Primes BM+ 60 User manual

BeamMonitor BM+
BM+ 60, BM+ 100S
LaserDiagnosticsSoftware LDS
35,0(6
Revision 02 EN - 02/2022
Original Instructions
BeamMonitor BM+ 100S

BeamMonitor BM+ 35,0(6
3
Revision 02 EN - 02/2022
IMPORTANT!
READ CAREFULLY BEFORE USE.
KEEP FOR FUTURE USE.

BeamMonitor BM+
35,0(
6
4Revision 02 EN - 02/2022
Table of contents
1 Basic safety notes 7
2 Symbols and conventions 8
3 About this operating manual 9
4 Device description 10
4.1 Device type overview...............................................................................................................10
4.2 Functional description .............................................................................................................10
4.3 Measuring principle .................................................................................................................10
4.4 Optical displays.......................................................................................................................11
4.5 Explanation of the product safety labels ..................................................................................11
4.5.1 Warning of hand injuries..............................................................................................11
4.5.2 Observe beam path ....................................................................................................12
4.6 Scope of delivery and accessories ..........................................................................................12
5 Quick overview installation 13
6 Transport and storage 13
7 Mounting 14
7.1 Conditions at the installation site .............................................................................................14
7.2 Installation in the laser system .................................................................................................14
7.2.1 Prepare mounting .......................................................................................................14
7.2.2 Possible mounting positions........................................................................................14
7.2.3 Align the device...........................................................................................................15
7.2.4 Mount the device ........................................................................................................15
7.3 Deinstallation of the device......................................................................................................18
8 Connections 18
8.1 Overview of the connections ...................................................................................................18
8.1.1 Connections of the BeamMonitor BM+ 60 ..................................................................18
8.1.2 Connections of the BeamMonitor BM+ 100S..............................................................18
8.2 Power supply (Power In)..........................................................................................................19
8.3 Ethernet ..................................................................................................................................20
8.4 PRIMES bus RS485................................................................................................................20
8.5 Connection of the BeamMonitor BM+ and PowerMonitor PM48/100 to the PC .....................21
9 Measuring with the LaserDiagnosticsSoftware LDS 22
9.1 Warning messages..................................................................................................................22
9.2 Connecting / disconnecting the device with the LaserDiagnosticsSoftware LDS......................24
9.2.1 Switch on the device and connect it to the LDS..........................................................24
9.2.2 If the device does not appear in the connections window ...........................................25
9.2.3 Change the network address of a connected device...................................................26
9.2.4 Disconnect and switch off the device ..........................................................................26
9.3 General information about working with the LDS .....................................................................27
9.3.1 Open „Device control“ menu .......................................................................................27
9.3.2 Open a measuring mode ............................................................................................27
9.3.3 Enter parameters and activate ....................................................................................28
9.3.4 Move axes ..................................................................................................................29
9.3.5 Saving options ............................................................................................................30
9.3.6 Considering the messages in the LaserDiagnosticsSoftware LDS during
measurement..............................................................................................................31

BeamMonitor BM+ 35,0(6
5
Revision 02 EN - 02/2022
9.4 Single planes...........................................................................................................................32
9.4.1 Settings ......................................................................................................................32
9.4.2 Advanced settings ......................................................................................................35
9.4.3 Search laser beam automatically with the find beam function......................................37
9.4.4 Adjust the size and position of the measurement window manually.............................38
9.4.5 Start measurement .....................................................................................................39
9.4.6 Manual caustic measure .............................................................................................39
9.4.7 Display of the measurement results.............................................................................41
9.5 Monitor ...................................................................................................................................42
9.5.1 Settings ......................................................................................................................42
9.5.2 Advanced settings ......................................................................................................44
9.5.3 Search laser beam automatically with the find beam function......................................45
9.5.4 Adjust the size and position of the measurement window manually.............................46
9.5.5 Start measurement .....................................................................................................47
9.5.6 Display of the measurement results.............................................................................48
9.6 Linescan .................................................................................................................................49
9.6.1 Settings ......................................................................................................................49
9.6.2 Advanced settings ......................................................................................................51
9.6.3 Search laser beam automatically with the find beam function......................................52
9.6.4 Adjust the width (length) and position of the measuring line manually ..........................53
9.6.5 Start measurement .....................................................................................................54
9.6.6 Display of the measurement results.............................................................................55
10 Troubleshooting 56
11 Maintenance and service 57
11.1 Maintenance intervals..............................................................................................................57
11.2 Cleaning the device surfaces...................................................................................................57
12 Measures for the product disposal 57
13 Declaration of conformity 58
14 Technical data 60
15 Dimensions 62
15.1 BeamMonitor BM+ 60.............................................................................................................62
15.2 BeamMonitor BM+ 100S ........................................................................................................63
16 Appendix 64
16.1 GNU GPL license notice..........................................................................................................64
16.2 Variety of detectors .................................................................................................................64
16.3 Replace the detector...............................................................................................................65
16.3.1 Remove cover.............................................................................................................65
16.3.2 Disassemble the detector ...........................................................................................65
16.3.3 Assemble the detector................................................................................................67
16.3.4 Replace cover.............................................................................................................67

BeamMonitor BM+
35,0(
6
6Revision 02 EN - 02/2022
PRIMES - The Company
PRIMES manufactures measuring devices used to analyze laser beams. These devices are employed for
the diagnostics of high-power lasers ranging from CO2lasers and solid-state lasers to diode lasers. A wave-
length range from infrared through to near UV is covered, offering a wide variety of measuring devices to
determine the following beam parameters:
• Laser power
• Beam dimensions and position of an unfocused beam
• Beam dimensions and position of a focused beam
• Beam quality factor M²
PRIMES is responsible for both the development, production, and calibration of the measuring devices. This
guarantees optimum quality, excellent service, and a short reaction time, providing the basis for us to meet all
of our customers’ requirements quickly and reliably.
PRIMES GmbH
Max-Planck-Str. 2
64319 Pfungstadt
Germany
Tel [phone]
[email protected]
www.primes.de

BeamMonitor BM+ 35,0(6
7
Revision 02 EN - 02/2022
1 Basic safety notes
Intended use
The device has been designed exclusively for measurements of high-power lasers.
Use for any other purpose is considered as not intended and is strictly prohibited. Furthermore, intended use
requires that you observe all information, instructions, safety notes and warning messages in this operating
manual. The specifications given in chapter14 „Technical data“ on page60 apply. Any given limit values
must be complied with.
If not used as intended, the device or the system in which the device is installed can be damaged or de-
stroyed. In addition, there is an increased risk to health and life. Only use the device in such a way that there
is no risk of injury.
This operating manual is an integral part of the device and must be kept in the immediate vicinity of the place
of use, accessible to personnel at all times.
Every person who is responsible for the installation, start-up or operation of the device must have read and
understood the operating manual and, in particular, the safety instructions.
If you still have questions after reading this operating manual, please contact PRIMES or your supplier for
your own safety.
Observing applicable safety regulations
Observe the safety-relevant laws, guidelines, standards and regulations in the current editions published by
the state, standardization organizations, professional associations, etc. In particular, observe the regulations
on laser safety and comply with their requirements.
Necessary safety measures
DANGER
Serious eye or skin injury due to laser radiation
The device measures direct laser radiation, but does not emit any radiation itself. However, during
the measurement the laser beam is reflected at the rotating measuring tip. This produces scattered
or directed reflection of the laser beam (laser class 4). The reflected beam is usually not visible.
X
In measurement mode, a safety distance of one meter to the device must be maintained even when
wearing safety goggles and safety clothing.
X
Protect yourself from direct and reflected laser radiation while working with the device by taking the
following measures:
• Never leave the device unattended when taking measurements.
• If the device is moved from its aligned position, increased scattered or directed reflection of the laser
beam occurs during measuring operation. Mount the device in such a way that it cannot be moved by
unintentional bumping or pulling on the cables.
• Install safety switches or emergency safety mechanisms that allow the laser to be switched off immedi-
ately.
• Use suitable beam guidance and beam absorber elements which do not emit any hazardous substances
when irradiated.
• Wear safety goggles OD 6 adapted to the power, power density, laser wavelength and operating mode
of the laser beam source in use.
• Wear suitable protective clothing or protective gloves if necessary.
• If possible, also protect yourself from direct laser radiation and scattered radiation by using separating
protective devices that block or attenuate the radiation.

BeamMonitor BM+
35,0(
6
8Revision 02 EN - 02/2022
Employing qualified personnel
The device may only be operated by qualified personnel. The qualified personnel must have been instructed
in the installation and operation of the device and must have a basic understanding of working with high-
power lasers, beam guiding systems and focusing units.
Conversions and modifications
The device may not be modified in terms of design or safety without the explicit consent of the manufacturer.
The same applies to unauthorized opening, dismantling and repair. The removal of covers is only permitted
within the scope of the intended use.
Liability disclaimer
Manufacturer and distributor exclude any liability for damages and injuries which are direct or indirect con-
sequences of using the device not as intended or modifying the device or the associated software without
authorization.
2 Symbols and conventions
Warning messages
The following symbols and signal words indicate possible residual risks in the form of warnings:
DANGER
Means that death or serious physical injuries will occur if necessary safety precautions are not
taken.
WARNING
Means that death or serious physical injuries may occur if necessary safety precautions are not
taken.
CAUTION
Means that minor physical injury may occur if necessary safety precautions are not taken.
NOTICE
Means that property damage may occur if necessary safety precautions are not taken.
Product safety labels
The following symbols are used on the device itself to indicate imperatives and possible dangers:
Read and observe the operating instructions and safety guidelines before startup!
Hand injuries warning

BeamMonitor BM+ 35,0(6
9
Revision 02 EN - 02/2022
General warning sign
Observe beam path
Further symbols and conventions in this operating manual
Here you can find useful information and helpful tips.
XIndicates a simple instruction.
If several such instructions appear one below the other, then the order of their execution is irrel-
evant or they are alternative procedures.
1.
2.
...
A numbered list identifies a sequence of instructions that must be executed in the specified order.
Indicates the result of an action to explain processes that take place in the background.
Indicates an observation prompt to draw attention to visible feedback from the device or the soft-
ware.
Observation prompts make it easier to check whether an instruction was executed successfully.
Often they also guide to the next instruction.
Points to a control element that is to be pressed/ clicked.
Points to an element described in the text (for example an input field).
3 About this operating manual
This manual describes the installation and operation of the BeamMonitor BM+ and how to perform measure-
ments with the LaserDiagnosticsSoftware LDS 1.1.2.
For measurement operation with a PC, the LaserDiagnosticsSoftware LDS must be installed on the PC. The
LDS is included in the scope of delivery.
The software description includes a brief introduction on using the device for measurements.
For a detailed description of the software installation, file management and evaluation of the measurement
data, please refer to the separate instructions for the LaserDiagnosticsSoftware LDS.
This operating manual describes the software version valid at the time of printing. Since the user
software is continuously being developed further, the supplied data medium may have a higher ver-
sion number.
If you have questions, please let us know the software version you are using. The software version can be
found under the following menu item: Help > About LaserDiagnosticsSoftware.

BeamMonitor BM+
35,0(
6
10 Revision 02 EN - 02/2022
4 Device description
4.1 Device type overview
There are two types of the BeamMonitor BM+.
BeamMonitor BM+ 60 BeamMonitor BM+ 100S
Fig. 4.1: Device types BM+ 60 and BM+ 100S
4.2 Functional description
The BeamMonitor BM+ is an opto-mechanically scanning measuring system that scans the laser beam with
a special measuring tip. This is equipped with a small pinhole or reflecting mirror that collects a small section
of the laser beam. Another reflecting mirror guides this portion of the laser light to a detector selected and
configured depending on the used wavelength.
By moving the rotary disk forth a power density distribution is created. The high orbital velocity of the rotating
measuring tip facilitates analysis of high power densities. A very high signal-to-noise ratio is achieved thanks
to the dynamics of the analog-digital converter used. Very low intensities are shown with equal precision next
to the high peak intensities.
4.3 Measuring principle
Using the new LaserDiagnosticsSoftware LDS you can set up the BM+ to automatically repeat measure-
ments in a predefined interval. Accumulate unlimited measurements and check how the beam profile or loca-
tion changes over a long time. For the consideration of shorter time intervals the established Linescan can be
used up to a frequency of 25Hz.
With a newly developed algorithm, the automatic recognition and analysis of rectangular beams becomes
quite straightforward. Besides the lateral length, many unique parameters like the azimuth angle, flank steep-
ness, flatness and uniformity are precisely calculated.
Detector
Horizontal carrier
Measuring tip
Rotary disk
x
y
Laser beam
y
xMirror
Fig. 4.2: Optomechanical design of the BeamMonitor BM+

BeamMonitor BM+ 35,0(6
11
Revision 02 EN - 02/2022
4.4 Optical displays
The status display consists of a light ring that indicates different states of the BeamMonitorBM+ with differ-
ent colors and static or rotating lights.
Color Lighting state Meaning
White The entire ring illuminates The supply voltage is connected
Yellow Rotating light The measuring tip rotates.
Red Rotating light The measuring tip rotates and the y-axis is
moved. The measurement is in progress.
Tab. 4.1: States of the status display
4.5 Explanation of the product safety labels
4.5.1 Warning of hand injuries
A potential hazard area for hand injuries and device damage is marked with a symbol on the device.
The measuring tip of the BeamMonitor BM+ rotates at high speed during the measuring operation. Even af-
ter the measurement or switching off the device, the measuring tip will continue to rotate for a certain amount
of time. To avoid hand injury, do not reach into the aperture of the device.
If the rotating measuring tip hits an obstacle, the measuring tip is de-adjusted. In this case, the device must
be sent in for service. Therefore, no objects may get into the aperture.
Rotating measuring tip
Fig. 4.3: Danger caused by the rotating measuring tip using the BM+ 100S as an example

BeamMonitor BM+
35,0(
6
12 Revision 02 EN - 02/2022
4.5.2 Observe beam path
The BeamMonitor BM+ can be mounted in any installation position. The direction of the laser beam through
the device must be observed. The beam path is indicated on the device.
Laser beam
Fig. 4.4: Beam path using the BM+ 60 as an example
4.6 Scope of delivery and accessories
The following parts are included in the scope of delivery of the BeamMonitor BM+:
• BeamMonitor BM+
• PRIMES power supply
• Power cable
• Patch cable Cat.5e, 5m, Cross-Over
• Patch cable Cat.5e, 5m
• USB stick (PDF of operating instructions, software, etc.)
• Operating manual BeamMonitor BM+
• Operating manual LaserDiagnosticsSoftware LDS
The following accessories are available for the BeamMonitor BM+:
• Transport and storage case

BeamMonitor BM+ 35,0(6
13
Revision 02 EN - 02/2022
5 Quick overview installation
1. Installing the LaserDiagnosticsSoftware LDS on the PC
• The software is included in the scope of delivery.
See separate Operating Manual
of the LaserDiagnosticsSoftware
LDS
2. Taking safety precautions Chapter 1 on page7
3. Prepare mounting
• Observe warning messages
• Set mounting position
• Mounting the device stably
Chapter 7 on page14
4. Establish connections
• Power supply Power In
• Ethernet
• PRIMES-Bus (RS485)
• Parallel operation of the BeamMonitor BM+ for example with the
laser power meter PowerMonitor PM48/100
Chapter 8 on page18
5. Measure
• Observe warning messages
• Connect device to the LDS
• Perform measurements
Chapter 9 on page22
6 Transport and storage
NOTICE
Damage/ Destruction of the device
Optical components may be damaged if the device is subjected to hard shocks or is allowed to fall.
X
Handle the device carefully when transporting or installing it.

BeamMonitor BM+
35,0(
6
14 Revision 02 EN - 02/2022
7 Mounting
7.1 Conditions at the installation site
• The device must not be operated in a condensing atmosphere.
• The ambient air must be free of organic gases.
• Protect the device from splashes of water and dust.
• Operate the device in closed rooms only.
7.2 Installation in the laser system
7.2.1 Prepare mounting
Check the space available before installing the device, especially the required space for the connec-
tion cables. The device must be firmly installed and must be mounted with screws (see chapter 7.2.4 on
page15).
DANGER
Fire and explosion hazards due to scattered or directed laser radiation
When the BeamMonitor BM+ is being operated, the irradiation must be fully absorbed behind the
measurement zone. Fire bricks or other partly-absorbing surfaces are not suitable.
X
Use an adequate absorber. Dependent on the application, PRIMES offers suitable laser power me-
ters, such as the PowerMonitor PM48/100.
7.2.2 Possible mounting positions
The BeamMonitor BM+ can be mounted horizontally or vertically.
Beam incidence
Mounting surface
Mounting surface
BeamMonitor BM+
Mounting surface
Beam incidence
Mounting surface
BeamMonitor BM+
Horizontal installation Vertical installation
Mounting surface
Beam incidence
Mounting surface
BeamMonitor BM+
Beam incidence
Mounting surface
BeamMonitor BM+
Mounting surface
Fig. 7.1: Possible mounting positions of the device

BeamMonitor BM+ 35,0(6
15
Revision 02 EN - 02/2022
7.2.3 Align the device
For the BeamMonitor BM+, a perpendicular beam incidence with respect to the x-y plane must be ensured.
The laser beam should hit the inlet aperture in the center.
DANGER
Serious eye or skin injury due to laser radiation
If the ratio of the laser beam diameter to the inlet aperture is too large, increased scattered or di-
rected reflection of the laser beam (laser class 4) will occur during measuring operation. The hous-
ing of the BeamMonitor BM+ can heat up.
X
The 86% laser beam diameter must not exceed 0.7 times the inlet aperture.
X
Especially in case of laser with high beam quality, the laser beam diameter must not exceed 0.6
times the inlet aperture. Otherwise, a falsification of the measuring results due to the cutting off of
border fields is to be expected.
This can lead to measurement errors, especially when determining the radius using the second mo-
ment method.
7.2.4 Mount the device
DANGER
Serious eye or skin injury due to laser radiation
If the device is moved from its calibrated position, increased scattered or directed reflection of the
laser beam occurs during measuring operation (laser class 4).
X
Mount the device in a way that it cannot be moved by an unintentional knock or cables being pulled
accidentally.
NOTICE
Damage/ Destruction of the device
Too long fastening screws can damage internal components in the device.
X
The fastening screws must not be screwed in more than 10mm into the housing.
There are four threaded holes M6 in the mounting surface of the housing for assembly on a support bracket
provided by the customer (see Fig. 7.2 on page16 and Fig. 7.3 on page17).
Please use at least four screws M6 to fasten the device. The total length of the screws depends on the di-
mensions of the customer’s support bracket.

BeamMonitor BM+
35,0(
6
16 Revision 02 EN - 02/2022
Mount the BeamMonitor BM+ 60
Beam
4x M6
7660
316
133
43
212
106
M6 M6
M6 M6
Beam
4x M6
7660
316
60133
43
106
212
Ø 60
M6 M6
M6 M6
Fig. 7.2: Threaded holes on the BeamMonitor BM+ 60

BeamMonitor BM+ 35,0(6
17
Revision 02 EN - 02/2022
Mount the BeamMonitor BM+ 100S
PRIMES
Zeichnungs-Nr. und Index an vorgegebener Stelle anbringen.
[phone] / [phone]
[email protected] / [email protected]
Christian Gerhardt-Nickels / Volker Kast
Ansprechpartner in der Konstruktion
4x M6
100
100
100 96
63
M6
M6
M6 M6
PRIMES
Zeichnungs-Nr. und Index an vorgegebener Stelle anbringen.
[phone] / [phone]
[email protected] / [email protected]
Christian Gerhardt-Nickels / Volker Kast
Ansprechpartner in der Konstruktion
150
75
75
100
75
292
71
63
4x M6
436
100
M6 M6
M6 M6
Fig. 7.3: Threaded holes on the BeamMonitor BM+ 100S

BeamMonitor BM+
35,0(
6
18 Revision 02 EN - 02/2022
7.3 Deinstallation of the device
1. Turn off the laser source.
2. Ensure that moving parts, e.g. robot arms, etc. are at a standstill and cannot be set in motion uninten-
tionally.
3. Switch off the BM+ at the Power On / Off switch.
4. Unscrew the fixing screws from the threaded holes.
5. Disconnect the cables and remove the device from the laser system.
8 Connections
Please only use the PRIMES power supply unit and the provided connection cables.
Please establish all electrical connections and switch on the device before starting the LaserDiagnosticsSoft-
ware LDS.
8.1 Overview of the connections
8.1.1 Connections of the BeamMonitor BM+ 60
Ethernet
PRIMES-Bus
RS485
Power supply
connection
Fig. 8.1: Connections of the BeamMonitor BM+ 60
8.1.2 Connections of the BeamMonitor BM+ 100S
Ethernet
PRIMES-Bus
RS485
Power supply
connection
Fig. 8.2: Connections of the BeamMonitor BM+ 100S

BeamMonitor BM+ 35,0(6
19
Revision 02 EN - 02/2022
8.2 Power supply (Power In)
The BeamMonitor BM+ requires a voltage supply of 24V±5% (DC) for the operation. A suitable power sup-
ply is included in the scope of delivery.
BeamMonitor BM+ 100S
PRIMES power supply
Fig. 8.3: Connection of the power supply using the BM+ 100S as an example
Harting M12-P-PCB-THR-2PC-5P-LCOD-M-STR
FE
41
23
Pin Function
1 +24V
2 Not assigned
3 GND
4 Not assigned
5 FE (functional earth)
Tab. 8.1: Pin assignment of the connection socket for the PRIMES power supply

BeamMonitor BM+
35,0(
6
20 Revision 02 EN - 02/2022
8.3 Ethernet
Data is transmitted between the BeamMonitor BM+ and PC via the Ethernet connection.
Connect the BeamMonitor BM+ to the PC via a crossover cable or to the network via a patch cable.
BeamMonitor BM+ 100S
Ethernet
LAN
or
Ethernet
PC
Crossover cable Patch cable
Fig. 8.4: Ethernet connection using the BM+ 100S as an example
8.4 PRIMES bus RS485
Another device, such as a PowerMonitor PM48/100, can be connected to the BeamMonitorBM+ via the
RS485 interface (PRIMES bus).
The signal from the PM48/100 is transmitted through the BM+ to the PC via the Ethernet interface. The ad-
ditional measuring device is powered by the power supply of the BM+.
Pin assignment D-sub socket, 9-pin (view of plug-in side)
1
5
69
Pin Function
1 GND
2 RS485 (+)
3 +24V
4 Not assigned
5 Not assigned
6 GND
7 RS485 (–)
8 +24V
9 Not assigned
Tab. 8.2: Pin assignment of the D-Sub socket, PRIMES bus
