For successful assembly of your MODEL #4701 Chicken Coop with Herb Planter
Follow this pecking order
LEVEL = GOOD!
NOT LEVEL = NOT GOOD
READ THESE I STRUCTIO S!
If you’ve never followed instructions before, this is a good time to start!
These tips have been compiled to lead you to a successful assembly. We
know you can do this!
If you still run into trouble, you can call our Prevue Customer Service line
at 1 [phone].
FI D A LEVEL SURFACE
Build your coop on a flat surface and, with a friend, carry it to the location
where it will be used. Assembling the coop on the flattest surface available
will help you greatly when squaring up panels and aligning the roof panels.
FI D A FRIE D (or GO IT ALO E—both are OK)
If you follow these steps, coop assembly will be easy for one person. But you
may find a second person’s assistance useful in some steps.
If you have to move the assembled coop to its final location, you will most
certainly need assistance to protect the integrity of the structure.
COU T CO TE TS OF HARDWARE PACKETS
After unpacking all components, count the contents of the screw packets.
Compare the counts against the Parts List on the next page. There should
be at least one spare for each packet. If any packets are short, please con-
tact Prevue or use your own appropriate-size replacements.
READ!
READ!
READ!
1
2
3
4EASY AS 1-2-3 !

CARE ADVISORIES
For successful assembly of your MODEL #4701 Chicken Coop with Herb Planter
Follow this pecking order
4701— 10/17—USL.2 Made in China for Prevue Pet Products, Inc., 224 N Maplewood Ave, Chicago IL 60612 USA • www.prevuepet.com • 1 [800 243-3624 • customerservice @ prevuepet.com
5
CUSTOMER SUPPORT
Please contact Prevue Pet Products:
PHONE [phone]
ONLINE www.prevuepet.com
EMAIL [e-mail]
These instructions are online, under the item’s
detail listing at www.prevuepet.com.
For the comfort and health of your chickens, this coop size
is most appropriate for 2 to 3 hens.
•
se plastic or ceramic saucers or plastic tarp under all
potted plants in the herb planter box to protect the wood
from constant contact with moisture.
•
When moving the coop, remove the ramp and bar unit for
safety.
To maintain the longevity of your purchase, we recommend that you
periodically treat it with a non-toxic sealant and protect it with a tarp
or other covering during extended periods of inclement weather.
For more wonderful cages, toys, and
accessories for dogs, cats, birds, chickens,
rabbits, ferrets and small animals, visit
www.prevuepet.com

CUSTOMER SUPPORT
Please contact Prevue Pet Products:
PHONE [phone]
ONLINE www.prevuepet.com
EMAIL [e-mail]
MODEL #4701 Chicken Coop with Herb Planter
PARTS LIST
4701— 10/17—USL.3 Made in China for Prevue Pet Products, Inc., 224 N Maplewood Ave, Chicago IL 60612 USA • www.prevuepet.com • 1 [800 243-3624 • customerservice @ prevuepet.com
]D1
]D2
]F
]E
]C
]B
]M1
]M2
]L2
]L1
]A1
]N
]A2

CUSTOMER SUPPORT
Please contact Prevue Pet Products:
PHONE [phone]
ONLINE www.prevuepet.com
EMAIL [e-mail]
MODEL #4701 Chicken Coop with Herb Planter
PARTS LIST
P1
2"L (50mm)
11 pcs +1
(use All in Step 2)
P2
1¾"L (45mm)
24 pcs +1
(use All in Step 1)
P3
1⅜"L (35mm)
6 pcs +1
(use All in Step 4)
P4
1"L (25mm)
24 pcs +1
(use All in Step 4)
P5
⅝"L (16mm)
4 pcs +1
(use All in Step 3)
HARDWARE
I CLUDED:
Screwdriver
or power drill
with
Phillips head
end/bit
TOOLS
REQUIRED:
4701— 10/17—USL.4 Made in China for Prevue Pet Products, Inc., 224 N Maplewood Ave, Chicago IL 60612 USA • www.prevuepet.com • 1 [800 243-3624 • customerservice @ prevuepet.com
]K1
]K2
]H
]G
]J
]T
]I
]O1
]Q3
]Q4
]Q1
]Q2
]R2
]R1
]S
]P1
]P2
]O2

Chicken Coop with Herb Planter
2–3 Hens
Model: #4701 Instructions online at www.prevuepet.com
4701— 10/17—USL.5 Made in China for Prevue Pet Products, Inc., 224 N Maplewood Ave, Chicago IL 60612 USA • www.prevuepet.com • 1 [800 243-3624 • customerservice @ prevuepet.com
CUSTOMER SUPPORT
Please contact Prevue Pet Products:
PHONE [phone]
ONLINE www.prevuepet.com
EMAIL [e-mail]
1Assemble the COOP HOUSE.
You will need these pie es:
Assemble the PLANTER BOX.
You will need these pie es:
× 8
× 8
PLEASE READ:
Align the right side
coop house panel
FLUSH ALONG THE
TOP EDGE with the
front & ba k panels.
Attach the bac panel to
the right panel with [P2]
screws, using the pre-drilled
holes as guides.
Attach the remaining panels,
also with [P2] screws.
NOTE: Make sure
top edges are flush.
NOTE: Make sure
top edges are flush.
NOTE: The right side panel D
can be identified b the rail
extension along the bottom.
Attach the bac panel to the
right panel with [P2] screws,
using the pre-drilled holes as
guides. Attach the remaining
panels, also with [P2] screws.
Set the floor in place.

4701— 10/17—USL.6 Made in China for Prevue Pet Products, Inc., 224 N Maplewood Ave, Chicago IL 60612 USA • www.prevuepet.com • 1 [800 243-3624 • customerservice @ prevuepet.com
1...co ti ued
Assemble the CHICKEN RUN.
You will need these pie es:
× 8
NOTE: The left side
panel can be identified
b the rail extension
along the top edge. F
Attach the bac panel to the right
panel with [P2] screws, using the
pre-drilled holes as guides. Attach
the remaining panels, also
with [P2] screws.
2Atta h the assembled units
together:
Set the coop house on the left end of the chic en run.
Locate the pre-drilled holes on the underside of the frame rails.
Attach the chic en run to the coop house with [P1] screws up
through the pre-drilled holes.
× 5

4701— 10/17—USL.7 Made in China for Prevue Pet Products, Inc., 224 N Maplewood Ave, Chicago IL 60612 USA • www.prevuepet.com • 1 [800 243-3624 • customerservice @ prevuepet.com
2...co ti ued
Set the herb planter box on the right end of the chic en run.
Locate the pre-drilled holes on the underside of the frame rails.
Attach with [P1] screws.
× 6
ESTI G
TRAY
RAMP &
SUPPORT BAR
Leave about a ¾" gap from the
end of the bar to the ramp.
Attach the ramp to the support
bar with [P5] screws.
× 4
3
Cutawa viewCutawa view
Install the COOP COMPONENTS in this order:

4701— 10/17—USL.8 Made in China for Prevue Pet Products, Inc., 224 N Maplewood Ave, Chicago IL 60612 USA • www.prevuepet.com • 1 [800 243-3624 • customerservice @ prevuepet.com
3... ontinued
4Assemble the ROOF. You will
need these pie es first:
PERCH
BARS
COOP FLOOR
TRAY
Cutawa view
Center the front and bac roof panels over the coop house. Catch the
bloc s (on the underside of the roof) onto the top of the coop house frame.
Tip the panels together and align them with your hands so they are flush
at the pea and also side-to-side.
Tip the left side and right side
roof panels into place.

4701— 10/17—USL.9 For more wonderful cages, toys, and accessories for dogs, cats, birds, chickens, rabbits, ferrets and small animals, visit www.prevuepet.com
4... ontinued
For the ROOF TRIM, you will
need these pie es:
× 20
Lay the roof trim pieces in position.
Using the pre-drilled holes, attach
the trim with [P4] screws.
× 4
Lay the roof cap in position over the
pea and attach with [P4] screws.
× 6
★
Your coop is now
fully assembled and
ready for use.
Using the pre-drilled holes, attach
the entire roof unit to the coop house
frame with [P3] screws.
