat it with a non-toxic sealant and protect it
with a tarp or other covering during extended periods of inclement weather.

465—05/20— A4.2 For more wonderful cages, toys, and accessories for cats, birds, chickens, rabbits, ferrets, dogs and small animals, visit www.prevuepet.com
Instructions online at www.prevuepet.com
For successful assembly of your 4–6 hen Chicken Coop
Follow this pecking order
465
ODEL #
7
6LEVEL = GOOD! NOT LEVEL = NOT GOOD
SPECIAL ATTENTION NOTICE
ASSE BLY STEP5: Frame alignment is critical for successful assembly
CHICKEN
RUN
COOP
HOUSE
NEST BOX
CHICKEN
RUN
COOP
HOUSE
NEST BOX

ALIGNED FRAME = GOOD!
1. Square up the coop framework first, before applying
the roof panels. his is the single most-important step you
can take to guarantee the best roof alignment. An aligned
frame will result in a more solid, stable assembly and
nicer finished product.
2. Position the roof panels in place over the chicken run
area. Check alignment. Position the roof panels over the
coop house area. Check alignment.
3. When all panels have been placed in position and
aligned, then attach each with the appropriate screws.
RE E BER: DO NOT screw the roof panels down until the
coop frame has been squared up and all roof panels have
been laid in position and evenly aligned.
The view of the coop
framework from above
shows good alignment
of all coop and
chicken run panels.
SKEWED FRAME = BAD!
The view of the coop
framework from above,
with skewed alignment.
This will result in bad
roof panel placement.
Just slide the frame-
work over to realign.
FINDALEVELSURFACE
Build your coop on a flat surface and, with a friend, carry it to the location where
it will be used. Assembling the coop on the flattest surface available will help
you greatly when squaring up panels and aligning the roof panels.

CUSTOMER SUPPORT
For assistance or replacement parts,
please contact Prevue Pet Products:
PHONE [phone]
ONLINE www.prevuepet.com
EMAIL [e-mail]
465—05/20— A4.3 Made in China for Prevue Pet Products, Inc., 224 N Maplewood Ave, Chicago IL 60612 USA • 1 [312 243-3624 • www.prevuepet.com • customerservice @ prevuepet.com
KEY:
CB = Coop Back
CC = Coop Center
CE = Center Extenders
CF = Coop Front
NB = Nest Box
RP = Roof Panel
RE = Roof End
R = Roof rim
4–6 hen Chicken Coop
PARTS LIST
Instructions online at www.prevuepet.com
465
ODEL #
PERCH BARS
FLOORPANELS
DIVIDERS
]Cb1
]Cb2
]Cc
]Cf1
]Cf2
]Ce1
]Ce2
]Ce3]Ce4
]Cf3
]Cb3
]Nb4
]Nb5
]Nb1
]Nb3.1
]Nb3.2
]Nb2

465—05/20— A4.4 For more wonderful cages, toys, and accessories for cats, birds, chickens, rabbits, ferrets, dogs and small animals, visit www.prevuepet.com
4–6 hen Chicken Coop
PARTS LIST
CUSTOMER SUPPORT
For assistance or replacement parts,
please contact Prevue Pet Products:
PHONE [phone]
ONLINE www.prevuepet.com
EMAIL [e-mail]
Instructions online at www.prevuepet.com
hese parts are
interchangeable
for themselves:
All Rp1s
All Rp2s
All Rp3s
All Re1s
All Re2s
All Re3s
All Rt1s
All Rt2s
⁕
HARDWARE:
(spares are included but not reflected in counts)
TOOLSREQUIRED:
P
Wood Peg
28 pcs
Screwdriver or power drill
with Phillips head bit
Rubber mallet
P
465
ODEL #
]Rp1
]Rp1
]Rp1
]Rp1
]Rp2
]Rp3
]Rp3
]Rp2
]Re3
]Re1
]Re1]Re2
]Re3
]Re1
]Re1
]Re2
]Rt1
]Rt2
]Rt2
]Rt1
]Rt2
]Rt2
P1
2⅜"L (60.5mm)
4 pcs
P1
P2
2"L (51 mm)
8 pcs
P2
P3
1¾"L (44.5 mm)
22 pcs
P3
P4
1⅜"L (35 mm)
56 pcs
P4
P5
1"L (25.5 mm)
40 pcs
P5
P6
⅝"L (16 mm)
6 pcs
P6

CUSTOMER SUPPORT
For assistance or replacement parts,
please contact Prevue Pet Products:
PHONE [phone]
ONLINE www.prevuepet.com
EMAIL [e-mail]
4–6 hen Chicken Coop
ASSE BLY
Instructions online at www.prevuepet.com
465—05/20— A4.5 Made in China for Prevue Pet Products, Inc., 224 N Maplewood Ave, Chicago IL 60612 USA • 1 [312 243-3624 • www.prevuepet.com • customerservice @ prevuepet.com
OOLS: Phillips head screwdriver / Rubber mallet • For best results, follow the Assembly Steps in the order presented.
KEY:
CB = Coop Back
CC = Coop Center
CE = Center
Extenders
CF = Coop Front
NB = Nest Box
RP = Roof Panel
RE = Roof End
R = Roof rim
1PIECES
]Cb1
]Cb2
]Cb3
]Cc
P
P3
P
PREP: ap wood pegs into predrilled
holes indicated by the osymbol.
× 12 × 8
P3
Orient the side panels with
bottom ed e rails facin the
coop interior.
Align wood pegs with the
predrilled guide holes and
attach the panels together
with [P3] screws.
465
ODEL #
If a dowel snaps in the hole:
a.) Drill the hole out and replace with a spare
b.) Use a spare screw
c.) Use a nail
Dowels are mainly for uidance when
ali nin panels and are not structural.

465—05/20— A4.6 For more wonderful cages, toys, and accessories for cats, birds, chickens, rabbits, ferrets, dogs and small animals, visit www.prevuepet.com
P
P2
× 12 × 8
P
PREP: ap wood pegs into predrilled
holes indicated by the osymbol on
all roof extender pieces.
P2
PREP: Arrange the pieces. Viewed from
the front, roof extenders with the most
extreme end-angle cuts are positioned
on the outside.
ROOF EXTENDERS:
Insert the roosting
perch bars into the
notched holders.
Align the wood peg on the back
of the extender with the guide
hole on the coop door frame.
Attach middle extenders first.
Attach all with [P2] screws.
PERCH BARS:
Set the coop
floor panels into
the coop base.
COOP FLOOR:
PERCH
BARS
ROOF
EXTENDERS
FLOOR
PANELS
2PIECES
view from FRONT view from BACK

465—05/20— A4.7 Made in China for Prevue Pet Products, Inc., 224 N Maplewood Ave, Chicago IL 60612 USA • 1 [312 243-3624 • www.prevuepet.com • customerservice @ prevuepet.com
3PIECES
]Nb1
]Nb5
]Nb3.1 +.2
]Nb2
]Nb4
P3
P5
P6
× 8 × 4 × 6
1
2
PREP: Center the divider stop
bar from side-to-side and flush
with the outer edge.
P3
Attach nest box ends
with [P3] screws.
2 per side
ENDS:
FLOOR:
FLOOR PREP:
ip the nest box floor into
position between the end panels
with the divider stop bar facing
the coop interior.
P5
Attach the nest box side
with [P5] screws.
DIVIDERS:
Insert the nest box dividers into the slots by
tipping the inside corner (1) in first and rotating
the outside corner (2) down into place.
P6
Attach the
nest box lid
hinges to
the coop with
[P6] screws.
PREP: Before attaching
the nest box lid, lay it
in position and close the
padlock flap over the
corresponding hardware.
his will align the nest
box lid in the correct
position.
LID:
Attach with
[P3] screws.
P3
]Nb1]Nb2
]Nb3.1 +.2
SIDE:
]Nb4
]Nb5

465—05/20— A4.8 For more wonderful cages, toys, and accessories for cats, birds, chickens, rabbits, ferrets, dogs and small animals, visit www.prevuepet.com
4PIECES
P
P1
P3
× 4 × 4 × 6
P3
Align the front panel flush
with the sides and attach
with [P3] screws.
P1
Align the side panels
flush with the coop and
attach with [P1] screws.
ATTENTION: When attachin the chicken run
side panels and the front panel, make sure the
panels ali n flush with the outside ed es.
P
PREP: ap wood
pegs into predrilled
holes indicated by
the osymbol.
]Cf1
]Cf2
]Cf3

3
2
1
1
1
1
2
3
coop house
chicken run
asphalt-coatin wraps
around to the sides
on outer-ed e panels
3
2
1
13
1
12
uide holes closest to the ed e
are for the middle seam
numberin stamps
are for identification
Roof panels, asphalt-side down →
Roof panels, on the coop ↓
465—05/20— A4.9 Made in China for Prevue Pet Products, Inc., 224 N Maplewood Ave, Chicago IL 60612 USA • 1 [312 243-3624 • www.prevuepet.com • customerservice @ prevuepet.com
5PIECES
CHICKEN
RUN
COOP
HOUSE
NEST BOX
NEST BOX
GOOD ALIGNMENT IS EVERYTHING
o assure a clean finish to your coop, pay special attention to the coop frame
alignment. Squaring up your frame will result in the correct alignment for the
roof panels, roof seams, and all roof trim.
•A dia ram of the coop framework as
viewed from above, showin square 90° corners
and perfect, flush ali nment of all coop frame
panels.
An off-kilter frame ali nment will make it
difficult to place the roof panels correctly; will
create poor roof seams; will make it difficult
to finish the end trim neatly or ali n the top
trim correctly, and; will result in a ja ed and
sloppy coop roof.
GOOD FRAME ALIGNMENT
results in
GOOD ROOF PANEL ALIGNMENT
PLEASE READ FIRST
PREP: Lay all roof panels face-down
on the ground, following the order
and placement shown ↘
ROOF PANEL
PLACEMENT GUIDE
NOTE: Numbered roof parts follow this pattern:
• All 1s are center panels.
• All 2s & 3s are outer-ed e panels, and
have asphalt coatin wrappin around to the
outside ed es.
PLACEMEN
GUIDE ONLY.
See next page
for Assembly
Steps.
⁕

2
2
3
3
3
2
1
13
1
12
2
2
1
2
2
2
3
1
1
11
3
3
P4
BEGIN WITH THE CHICKENRUN END:
Lay panels 2& 3in position. Align the
wood pegs along the roof lines with the
guide holes on the panel undersides. If
dowels and guide holes don’t properly
align, gently adjust the coop frame until
alignment is achieved.
Lay center panels 1& 1in position.
DONOTATTACHPANELS.Check the
roof panel alignment. Adjust the coop
frame as necessary to get as straight
an alignment as possible.
A ja ed, uneven, stair-stepped ali nment alon the roof
panels means the coop frame is not ali ned. Shift the coop
frame ri ht or left to et a clean ali nment ed e.
COOPHOUSE END:
Place panels over the Coop House end,
using the same method: outer-edge
panels first, then center panels.
Recheck the alignment and adjust as
necessary.
With roof panels aligned, starting with
the center panels/middle seam, begin
attaching the roof to the frame.
Attach end cap
trim with [P4] screws.
P5
Start with the peak
trim/middle seam and
work out to the ends.
Attach with [P5] screws.
P4
Attach with [P4] screws.
ROOFENDCAPTRI :
Attach the two middle [1]
end trim first.
Align the outer-edge (2& 3)
trim off of the middle pieces.
PREP: Lay the roof seam trim
in position FIRS and adjust for
the cleanest alignment.
1trim slats are positioned
along the peak.
2trim slats are positioned
over the side seams.
Assembly completed. {
465—05/20— A4.10 For more wonderful cages, toys, and accessories for cats, birds, chickens, rabbits, ferrets, dogs and small animals, visit www.prevuepet.com
5PIECES
P4
P5
× 56 × 36
INCORRECT ALIGNMENT CORRECT ALIGNMENT
]Rt
]Rt
]Re
]Re
]Rp
]Rp
