Primus GLADIUS400T User manual

GLADIUS400T SETUP

Product layout
1. Braided cable
2. Gaming-grade rubberized scroll wheel
3. Omron micro switches
4. Side keys
5. DPI switch
6. Anti-slip grip sides
7. Logo and palm RGB backlight
8. High-precision optical sensor
9. Large glide metal feet and surface
Default button assignment
1. Left click
2. Right click
3. Wheel click
Scroll up
Scroll down
4. DPI cycle:
Parameter 1 = white
Parameter 2 = cyan
Parameter 3 = blue
Parameter 4 = green
Parameter 5 = purple
Parameter 6 = orange
5. Forward
6. Backward
11
132
4
2
4
5
7
3
68
9
5
6
Six strategically placed buttons

This gaming software allows you to configure the mouse through a single user-friendly application.
1. Button function settings:
8 commands with up to 50 selectable actions each
2. Polling rate settings
3. DPI parameters
4. Light effects
5. Gaming profiles: 5 different configurations are available
6. Color palette
7. Confirmation buttons
Configuration tool
A. Basic settings
1. Speed parameters for the mouse click, scroll and movement
2. Macro manager section
3. Gaming profiles
4. Confirmation buttons
B. Advanced settings
Initial setup
System requirements:
Windows XP / 7 / 8 / 8.1 / 10
1. Turn on your computer.
2. Go to www.primusgaming.com to
download the driver software.
3. Run the set up program and follow the
onscreen installation prompts.
4. The system will notify you when the
process has been completed and the
device is ready to be used.
5. Connect the mouse to the USB port.
6. If firmware updates are available, the
software will notify you. Follow the
onscreen prompts to execute the process.
7. Once the firmware is flashed successfully,
you will need to disconnect the mouse and
reconnect it again.
2

How to record a Macro
1. Click New and choose a name to identify
the new sequence.
2. Click Start record. You may choose the
loop times and also the delay in keystroke
sequence.
3. When done, click Stop record followed by
Apply.
4. Macros can be assigned to the 1-4 and 7-8
buttons of the mouse.
5. Once the macro is created, go to the
button functions settings. From the drop
down menu, choose Macro and then select
the macro profile you just recorded.
6. The following window will pop up. Choose
the macro from the list and also the action
that will bring the macro to an end. When
done click OK.
3
